Tripp Lite B126-1A1-WHD4HH User manual

1
Mini Wireless HDMI
Extender Kit, 50 ft. (15 m)
Model: B126-1A1-WHD4HH
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
Owner's Manual
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty
Este manual esta disponible en español en la página
de Tripp Lite: tripplite.com
Ce manuel est disponible en français sur le site Web
de Tripp Lite : tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der
Tripp Lite-Website verfügbar: www.tripplite.com
Русскоязычная версия настоящего руководства представлена на
веб-сайте компании Tripp Lite по адресу: tripplite.com
20-09-243-933C8B-EN.indd 120-09-243-933C8B-EN.indd 1 9/29/2020 9:10:45 AM9/29/2020 9:10:45 AM

2
• HDMI Mini Transmitter
• HDMI Mini Receiver
• (2) USB Micro-B to USB-A M/M Cables
• (2) HDMI M/F Cables
• (2) Right-Angle HDMI M/F Adapters
• Owner’s Manual
• Extends an HDMI audio/video signal wirelessly up to 50 ft.
(15 m) from the source
• All-in-one wireless solution—no cabling infrastructure required
• Transmits high-definition video and stereo audio
• Protects your transmissions with AES 128 encryption
• HDMI 1.3 and HDCP 1.2 compatible
• Supports 24-bit Deep Color (8 bits per channel)
• Supports 300 MHz/3.4 Gbps per channel bandwidth
(10.2 Gbps total)
• Plug-and-play—no software or external power required
• HDMI source device, such as a Blu-ray™ player or a laptop
• HDMI display device, such as a television, monitor or projector
Package Contents
Product Features
System Requirements
20-09-243-933C8B-EN.indd 220-09-243-933C8B-EN.indd 2 9/29/2020 9:10:45 AM9/29/2020 9:10:45 AM

3
Transmitter
Indicators and Connection
1HDMI Input (Male): Connects to the source device’s HDMI port with
the included HDMI cable.
2
Signal LED: Illuminates when both units are powered on and connected.
Blinks rapidly when transmitting a signal; blinks slowly when not.
3USB Micro-B Port (Female): Connects to the source’s USB-A port
with the included USB Micro-B cable.
4
Power LED: Illuminates when the transmitter is powered on.
1
1
2
2
3
3
4
4
1HDMI Output (Male): Connects to the display device’s HDMI port with
the included HDMI cable.
2
Signal LED: Illuminates when both units are powered on and connected.
Blinks rapidly when transmitting a signal; blinks slowly when not.
3USB Micro-B Port (Female): Connects to the display’s USB-A port
with the included USB Micro-B cable.
4Power LED: Illuminates when the receiver is powered on.
Receiver
20-09-243-933C8B-EN.indd 320-09-243-933C8B-EN.indd 3 9/29/2020 9:10:45 AM9/29/2020 9:10:45 AM

4
Installation and Operation
Refer to the following steps and diagrams to set up your
transmitter/receiver installation.
DVD
HDMI Extender
TX Sender*
HDMI Extender
RX Receiver
Micro USB Cable
HDMI Display
*Transmitter is bus-powered; however, if signal strength is not ideal, additional power
can be provided via the included Micro-USB cable.
Installation and Operation
1. Connect the transmitter to the source device’s HDMI port.
2. Connect the receiver to the display device’s HDMI port.
3. The transmitter is bus-powered and requires no external
power. However, if the signal is not strong enough, additional
power can be provided to the transmitter by connecting the
included USB Micro-B cable between the transmitter’s USB
Micro-B port and the source’s USB-A port.
4. Connect the included USB Micro-B cable between the
receiver’s USB Micro-B port and the display’s USB-A port.
5. The transmitter’s and the receiver’s Power LEDs will illuminate
to indicate they are receiving power.
6. The transmitter’s and the receiver’s Signal LEDs will illuminate
to indicate they are sharing a wireless connection.
20-09-243-933C8B-EN.indd 420-09-243-933C8B-EN.indd 4 9/29/2020 9:10:46 AM9/29/2020 9:10:46 AM

5
Specifications
Specifications B126-1A1-WHD4HH
Transmitter HDMI (Male)
Receiver HDMI (Male)
Power
Transmitter Power USB Micro-B
Receiver Power USB Micro-B
Power Consumption TX: <2.5W; RX: <5W
Video Transmission
HDMI Compliance HDMI 1.3
HDCP Compliance HDCP 1.2
HDMI Resolution 1080p @ 60 Hz
Maximum Transfer Rate 10.2 Gbps
Input and Output
TMDS Signal 0.5 to 1.5Vp-p (TMDS)
Input and Output
DDC Signal Input 5Vp-p(TTL)
Transfer Method 5.8G Wireless Transmission
Transmission distance 15 m (50 ft.)
Latency ≤200 ms
Environmental
Protection
Level (Electrostatic)
1a Contact Discharge Level 3
1b Air Discharge Level 3
Standard: IEC61000-4-2
Working Temperature 32° to 122°F (0° to 50°C)
Storage Temperature 14° to 158°F (-10° to 70°C)
Humidity (No
Condensation) 0 to 90%
20-09-243-933C8B-EN.indd 520-09-243-933C8B-EN.indd 5 9/29/2020 9:10:46 AM9/29/2020 9:10:46 AM

6
Troubleshooting
1. The picture is flickering or not showing at all. Make sure
nothing that could impede the signal strength is between the
transmitter and receiver units. Attempting to transmit video
through plaster or glass walls and windows may result in
limited signal quality.
2. The transmitter and receiver are failing to establish a
connection. Make sure the transmitter is plugged in correctly
to the HDMI port on the source device and the receiver
unit is plugged in correctly to the HDMI port of the display.
Then, make sure the receiver is correctly receiving power
by confirming the USB Micro-B cable is plugged in correctly
(see Installation and Operation). Make sure the distance
between the transmitter and receiver does not exceed 15
meters (50 feet). If video is still not being transmitted, unplug
the transmitter from the source device and plug it back in to
reset the connection.
3. The audio from the source content is not being
transmitted properly. If using a source with internal
speakers (such as a notebook or laptop computer), the
user must manually change the output sound on the source
settings to “HDMI Extender.”
4. The transmitter or receiver is overheating. If the product
gets too hot, it will not function properly. Are the units located
in an area that exposes them to elevated temperatures? See
Specifications for the exact temperature range of the units.
20-09-243-933C8B-EN.indd 620-09-243-933C8B-EN.indd 6 9/29/2020 9:10:46 AM9/29/2020 9:10:46 AM

7
Warranty and Product Registration
3-Year Limited Warranty
Seller warrants this product, if used in accordance with all applicable instructions, to be free
from original defects in material and workmanship for a period of 3 years from the date of initial
purchase. If the product should prove defective in material or workmanship within that period,
Seller will repair or replace the product, at its sole discretion.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM
ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER
THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY
OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND
THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some
states do not allow limitations on how long an implied warranty lasts, and some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above limitations
or exclusions may not apply to you. This warranty gives you specific legal rights, and you may have
other rights which vary from jurisdiction to jurisdiction.)
WARNING: The individual user should take care to determine prior to use whether this device is
suitable, adequate or safe for the use intended. Since individual applications are subject to great
variation, the manufacturer makes no representation or warranty as to the suitability or fitness of
these devices for any specific application.
Product Registration
Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically
entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without
notice. Photos and illustrations may differ slightly from actual products.
