Tripp Lite Data Shield DB25-ALL User manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: DB25-ALL
Network Surge Suppressor - Essential protection for data and communication lines
Highlights
Complete serial port (DB25) surge protection
Protects against the effects of electrostatic discharge, faulty wiring and
lightning
Lifetime product warranty
Heavy duty grounding lead
Description
Tripp Lite's DB25-ALL offers dataline surge suppression for any DB25 serial port, regardless of cable configurations. Connects and protects all 25
pins plus D shell chassis for universal protection of any DB25 application. User configurable for use with male or female captive DB25 port.
Convenient DB25 input and output connects directly to the protected port, obtaining a ground outlet from the computer chassis. Surge suppression
is handled with balanced arrays of high-speed avalanche diodes that divert excess energies created by electrostatic discharges, faulty wiring or
lightning away from network interface connections. Tripp Lite network surge suppressors reduce blown interface connections, garbled transmissions,
system lock-ups and hard equipment failure by safely shunting dataline surges to ground. Lifetime warranty.
SUPPRESSION: Reversible DB9 m/f jacks, protects pins 1-25 and chassis, 18V clamping
Applications
Ideal for the protection of data terminals, data communications equipment, PCs, printers, modems and more.
Package Includes
DB25-ALL dataline protector
Instruction manual and warranty information
Features
DB25 protects 25 pin serial connections for dataline surge suppression of data terminal, data communications equipment and PCs, printers,
modems and more
Reversible for use with male or female captive DB25 ports
Offers protection on all 25 data lines, plus D shell chassis
Surge suppression utilizing high speed avalanche diodes divert excess energies on the network to ground
Lifetime product warranty
Specifications
OVERVIEW
Intended Application Computer Networking
OUTPUT

Output volt amp capacity
(amps)
340 amps
INPUT
UPS input connection type DB25
Recommended Electrical
Service
120V, 230V
Input cord length (ft.) No Cord
SURGE / NOISE SUPPRESSION
Clamping voltage (RMS) 18V
DATALINE SURGE SUPPRESSION
Telephone/DSL Protection No
Cable (Coax) Protection No
Additional Dataline Protection 1-25 & Chassis
PHYSICAL
Style In-Line
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=159.
