TTS Easi-Scope User manual

TTS Group Ltd.,
Park Lane Business Park,
Kirkby-in-Ashfield,
Nottinghamshire,
NG17 9GU, UK
Warranty & Support
This product is provided with a one year warranty for problems found during
normal usage. Mistreating the Easi-Scope or opening the unit will invalidate this
warranty.
All out of warranty repairs will be subject to a replacement fee.
Technical Support
Please visit www.tts-group.co.uk for the latest product information.
Email [email protected] for technical support.
TTS Group Ltd.
Park Lane Business Park
Kirkby-in-Ashfield
Nottinghamshire,
NG17 9GU, UK.
Freephone: 0800 318686 Freefax: 0800 137525
TTS Product Code:
EL00015
Magnifies specimens up to
41x on a 17” computer monitor
WARNING: Do not dispose of this product in
household waste. Hand it over to a collection point
for recycling electronic appliances.
WARNING! Not suitable for children under
36 months due to small parts – choking hazard.
Made in China, on behalf of the TTS Group Ltd.
TTS is part of the RM group
Nxxxxx
N448
+
_C
5V
Easi-Scope
Easi-Scope
www.tts-shopping.com
USER GUIDE

Easi-Scope
Important information
Please read this instruction manual carefully before using this product, and retain
these instructions for future reference.
Improvements and changes to this text necessitated by typographical errors,
or improvements to the software and/or equipments may be made at any time
without notice.
Warning
Do not shine the Digital Microscope’s LEDs in the eye, doing so may cause
permanent eye damage.
Product description
This product is a USB powered device which magnifies specimens up to 41x on a
17” computer monitor.
Snapshot of the specimens can be captured using the shutter button located on
the top of the device. Video recording is also available.
Care and maintenance
nKeep the device dry and protect it from water or vapour.
nDo not leave your device in a place with an extreme high or low
temperature.
nDo not touch the device with a wet hand as it may damage the device, or
cause an electric shock to the user.
nDo not use or store the device in dusty, dirty areas as its moving parts may
be damaged.
nDo not use harsh chemicals, cleaning solvents or strong detergents to clean
the device. Wipe it with a soft cloth slightly dampened in a mild soap-and-
water solution.
Computer requirements
Windows based PC
Compatible operating systems
Windows XP SP2, SP3
Windows Vista (32 bit or 64 bit)
Windows 7 (32 bit or 64 bit)
Windows 8 (32 bit or 64 bit)
CPU Speed P4-1.8GHz or above
RAM 512 MB or above
Hard disk 800 MB or above
USB USB 2.0
Mac OS based PC
Compatible operating systems
Mac OS X 10.4.8 - Mac OS X 10.8.1
CPU Power PC G3/G4/G5 or Intel
based
RAM 128 MB or above
Hard disk 800 MB or above
USB USB 2.0
Table of Contents
Important information 2
Care and maintenance 2
Warning 3
Product description 3
Computer requirements 3
Package contents 6
Product overview 4
Product specification4
Software installation 5
Getting started 5
Connecting the device 5
Starting the software 6
Focusing 6
Using the software 7
System settings menu 7
Device setup 8
Timed shot setup 8
Movie setup 8
Save setting 8
Language setting 8
Advanced settings 8
Saved files 9
Uninstalling the software 9
Legal information 9
2 3

Product overview Software installation
Windows based PC
1. Insert the supplied application CD to the CD-ROM of the computer.
2. Double click the “Digital Viewer.exe” icon located within the CD.
3. Follow the Digital Viewer setup wizard to install the software and drivers
for the Digital Microscope.
Mac OS based PC
1. Insert the supplied application CD to the CD-ROM of the computer.
2. Double click the “Digital Viewer.dmg” icon located within the CD.
3. Drag the Digital Viewer icon into the Applications folder.
Getting started
Assembling the product
Insert one of the adaptors into the adaptor slot, and fasten it by turning it gently
in the clockwise direction.
Connecting the device
Connect the device to a USB socket of the computer.
Product specification
Connection type USB 2.0
Effective magnification 14” monitor - 34x 17” monitor - 41x
Effective viewing area 8mm x 6mm
Illumination Four LED array
Sensor CMOS
Sensor resolution 680 x 480 pixels (VGA)
Size 75mm x 50mm x 50mm
Weight 133 grams
Lens
Focusing
Ring
LED Lights
Adaptor Slot
USB Cable
Shutter Button
Easi-Scope
4 5

Starting the Digital Viewer software
Windows based PC
The Digital Viewer software can be launched by double clicking the Digital
Viewer icon from the desktop, or from the start menu (Start > All Programs >
Digital Viewer > Digital Viewer).
Mac OS based PC
The Digital Viewer software can be launched by double clicking the Digital
Viewer icon from the Applications menu.
Focusing
Adjust the focus of the image manually by rotating the focusing ring.
Using the Digital Viewer software
The following buttons are available:
System settings menu
The first time the Digital Viewer is opened, the default settings will be loaded, you
may change these settings manually in the system settings menu.
Clicking this will open the system settings menu (see next
section).
Clicking this will capture the on screen image of the
device.
Clicking this will activate or deactivate the timed shot
feature. When activated, images will be captured at a
regular interval.
Clicking this will activate or deactivate the video recording
feature.
Clicking this will show the copyright and version
information of the application software.
Clicking this will shut down the application software.
Easi-Scope
6 7

Device setup
If the image captured by the Digital Microscope was not displayed by default,
you can change this by selecting it from the “Device” drop-down menu.
The resolution of images you capture can be changed from the “Resolution”
drop-down menu.
Timed shot setup
The frequency and duration of automatic images capture can be adjusted under
this option.
Movie setup
The resolution of videos you record can be changed from the “Resolution” menu.
You can also set a maximum file size for each video.
Save setting
The default location for captured images or videos can be changed under this
option.
Language setting
The language of the Digital Viewer software can be changed under this option.
Advanced settings
By clicking the “More...” button on the right of the system settings menu, you
will be able to manually adjust all of the image settings. Note that the settings
available may be different, depending on your operating system.
Saved files
With the Digital Viewer application software opened, you can locate the saved
files folder by clicking the “More...” button located on the left of the main software
window.
Full screen
To activate the full screen mode, click the full screen button located on the bottom
right hand corner of the Digital Viewer application software window.
To exit full screen mode, either double click on the screen, or press the “Esc”
button on the keyboard.
Uninstalling the Digital Viewer software
Windows based PC
Select “Uninstall Digital Viewer” from the start menu (Start > All Programs > Digital
Viewer > Uninstall Digital Viewer).
Mac OS based PC
Drag the Digital Viewer application icon from the “Applications” folder to “Trash”.
Legal information
This document is published without any warranty. While the information provided
is believed to be accurate, it may include errors or inaccuracies. In no event
shall the manufacturer or its distributors be liable for incidental or consequential
damages of any nature, including but not limited to loss of profits or commercial
loss, arising out of the use of the information in this document.
Intel is a trademark of Intel Corp. in the U.S. and other countries. Mac, Mac OS
and OS X are trademarks of Apple Inc., registered in the U.S. and other countries.
PowerPC™ and the PowerPC logo™ are trademarks of International Business
Machines Corporation, used under license therefrom. Windows is a registered
trademark of Microsoft Corporation in the United States and other countries.
