TTS Flexi-Scope User manual

Warranty & Support
This product is provided with a one year warranty for problems found
during normal usage. Mistreating the Flexi-Scope or opening the unit will
invalidate this warranty.
All out of warranty repairs will be subject to a replacement fee.
Technical Support
Please visit www.tts-group.co.uk for the latest product information.
Email [email protected] for technical support.
TTS Group Ltd.
Park Lane Business Park
Kirkby-in-Ashfield
Nottinghamshire,
NG17 9GU, UK.
Freephone: 0800 318686 Freefax: 0800 137525
Nxxxxx
N448
TTS Product Code:
EL00149
WARNING: Do not dispose of this product in
household waste. Hand it over to a collection
point for recycling electronic appliances.
WARNING! Not suitable for children under
36 months due to small parts – choking hazard.
Made in China, on behalf of the TTS Group Ltd.
Flexi-Scope

Take pictures and video
up to 200x magnification
Flexi-ScopeTM
USER GUIDE

Important Information
n Please retain these instructions for future reference
n Do not allow your Flexi-Scope to come into contact with water or
other liquids
n In the event of an electro-static discharge, your Flexi-Scope may
malfunction. In this case, you may need to disconnect from the
computer to reset it
n Warranty is void if the case is opened for any reason
n The warranty does not cover any data loss from the unit nor any
consequential loss of information
Bendy gooseneck
Focus Wheel
Photo Button
LED Lights
Exit Photo
Switch Socket
LED Lights
on/off

Flexi-Scope Controls
There are two buttons on the base of the Flexi-Scope:
Press the snapshot button to take a new picture.
Press the Light button to turn on the LEDs.
In addition to the camera button, Flexi-Scope has a 3.5mm mono jack
socket so that external switches can be used to take pictures.
To adjust the focus, rotate the
adjustment wheel slowly until the
image on the screen is displayed
clearly.
Flexi-ScopeTM

Using the Flexi-Scope software
Place CD into CD-ROM drive and follow steps shown on
screen, then reboot PC before you start the program.
Control Panel
Current image
Maximise Image
Saved Images
Click this icon to take a picture. Pictures taken will be
stored in the Folder “C\MyPic130” by default
Start video recording and choose the Video settings.
Videos will be stored in C\MyVideo130 by default.
Video settings
Allows the user to take pictures and video automatically
at set intervals
Click this icon to Exit the program
Click this icon to launch the “Flexi-Measure” application
To start the program, go to “Start” “Flexi-Scope”

Using the Flexi-Measure software
X & Y co-ordinates will be displayed.
Before measurement, you need to know
the Magnification reference number of
the captured images and enter it into
the magnification box”
Capture the image and read the
magnification reference number from
the focus wheel. Enter this figure into
the magnification box
Dimension Tools
Colour & font
Foot-Notes
Measurement
Settings
Flexi-ScopeTM

You can draw circle by moving the cursor to 3 points
Click this icon if you want to “undo’ your previous action
Click this icon to choose the colour of the line or circle you
want to show on screen.
You can add footnotes on photo. Click this icon & move
cursor to place where you want to add text; then input your
text in the blank text box.
D = Diameter R = Radius
A = Area C = Circumference

All captured images are saved in “C:\MyPic130” by default.
Opening a captured image will display the image on the
screen for measurement.
Click “Save” to save images to a location.
To email an image, Click “email” This will load your default
email program (* applicable for Microsoft Outlook only)
Click this icon to choose the footnote font size & colour
Click on this icon to enter the magnification reference (this
must be done before making measurements
Image Sensor 1.3Megapixels Colour Sensor
Resolution 1.3M pixel (1280 x 960)
Frame rate 30 fps
Magnification 10X - 200X
LED lamp 6 LED light for illumination
Lens high precision glass lens with filter
OS Support Windows XP / Vista
Interface High speed USB 2.0
Feature Specification
Settings
Technical specification
Flexi-ScopeTM
