Troax 89110003 User manual

Follow me
Power Door
Single Rail
89110003/4
www.troax.com
Art no: 88754651 ver. 02 Print no: 202112-8185-EN
Warehouse
partitioning
Drive installation instructions
&
Quick start guide

89110003/42/10 www.troax.com
Power Door Single Rail 89110003/4
Art no: 88754651 ver. 02
513
x4
M8
x4
M8x20
x50
x10 x2
x1
x1
x5
6 3
CE-label Power door 89110012
x1 x1 x1

www.troax.com 89110003/4 3/10
Art no: 88754651 ver. 02
4
1
5
3
2

89110003/44/10 www.troax.com
Art no: 88754651 ver. 02
13
8
1211
9
13
10
6
7
3
x4
1mm

www.troax.com 89110003/4 5/10
Art no: 88754651 ver. 02
15
1413
17 18
Troax Power sliding door
8911000x
Motor control
installaon instrucons
MS472
1iBAEN2020
Version July 2020
Information without guarantee, errors ex
cepted
16

89110003/46/10 www.troax.com
Art no: 88754651 ver. 02
19
3
20
21
CE-label
Power door

www.troax.com 89110003/4 7/10
Art no: 88754651 ver. 02
QUICK START
GUIDE
1

89110003/48/10 www.troax.com
Art no: 88754651 ver. 02
Short instruction of starting the motor control unit.
Please check Motor control installation instructions
for detailed information.
Sprache:
1: Deutsch
A
Language:
2: English
B
3
Type of gate: 02
+/- menu <RET>
A
A: Select your language with the
+/- Button.
B: Press Return to conrm.
2
0: Door small L
1: Door medium L
2: Door large L
3: Door small R
4: Door medium R
5: Door large R
A: Press Return
B: Select the gate type with the
+/- Button.
C: Press Return to conrm
Type of gate:
0: Door small L
B
C

www.troax.com 89110003/4 9/10
Art no: 88754651 ver. 02
max 1500 mm max 3000 mm max 3000 mm
max 2200 mm max 2200 mm
max 20 kg max 40 kg max 80 kg
Small Medium
Large
Left (L) Right (R)
max 4400 mm

89110003/410/10 www.troax.com
Art no: 88754651 ver. 02
x3
4
6
Memorizing
runs: <RET>
A
B
Fin pos open?
Conf. <RET>
A
5
A: Press the Menu
Button several times
until the display shows
Memorizing runs.
B: Conrm with Return
A: Press Return to start
the automatic
memorizing runs
Attention: the door
closes and opens
automatically 3 times.
Starts with open
You can stop the
memorizing runs at any
time by pressing any
button
Attention !
Memorizing
Memor runen OK?
YES NO <RET>
When nished the door remains open.
A: Conrm with Return
A
7
