Owner’s Manual
HDMI + Power over Cat5
Active Extender Kit
Model: B126-1A1-POC
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2016 Tripp Lite. All rights reserved.
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
15-12-242-933539-EN.indd 1 1/8/2016 1:51:32 PM

2
Product Features
Package Includes
Optional Accessories
• Extends a 1080p (@ 60 Hz) signal up to 125 ft. from source
• Built-in Power over Cable (POC) technology powers receiver over
Cat5e/6/6a cable
• Additional HDMI port on transmitter for connecting local display
• Built-in equalization control on receiver for adjusting video image
• Includes hardware for mounting both units on wall, rack or pole
• Supports up to 7.1-channel surround sound audio
• HDCP and 3D compatible
• Plug and play—no software or drivers necessary
• B126-1A1-POC Transmitter Unit
• B126-1A1-POC Receiver Unit
• External Power Supply with NEMA 1-15P Plug
(Input: 100–240V, 50/60 Hz, 0.5A; Output: 5V, 2A)
• Screwdriver for Equalization Adjustment
• Mounting Hardware
• Owner’s Manual
• N202-Series Cat6 24 AWG Solid-Wire Patch Cables
• P568-Series High-Speed HDMI Cables
• P569-XXX-LOCK* High-Speed HDMI Cables with Ethernet and Locking
Connectors
* Available in lengths up to 15 ft. XXX refers to length
(e.g. 006 = 6 ft., 015 = 15 ft., etc.)
15-12-242-933539-EN.indd 2 1/8/2016 1:51:32 PM

3
Mounting Instructions
The B126-1A1-POC comes with mounting hardware that allows it to be
mounted in a variety of ways. The following images show the different ways
the included mounting brackets can be attached for different mounting
methods.
Wall-Mount
19-Inch Rack-Mount Pole-Mount
15-12-242-933539-EN.indd 3 1/8/2016 1:51:34 PM

4
Extender Kit Installation
Notes:
1. Test to make sure the entire installation works properly before pulling cables
through ceilings or walls.
2. To achieve maximum distance and performance, use 24 AWG solid-wire Cat5e/6
cable. Using stranded-wire Cat5e/6 cable or cable with a gauge (AWG) size higher
than 24 AWG will result in shorter extension distance. Higher gauge cabling, such
as 26 AWG, has a more limited transmission capability than lower gauge cabling.
All Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid-wire cabling.
3. Press the Audio button on the transmitter to switch between stereo and
7.1-channel surround sound audio. The unit is set to transmit stereo by default.
OPTIONAL
LOCAL MONITOR
LOCAL TRANSMITTER
Up to 125 ft. at 1080p (60Hz)
REMOTE RECEIVER
Blu-ray™ PLAYER
LOCALAUDIO INPUT OUTPUT
OUTPUT
1. Make sure the HDMI source is turned OFF.
2. Connect the HDMI source to the INPUT port on the transmitter.
3. Optional: Connect a local monitor to the LOCAL port on the transmitter.
4. Connect the external power supply to the transmitter, and plug it into a
Tripp Lite surge protector, power distribution unit (PDU) or
uninterruptible power supply (UPS). The green RJ45 LED lights to
indicate the unit is receiving power.
15-12-242-933539-EN.indd 4 1/8/2016 1:51:35 PM

5
Extender Kit Installation
5. Using a Cat5e/6 cable, connect the RJ45 port on the transmitter to the
RJ45 port on the receiver. The green RJ45 LED on the receiver lights to
indicate the unit is receiving power. The orange RJ45 LED lights to
indicate the unit is connected to a transmitter that is powered on.
6. Connect the receiver’s HDMI port to a monitor.
7. Turn on the power to the HDMI source. The orange RJ45 LED on the
transmitter lights to indicate a signal is being received from the source.
8. If necessary, adjust the video image using the included screwdriver and
the equalization control on the receiver.
Note: An improper equalization setting can cause the monitor not to display an
image at all. Try each equalization setting until an acceptable image is displayed.
Troubleshooting
If you are unable to get an acceptable image after following the installation
instructions, try the troubleshooting tips below.
1. Is the external power supply that came with the product
connected and plugged into a working power source? For the
product to function properly, it must be connected to and receiving
power from the external power supply.
2. Was the power to the HDMI source turned off prior to
installation? If not, restart it.
3. What resolution are you trying to reach? See the Product Features
and Installation sections in this manual for details on maximum
distance and resolution. The shorter the extension distance, the higher
the resolution you will be able to obtain. If you are not able to receive
an acceptable image, try lowering your computer’s video resolution or
adjusting the refresh rate.
4. What type of cabling are you using? Inferior cabling can result in
poor performance, so it is important you use cables that can support
the video resolution you are trying to obtain. To achieve maximum
distance and resolution, 24 AWG solid-wire UTP cable (such as
Tripp Lite’s N202-Series cables) must be used.
15-12-242-933539-EN.indd 5 1/8/2016 1:51:35 PM

6
Troubleshooting
5. Test your cables to ensure they are working properly. For example,
connect your Cat5e/6 cable between a computer and a network to
verify it establishes a network connection.
6. Do you have any patch panels or other devices between the
transmitter and receiver units? Tripp Lite’s HDMI + Power over Cat5
Active Extender Kit is designed to connect directly from the transmitter
to the receiver via UTP cable. The more connection points that are
between the source and the remote monitor, the more likely that signal
degradation will occur, causing poor performance. If you have a patch
panel or other device between, it should be removed from the
installation.
7. Do you have a splitter, switch or other device between the
computer and transmitter or between the receiver and display?
Tripp Lite’s HDMI + Power over Cat5 Active Extender Kit is designed for
the transmitter to connect directly with the source computer and for the
receiver to connect directly to the display. If you have a splitter, switch
or other device between, it should be removed from the installation.
8. Check your cabling for any damages that may have occurred
during installation. If a cable connector is loosened from being pulled
through ceilings/walls or the cable jacket is damaged, causing the
wiring to be exposed, you will not be able to achieve maximum
performance.
9. Are the transmitter and/or receiver units located in an area that
exposes them to elevated temperatures? If the product is
overheating, it will not function properly.
15-12-242-933539-EN.indd 6 1/8/2016 1:51:35 PM

7
Warranty and Product Registration
1-YEAR LIMITED WARRANTY
TRIPP LITE warrants its products to be free from defects in materials and workmanship for
a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this
warranty is limited to repairing or replacing (at its sole option) any such defective products. To
obtain service under this warranty, you must obtain a Returned Material Authorization (RMA)
number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be
returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges
prepaid and must be accompanied by a brief description of the problem encountered and proof
of date and place of purchase. This warranty does not apply to equipment, which has been
damaged by accident, negligence or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid
limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT,
INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE
USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of
equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by
third parties, or otherwise.
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You'll be
automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
15-12-242-933539-EN.indd 7 1/8/2016 1:51:35 PM

8
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
15-12-242 • 93-3539_RevA
Warranty and Product Registration
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly approved by Tripp Lite could void
the user’s authority to operate this equipment.
WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive and
implementing regulations, when customers buy new electrical and electronic equipment
from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies
depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste
Use of this equipment in life support applications where failure of this equipment can reasonably
be expected to cause the failure of the life support equipment or to significantly affect its safety
or effectiveness is not recommended. Do not use this equipment in the presence of a flammable
anesthetic mixture with air, oxygen or nitrous oxide.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without
notice.
