Tripp Lite B032-VUA2 User manual

1
Owner’s Manual
2 Port VGA/USB + Audio
KVM Switch with
Built-in Cables
Model: B032-VUA2
Español 12 • Français 23 • Русский 34
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
17-10-491-93365E.indb 1 12/4/2017 11:01:23 AM

2
Product Features
Package Contents
• Control two computers from a single USB keyboard, mouse and VGA
monitor
• Compact design features built-in 4 ft. (1.2 m) cables for KVM and audio
connections
• USB mouse port can be used to connect a USB 1.1 hub for peripheral
sharing
• Supports video resolutions up to 2048 x 1536
• Hotkey commands let you set OS and keyboard language
• KVM stores the monitor’s EDID information to optimize display resolution
• Console mouse port emulation/bypass feature supports most mouse
drivers and multi-function mice
• Supports gaming keyboards and wireless keyboards/mice
• Features Hotkey and Mouse Port Switching
• Supports Windows®, Mac®, Sun and Linux®
• Sun/Mac keyboard support and emulation*
• No external power required
*PC keyboard combinations emulate Sun/Mac keyboards. Sun/Mac keyboards only
work with their own computers.
• B032-VUA2
• Owner’s Manual
17-10-491-93365E.indb 2 12/4/2017 11:01:23 AM

3
Optional Accessories
System Requirements
• P502-Series VGA/SVGA Monitor Cables with RGB Coax
• U222-004-R 4-Port USB 2.0 Hub
• U222-007-R 7-Port USB 2.0 Hub
• U222-010-R 10-Port USB 2.0 Hub
• U022-Series USB 2.0 A/B Device Cables
• U030-Series USB 2.0 Mini-B Cables
• U050-Series USB 2.0 Micro-B Cables
• VGA, SVGA or Multisync monitor
• USB Keyboard
• USB Mouse
• Computer with a VGA port
• Computer with USB ports
17-10-491-93365E.indb 3 12/4/2017 11:01:23 AM

4
Installation
Operation
Note: Make sure the power to all devices is turned off prior to installation. You must
unplug the power cords of any computers that have the Keyboard Power On Function.
1. Plug your USB keyboard, mouse and VGA monitor into the console ports
on the unit.
Note: If using a wireless keyboard and mouse, the dongle must be plugged into the
unit’s keyboard port in order to use the hotkey function.
2. (Optional) A USB hub can be connected to the USB console mouse port,
allowing you to add multiple USB peripherals to your installation.
Note: To ensure proper functionality, use a hub with an external power supply. The
KVM’s Mouse Emulation Mode must also be disabled (see the Keyboard Hotkey
Commands table in this manual for details) when connecting a hub.
3. Plug your speakers into the 3.5 mm speaker jack.
4. Plug the unit’s built-in USB, VGA and audio cables into the computers’
corresponding ports.
5. Power on your devices.
Note: The unit’s default power on function will link to the first computer being
powered on.
There are two ways of accessing computers and devices connected to the
KVM switch; Mouse Port Switching and Keyboard Hotkeys.
Note: When switching ports, wait a few seconds for the selected computer’s video to
display on the console monitor prior to switching ports again. Do not switch ports when
a USB peripheral device is in operation.
Mouse Port Switching Functionality
Note: Mouse port switching is disabled by default and must be enabled via keyboard
hotkey command. In addition, it is only supported when the KVM’s mouse emulation
mode is enabled (KVM mouse emulation is enabled by default—see the Keyboard
Hotkey Commands table for details).
17-10-491-93365E.indb 4 12/4/2017 11:01:23 AM

5
Operation
When enabled, Mouse Port Switching Functionality allows users with scroll
mice to simultaneously switch the focus of the KVM and Audio between
ports by double-clicking the scroll wheel.
Port Switching Keyboard Hotkey
Hotkeys switch functionality focus between ports using only the keyboard,
as well as perform other functions on the KVM switch. To switch the KVM
and Audio between the two ports, press the [Scroll Lock] key twice. If the
[Scroll Lock] [Scroll Lock] hotkey conflicts with other programs running on
your computer, it can be switched to [Ctrl] [Ctrl] via Hotkey command. See
the Keyboard Hotkey Commands table for details.
Performing Keyboard Hotkey Commands
All other hotkey operations are enabled by entering Hotkey Setting Mode.
When in Hotkey Setting Mode, the [Scroll Lock] and [Caps Lock] keyboard
LEDs flash in succession and ordinary keyboard and mouse functions are
suspended. Only hotkey related keystrokes can be performed. To initiate
Hotkey Setting Mode, perform the following command:
1. Press and hold down the [Num Lock] key.
2. While holding down the [Num Lock] key, press and release the minus [-]
key.
3. After releasing the minus [-] key, release the [Scroll Lock] key.
Note: If using [Num Lock] minus [-] conflicts with other programs, it can be
changed to [Ctrl] [F12] via Hotkey Command, in which [Ctrl] takes the place of
[Num Lock], and [F12] takes the place of the minus [-] key (See the Keyboard
Hotkey Commands table).
17-10-491-93365E.indb 5 12/4/2017 11:01:23 AM

6
Operation
Keyboard Hotkey Commands
The following table lists the keyboard hotkey commands available for use on
the KVM switch.
Combination Function
[Num Lock] plus
minus [-] key Or
[Ctrl] plus [F12]
key
[H] Toggles between the default [Num Lock] [-] and
the alternate [Ctrl] [F12] Hotkey Setting Mode
invocation keys.
[T] Toggles between the default [Scroll Lock]
[Scroll Lock] and alternate [Ctrl] [Ctrl] port
switching keyboard hotkey.
[F2] Activates Mac keyboard mapping.
[F3] Activates Sun keyboard mapping.
[F10] Auto detects keyboard operating platform.
[F4] Lists current switch settings via the paste
function of a text editor.
Note: To perform this hotkey command, you must
first have a text editor or word processor (such as
Microsoft® Word) open, with the cursor in the page
window. Upon pressing this hotkey, the KVM’s current
settings will display.
[F5] Performs a USB keyboard and mouse reset.
[F6][nn][ENTER] Sets the keyboard language layout.
Note: nn is a two-digit number that represents one of
the following keyboard language codes: US English 33;
French 08; Japanese 15.
[A] Initiates an Auto Scan.
[R][ENTER] Resets hotkeys to the default setting.
[M] Enables/Disables mouse emulation. This
function is enabled by default.
Note: In order for Mouse Port Switching to work, this
function must be enabled.
[N] Enables/Disables keyboard emulation. This
function is enabled by default.
[W] Enables/Disables mouse-port switching. This
function is disabled by default.
[ESC] or [Space Bar] Quits hotkey setting mode.
17-10-491-93365E.indb 6 12/4/2017 11:01:23 AM

7
Specifications
Computer Connections 2
Port Selection Hotkeys, Mouse
Connectors (Console Ports) Keyboard and Mouse: 2x USB Type-A Female (White)
Video: HD15 Female (Blue)
Speakers: 3.5 mm Mini-Stereo Female (Green)
Connectors (KVM Ports) Keyboard and Mouse: 2x USB Type-A Male (Black)
Video: HD15 Male (Blue)
Speakers: 3.5 mm Mini-Stereo Male (Green)
LED Quantity and Color 2x Green
Built-in Cable Length 4 ft. (1.2 m)
Video Resolution 2048 x 1536
Scan Interval 5 seconds
Power Consumption 0.33W
Operating Temperature 32° to 122°F (0° to 50°C)
Storage Temperature -4° to 140°F (-20° to 60°C)
Humidity 0 to 80% RH, Non-Condensing
Housing Material Plastic
Weight 0.8 lb. (0.36 kg)
Dimensions [L x W x H] 3.11 x 2.60 x 1.02 in. (7.9 x 6.6 x 2.6 cm)
17-10-491-93365E.indb 7 12/4/2017 11:01:23 AM

8
Appendix
Mac Keyboard Emulation
The PC compatible (101/104 key) keyboard can emulate the functions of
the Mac keyboard using the PC keystrokes in the table below.
Note: When more than one key is required on the PC Keyboard to emulate the Mac
keyboard, press and release the first key, and then press and release the second key.
PC Keyboard Mac Keyboard
[Shift] [Shift]
[Ctrl] [Ctrl]
[Ctrl], [1]
[Ctrl], [2]
[Ctrl], [3]
[Ctrl], [4]
[Alt] [Alt]
[Print Screen] [F13]
[Scroll Lock] [F14]
[=]
[Enter] [Return]
[Backspace] [Delete]
[Insert] [Help]
[Ctrl], [F15]
17-10-491-93365E.indb 8 12/4/2017 11:01:24 AM

9
Appendix
Sun Keyboard Emulation
The PC compatible (101/104 key) keyboard can emulate the functions of
the Sun keyboard using the PC keystrokes in the table below.
Note: When more than one key is required on the PC Keyboard to emulate the Sun
keyboard, press and release the first key, and then press and release the second key.
PC Keyboard Sun Keyboard
[Ctrl], [T] [Stop]
[Ctrl], [F2] [Again]
[Ctrl], [F3] [Props]
[Ctrl], [F4] [Undo]
[Ctrl], [F5] [Front]
[Ctrl], [F6] [Copy]
[Ctrl], [F7] [Open]
[Ctrl], [F8] [Paste]
[Ctrl], [F9] [Find]
[Ctrl], [F10] [Cut]
[Ctrl], [1]
[Ctrl], [2]
[Ctrl], [3]
[Ctrl], [4]
[Ctrl], [H] [Help]
[Compose]
17-10-491-93365E.indb 9 12/4/2017 11:01:24 AM

10
Appendix
Warranty & Product Registration
Factory Default Settings
Setting Default
Port Switching Hotkey [Scroll Lock], [Scroll Lock]
Hotkey Setting Mode Invocation Command [Num Lock] plus minus [-] key
Auto Scan Interval 5 seconds
Keyboard Operating Platform PC Compatible
Mouse Emulation Enabled
Keyboard Emulation Enabled
Mouse Port Switching Disabled
3-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of
three (3) years from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited
to repairing or replacing (at its sole option) any such defective products. To obtain service under
this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or
an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized
TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief
description of the problem encountered and proof of date and place of purchase. This warranty does
not apply to equipment, which has been damaged by accident, negligence or misapplication or has
been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid
limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT,
EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any
costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software,
loss of data, costs of substitutes, claims by third parties, or otherwise.
Product Registration
Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically
entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
17-10-491-93365E.indb 10 12/4/2017 11:01:24 AM
