Installation and Operation Manual
E 3 5 D 6
C o n v e c t i o n O v e n
The reproduction or copying of any part of this manual by any means whatsoever is strictly forbidden unless authorized previously in writing
by the manufacturer.
In line with policy to continually develop and improve its products, Moffat Ltd. reserves the right to change the specifications and design
without prior notice.
© Copyright Moffat Ltd. March 2017.
Moffat Limited
Rolleston 7675
New Zealand
AUSTRALIA
Moffat Pty Limited
E.Mail: vsales@moffat.com.au
Main Office: (tel): +61 (03) 9518 3888
(fax): +61 (03 9518 3833
Service: (tel): 1800 622 216
Spares: (tel): 1800 337 963
Customer Service: (tel): 1800 335 315
(fax): 1800 350 281
CANADA
Serve Canada
Web: www.servecanada.com
E.Mail: info@servecanada.com
Sales: (tel): 800 551 8795 (Toll Free)
Service: (tel): 800 263 1455 (Toll Free)
NEW ZEALAND
Moffat Limited
Web:www.moffat.co.nz
E.Mail: sales@moffat.co.nz
Main Office: (tel): 0800 663328
UNITED KINGDOM
Blue Seal
Web: www.blue-seal.co.uk
E.Mail: sales@blue-seal.co.uk
Sales: (tel): +44 121 327 5575
(fax): +44 121 327 9711
Spares: (tel): +44 121 322 6640
(fax): +44 121 327 9201
Service: (tel): +44 121 322 6644
(fax): +44 121 327 6257
UNITED STATES
Moffat
Web: www.moffat.com
Sales: (tel): 1-800 551 8795 (Toll Free)
(tel): 336 661 1556
(fax): 336 661 9546
Service: (tel): 866 673 7937 (Toll Free)
REST OF WORLD
Moffat Limited
Web:www.moffat.co.nz
E.Mail: expo[email protected]
Contents List
Safety Information
Installation Requirements
Unpacking
Location
Clearances
Stand Mounted Ovens
Electrical Connection
Water Connection
Recommended Water Specifications
Positioning and Levelling of Oven
Initial Start-Up
Commissioning
Operation Guide
Baking in Manual Mode
Cooking in Manual Mode using Core Temp Probe
Baking in Program Mode
Programs
Parameters
Programs Revision Numbering
Files
Changing Operator Settings
Operator Settings
Cleaning Guidelines
Oven Cleaning
Periodic Maintenance
Introduction
2
Before using your new oven, please read this instruction manual
carefully, pay particular attention to any information labelled
‘WARNING’, ‘CAUTION’, ‘IMPORTANT’ or ‘NOTE’ in this manual.
Indicates a hazardous situation
which, if not avoided, will result in
death or serious injury.
Indicates a hazardous situation
which, if not avoided, will result in
minor or moderate injury.
If you are unsure of any aspect of the installation, instructions or
performance of your oven, contact your TURBOFAN dealer promptly.
In many cases a phone call could answer your question.
Should you contact your TURBOFAN dealer on any matter concerning
this oven, please have the information provided opposite, readily
available.
This manual must be kept by the owner for future reference.
A record of
Date of Purchase,
Date of Installation
and
Serial
Number of the oven
should be recorded in the area provided
below.
The serial number of this oven can be found on the
Technical Data Plate located on the front right hand side
panel, see diagram in ‘Installation Section’.
For your safety, please pay attention to the following symbols
marked on the appliance.
- Risk of electric shock.
No user serviceable parts inside.
Qualified service person access only.
Disconnect from power before servicing.
Specifications
3
USA / Canada / Mexico
Model Voltage Frequency Phase Amps Electrical Rating
E35D6-**-T263 220-240V 60 Hz 3P+E 30.3 12.5kW @ 240V
E35D6-**-P263 208V 60 Hz 3P+E 31.1 11.2kW @ 208V
E35D6-**-T261 220-240V 60 Hz 1P+N+E 52.0 12.5 kW @ 240V
E35D6-**-P261 208V 60 Hz 1P+N+E 53.7 11.2 kW @ 208V
Australia / New Zealand / UK
Model Voltage Frequency Phase Amps Electrical Rating
E35D6-**453 400-415V 50 Hz 3P+N+E 17.4 12.5kW @ 415V
E358D6-**-453 400-415V 50 Hz 3P+N+E 11.1 8.0kW @ 415V
E35D6H-**-453 400-415V 50 Hz 3P+N+E 18.3 / 17.4 / 17.4 12.7kW @ 415V
E35D6-**-251 230-240V 50 Hz 1P+N+E 52.0 12.5 kW @ 240V
E35D6H-**-251 230-240V 50 Hz 1P+N+E 52.9 12.7 kW @ 240V
International
Model Voltage Frequency Phase Amps Electrical Rating
E35D6-**-353 380V 50 Hz 3P+N+E 18.9 12.5kW @ 380V
E35D6-**-363 380V 60 Hz 3P+N+E 18.9 12.5kW @ 380V
E35D6-**-P263 208-220V 60 Hz 3P+E 32.8 12.5kW @ 220V
E35D6-**-T263 230-240V 60 Hz 3P+E 30.1 12.5kW @ 240V
E35D6-**-P253 208-220V 50 Hz 3P+E 32.8 12.5kW @ 220V
E35D6-**-T253 230-240V 50 Hz 3P+E 32.8 12.5kW @ 240V
Specifications
4
Oven Tray Details
Tray Capacity Qty 6, 460 x 660mm / 18” x 26”, Full Size Sheet Pan Capacity.
Tray Spacing 105mm / 4⅛”.
Water Connection
Max Water Inlet Pressure 80 psi / 550 kPa.
Connection Size 3/4” BSP Male.
NOTE: If the bake Steam / Moisture Mode baking option is not required, the oven does not need to be connected to a
water supply.
Specifications
5
Oven Tray Details
Tray Capacity Qty 6, 460 x 762mm / 18” x 30”, Tray Capacity.
Tray Spacing 105mm / 4⅛”.
Water Connection
Max Water Inlet Pressure 80 psi / 550 kPa.
Connection Size 3/4” BSP Male.
NOTE: If the bake Steam / Moisture Mode baking option is not required, the oven does not need to be connected to a
water supply.
Installation
6
1. Remove all packaging and transit protection including all
protective plastic coating from the exterior stainless steel
panels.
2. Check the oven and supplied parts for damage. Report any
damage immediately to the carrier and distributor.
3. Check that the following parts have been supplied with your
oven:-
4 x Leg Adjustable.
Brass Adaptor.
Rubber Washer.
4. Report any deficiencies to the distributor who supplied your
oven.
5. Securely fit the 4 legs supplied with the oven.
6. Check that the available electrical supply is correct to that
shown on the Technical Data Plate located on the front right
hand side panel.
 Also refer to the ‘Specifications’ section, ‘Oven
Specifications Tables’ for further details.
1. Position the oven in its approximate working position.
2. The unit should be positioned so that the control panel and
oven shelves are easily reachable for loading and unloading.
NOTE: The oven door can be reversed to increase
accessibility in certain locations. Refer to Appendix 1
at the rear of this Manual for door reversal details.
To ensure correct ventilation for the motor and controls, the
following minimum installation clearances are to be adhered to:-
Rear 50mm / 2”.
Left-hand side 50mm / 2”.
Right-hand side 50mm / 2”.
CLEARANCE FROM SOURCE OF HEAT.
A minimum distance of 300mm (12”) from appliance sides
is required.
NOTE: Fixed installations require at least 500mm - 20”
clearance at the right hand side of oven for service
access.
For stand mounted ovens, the oven feet are used to level the oven
on the stand. Refer to the instructions supplied with separately
ordered stands for mounting details.
The vent located on the top of the oven must NOT be
obstructed.
 Installation shall comply with local electrical, health and safety requirements.
 It is most important that this oven is installed correctly and that oven operation is correct before use.
 If you have any questions regarding the proper installation and / or operation of this oven, please contact your local
Turbofan distributor.
Technical Data Plate Location
Oven Vent Location
USA / Canada / Mexico Only.
Installation
7
1. The side racks can be fitted in one of two positions, in order to
take 16 or 18 inch trays.
2. To position racks for 16 inch trays, use the holes at the rear of
the rack.
3. Alternatively for 18 inch trays, use the holes nearest the centre
of the oven.
RCD (Residual Current Device) / GFCI (Ground-Fault Circuit-
Interrupter) protection of the power supply to this appliance is rec-
ommended.
Each oven should be connected to an adequately protected power
supply with an appropriate power cord.
An isolation switch must be mounted adjacent to, but not behind
the oven and must be readily accessible to the operator. This
switch must be clearly marked and readily accessible in case of fire.
Check the electricity supply is correct to as shown on the Technical
Data Plate on the front right hand corner of the oven side panel.
NOTE: All electrical connections must only be carried out by
a suitably qualified person.
1. Remove oven right hand side panel.
2. Bring the supply cable up through the cable entry point -
compression gland at the back of oven.
3. Connect the supply cable to the appropriately marked terminals
on the terminal block.
16 inch tray
locator
18 inch tray
locator
This oven must be earthed / grounded.
NOTE: Water connection shall be installed in accordance
with local water regulations in force and the applica-
ble standard / code, e.g.: PCA in Australia, EN 1717 in
UK / IE.
NOTE: If the Bake Steam / Moisture Mode is not required, the
oven does not require connecting to a water supply.
1. Connect a cold water supply
to the water inlet (R ¾”
Connector) on the oven.
NOTE:
For North America / Canada /
Mexico, use supplied ¾” GHT
Brass Adaptor when making
water connection to the oven.
- Max Inlet Pressure 80psi / 550kPa.
2. Turn ‘On’ the water supply and check for leaks.
In order to prevent corrosion or scaling in the oven and water
system due to supplying water that is either too soft or too hard,
the following recommendations should be used as a guideline.
Hardness: Between 60 and 90ppm.
PH: Greater than 7.5.
Chlorides: Less than 30 ppm.
1. Correctly locate the oven into its final operating position and,
using a spirit level, adjust the oven feet so that the oven is level
and at the correct height.
Before using the new oven;
1. For first time use of the oven, operate the oven for about 1
hour at 200°C / 400°F to remove any fumes or odours which
may be present.
2. Please refer to the Operation Section of this manual for details
on how to correctly operate and shutdown the oven.
Before leaving the new installation;
1. Check the oven functions in accordance with the operating
instructions specified in the ‘Operation’ section of this manual.
2. Ensure that the operator has been instructed in the areas of
correct operation and shutdown procedure for the appliance.
NOTE: If it is not possible to get the appliance to operate
correctly, turn ‘Off’ power supply at the mains supply
and contact the supplier of this appliance.
Water
Connection
Cable Entry Point -
Compression Gland
Terminal
Block
Operation
8
 This oven is intended for use in a commercial kitchen and must only be put to the use for which it was designed, i.e. baking food
Temperature Display -
Shows pre-set chamber temperature.
When used with the ‘Temp’ key, display shows
actual oven temperature for 5 seconds.
Shows baking programs and error codes.
‘Steam’ Key and LED -
Used to set / initiate steam injection
time (Bake Steam Mode).
LED is ‘On’ when steam is injecting.
Used to set automatic moisture level (Moisture
Mode).
LED is ‘On’ when automatic moisture injection is
set.
Temperature Adjustment Control
Time Display - e.g. 1.25 minutes.
Shows cook time in full minutes only
from 180 - 10, and in minutes and seconds for
the final 10 minutes.
NOTE:
In Core Temp Mode, time display alternates
between ‘CP’ and set core probe
temperature.
‘Vent’ Key and LED -
Opens or closes the oven vent.
LED is ‘Flashing’ when vent is
open.
LED is ‘Off’ when vent is closed.
Time Adjustment Control
NOTE: In Core Temp Mode, ‘Timer’ knob is
used to set core probe temperature.
‘On / Off’ (Stand-by) Control
‘Program’ Key and LED -
Used to enter/exit Manual and
Program Modes.
Used to select baking programs, and
to set baking parameters.
‘Temp’ Key and LED -
Displays actual oven temperature for 5
seconds on Temperature Display.
LED is ‘On’ when heating element is on
(heating indicator).
LED flashes when Upper Display is showing
actual temperature.
NOTE:
In Core Temp Mode, this key is used to
display Actual Oven Temperature (Upper
Display) and actual Core Probe Temperature
(Lower Display).
‘Stand-By Indicator LED -
LED is ‘On’ when mains power is supplied to the
oven, but ’On/Off’ switch is ’Off’.
‘Fan Lo’ Speed Key and LED -
Switches oven fan from high to low
speed.
LED is ‘On’ when fan is in Low Speed
Mode.
When LED is ‘Off’, fan is in High Speed Mode.
‘Timer-Start/Stop’ Key & LED -
The ‘Timer-Start/Stop’ key is used to
control the following functions:-
 Starting Timer / Program.
 Cancelling and Re-Setting Timer /
Program.
 Cancelling Alarm (All Modes).
 Starting Core Temp Mode (Core Temp
Mode).
Core Probe Connection Point.
