Tube-Line Nitro 315RS User manual

39335 (07/08/2015)Operator’s Manual

Intentionally Left Blank

I - Nitro 375RS
Table of Contents
Operator’s Manual III
Warranty and Limitation of Liability ...........................................................III
Serial Number ...........................................................................IV
Specications ...........................................................................V
Principals of Operation ....................................................................VI
Section 1 - Safety 1-1
Safety Signal Words / Safety Messages ......................................................1-1
Safety Guidelines .......................................................................1-2
Lighting & Marking.......................................................................1-2
General Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
A Word To The Operator ..................................................................1-3
Equipment Safety Guidelines ..............................................................1-4
Safety Training. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
Safety Signs ...........................................................................1-5
How to Install Safety Signs ................................................................1-5
Safety Sign Locations ....................................................................1-6
Safety Decals ..........................................................................1-7
Safety Decals ..........................................................................1-8
Preparation Safety.......................................................................2-1
Hydraulic Requirements ..................................................................2-1
PTO / Horsepower Requirements ...........................................................2-1
Hook-up / Unhooking.....................................................................2-1
Section 2 - Operation 2-1
Tractor Preparation ......................................................................2-2
Spreader Preparation ....................................................................2-2
Before Using ...........................................................................2-2
After operating for 2 hours: ................................................................2-2
After operating for 10 hours: ...............................................................2-2
Operation Safety ........................................................................2-3
Pre-operation Checklist ...................................................................2-3
Loading ...............................................................................2-4
Unloading .............................................................................2-4
Travel Speed ...........................................................................2-5
Unplugging ............................................................................2-5
Storage and Cleaning ....................................................................2-5
Transport Safety ........................................................................3-1
Storage Safety..........................................................................3-1
Maintenance Safety......................................................................3-1
Section 3 - Transportation / Storage 3-1
Tire Safety .............................................................................4-1
Hydraulic Safety ........................................................................4-1
Section 4 - Troubleshooting / Maintenance 4-1
Fluids & Lubricants ......................................................................4-2
Greasing your Machine ...................................................................4-2

Nitro 375RS - II
Adjusting Apron Chain Tension .............................................................4-2
Every 10 Hours/Daily.....................................................................4-3
Every 10 Hours/Daily.....................................................................4-4
Every 10 Hours/Daily.....................................................................4-5
Section 5 - Parts Breakdowns & Lists 5-1
Front Components.......................................................................5-2
Front Shields ...........................................................................5-4
Front Apron Drive .......................................................................5-6
Driveline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-8
Side Shields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-10
Endgate ..............................................................................5-12
Rear Apron Drive .......................................................................5-14
Floor & Side Boards ....................................................................5-16
Beaters ..............................................................................5-18
Walking Beams ........................................................................5-20
Apron Runners ........................................................................5-22
Hydraulic Schematic ....................................................................5-24
Section 6 - Optional Features 6-1
Lights.................................................................................6-2
Manual Light KIt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
Hydraulic Light Kit .......................................................................6-5
Light Kit Hydraulics ......................................................................6-6
Light Kit Wiring Harness ..................................................................6-8
Flow Control Hydraulics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-10
Electric Flow Control Wiring ..............................................................6-12
Chain Drive Hydraulics ..................................................................6-14
Reversing the Apron Chain (with Optional Flow Control) ........................................6-14
Torque Value Chart - Imperial VII
Torque Value Chart - Metric VIII

III Operator’s Manual - Nitro 375RS
Operator’s Manual
Thank you for choosing the Tubeline 375RS Manure Spreader.
Our hope is that it will give you many years of productive service.
This machine is designed to wrap a continuous line of round bales in a lm of plastic.
Please read and understand this manual and the machine before operation.
Warranty and Limitation of Liability
All equipment is sold subject to mutual agreement that it is warranted by the company to be free from
defects of materials and workmanship. But the company shall not be liable for special, indirect or
consequential, damages of any kind under this contract or otherwise. The company’s liability shall be
limited exclusively to replacing or repairing without charge, at its factory or elsewhere, at its discretion.
Any material, or workmanship defects which become apparent within one year from the date on which
the equipment was purchased, and the company shall have no liability for damages of any kind. The
buyer by the acceptance of the equipment will assume all liability for any damages, which may result
from the use or misuse by his employees or others.
Warranty coverage is null and void unless Warranty
Registration form has been completely lled in and is on le at
Tubeline Manufacturing Ltd.

Nitro 375RS - Operator’s Manual IV
Serial Number
The implement serial number is located on the front of the frame.
This number helps us to track changes and improvements and must be mentioned
when ordering parts or requesting service. For your convenience, a space has been
provided inside the front cover of this manual to record the serial number,
model number, purchase date, and dealer name.
Model # : ____________________________
Serial # : ____________________________
Date Purchased : _____________________
Dealer Name : ________________________

V Operator’s Manual - Nitro 375RS
Specications
Nitro 375
Cu.ft. Struck 281’
Heaped Cu.ft 410’
Inside Width 62.5”
Inside Depth 34.5”
Inside Length 175”
Loading Height 74”
Overall Length 25’
Beater Diameter 34”
Beater Speed 420 RPM
Axle Type Tandem
Hub Capacity 12,000 lbs
PTO Speed 1000 RPM

Nitro 375RS - Operator’s Manual VI
Principals of Operation
The Nitro 375 RS Manure Spreader is designed to be hitched behind a tractor with a minimum of 90
HP. The Manure Spreader consists of a poly board oor trailer with an apron chain drag system, that
pulls material to the rear of the trailer, through a set of vertical, spinning beaters and is then spread in
an even pattern on the eld. The rear beaters are connected to the tractor’s PTO via gearboxes and
PTO drivelines. The variable speed apron chain is operated from the tractor cab, and controls the
speed of materials being fed through the beaters.
The apron chain and rear lift gate are operated using the tractor’s hydraulic power
outputs. The rear lift gate prevents material from jamming the beaters while loading,
as well as preventing material from falling onto a roadway during transport.
We recommend that you carefully read this entire manual before operating the Manure Spreader.
Please do not assume you know how to operate and maintain your machine before reading this man-
ual carefully. Keep this manual available for reference.
Call your authorized dealer if you need any assistance or more information.

1-1 Section 1 - Safety - Nitro 375RS
Section 1 - Safety
Take note! This safety alert symbol is found throughout this manual to call your
attention to instructions involving yourself and others working around the machine.
Failure to follow these instructions can result in injury or death!
This symbol means
- Attention!
Become Alert!
Your Safety is involved!
Safety Signal Words / Safety Messages
Caution: Indicates a potentially hazardous situation that may result in injury.
Warning: Indicates a potentially hazardous situation that could result is serious
injury or death.
Danger: Indicates a hazardous situation that needs to be avoided. It is you the
operator that needs to be aware of these dangers.
If you have any questions not answered in this manual, please contact your
dealer or Tubeline Manufacturing Ltd.
You can also check for a newer manual version at www.tubeline.ca/support
6455 Reid Woods Drive,
R. R. #4 Elmira
Ontario, Canada
N3B 2Z3
Email : [email protected]
Fax : [phone]
Tel : [phone]

Nitro 375RS - Section 1 - Safety 1-2
Safety Guidelines
Safety of the operator is one of our main concerns, however we do hear of some accidents that could
have been avoided if some precautions had been taken. To avoid personal injury study the following
precautions and insist those working with you or for you, follow them.
In most cases the pictures will have the shielding in place, in some they may be removed, only to
show a view behind the shield. Keep all the shields, safety doors in place. If they become faulty and
fail to work replace them. They are for your safety, do not operate the equipment with them removed.
Replace any decals that may be missing or that are not readable. Location of the decals is indicated
in this manual.
Do not operate this machine while under the inuence of drugs or alcohol.
Review the safety instructions with all users annually.
This equipment should not be operated by children, or with those unfamiliar with the operation of the
machine. Do not allow persons to operate this machine until they have read this manual and/or were
instructed by a qualied person.
Do not paint over, remove or deface any safety signs or warning decals on your equipment. Observe
all safety signs and practice the instructions on them.
If the bale seems to be larger then the hoop do not try to force the material through as the lm spools
may touch the bale and break the plastic. If is stalls halfway through you can’t back up, you will have
to pull the bale apart by hand.
Lighting & Marking
This machine is equipped with lights and reectors as required by the most stringent government and
ASAE specications. They should work with the tractor 7-pin connector.
