Owner’s Manual
4K/60 DisplayPort over Cat6
Extenders and Splitters
Extender Kits Model: B127-1A1-DH
Splitters kit Models: B127-002-D2H, B127-004-D4H
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
www.tripplite.com/warranty
Español 13 • Français 25 • Русский 37
19-01-458-93393A.indb 1 3/8/2019 2:42:22 PM

2
Package Contents
Product Features
B127-1A1-DH B127-002-D2H B127-004-D4H
Local Unit (L), Remote Unit (R) or Both (B) B B B
External Power Supplies 1 1 1
Mounting Hardware Y Y Y
All
• Support 4K video resolution (3840 x 2160 @ 60 Hz) and 4:4:4
chroma subsampling
• Support up to 7.1-channel surround sound audio
• DisplayPort 1.2a compatible
• Supports up to 8-channel LPCM, AC-3, DTS digital audio
• Plug and play—no software or drivers required
B127-1A1-DH
• DisplayPort over Cat6 Power-over-Cable (PoC) Extender Kit
• Extends a 4K (3840 x 2160 @ 60 Hz) signal up to 125 ft. (38 m)
from the source
• Additional HDMI port on the local transmitter unit allows connection of
a local monitor
19-01-458-93393A.indb 2 3/8/2019 2:42:22 PM

3
Product Features
• Remote receiver unit features built-in equalization (EQ) control and
auto EDID image adjustment
• Includes mounting hardware that allows both the local transmitter and
remote receiver units to be wall-mounted, rack-mounted or pole-
mounted
B127-002-D2H
• DisplayPort over Cat6 Power Over Cable (PoC) 2 Port Splitter/Extender
Kit
• Extends a 4K (3840 x 2160 @ 60 Hz) signal up to 125 ft. (38 m)
from the source
• Remote HDMI receiver units feature built-in equalization (EQ) control
and auto EDID image adjustment
• Kit includes a 2-Port Splitter Extender and two Remote Receivers
• Includes mounting hardware that allows unit to be wall-mounted, rack-
mounted or pole-mounted
B127-004-D4H
• DisplayPort over Cat6 Power-over-Cable (PoC) 4 Port Splitter/Extender
Kit
• Extends a 4K (3840 x 2160 @ 60 Hz) signal up to 125 ft. (38 m)
from the source
• Remote HDMI receiver units feature built-in equalization (EQ) control
and auto EDID image adjustment
• Kit includes a 4-Port Splitter Extender and four Remote Receivers
• Includes mounting hardware that allows unit to be wall-mounted, rack-
mounted or pole-mounted
• Additional HDMI port on the local transmitter unit allows connection of
a local monitor
19-01-458-93393A.indb 3 3/8/2019 2:42:22 PM

4
Product Features
Disclaimer
Optional Accessories:
• N202-Series Cat6 24 AWG Solid-Wire Patch Cables
• P569-XXX-CERT or P568-XXX-2A Series High-Speed HDMI 2.0 Cables
• P580-XXX DisplayPort Cables
Before installation, please check the following settings of your source(s)
and TV/monitor(s):
1. Set monitor to display at 60 Hz. Double check factory settings, as
default can be set to a lower frequency (Hz).
2. Ensure your monitor’s input setting is set to HDMI 2.0. Some displays
may have a default setting of HDMI 1.4
3. Verify your monitor has the HDR feature enabled. Some displays may
have this feature disabled as a default setting.
4. Check if the Ultra HD (UHD) Deep Color setting is enabled on your TV/
monitor. Confirm with your TV/monitor manufacturer which HDMI ports
support UHD Deep Color.
Note: If wishing to connect a local monitor to your installation, depending on
your TV/monitor make/model, the UHD Deep Color setting may need to be
disabled on your local TV/monitor to achieve 4K 60 Hz resolution.
19-01-458-93393A.indb 4 3/8/2019 2:42:22 PM

5
Mounting Instructions (select models)
The B127-1A1-DH, B127-002-D2H and B127-004-D4H include
mounting hardware, allowing for a variety of mounting methods. The
following images illustrate how the included mounting brackets can be
attached for different installations.
Note: The model shown in the below images is for illustrative purposes only. Your
product may vary by model number, size or port orientation. The mounting options
for all over IP units are the same.
Wall-mount
19” Rack-mount Pole-mount
19-01-458-93393A.indb 5 3/8/2019 2:42:22 PM

6
Standard Extender Kit Installation
Notes:
• Test to ensure the entire installation works properly before pulling cables through
ceilings/walls.
• To achieve maximum distance and performance, use 24 AWG solid-wire Cat6
cable. Using stranded-wire Cat6 cable, or cable with a gauge (AWG) size higher
than 24 AWG. will result in shorter extension distance. Higher gauge cabling,
such as 26 AWG, has a more limited transmission capability than lower gauge
cabling. All Tripp Lite N202-Series Cat6 cables use 24 AWG solid-wire cabling.
• The installation diagram shows a B127-1A1-DH unit.
• External power is not required for the remote receiver due to Power-over-Cable
(PoC) technology incorporated in the transmitter unit.
B127-1A1-DH
Extender Kit
MONITOR PC
LOCAL
TRANSMITTER
REMOTE
RECEIVER
Up to 125 ft. (38 m) at 4K/60 Hz
Up to 125 ft. (38 m) Cat6 cable at 4K/60 Hz
Up to 15 ft. (4.5 m) HDMI 2.0 cable at 4K/60 Hz
Up to 15 ft. (4.5 m) DisplayPort cable at 4K/60 Hz
1
2
3
19-01-458-93393A.indb 6 3/8/2019 2:42:22 PM

7
Standard Extender Kit Installation
1. Make sure all equipment in the installation—such as TVs, Blu-ray
players and the transmitter—is powered OFF.
2. Using DisplayPort cables (such as Tripp Lite P580-XXX Series),
connect the DisplayPort source to the INPUT port on the
B127-1A1-DH local transmitter unit.
3. Optional for B127-1A1-DH: Using an HDMI 2.0 cable (such as
Tripp Lite P569-XXX-CERT or P568-XXX-2A Series cable), connect
a local monitor to the LOCAL port on the B127-1A1-DH local
transmitter unit.
4. Using Cat6 cable, connect the RJ45 port on the local transmitter unit
to the RJ45 port on the remote receiver unit.
5. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT or
P568-XXX-2A Series cable), connect the remote receiver unit’s HDMI
port to a monitor.
6. Power on all connected displays. The LOCAL (orange) LED will
illuminate to indicate the local port is connected to a display.
7. Connect the external power supply to the local transmitter unit and plug
it into an available wall outlet or (optional) a Tripp Lite Surge Protector,
Power Distribution Unit (PDU) or Uninterruptible Power Supply (UPS).
The POWER (green) LED will illuminate to indicate the unit is receiving
power from the external power supply. The POWER (green) LED on the
remote receiver unit will illuminate to indicate the unit is receiving power
from the local transmitter unit by way of PoC technology.
8. Turn on the power to the DisplayPort source. The OUTPUT (orange)
LED on the local transmitter unit will illuminate to indicate a signal is
received from the source.
9. The RJ45 (orange) LED will illuminate on both local transmitter and
remote receiver units to indicate a signal is being received from
source to display. The screen should now display on the connected
monitor.
19-01-458-93393A.indb 7 3/8/2019 2:42:22 PM

8
Standard Extender Installation
Notes:
• Test to ensure the entire installation works properly before pulling cables through
ceilings/walls.
• To achieve maximum distance and performance, use 24 AWG solid-wire Cat6
cable. Using stranded-wire Cat6 cable, or cable with a gauge (AWG) size higher
than 24 AWG. will result in shorter extension distance. Higher gauge cabling,
such as 26 AWG, has a more limited transmission capability than lower gauge
cabling. All Tripp Lite N202-Series Cat6 cables use 24 AWG solid-wire cabling.
• The installation diagram shows the B127-004-D4H local transmitter unit. The
B127-002-D2H installation is the same, except there are only two remote ports
and no local monitor port.
• External power is not required for the B127-100-H or B127-100-H-SR.
B127-004-D4H
extender kit
OPTIONAL
LOCAL MONITOR
PC
B127-004-D4H
B127-100-H
B127-100-H-SR
B127-100-H
B127-100-H-SR
Up to 125 ft. (38 m) Cat6 cable at 4K/60 Hz
Up to 50 ft. (15 m) Cat6 cable at 4K/60 Hz
Up to 15 ft. (4.5 m) HDMI 2.0 cable at 4K/60 Hz
Up to 15 ft. (4.5 m) DisplayPort cable at 4K/60 Hz
2
1
3
4
19-01-458-93393A.indb 8 3/8/2019 2:42:22 PM

9
Standard Extender Installation
1. Make sure all equipment in the installation—such as TVs, Blu-ray
players and the transmitter—is powered OFF.
2. Using DisplayPort cables (such as Tripp Lite P580-XXX Series),
connect the DisplayPort source to the INPUT port on the
B127-002-D2H or B127-004-D4H local transmitter unit.
3. Optional for B127-004-D4H: Using an HDMI 2.0 cable (such as
Tripp Lite P569-XXX-CERT or P568-XXX-2A Series cable), connect
a local monitor to the LOCAL port on the B127-004-D4H local
transmitter unit.
4. Using Cat6 cable, connect the RJ45 output port on the local
transmitter unit to the RJ45 port on the B127-100-H remote receiver
unit.
5. Repeat step 4 for each additional remote receiver unit being
connected.
6. Using an HDMI 2.0 cable (such as Tripp Lite P569-XXX-CERT or
P568-XXX-2A Series cable), connect the B127-100-H’s HDMI port to
a monitor.
7. Repeat Step 6 for each additional remote B127-100-H receiver unit
in the installation.
8. Power on all connected displays. The LOCAL (orange) LED will
illuminate to indicate the local port is connected to a display.
9. Connect the external power supply to the B127-002-D2H or
B127-004-D4H local transmitter unit and plug it into an available
wall outlet or (optional) a Tripp Lite Surge Protector, Power Distribution
Unit (PDU) or Uninterruptible Power Supply (UPS). The POWER
(green) LED will illuminate to indicate the unit is receiving power from
the external power supply. On the B127-100-H, the POWER (green)
LED on the remote receiver unit will illuminate to indicate the unit is
receiving power from the extender/splitter.
19-01-458-93393A.indb 9 3/8/2019 2:42:22 PM

10
10. Turn on the power to the DisplayPort source. The (orange) LEDs on
the B127-002-D2H and B127-004-D4H will illuminate to indicate a
signal is received from the source. Additionally, the OUTPUT (orange)
LED will illuminate for each port signal connection.
11. The RJ45 (orange) LEDs on the B127-100-H will illuminate to
indicate a signal is being received from the extender/splitter. The
screen should now display on the connected monitor.
Standard Extender Installation
