Tripp Lite U357-1M2-NVMEG2 User manual

1
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
Owner’s Manual
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR®surge protector in our monthly drawing!
tripplite.com/warranty
USB 3.2 Gen 2 M.2 SSD
Enclosure (PCle and NVMe)
with USB Hub for PlayStation 5
Model: U357-1M2-NVMEG2
Español 15 • Français 29
Русский 43 • Deutsch 57
21-10-337 9340FC.indb 121-10-337 9340FC.indb 1 12/3/2021 1:23:24 PM12/3/2021 1:23:24 PM

2
Product Features
Package Contents
System Requirements
• USB-A ports support USB 3.2 Gen 2 data transfer
speeds up to 10 Gbps
• LEDs indicate power is on and read/write is
occurring
• Aluminum case maintains fast heat dissipation,
which allows for stable, smooth file transfers
• Hot-swappable enclosure supports multi-size M.2
SSD specifications (42 mm, 60 mm, 80 mm),
PCle and NVMe protocol, SSD TRIM and UASP
acceleration, and M.2 M-Key and B&M-Key socket
• Plug-and-play operation with no software required
for easy, immediate installation
• U357-1M2-NVMEG2 M.2 SSD Enclosure
• USB-A Cable (M/F)
• Aluminum Sheet
• (2x) Silicone Sheets
• Owner’s Manual
• Playstation®
• Windows®8, 10 or 11
21-10-337 9340FC.indb 221-10-337 9340FC.indb 2 12/3/2021 1:23:24 PM12/3/2021 1:23:24 PM

3
Optional Accessories
Installation
• U324-Series USB 3.2 Extension Cables
Notice:
• This product uses the M-Key interface, which
belongs to the NVMe protocol channel. When
installing the M.2 SSD for this product, please
check the hard disk interface and protocol channel.
• Although the USB end of the product supports
hot-swapping when installing the M.2 SSD, it
must be done when the power is off.
• When disassembling and installing the hard disk
box, take care to prevent any accessories from
becoming lost.
1. Hold the product as shown below, and slide the
upper cover to the left to remove it.
21-10-337 9340FC.indb 321-10-337 9340FC.indb 3 12/3/2021 1:23:25 PM12/3/2021 1:23:25 PM

4
Installation
2. Slide the M.2 card into the enclosure at an angle.
3. Gently press down on the M.2 SSD, and snap it
into the standard rubber cartridge.
21-10-337 9340FC.indb 421-10-337 9340FC.indb 4 12/3/2021 1:23:28 PM12/3/2021 1:23:28 PM

5
Installation
4. Place a silicone sheet and then the aluminum
sheet over the M.2 SSD card.
5. Attach the upper cover to the enclosure by pressing
it and sliding it to the right.
21-10-337 9340FC.indb 521-10-337 9340FC.indb 5 12/3/2021 1:23:29 PM12/3/2021 1:23:29 PM

6
Installation
Note: For use with a PlayStation 4 game console or
computer, the U357-1M2-NVMEG2 must be
used with the included USB cable (M/F).
21-10-337 9340FC.indb 621-10-337 9340FC.indb 6 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM

7
Operation
21-10-337 9340FC.indb 721-10-337 9340FC.indb 7 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM

8
Operation
When you install a new disk in the enclosure and
connect it to your PS5 console, you must format the
disk in the Storage settings. Note: Disk formatting will
erase all previous data on the disk, so proceed with
caution.
21-10-337 9340FC.indb 821-10-337 9340FC.indb 8 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM

9
Operation
PS5 consoles only support games with PS4 attributes
to run on external disks. If you want to run games
with PS5 attributes, you must copy them to the PS5’s
built-in storage device.
21-10-337 9340FC.indb 921-10-337 9340FC.indb 9 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM

10
Specifications
Input Connection 2x USB-A (Male)
Output Connection 1x USB-A (Female)
Data Transfer Rates 10 Gbps (USB 3.2 Gen 2)
LED Solid White – Power On
Flashing White – Read and Write
Material Aluminum
Maximum Drive
Capacity
No capacity limit,
but PS5 requires
external devices to
be 250 Gb to 8 Tb
Operating
Temperature Range
32° to 131°F
(0° to 55°C)
Storage
Temperature Range
14° to 158°F
(-10° to 70°C)
Relative Humidity 10 to 85% RH,
Non-Condensing
Dimensions
(H x W x D)
4.7 x 1.8 x 0.6 in. /
120 x 45 x 16 mm
21-10-337 9340FC.indb 1021-10-337 9340FC.indb 10 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM

11
Frequently Asked Questions
Q: Can the U357-1M2-NVMEG2 be used on PS4
game consoles or computers?
A: Yes. But it must be used with the included USB-A
cable (M/F), and the corresponding file system
format must be changed.
Q: Why are the read/write speeds slow in actual use
and unable to reach USB 3.2 Gen 2 speeds?
A: The U357-1M2-NVMEG2 has undergone rigorous
testing, and the read/write speed can reach USB
3.2 Gen 2 speeds under normal conditions. If
the speed is slow, confirm that the USB host port
to which the U357-1M2-NVM is connected is
compatible with USB 3.2 Gen 2.
Q: On a Windows computer, after installing the new
hard disk, why can’t I find the portable hard disk or
the corresponding drive letter in My Computer?
A: When using a new hard disk for the first time,
you must initialize, format and partition the disk
in Computer Management > Disk Management
before it can be used normally.
21-10-337 9340FC.indb 1121-10-337 9340FC.indb 11 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM

12
Q: Why can’t Windows XP recognize the hard disk with
a capacity of more than 2 Tb?
A: Due to Windows XP system limitations, the hard
disk capacity that can be recognized on this system
cannot exceed 2 Tb. It can be supported only by
computers upgraded to Windows Vista (64 bits) or
higher. It is recommended to convert the disk to a
GPT disk partition.
Q: How can I protect the hard disk and data and have
a safe exit?
A: To remove the mobile hard drive without shutting
down the operating system, it is recommended
that you safely remove the USB peripheral icon
through the lower right corner of the system to
safely pop the USB device, and then turn off the
power to remove the device.
Q: Can NVMe protocol SSDs be used in Windows
versions prior to 8.1?
A: If Windows 7 or 8 needs to install an NVMe
support match, Windows 8.1 and later versions
have an integrated NVMe driver.
Frequently Asked Questions
21-10-337 9340FC.indb 1221-10-337 9340FC.indb 12 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM

13
Warranty and Product Registration
1-Year Limited Warranty
Seller warrants this product, if used in accordance with all applicable instructions, to
be free from original defects in material and workmanship for a period of one (1) year
from the date of initial purchase. If the product should prove defective in material or
workmanship within that period, Seller will repair or replace the product, at its sole
discretion.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING
FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS
WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT
TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES,
INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN
DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY
EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some
states do not allow limitations on how long an implied warranty lasts, and some states
do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitations or exclusions may not apply to you. This warranty gives you specific
legal rights, and you may have other rights which vary from jurisdiction to jurisdiction.)
WARNING: The individual user should take care to determine prior to use whether this
device is suitable, adequate or safe for the use intended. Since individual applications
are subject to great variation, the manufacturer makes no representation or warranty
as to the suitability or fitness of these devices for any specific application.
PRODUCT REGISTRATION
Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be
automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
*No purchase necessary. Void where prohibited. Some restrictions apply. See website
for details.
WEEE Compliance Information for Tripp Lite Customers and Recyclers
(European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive
and implementing regulations, when customers buy new electrical and
electronic equipment from Tripp Lite, they are entitled to:
• Send old equipment for recycling on a one-for-one, like-for-like basis
(this varies depending on the country)
• Send the new equipment back for recycling when this ultimately
becomes waste
Use of this equipment in life support applications where failure of this equipment
can reasonably be expected to cause the failure of the life support equipment or to
significantly affect its safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement. Specifications are subject to
change without notice. Photos and illustrations may differ slightly from actual products.
21-10-337 9340FC.indb 1321-10-337 9340FC.indb 13 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM

14
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
21-10-337 • 9340FC_RevA
21-10-337 9340FC.indb 1421-10-337 9340FC.indb 14 12/3/2021 1:23:31 PM12/3/2021 1:23:31 PM

15
1111 W. 35th Street, Chicago, IL 60609, EE. UU.
tripplite.com/support
Copyright © 2021 Tripp Lite. Todos los derechos reservados.
Manual del Propietario
Gabinete SSD M.2 USB 3.2 Gen 2
(PCle y NVMe) con Hub USB para
PlayStation 5
Modelo: U357-1M2-NVMEG2
English 1 • Français 29
Русский 43 • Deutsch 57
21-10-337 9340FC.indb 1521-10-337 9340FC.indb 15 12/3/2021 1:23:31 PM12/3/2021 1:23:31 PM

16
Características del Producto
Contenido del empaque
Requisitos del sistema
• Los puertos USB A soportan velocidades de
transferencia de datos de USB 3.2 Gen 2 de hasta
10 Gbps
• Los LEDs indican que la energía está encendida y
que se está ejecutando la lectura y escritura
• La caja de aluminio disipa rápidamente el calor, lo que
permite transferencias estables y suaves de archivos
• El gabinete Hot-Swap soporta especificaciones M.2
SSD de múltiples tamaños (42 mm, 60 mm, 80
mm), protocolo PCle y NVMe, aceleración de SSD
TRIM y UASP y enchufe M.2 M-Key y B&M-Key
• Operación "conectar y usar" sin necesidad de
software para una instalación fácil e inmediata
• U357-1M2-NVMEG2 – Gabinete SSD M.2
• Cable USB-A (M/H)
• Lámina de Aluminio
• (2x) Láminas de Silicón
• Manual del Propietario
• PlayStation®
• Windows®8, 10 u 11
21-10-337 9340FC.indb 1621-10-337 9340FC.indb 16 12/3/2021 1:23:31 PM12/3/2021 1:23:31 PM

17
Accesorios Opcionales
Instalación
• Cables de Extensión USB 3.2 de la Serie U324
Aviso:
• Este producto utiliza la interfaz M-Key, que
pertenece al canal de protocolo NVMe. Al instalar
el SSD M.2 para este producto, compruebe la
interfaz de disco duro y canal de protocolo.
• Aunque la terminal USB del producto soporta
hot-Swap al instalar el SSD M.2,
debe hacerse cuando la energía esté apagada.
• Al desarmar e instalar la caja de disco duro, tome
precauciones para evitar que se pierdan accesorios.
1. Sostenga el producto como se muestra a
continuación y deslice la cubierta superior a la
izquierda para retirarlo.
21-10-337 9340FC.indb 1721-10-337 9340FC.indb 17 12/3/2021 1:23:31 PM12/3/2021 1:23:31 PM

18
Instalación
2. Deslice la tarjeta M.2 en el gabinete en un ángulo.
3. Presione suavemente hacia abajo en el SSD M.2 e
insértelo en el cartucho de caucho estándar.
21-10-337 9340FC.indb 1821-10-337 9340FC.indb 18 12/3/2021 1:23:33 PM12/3/2021 1:23:33 PM

19
Instalación
4. Coloque una lámina de silicón y luego la lámina de
aluminio sobre la Tarjeta SSD M.2.
5. Fije la cubierta superior al gabinete oprimiéndola y
deslizándola a la derecha.
21-10-337 9340FC.indb 1921-10-337 9340FC.indb 19 12/3/2021 1:23:34 PM12/3/2021 1:23:34 PM

20
Instalación
Nota: Para uso con una consola de juegos
PlayStation 4 o computadora, el
U357-1M2-NVMEG2 debe usarse con el
cable USB incluido (M/H).
21-10-337 9340FC.indb 2021-10-337 9340FC.indb 20 12/3/2021 1:23:34 PM12/3/2021 1:23:34 PM
