Tripp Lite U442-DOCK5-GY User manual

1
Owner’s Manual
USB-C™Portable Docking
Station, Gray
Model: U442-DOCK5-GY
USB Type-C and USB-C are trademarks of USB Implementers Forum
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR surge protector in our monthly drawing!
www.tripplite.com/warranty
Español 12 • Français 22 • Русский 32

2
Product Features
• Supports DisplayPort Alternate Mode for
connecting an HDMI monitor via USB-C or
Thunderbolt™3 port
• Supports connection of DVI monitor via HDMI to
DVI adapter (see Optional Accessories for more
information)
• HDMI port supports 4096 x 2160 30 Hz 4:4:4
video resolutions
• Ethernet port supports true 10/100/1000 Mbps
network speeds
• USB-A and Type-C data ports support data transfer
rates up to 5 Gbps
• All USB-A 3.0 ports support data and charging
• Dedicated BC 1.2-compliant USB port provides up
to 1.5A of fast charging power to mobile devices
(when connected to power)
• USB-C device port supports data and Power
Delivery (PD) charging with power input up to
20V 5A (100W)
• 5V 2A (10W) of power dedicated to the USB-A
ports when connected to a PD 3.0-compliant
charger*
• Micro SD and SD/MMC Memory Card Slots allow
external memory access via USB-C or Thunderbolt
3 port

3
Product Features
System Requirements
• Supports PD 3.0 Fast Role Swap to maintain data
and power connection upon removal of charging
power
• Automatically resumes operation from hibernation
and suspend mode
• IEEE 802.3az (Energy Efficient Ethernet) compliant
• Supports full-duplex and half-duplex operations
• Supports Wake-On LAN
• Compact design fits easily into your laptop bag
• Plug-and-play—no software or drivers required
*When no power supply is connected, the output of the USB-A
ports are dependent on the connected source.
• Computer with USB-C or Thunderbolt 3 port that
supports DisplayPort Alternate Mode
• DVI** or HDMI monitor
• Ethernet Network with speeds up to
10/100/1000 Mbps
**Requires an adapter (see Optional Accessories for more
information)

4
Package Includes
Optional Accessories
• U442-DOCK5-GY
• Owner’s Manual
• N201-Series Cat6 Gigabit Snagless Patch Cables
• P566-Series HDMI to DVI Adapter Cables
• P568-Series High-Speed HDMI Cables
• U322-Series USB 3.0 A/B Device Cables
• U326-Series USB 3.0 Micro-B Device Cables
• U420-XXX-5A USB-C Cable

5
Product Overview
1USB-A 3.0 Ports (Female) – Connect up to
2 USB peripherals/devices for charging or data
transfer.
2Micro SD Memory Card Slot – Connects a Micro
SD Memory Card.
3SD/MMC Memory Card Slot – Connects an
SD/MMC Memory Card.
4HDMI Port (Female) – Connects an HDMI
monitor.
5USB-A 3.0 BC 1.2 Port (Female) – Provides up
to 1.5A of fast charging power to mobile devices.
6
1 2
7
3
5 4
Side 1
Side 2
Rear

6
Installation
Note:
• When the USB-C port is connected to a power source,
15W of power is dedicated to the docking station and other
devices. The remainder is used to charge the connected
device.
• See Optional Accessories section for suggested cables.
• When the unit is connected to the USB-C port on your
computer and to a network via Cat5e/6 cabling, a network
connection will be automatically established. If no connection
is made, you can manually establish one by going to your
computer’s network settings. For example, when using a
Mac, you would navigate to the “Network” icon found in
System Preferences; click the “Assist Me” button to access
the Network Setup Assistant, then follow the prompts to
establish a connection.
Product Overview
6USB-C Charging and Data Port (Female) –
Connects your device to a USB-C PD charger for
charging or data transfer.
7RJ45 Port (Female) – Connects to a
10/100/1000 Mbps network.

7
Installation
1. Connect the dock’s USB Type-C connector to the
USB-C or Thunderbolt 3 port on your laptop, tablet
or other device.
2. Using an HDMI cable (such as Tripp Lite P568-
Series High-Speed HDMI cables), connect the
dock’s HDMI port to the HDMI port on a monitor.
3. Connect up to three USB devices to the dock’s
USB-A hub ports for data or charging.
4. Connect a USB Type-C device to the dock’s Type-C
port for data or charging.
5. Using UTP cable, connect the adapter’s RJ45 port
to a network.
6. Insert a Micro SD and/or SD/MMC card into the
corresponding memory card slot to access external
memory.

8
Specifications
Connectors-Input
USB USB-C (Male)
Connectors-Output
USB-A (x3) USB 3.0 A (Female)
USB PD Charging and
Data
USB-C (Female)
10/100/1000 Ethernet RJ45 (Female)
HDMI HDMI (Female)
Memory Card Slots Micro SD and SD/MMC
Environmental
Operating Temperature 32°F to 113°F
(0°C to 45°C)
Operating Humidity 10% to 85% RH,
Non-Condensing
Storage Temperature 14°F to 158°F
(-10°C to 70°C)
Storage Humidity 5% to 90% RH,
Non-Condensing
Power Requirements
USB-C Charging Port Supports up to 20V 5A
(100W) Input

9
Warranty and
Product Registration
3-Year Limited Warranty
Tripp Lite warrants its products to be free from defects in
materials and workmanship for a period of three (3) years from
the date of initial purchase. Tripp Lite’s obligation under this
warranty is limited to repairing or replacing (at its sole option)
any such defective products. To obtain service under this
warranty, you must obtain a Returned Material Authorization
(RMA) number from Tripp Lite or an authorized Tripp Lite
service center. Products must be returned to Tripp Lite or an
authorized Tripp Lite service center with transportation charges
prepaid and must be accompanied by a brief description of the
problem encountered and proof of date and place of purchase.
This warranty does not apply to equipment, which has been
damaged by accident, negligence or misapplication or has
been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, Tripp Lite MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. Some states do not permit limitation or exclusion
of implied warranties; therefore, the aforesaid limitation(s) or
exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL Tripp Lite
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE. Specifically, Tripp Lite is not liable for any costs, such
as lost profits or revenue, loss of equipment, loss of use of
equipment, loss of software, loss of data, costs of substitutes,
claims by third parties, or otherwise.

10
Warranty and
Product Registration
Product Registration
Visit www.tripplite.com/warranty today to register your new
Tripp Lite product. You’ll be automatically entered into a
drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some
restrictions apply. See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.

11
Warranty and
Product Registration
• Consult the dealer or an experienced radio/TV technician for
help.
Any changes or modifications to this equipment not expressly
approved by Tripp Lite could void the user’s authority to operate
this equipment.
WEEE Compliance Information for Tripp Lite
Customers and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment
(WEEE) Directive and implementing regulations,
when customers buy new electrical and electronic
equipment from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one,
like-for-like basis (this varies depending on the
country)
• Send the new equipment back for recycling when
this ultimately becomes waste
Use of this equipment in life support applications where failure
of this equipment can reasonably be expected to cause the
failure of the life support equipment or to significantly affect its
safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice. Photos
and illustrations may differ slightly from actual products.
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
19-05-040 93-3958_RevA

12
Manual del Propietario
Estación de Conexión
Portátil USB C™, Gris
Modelo: U442-DOCK5-GY
USB Tipo C y USB C son marcas comerciales registradas del
USB Implementers Forum
1111 W. 35th Street, Chicago, IL 60609, EE. UU.
www.tripplite.com/support
Copyright © 2019 Tripp Lite. Todos los derechos reservados.
English 1 • Français 22 • Русский 32

13
Características del Producto
• Soporta DisplayPort de Modo Alterno para conectar
un monitor HDMI mediante un puerto USB C™o
Thunderbolt 3
• Soporta la conexión de un monitor DVI mediante
adaptador HDMI a DVI (Vea Accesories Opcionales
para información adicional)
• El puerto HDMI soporta resoluciones de video
4096 x 2160 30 Hz 4:4:4
• El puerto Ethernet soporta velocidades reales de
red de 10Mbos / 100Mbps / 1000Mbps
• Los puertos de datos USB-A y Type-C soportan
tasas de transferencia de datos hasta 5 Gbps
• Todos los puertos USB A 3.0 permiten carga y
transferencia de datos
• Un puerto USB dedicado compatible con BC 1.2
proporciona hasta 1.5A de alimentación de carga
rápida a los dispositivos conectados (cuando se
conecta a la energía)
• El puerto USB-C permite transferencia de datos
y carga Power Delivery (PD) con alimentación de
hasta 20V 5A (100W).
• 5V 2A (10W) de potencia están dedicados a los
puertos USB A cuando se conecta un cargador
compatible con PD 3.0*
• Las ranuras para tarjeta de memoria Micro SD y
SD / MMC permiten acceso a memoria externa a
través de un puerto USB C o Thunderbolt 3

14
Características del Producto
Requisitos del Sistema
• Permite Intercambio Rápido de Roles [FRS] PD 3.0
para mantener la conexión de datos y energía una
vez retirada la energía de carga
• Restablece automáticamente la operación desde
el modo de hibernación y suspensión
• Compatible con IEEE 802.3az (Ethernet Eficiente
con la Energía)
• Soporta operaciones Dúplex y Semi-dúplex
• Permite Wake-on LAN
• El diseño compacto cabe fácilmente en una bolsa
de su laptop
• Conectar y Usar—No requiere software ni
controladores
*Cuando no está conectado un suministro de energía, la salida
de los puertos USB A dependen de la fuente conectada.
• Computadora con puerto USB C o Thunderbolt 3
que soporte DisplayPort Modo Alterno
• Monitor DVI** o HDMI
• Red Ethernet con velocidades hasta
10Mbps / 100Mbps / 1000Mbps
**Requiere de un adaptador (Vea Accesorios Opcionales
para mayor información)

15
El Paquete Incluye
Accesorios Opcionales
• U442-DOCK5-GY
• Manual del Propietario
• Cables Patch Snagless Cat6 Gigabit Serie N201
• Cables Adaptadores de HDMI a DVI de la Serie
P566
• Cables HDMI de Alta Velocidad de la Serie P568
• Cables para Dispositivo USB 3.0 A/B de la Serie
U322
• Cables para Dispositivo USB 3.0 Micro-B de la
Serie U326
• U420-XXX-5A – Cable USB C

16
Vista General del Producto
1Puertos USB A 3.0 (Hembra) – Conecte
hasta 2 periféricos o dispositivos para carga o
transferencia de datos USB.
2Ranura para Tarjeta de Memoria Micro SD –
Conecta una Tarjeta de Memoria Micro SD.
3Ranura para Tarjeta de Memoria SD / MMC –
Conecta una Tarjeta de Memoria SD / MMC.
4Puerto HDMI (Hembra) – Conecta un monitor
HDMI
5. Puerto USB A 3.0 BC 1.2 (Hembra) –
Proporciona hasta 1.5A de alimentación para
carga rápida a los dispositivos conectados.
6
1 2
7
3
5 4
Lado 1
Lado 2
Atrás

17
Instalación
Nota:
• Cuando el puerto USB C se conecta a una fuente de
alimentación, 15W de potencia se dedican a la estación de
conexión y otros dispositivos. El resto se usa para cargar el
dispositivo conectado.
• Para ver los cables sugeridos, consulte la sección de
Accesorios Opcionales.
• Cuando la unidad esté conectada al puerto USB C en su
computadora y a una red mediante cableado Cat5e o Cat6,
se establecerá automáticamente una conexión de red. Si no
se realiza conexión, se puede establecer una manualmente
yendo a la configuración de red de su computadora. Por
ejemplo, al usar un Mac, desplácese hasta el icono de "Red"
en preferencias del sistema; haga clic en "Ayudarme" para
tener acceso al asistente de configuración de red, luego siga
las instrucciones para establecer una conexión.
Vista General del Producto
6Puerto USB C para Carga y Datos (Hembra) –
Conecta su dispositivo a un cargador USB C PD
para cargar o transferencia de datos.
7Puerto RJ45 (Hembra) - Se conecta a una red
10Mbps / 100Mbps /1000Mbps

18
Instalación
1. Conecte el conector USB Tipo C de la estación de
conexión al puerto USB C o Thunderbolt 3 en su
laptop, tableta u otro dispositivo.
2. Usando un cable HDMI (como los cables HDMI
de alta velocidad de la serie P568 de Tripp Lite),
conecte el puerto HDMI de la estación de conexión
al puerto HDMI en un monitor.
3. Conecte hasta tres dispositivos USB a los puertos
de hub USB-A de la estación de conexión para
transferencia de datos o carga.
4. Conecte un dispositivo USB Tipo C al puerto de
datos Tipo C de la estación de conexión para
transferencia de datos o carga.
5. Usando cable UTP, conecte el puerto RJ45 del
adaptador a una red.
6. Para acceder a la memoria externa, inserte
una tarjeta Micro SD o SD / MMC en la ranura
correspondiente para la tarjeta de memoria.

19
Especificaciones
Conectores-Entrada
USB USB C (Macho)
Conectores-Salida
USB A (x3) USB 3.0 A (Hembra)
Carga PD y Transferencia
de Datos USB
USB C (Hembra)
Ethernet 10Mbps /
100Mbps / 1000Mbps
RJ45 (Hembra)
HDMI HDMI (Hembra)
Ranuras para Tarjeta de
Memoria
Micro SD y SD / MMC
Ambiental
Temperatura de
Operación
0 °C a 45 °C
[32 °F a 113 °F]
Humedad de Operación De 10% a 85% de HR,
Sin Condensación
Temperatura de
Almacenamiento
-10 ºC a 70 ºC
[14 ºF a 158 ºF]
Humedad de
Almacenamiento
De 5% a 90% de HR,
sin condensación
Requerimientos de Energía
Puerto de Carga USB C Soporta Entrada de Hasta
20V 5A (100W)

20
Garantía Limitada de 3 años.
Tripp Lite garantiza durante un período de tres (3) años
a partir de la fecha de compra inicial que este producto
no tiene defectos de materiales ni de mano de obra. La
obligación de Tripp Lite bajo esta garantía está limitada a la
reparación o reemplazo (A su entera discreción) de cualquier
producto defectuoso. Para obtener servicio bajo esta garantía,
debe obtener un número de Autorización de Devolución de
Mercancía [RMA] de Tripp Lite o de un centro de servicio
autorizado de Tripp Lite. Los productos deben ser regresados a
Tripp Lite o a un centro de servicio autorizado de Tripp Lite con
los cargos de transporte prepagados y deben acompañarse
con una breve descripción del problema y un comprobante
de la fecha y el lugar de compra. Esta garantía no se aplica a
equipos que hayan sido dañados por accidente, negligencia
o mal uso, o hayan sido alterados o modificados de alguna
manera.
EXCEPTO COMO SE INDICA EN EL PRESENTE, TRIPP LITE NO
OTORGA GARANTÍAS EXPRESAS O IMPLÍCITAS, INCLUIDAS
LAS GARANTÍAS DE COMERCIABILIDAD Y ADECUACIÓN PARA
UN PROPÓSITO PARTICULAR. Algunos estados no permiten
la limitación o exclusión de garantías implícitas; por lo tanto,
las limitaciones o exclusiones antes mencionadas pueden no
aplicarse al comprador.
EXCEPTO COMO SE INDICA ANTERIORMENTE, EN NINGÚN
CASO TRIPP LITE SERÁ RESPONSABLE POR DAÑOS DIRECTOS,
INDIRECTOS, ESPECIALES, INCIDENTALES O CONSECUENTES
QUE SURJAN DEL USO DE ESTE PRODUCTO, INCLUSO
SI SE ADVIERTE SOBRE LA POSIBILIDAD DE TAL DAÑO.
Específicamente, Tripp Lite no es responsable por ningún
costo, como pérdida de ganancias o ingresos, pérdida de
equipos, pérdida del uso de equipos, pérdida de software,
pérdida de datos, costos de sustituciones, reclamaciones de
terceros o de cualquier otra forma.
Garantía
