Tuffy 050 User manual

Page 1 of 2 - 1/28/2008 – Rev122006
INSTALLATION INSTRUCTIONS
XJ Security Console Part # 050
Please read and fill out the enclosed warranty registration card to activate your warranty.
Tools Needed
Marking Pencil or Pen
½ ” Socket and Ratchet
½ ” Wrench
5/16” Wrench
3/8 ” Wrench
Drill and 3/8” drill bit (1/8” bit recommended for pilot hole)
Shipping Package
(3)5/16 x 1 ¼” Grade 8 Bolts (2) 10-32 Unslotted Machine screws
(3) 5/16” Locknuts (2)10-32 Locknuts (6)5/16” Washers (4)#10 Washers (2) Hole Plugs
Mounting Directions
1. Pull the emergency brake all the way up and place the console between the seats in
the position desired.
2. Mark the floor directly under the (3) 3/8” mounting holes.
3. Remove the console, cut holes in the carpet where the marks are and drill a 3/8”
hole in each marked spot. Warning, failure to cut the carpet out of the way may
cause the drill bit to snag the carpet and pull a thread.

Page 2 of 2 - 1/28/2008 – Rev122006
4. Fasten down the rear of the console using (3) 5/16 x 1 ¼” bolts, (3) 5/16 locknuts,
and (6) 5/16” washers.
5. Attach the drink holder to the rear of the console in either the upper or lower
mounting holes using (2) 10-32x ½” screws, (2) #10 locknuts, and (4) #10 washers.
6. Insert (2) ¼” hole plugs into the drink holder mounting holes not used.
7. Apply neoprene seal as instructed on next page.
8. Check lock operation.
Call [phone] for Technical Support
