Tripp Lite B004-DPUA2-K User manual

1
Owner’s Manual
DisplayPort KVM Switch
with Audio and SuperSpeed
USB 3.0 Hub
Models: B004-DPUA2-K, B004-DPUA4-K
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector—a $50 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2015 Tripp Lite. All rights reserved.
Table of Contents
Package Contents 2
Optional Accessories 2
System Requirements 2
Features 3
Installation 4
Operation 5
Warranty and 7
Product Registration
15-05-047-933455.indd 1 5/7/2015 4:20:53 PM

2
Package Contents
Optional Accessories
System Requirements
B004-DPUA2-K
• (x2) DisplayPort Cables – 4 ft.
• (x2) USB 3.0 A/B Cables – 4 ft.
• (x2) 3.5 mm Mini-Stereo Speaker/
Microphone Cables – 4 ft.
• External Power Supply
(Input: 100/240V, 50/60Hz, 0.5A;
Output: 9V, 2A)
• Owner’s Manual
B004-DPUA4-K
• (x4) DisplayPort Cables – 6 ft.
• (x4) USB 3.0 A/B Cables – 6 ft.
• (x4) 3.5 mm Mini-Stereo Speaker/
Microphone Cables – 6 ft.
• External Power Supply
(Input: 100/240V, 50/60Hz, 0.5A;
Output: 9V, 2A)
• Owner’s Manual
• P579-006 DisplayPort Extension Cable (M/F) – 6 ft.
• P580-Series DisplayPort Cables (M/M)
• U322-Series USB 3.0 A/B Cables (M/M)
• U324-Series USB 3.0 A/A Extension Cables (M/F)
• U326-Series USB 3.0 Micro-B/A Cables (M/M)
• DisplayPort monitor
• Computer with an available USB 3.0 port (a USB 2.0 or 1.1 port can be used,
but it will not achieve USB 3.0 speeds)
• USB keyboard and mouse
• Speaker and microphone with 3.5 mm mini-stereo jacks
(if using the audio feature)
• Computer with 3.5 mm mini-stereo speaker and microphone jacks
(if using the audio feature)
• OS-independent; compatible with all major operating systems
15-05-047-933455.indd 2 5/7/2015 4:20:53 PM

3
Features
• Control two or four DisplayPort computers with a single DisplayPort monitor, USB
keyboard and USB mouse
• DisplayPort, USB 3.0, and audio cabling included
• Switch ports via pushbutton or keyboard hotkey commands
• Auto Scan feature automatically switches between connected computers at
regular intervals
• 3.5 mm mini-stereo speaker and microphone connections allow sharing of audio
equipment between systems
• Supports 2-channel stereo audio
• Audio can be switched independently, allowing music to play from one computer
while you access another computer
• Features two SuperSpeed USB 3.0 hub ports for sharing peripherals between
connected computers
• Supports USB 3.0 data transfer rates up to 5 Gbps; backward compatible with
USB 2.0 and 1.1 devices
• USB hub functionality can be switched independently, allowing you access to one
computer while the USB hub ports remain connected to another computer
• Advanced emulation technology ensures compatibility with USB keyboards and
mice, and provides super-fast port switching
• Supports digital video resolutions up to 2560 x 1600
• DDC emulation sends the monitor’s EDID information to connected computers to
ensure optimal video quality
15-05-047-933455.indd 3 5/7/2015 4:20:53 PM

4
Installation
Notes: Before beginning installation, power off all devices that will be connected to the KVM
switch. You must also unplug the power cords of any computers that have the keyboard
“Power On” feature.
1. Connect the external power supply to the KVM switch, then plug it into a
Tripp Lite Surge Protector, Uninterruptible Power Supply (UPS), or
Power Distribution Unit (PDU).
2. Connect the USB keyboard and mouse to the KVM’s corresponding USB
console ports.
3. If connecting a microphone and speakers, plug their 3.5 mm mini-stereo plug
into the KVM’s corresponding 3.5 mm mini-stereo console ports.
4. Connect the DisplayPort monitor to the KVM’s DisplayPort console port.
5. If connecting USB peripherals, plug them into the KVM’s two SuperSpeed
USB 3.0 hub ports.
6. Using the included DisplayPort, USB 3.0, and audio cables, connect the
computer ports on the KVM to a computer.
7. Repeat step 6 for each computer you are connecting.
8. Power on the connected computers and devices.
15-05-047-933455.indd 4 5/7/2015 4:20:53 PM

5
Operation
There are two ways to access the computers connected to your KVM switch;
Pushbutton or Keyboard Hotkey Commands.
Pushbutton
Press the pushbutton located on the front of the KVM of the port you want to
switch to. When switching between ports, the default is for the computer, audio
and USB hub functionality to be switched together. To un-bind either audio or USB
hub control from port switching, use the keyboard hotkey commands listed in the
following section.
Keyboard Hotkey Commands
Another way to switch between connected computers is to use keyboard hotkey
commands. Besides allowing you to switch computers, hotkey commands perform
other functions, such as binding/unbinding computer switching with audio and/or the
USB hub ports, initiating an auto scan, etc. When entering a hotkey command, each
keystroke must be within two seconds of the previous keystroke for the command
to be initiated. The following table lists the available keyboard hotkey commands,
explains how to initiate them and describes their function.
Command Hotkey Description
Select Computer
Port
[Scroll Lock]
[Scroll Lock] [x]
x = 1, 2, 3 or 4
Switches the KVM focus to the
selected port.
Select USB
Hub Focus
[Scroll Lock]
[Scroll Lock] [Fx]
Fx = [F1] for port
1, [F2] for port
2, etc.
Selects which computer port has the
focus of the USB hub ports.
Note: When computer and hub switching are
bound together, switching hub focus will also
switch the focus of the KVM.
Select Audio
Focus
[Scroll Lock]
[Scroll Lock] [Fy]
Fy = [F5] for port
1, [F6] for port
2, etc.
Selects which computer port has the
focus of the audio and microphone
ports.
Note: When computer and audio switching
are bound together, switching audio focus will
also switch the focus of the KVM.
Bind Computer
and Hub
Switching
[Scroll Lock]
[Scroll Lock] [Z]
Binds computer and hub switching
together. This is enabled by default.
15-05-047-933455.indd 5 5/7/2015 4:20:53 PM

6
Operation
Command Hotkey Description
Unbind Computer
and Hub
Switching
[Scroll Lock]
[Scroll Lock] [X]
Unbinds computer and hub switching,
allowing access to one computer while
the focus of the hub is on the other.
Bind Computer
and Audio
Switching
[Scroll Lock]
[Scroll Lock] [Q]
Binds computer and audio switching
together. This is enabled by default.
Unbind Computer
and Audio
Switching
[Scroll Lock]
[Scroll Lock] [W]
Unbinds computer and audio switching,
allowing access to one computer while
playing audio from the other.
Next Lower
Computer Port
[Scroll Lock]
[Scroll Lock] [h]
Switches the KVM focus to the
computer directly prior to the currently
selected computer.
Next Active
Lower Computer
Port
[Scroll Lock]
[Scroll Lock]
[Backspace]
Switches the KVM focus to the next
active computer directly prior to the
currently selected computer. If a
computer is not connected to a port, or
if the connected computer is powered
off, it will be skipped.
Next Higher
Computer Port
[Scroll Lock]
[Scroll Lock] [ ]
Switches the KVM focus to the
computer directly after the currently
selected computer.
Define Hotkey
Preceding
Sequence
[Scroll Lock]
[Scroll Lock] [H]
[x] x = [Scroll
Lock], [Caps
Lock], [Num
Lock], [Esc],
[F12], Left [Ctrl],
and Right [Ctrl]
Selects which key will be used for
the hotkey preceding sequence. The
default is [Scroll Lock].
Note: The Hotkey Preceding Sequence
can also be changed using the front panel
buttons. Press and hold down the highest
number button (2 or 4) until you hear two
beeps. After the two beeps, release the
button and press the key that you wish to use
for the Hotkey Preceding Sequence.
Auto Scan [Scroll Lock]
[Scroll Lock] [S]
Initiates an Auto Scan at a scan
interval of 10 seconds.
15-05-047-933455.indd 6 5/7/2015 4:20:53 PM

7
Command Hotkey Description
Auto Scan with
Programmable
Scan Interval
[Scroll Lock]
[Scroll Lock]
[S] [x]
x = 1 through 6
1 = 10, 2 = 20,
3 = 30, 4 = 40,
5 = 50, 6 = 60
Initiates an Auto Scan at the chosen
scan interval.
Exit Auto Scan Press any key
on the keyboard,
or the KVM
pushbutton
Stops an Auto Scan at the selected
computer.
Turn Beeper
On/Off
[Scroll Lock]
[Scroll Lock] [B]
Turns beeping sound on or off
Restore Defaults [Scroll Lock]
[Scroll Lock] [R]
Restores the KVM’s default settings.
Operation
Warranty and Product Registration
1-YEAR LIMITED WARRANTY
TRIPP LITE warrants its products to be free from defects in materials and workmanship for a
period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty
is limited to repairing or replacing (at its sole option) any such defective products. To obtain
service under this warranty, you must obtain a Returned Material Authorization (RMA) number
from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to
TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and
must be accompanied by a brief description of the problem encountered and proof of date and
place of purchase. This warranty does not apply to equipment, which has been damaged by
accident, negligence or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid
limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is
not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment,
loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.
15-05-047-933455.indd 7 5/7/2015 4:20:53 PM

8
Warranty and Product Registration
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You’ll be
automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the
user’s authority to operate this equipment.
WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing
regulations, when customers buy new electrical and electronic equipment from Tripp Lite
they are entitled to:
• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies
depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without
notice.
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
15-05-047 93-3455_RevA
15-05-047-933455.indd 8 5/7/2015 4:20:55 PM
