True TWT-93D-6 User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • Fax [phone] • [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
TWT-93D-6
TWT-93D-6
Model Drawers
Capacity
(Cu. Ft.)
(liters)
Cabinet Dimensions
(inches)
(mm)
LD
†H*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TWT-93D-6 6 30.9
875
931/4
2369
323/8
823
333/8
848
1/2
1/2
115/60/1
230-240/50/1
9.7
4.2
5-15P
▲
7
2.13
610
277
7/07
True’s deep worktop units are
designed with enduring quality that
protects your long term investment.
True’s deep worktop units features
the combined advantage of
convenient worktop prep space
with deeper refrigerated storage.
Designed using the highest
quality materials and components
to provide the user with colder
product temperatures, lower utility
costs, exceptional food safety and
the best value in today’s food
service marketplace.
Oversized, environmentally friendly
(134A) forced-air refrigeration
system holds 33°F to 38°F (.5°C to
3.3°C).
All stainless steel front, top and
cabinet ends. Matching aluminum
finished back. Cabinet top and
backsplash are one piece formed
construction. Bacteria and food
particles cannot be trapped
underneath as with other two-piece
worktop units.
NSF approved, white aluminum
interior liner. 300 series stainless
floor with coved corners.
Each drawer accommodates two (2)
full size 12"L x 20"D x 8"H (305 mm
x 508 mm x 204 mm) food pan (sold
separately).
Foamed-in-place, high density
polyurethane insulation (CFC free).
Deep Worktop:
Drawered Refrigerator
†Depth does not include 1" (26 mm) for rear bumpers and 1/4"(7 mm) for front bumper. ▲Plug type varies by country.
*Height does not include 61/4" (159 mm) for castors or 6" (153 mm) for optional legs.
R
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TWT-93D-6 TFPY36E TFPY33S TFPY36P TFPY363
TWT-93D-6
DESIGN
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures, lower
utility costs, exceptional food safety and
the best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free) 134A
refrigerant.
• Oversized, factory balanced refrigeration
system with guided airflow to provide
uniform product temperatures.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains cabinet
temperatures of 33°F to 38°F (.5°C to
3.3°C) for the best in food preservation.
• Sealed, cast iron, self-lubricating
evaporator fan motor(s) and larger fan
blades give True worktop units a more
efficient low velocity, high volume
airflow design. This unique design
ensures faster temperature recovery
and shorter run times in the busiest of
foodservice environments.
• Condensing unit is accessed from
behind front grill; slides out for easy
maintenance.
CABINET CONSTRUCTION
• Exterior - stainless steel front, top and
cabinet ends. Matching aluminum
finished back. Cabinet top and
backsplash are one piece formed
construction.
• Interior - attractive, NSF approved, white
aluminum liner. 300 series stainless floor
with coved corners.
• Insulation - entire cabinet structure and
drawer facings are foamed-in-place using
high density, CFC free, polyurethane
insulation.
• 5" (127 mm) diameter stem castors - locks
provided on front set. 36" (915 mm)
work surface height.
DRAWERS
• Stainless steel exterior with white
aluminum liner to match cabinet interior.
• Each drawer fitted with 12" (305 mm)
long recessed handle that is foamed-
in-place with a sheet metal interlock to
ensure permanent attachment.
• Heavy-duty stainless steel drawer slides
and rollers. Removable without tools for
easy cleaning.
• Magnetic drawer gaskets of one piece
construction, removable without tools
for ease of cleaning.
PAN CAPACITY
• Each drawer accommodates two (2) full
size 12"L x 20"W x 8"D (305 mm x 508
mm x 204 mm), four (4)
1
/ 2 pans, or six (6)
1
/ 3 pans (sold separately).
MODEL FEATURES
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• Drawers will support a wide variety of
incremental pan size configurations;
divider bars available.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase, 15 amp dedicated outlet. Cord
and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 230-240V / 50 Hz.
❒ 6" (153 mm) standard legs.
❒ 6" (153 mm) seismic/flanged legs.
❒ 2
1
/ 2 " (64 mm) diameter castors.
❒ 3" (85 mm) diameter castors.
❒ Single utility shelf.
❒ Double utility shelf.
❒ 30" (762 mm) deep,
1
/ 2 " (13 mm) thick,
white polyethylene cutting board.
Requires ”L” brackets.
❒ 32
1
/ 8 " (816 mm) deep,
1
/ 2 " (13 mm) thick,
composite cutting board. Requires “L”
brackets.
❒ Heavy duty, 16 gauge tops.
❒ Heavy duty package - 16 gauge tops, 20
gauge door, sides and back with stainless
interior.
❒ Exterior round digital temperature
display (factory installed).
❒ Remote cabinets (condensing unit
supplied by others; system comes
standard with 404A expansion valve
and requires R404A refrigerant). Consult
factory technical service department for
BTU information.
115/60/1
NEMA-5-15R
Deep Worktop:
Drawered Refrigerator
ELEVATION RIGHT VIEW
1"
(26 mm )
251/2"
(648 mm )
1/4"
(7 mm )
587/8"
(1496 mm )
323/8"
(823 mm )
25/8"
(67 mm )
131/32"
(51 mm )
3013/32"
(773 mm )
39/16"
(91 mm )
3515/16"
(913 mm )
931/4"
(2369 mm )
335/16"
(847 mm )
391/2"
(1004 mm )293/4"
(756 mm )
39/16"
(91 mm )
81/4"
(210 mm )
123/4"
(324 mm )
63/16"
(158 mm)
5"
(127 mm)
