True Fitness CS4 User manual

800.426.6570 / www.truefitness.com
Commercial Series
Treadmill
Owner’s Guide

In 1981 Frank Trulaske
launched True Fitness
Technology with one goal
in mind – to make the
finest fitness equipment on
the market.
His team began by
manufacturing premium,
handcrafted treadmills
with a focus on quality
and durability. Now, 25
years later, True Fitness
has established its
reputation as one of the
oldest and most respected
fitness equipment
manufacturers worldwide.
While True treadmills
continue to enjoy top reviews from
major consumer magazines and
fitness experts, its line of products
has expanded.
Today True also produces
award-winning exercise
bikes, ellipticals, and
TrueStretch, our patented
flexibility unit.
True Fitness is dedicated
to always staying a step
ahead of the competition
and supplying its valued
customers with the finest
workout equipment
in the industry. True’s
equipment is designed to
accommodate the needs
of everyone from the
professional athlete to the
weekend warrior.
So, with a solid 25 years
of fitness experience, you can count
on True Fitness both now and in the
future to meet your goals for a happy,
healthy lifestyle.
Thank You For Selecting True
“Our original
goal was to build
the world’s best
fitness equipment,
and today we
believe we’re
doing it!”


When using this exercise machine, basic precautions should
always be followed, including the following:
Read all instructions before using this treadmill.
Consult your physician before beginning any exercise program.
Do not use if you have a cold or fever.
Warning: to reduce the risk of burns, fire and
electric shock and injury to persons, follow these
instructions:
Danger: To reduce the risk of electric shock, always unplug the
treadmill before cleaning.
Unplug it from the outlet when not in use and before any service
is performed.
Keep the power cord away from heated surfaces.
Never operate this treadmill if it has a damaged power cord
or plug, if it is not working properly, if it has been damaged or
dropped, or if it has been submerged in water. In these cases, this
treadmill should be examined by a qualified service technician.
CS Treadmill Owner’s Guide
Review for Your Safety
IMPORTANT SAFETY INSTRUCTIONS
4

CS Treadmill Owner’s Guide 5
Review for Your Safety
IMPORTANT SAFETY INSTRUCTIONS
Other safety precautions:
Close supervision is necessary when the treadmill is being used
by or near children, or disabled persons.
Use this treadmill only for its intended use as described in this
manual.
Do not use attachments not recommended by the manufacturer.
Never drop or insert any object into any opening.
Do not allow animals on or near the treadmill.
Use the treadmill indoors only.
Never use the treadmill near water or while wet. Using this
treadmill around a pool, hot tub or sauna will void the warranty.
Do not operate where aerosol (spray) products are being used or
where oxygen is being administered.
Allow only trained personnel to service this equipment.
Avoid the possibility of bystanders being struck or caught
between moving parts by making sure that they are out of reach
of this treadmill while it is in motion.
Allow only one person at a time on this treadmill.

Table of Contents
CS Treadmill Owner’s Guide
6
Front Section
Safety instructions,
Quick Start Guide,
Table of Contents,
Model Differences
and Starting and
Stopping the
Treadmill Safely.
page 3
1 - Basic
Operation
page 11
2 - Heart
Rate Control
page 21
3 - User Programs
Three different types
page 29
4 - Fitness Tests
page 31
5 - Fan
page 35
Appendix C
page 53
6 - Designing an
Exercise Program
page 37
Appendix A
page 49
Appendix B
page 51
7- Care and
Maintenance
page 45
Appendix D
page 55

CS Treadmill Owner’s Guide 7
Quick Start Guide
Quick Start into a manual workout by pressing , or set up
a different workout by selecting a workout and adjusting settings
if necessary. Use keys or numeric keys and press to
accept each setting.
Adjust speed or incline at any time by using the dedicated
speed and incline keys on the control pod or keyboard.
Change data readouts by pressing .
Pause your workout by pressing .
Place your feet on the straddle covers.
Attach the safety lanyard to your waistband.
Place the safety key on the key holder.
Set up your workout (see Chapter 1) and press .
Stop the treadmill by reducing speed to 2 mph, then press .
Before
Your
Workout
During
Your
Workout
Starting
And
Stopping
Your
Treadmill
Safely

CS Treadmill Owner’s Guide
Model Differences
8
Model
Differences
This new treadmill is part of the True Commercial Series
treadmills. Since this owner’s guide covers all three commercial
models, you might notice descriptions of features that are
different from your treadmill. The main differences are in the
consoles.
Adds to CS 8.0:
• 8 Pre-set programs
• Heart rate control
• Cooling fans
• Two window LCD display
• 3% decline
CS 6.0
Same as CS 8.0 except:
• Single window LCD display
• No decline

Model Differences
CS Treadmill Owner’s Guide 9
CS 4.0
• “Simple” LED display
• All controls on main keyboard
• Manual operation only

chapter one
Basic Operations






Chapter 1: Basic Operations
Chapter 2: The Console
Chapter 3: User Programs
Chapter 4: Fitness Tests
Chapter 5: Fan Accessories
Chapter 6: Designing an Exercise Program
Chapter 7: Care and Maintenance 11

Using the Keyboard

Using the
Keyboard
CS Treadmill Owner’s Guide
12
Selecting Workouts: Press any of the workout keys and press
to begin your workout using the default settings.
Before pressing , you
may adjust other settings
like Workout Time and Body
Weight, pressing after
adjusting each setting. Press
at any time to begin
your workout. Note that HRC
workouts require settings
adjustments.
Adjusting Settings: Use the
numeric keypad or the
keys to adjust numeric settings.
Press to accept each
settings adjustment.
Control Pod / Primary Controls: During your workout, press
to stop the treadbelt and pause your workout. Press to
resume your workout. Press and hold to clear your workout.
Change Data Display: During your workout, press to
change the data displayed.
Safety Lanyard: This magnetized cord must be in place on the
treadmill balance bar location, and should be attached to your
clothing. The treadmill will not operate if the lanyard is not
attached.
CS 6.0 and CS 8.0 Workout Keys

Manual Operation

CS Treadmill Owner’s Guide 13
Important: Quick speed keys change speed with a single key press,
so take care in the keys you press.
Press , lighting the enable LED. Now the numeric keys
function as speed change keys from 1 mph to 9 mph. Quickspeed
is functional in any workout except fitness tests and Heart Rate
Control.
Disable QuickSpeed by pressing again.
During workout set up, set a correct body weight including clothes
so the treadmill can better estimate your calorie expenditure.
Quick
Speed
Body
Weight

This treadmill can monitor your heart rate using either a chest
strap or the metal grips on the hand rails (called contact heart
rate or CHR pads). A chest strap transmits your heart rate to
the treadmill via radio, and the CHR pads connect to a special
computer circuit to extract your heart rate.
Although this treadmill functions fine without using the heart rate
monitoring feature, this kind of monitoring gives you valuable
feedback on your effort level. Chest strap monitoring also allows
you to use Heart Rate Control, the most advanced exercise control
system available.
When you wear a Polar® or compatible transmitter strap, the
treadmill will display your heart rate as a digital beats-per-minute
(bpm) readout.
The transmitter strap should be worn
directly against your skin, about one inch
below the pectoral muscles/breast line (see
picture). Women should be careful to place
the transmitter below their bra line.
Some moisture is necessary between the
strap and your skin. Sweat from your exercise
works best, but ordinary tap water may be
used prior to your workout if desired.
Heart Rate Monitoring

Monitoring
Your
Heart RAte
CS Treadmill Owner’s Guide
14
Chest Strap
Heart Rate
Monitoring

CS Treadmill Owner’s Guide 15
Contact Heart Rate

The contact heart rate (CHR) system lets you monitor your heart
rate without wearing a strap.
Gently grasp the contact heart rate pads as shown.
When the system detects your hands, the Heart Rate label will
start flashing in time with your heart beat. During this time, the
system is analyzing and locking in your heart rate. Within about
15 seconds, your digital heart rate in beats per minute should be
displayed.
Important: The CHR System should only be used while walking
at speeds of 4 mph or lower. Above this speed the CHR accuracy is
unavoidably unreliable due to large muscle movements.
Contact
Heart Rate
(CHR)

For Best
CHR Results
CS Treadmill Owner’s Guide
Contact Heart Rate

16
1. Exercise with smooth body motions.
2. Breathe smoothly and regularly, and avoid talking. (Talking
will cause unrepresentative heart rate spikes of 5 to 10
bpm.)
3. Grip the pads lightly, not tightly.
4. Make sure your hands are clean, free of both dirt and hand
lotions.
When using a Heart Rate Control workout, it is best to use chest
strap monitoring. These workouts work best with the extra
accuracy gained from a chest-contact heart rate monitoring
system.
A Note on CHR Accuracy
CHR monitoring may be a bit less accurate than a
chest strap, since the heart rate signals are much
stronger at the chest.
About 5% of the population cannot be picked up
by any CHR system. This is because their heart is
positioned in a more up-and-down manner in their
chest, as opposed to leaning over to one side.

CS Treadmill Owner’s Guide 17
Pre-Set Workouts

Pre-Set
Workouts
Walking:
Calorie
Burn
Walking:
Hill
Intervals
Each workout has a four-minute warm up and a two-minute cool
down. Speed or grade changes stay in effect until the next change
is requested by the program. Changing the default workout time
adds or removes segments; it does not stretch or compress the
workout profile.
Change workout levels during your workout by pressing the
key for the workout you are using (its LED will be lit), adjusting
the numeric level, then pressing . Change to a new pre-set
workout during your workout by pressing any of the present
workout keys and pressing at your desired workout.
In a walking workout, all speeds are under 4 mph. Increasing
levels increases speed from 2 to 4 mph and grade from 4% to 10%;
speed and grade stay constant in the work section. Speed or grade
changes in the work section are permanent
Walking intervals with grade alternate between hills and nearly
flat in two-minute segments. Speed changes are permanent; grade
changes affect the current two-minute segment only.
Changes in Grade
Changes in Grade

Walking
and
Running:
Speed
Intervals
CS Treadmill Owner’s Guide
Pre-Set Workouts

18
Zero-grade walking or running intervals are in one-minute
segments. Grade changes are permanent; speed changes affect the
current one-minute segment only.
Zero-grade gradually increases speed then decreases speed,
changing once per minute. Grade changes are permanent; speed
changes affect the current one-minute segment only.
Changes in Speed
Changes in Speed
Walking
and
Running:
Speed
Ramp-Up

These are True’s original four pre-set workouts. Changing the
workout time stretches and compresses the workout profile, in
ontrast to the four new pre-set workouts. Other differences are
explained below in the individual workout sections.
Incline changes in varying amounts in contrast to the new Hills
workout, which has hills of the same size all throughout the workout.
Very similar to Hill Intervals, with varying incline changes.
Similar to Speed Ramp, except both speed and grade change.
= Incline
= Speed
CS Treadmill Owner’s Guide 19
Classic Pre-Set Workouts

Glute
Buster
Leg Shaper
Cardio
Challenge

Different from Speed Intervals 2 with the speed changing in
varying amounts.
When the treadmill is changing to a new target speed, the matrix
display readout will display the actual speed. As the speed is
changing, the message center will display
TARGET = 12.0 MPH
Once the treadmill reaches the new target speed, the Speed
readout will show the target speed.
Sports
Training
Actual
Speed
Display
CS Treadmill Owner’s Guide
Classic Pre-Set Workouts

20

The Console



21
chapter two
Chapter 1: Basic Operations
Chapter 2: The Console
Chapter 3: User Programs
Chapter 4: Fitness Tests
Chapter 5: Fan Accessories
Chapter 6: Designing an Exercise Program
Chapter 7: Care and Maintenance

CS 8.0 Keyboard

CS Treadmill Owner’s Guide
22
CS 8.0 Treadmill
Keyboard
Incline Up/Down Adjusts incline. Also used to choose programs.
Speed Slow/Fast Adjusts speed in 0.1 mph increments. Also used to set weight and other workout parameters.
Stop/Pause Stops the belt and pauses workout. If held for 3 seconds, resets all workout information.
Start/Quick Start Starts the belt and begins the workout.
Numeric Keys Direct entry of numeric data.
Enter Accepts workout parameters, and toggles the dual function displays.
Activate Quickspeed Enables the numeric keys to function as speed change keys from 1 mph to 9 mph. This is functional in any workout except fitness tests and heart rate control.
Advanced Options User programs and fitness tests.
HRC Cruise Control While in any workout, set your current heart rate as the target heart rate.
Cool Down Time period to cool down muscles and lower heart rate.
Reset Resets treadmill completely. Identical to pressing and holding STOP.
