Trolla TINE DE-THATCHER User manual

TINE DE-THATCHER
ASSEMBLY
1. Attach the Spring Tine (#17) to the Frame (#8) by using the Round Head Bolt M8x20 (#16), Hex Nut
M8 (#6) and Lock Washer Ø8 (#7), then tighten.
2.Attach the Lift Handle (#1) to the Frame (#8) by using the Hex Bolt M5x30 (#5) and Hex Nut M5 (#15),
then tighten.
3. Attach the Adjusting Rod (#4) to the Frame (#8) by using the Hex Bolt M8x25 (#3), Hex Nut M8 (#6)
and Lock Washer Ø8 (#7), then tighten.
4.Attach theAdjusting Frame (#14) to the Frame (#8) by using Pin (#9) and Hair Cotter Pin Ø3 (#10).
5. Insert the Plastic Cap (#18) to theAdjusting Frame (#14).
6. Attach the Connector (#11) to the Bracket (#12) by using the Hex Bolt M8x45 (#13), Hex Nut M8 (#6)
and Lock Washer Ø8 (#7), then tighten.
7.Attach the Connector (#11) to the Bracket (#12) by using Pin (#9) and Hair Cotter Pin Ø3 (#10).
8. Connect theAdjusting Steel Block (#2) with theAdjusting Rod (#4), adjust them for working depth.
9. The Hex Bolt M8x25 (#3), Hex Nut M8 (#6) and Lock Washer Ø8 (#7) will use for connecting the rake.
PARTS LIST
Part # Description QTY Part # Description QTY
1 Lift Handle 1 10 Hair Cotter Pin Ø3 2
2 Adjusting Steel Block 1 11 Connector 1
3 Hex Bolt M8x25 6 12 Bracket 1
4 Adjusting Rod 1 13 Hex Bolt M8x45 2
5 Hex Bolt M5x30 1 14 Adjusting Frame 1
6 Hex Nut M8 22 15 Hex Nut M5 1
7 Lock Washer Ø8 22 16 Round Head Bolt M8x20 15
8 Frame 1 17 Spring Tine 15
9 Pin 2 18 Plastic Cap 1

DRAWING & PARTS LIST
