Tripp Lite SMART1200LCD User manual

SmartPro LCD 120V 1200VA 700W Line-Interactive
UPS, AVR, 2U Rack/Tower, LCD, USB, DB9 Serial, 8
Outlets
MODEL NUMBER: SMART1200LCD
Description
The SMART1200LCD SmartPro LCD 120V, 1200VA/700W Line-Interactive Uninterruptible Power Supply
provides battery backup and AC power protection against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data.
Ideal for backing up your desktop computer or audio/visual components, this line-interactive UPS switches to battery backup mode in milliseconds to keep
your connected equipment running long enough to save files and shut down safely with no data loss.
Eight NEMA 5-15R outlets protect against surges, as well as provide up to 12 minutes of UPS battery support at half load (350W) and 4 minutes of support at
full load (700W). Automatic voltage regulation (AVR) corrects severe undervoltages as low as 75V and overvoltages as high as 147V without using any battery
power. EMI/RFI noise filtering improves your equipment’s performance and prevents damage. A 480-joule surge suppression rating protects your equipment
from harmful power surges.
NEMA 5-15P plug with 6-foot cord connects to any NEMA 5-15R socket. Large rotatable LCD screen with dimmer shows real-time input voltage, overload,
AVR and battery statuses at a glance. Alarm sounds to indicate power loss or low battery. With Tripp Lite’s free PowerAlert software (available via free web
download), the SMART1200LCD enables safe unattended system shutdown and file saves in case of a prolonged power failure.
Features
Reliable Battery Backup
Provides 1200VA/700W high-performance power protection for desktop computers, audio/video components, media centers and other electronics
Supports 50% load (350W) up to 12 minutes and full load (700W) up to 4 minutes
Audible alarm indicates loss of utility power or low battery
Optimized Outlets
8 NEMA 5-15R outlets provide battery backup and protect against surges or spikes that can harm equipment or data
Automatic Voltage Regulation (AVR)
Highlights
Supports a half-load (350W) up
to 12 min. during power outage
Supports a full load (700W) up to
4 min. during power outage
Features 8 protected NEMA
5-15R outlets
Offers automatic voltage
regulation (AVR)
LCD screen reports real-time
UPS and power status
Package Includes
SMART1200LCD SmartPro LCD
120V 1000VA/500W
Line-Interactive UPS
USB cable
DB9 serial cable
Telephone cable
Mounting hardware
Owner’s Manual
1 / 5

Corrects undervoltages as low as 75V and overvoltages as high as 147V without drawing battery backup power
Rotatable LCD Status Screen
Large LCD screen shows real-time input voltage, overload, AVR and battery statuses
Rotates for easy viewing in both horizontal and vertical installations
Dimmer switch controls brightness level
AC Line, Tel/DSL and Ethernet Surge Suppression
Surge suppression rating of 480 joules protects connected equipment and data from harmful power surges
Built-in RJ-45 jacks protect single-line tel/DSL or network Ethernet connection
EMI/RFI Line Noise Filtering
Removes electromagnetic and radio frequency interference that can disrupt or damage your equipment’s performance
USB and DB9 Communication Ports and Free PowerAlert Software
HID-compliant USB port integrates with built-in power management and auto-shutdown of Windows and Mac OS X
USB and DB9 serial ports work with Tripp Lite PowerAlert software (available for free download at www.tripplite.com/poweralert) to enable safe,
unattended system shutdown and file saves during prolonged power failure
Flexible Installation Options
NEMA 5-15P plug with 6-foot cord connects to any NEMA 5-15R socket
Adapts to vertical or horizontal installation without special hardware
Includes 2U brackets for rack-mount installation
Specifications
OUTPUT
Output Volt Amp Capacity (VA) 1200
Output kVA Capacity (kVA) 1.2
Output Watt Capacity (Watts) 700
Nominal Output Voltage(s)
Supported 110V; 115V; 120V
Nominal Voltage Details 115v nominal output in battery mode
Frequency Compatibility 60 Hz
Output Voltage Regulation (Line
Mode) -18%, +8%
Output Voltage Regulation (Battery
Mode) +/- 5%
Output Receptacles (8) 5-15R
Output AC Waveform (AC Mode) Sine wave
Output AC Waveform (Battery Mode) PWM sine wave
2 / 5

INPUT
Rated input current (Maximum Load) 7A
Nominal Input Voltage(s) Supported 120V AC
UPS Input Connection Type 5-15P; Right-Angled
Input Circuit Breakers 10A
UPS Input Cord Length (ft.) 6
UPS Input Cord Length (m) 1.8
Recommended Electrical Service 15A 120V
Input Phase Single-Phase
BATTERY
Full Load Runtime (min.) 4 min. (700w)
Half Load Runtime (min.) 12 min. (350w)
DC System Voltage (VDC) 24
Battery Recharge Rate (Included
Batteries) Less than 4.5 hours from 10% to 90%
Expandable Runtime No
VOLTAGE REGULATION
Voltage Regulation Description Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 75 to 147
Overvoltage Correction Input voltages between 128 and 147 are reduced by 12%
Undervoltage Correction Input voltages between 93 and 107 are boosted by 14%
Severe Undervoltage Correction Input voltages between 75 and 92 are boosted by 30%
USER INTERFACE, ALERTS & CONTROLS
Front Panel LCD Display Backlighted LCD screen indicates input voltage, 5-bar battery charge level, overload, AVR, on battery and replace
battery status; LCD screen rotates for rack/tower viewing
Switches 2 Switches control off/on power status and alarm-cancel/self-test operation; dimmer switch controls LCD brightness
Alarm Cancel Operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate
low-battery status
Audible Alarm Audible alarm indicates power-failure and low-battery status; alarm can be disabled using PowerAlert software
LED Indicators Front panel LCD display
SURGE / NOISE SUPPRESSION
UPS AC Suppression Joule Rating 480
UPS AC Suppression Response
Time Instantaneous
3 / 5

UPS Dataline Suppression 1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet
EMI / RFI AC Noise Suppression Yes
PHYSICAL
Included Mounting Accessory
Description Pair of mounting ears enable tower and 2-4 post rackmount installation
Primary Form Factor Rackmount
UPS Power Module Dimensions
(hwd, in.) 3.5 x 17.25 x 10.5
UPS Power Module Dimensions
(hwd, cm) 8.9 x 43.8 x 26.7
Rack Height (U Spaces) 2
Minimum Required Rack Depth
(inches) 13.5
Minimum Required Rack Depth (cm) 34.29
UPS Power Module Weight (lbs.) 29.4
UPS Power Module Weight (kg) 13.34
UPS Shipping Dimensions (hwd / in.) 7.5 x 15 x 21.5
UPS Shipping Dimensions (hwd /
cm) 19 x 38.1 x 54.6
Shipping Weight (lbs.) 29.4
Shipping Weight (kg) 13.3
UPS Housing Material ABS
Minimum Required Rack Depth (mm) 343
Primary UPS Height (mm) 89
Primary UPS Width (mm) 438
Primary UPS Depth (mm) 267
Shipping Height (mm) 190
Shipping Width (mm) 381
Shipping Depth (mm) 546
ENVIRONMENTAL
Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC Mode BTU / Hr. (Full Load) 180
Battery Mode BTU / Hr. (Full Load) 490
4 / 5

AC Mode Efficiency Rating (100%
Load) 93%
COMMUNICATIONS
Communications Interface USB (HID enabled); DB9 Serial
Network Monitoring Port Description Supports detailed monitoring of UPS and site power conditions
PowerAlert Software For local monitoring via the UPS’s built-in communication ports, download PowerAlert Local software at
http://www.tripplite.com/poweralert
Communications Cable USB and DB9 Serial cabling included
WatchDog Compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer Time 2-4 milliseconds
Low Voltage Transfer to Battery
Power (Setpoint) 75
High Voltage Transfer to Battery
Power (Setpoint) 147
SPECIAL FEATURES
Cold Start (Startup in Battery Mode
During a Power Failure) Cold-start operation supported
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI)
WARRANTY
Product Warranty Period (U.S. &
Canada) 3-year limited warranty
Product Warranty Period (Latin
America) 3-year limited warranty
Product Warranty Period
(International) 2-year limited warranty
Product Warranty Period (Mexico) 3-year limited warranty
Connected Equipment Insurance
(U.S., Canada & Puerto Rico) $250,000 Ultimate Lifetime Insurance
