iPort IW-1 Instruction Manual

Video
Wallplate
Male-to-Male RCA Cable
(not included, up to 25 feet)
RJ-45-to-Female
RCA Cable
(included) TV or Video Monitor
Male-to-Male
RCA Cable
(not included)
To Wallplate
Rear RCA
Connector
Local Zone Amplifier
From
Speaker
Outputs
To
Line
Inputs
Stereo
RCA
Cable
To
Wallplate
RJ-45
Connector
Cat5 Cable / RJ-45 Connectors
(front view)
(side view)
iPort
Unbalanced
Audio
Wallplate
+15V DC
Power Supply
iPort
Balanced Audio
Wallplate
(side view)
16/2 Speaker Wire
iPort 4 Pin
Connector Block
4 Pin
Screw
Connector
Wallplate
Aux Power
Connector
Block
Volume Contol
Wiring
Pin 1: R ch from VCLL to iPort
Pin 2: L ch from VCLL to iPort
Pin 3: Ground
Pin 4: R ch from iPort to VCLL
Pin 5: L ch from iPort to VCLL
To
iPort
From
iPort
VCLL 5 Pin
Connector Block
Line Level
Volume Control
(optional)
Twin Shielded
5 Conductor
Cable
Volume
Control
ON/OFF
Switch
iPort 5 Pin
Connector Block
To
iPort
From
iPort
iPort
Balanced Video
Wallplate
(front view)(side view)
S-Video
Cable
Composite
Video Cable
To
Video
Monitor
To
Video
Monitor
To
Wallplate
RJ-45
Connector
Cat5 Cable / RJ-45 Connectors
RJ-45
Video
Connection
Cat5 Cable / RJ-45 Connectors
To
Wallplate
RJ-45
Connector
RJ-45
Video
Connection
(front view) (side view)
iPort
Balanced Audio
Wallplate
6 Pin RJ-11
Connector
RS-232
Cable
Stereo
RCA Cable
BD-9
Connector
To
RS-232
Controller
To
Audio
System
Mono
Mini Plug
From IR
Controller
To
Wall
Outlet
+15V DC
Power Supply
Simple to Sophisticated
IW
© 2006 iPort, all rights reserved. www.iportmusic.com
IW Unbalanced Audio and Video Connections
IW Balanced Audio and Video Connections,
with optional Supplemental Power and Line Level Volume Control Connections
