Turner Hastings MA601HTR-CH User manual

Heated Towel Rail
Installation Guide
Please read these instructions carefully before installation.
Installation should be carried out by a qualified electrician.

Contents
What’s in the box?
Installation
Technical Specifications
Safety & Care Information
Warranty Information
Contact Us
3
4
5
6
7
8

What’s in the box?
• Turner Hastings Liquid Filled Towel Rail/Radiator prefilled with legs and wiring
attached
• 4 pcs Wall Flange
• 12 pcs Mounting screw
• 12 pcs Wall plug
• 6 pcs Grub/Set Screw
• 12 pcs Screw Cap Holder
• 12 pcs Screw Cap
• Allen Key
Check you’ve got everything:
• Cross Head Screwdriver
• Pencil
• Spirit Level
• Tape Measure
• Hammer
• Drill Bits (10mm & 3mm)
• Cordless Drill
• Electrical Supply
You will also need:
3

4. Connect to Main Supply
4
Installation
F
1- Pass the wall mounting screws
(C) through the screw cap holders
(F).
2- Place your radiator on the wall
and screw the mounting brackets
all the way into the wall with the
help of a screwdriver.
3- Attach the screw caps (G) to the
screw cap holders (F) on the wall
mounting brackets.
1- Place your radiator into the wall
mounting brackets.
2- Insert the setscrews (E) into the
slots on the mounting brackets and
your radiator then tighten the
setscrews by using an Allen key
(M3).
35
1
1
2
2
1- Drill holes (Ø 10 mm) into the
spots you have marked.
2- Nail the wall plugs (D) in the
holes by using a hammer.
1
2
32
90°
1- Adjust the height of your
radiator by using a metric
ruler.
2- Set the location of your
radiator as desired, align with
the ground by using a spirit
level and mark the position of
the wall mounting brackets.
1
2
12
Ensure the mains power supply is switched off before
attempting to carry out any electrical work. The wiring
for the rail must be at the bottom right of the rail (The
rails cannot be mounted upside down). We recommend
the rail is connected to a timer for more efficient control.
Connect the towel rail lead to the mains supply in
accordance with current electrical regulations and to
AS-NZS3000 Wiring Rules.

Technical Specications
SIZE (MM)
NO. OF BARS OUTPUT (W) IP RATINGSTOCK CODE
MA601HTR-CH
MA602HTR-BB
MA603HTR-BN
5
5
5
W600 x H800 x D122
W600 x H800 x D122
W600 x H800 x D122
300
300
300
IP44
IP44
IP44
Supply Voltage
Wiring Side
Wiring Method
Warranty on Rails
Warranty on Timer
Warranty on Finish
230-240V 50Hz
Bottom Right Only
Hardwired
10 Years
2 Years
5 Years
5

Exposed Wiring Installation GuideSafety & Care Information
Turner Hastings Heated Towel Rails should be inspected before installation for any
defects, only then installed and tested by a qualified electrician and in accordance
with current local regulations. WARNING: In order to avoid a hazard for very young
children, this appliance should be installed so that the lowest heated rail is at least
600 mm above the floor and with a 300mm clearance from permanent fixture.
Where possible the Turner Hastings Heated Towel Rail should be screwed into studs
or battons concealed in the wall.
Please read and understand this installation guide in full before commencing
installation. If you have any queries in regards to installation, please call 1300 00
2284.
• Observe and adhere to electrical guidelines AS-NZS3000 Wiring Rules and IP
ratings when placing your towel rail in wet areas
• Ensure any timers or switches used are installed in correct zones according to the
IP rating of the timer/switch
• Means for disconnection must be incorporated in the fixed wiring in accordance
with the wiring rules, ensure that your towel rail is connected by a suitably rated
RCD circuit
• Do not use the towel rail to hold towels or other articles that have been in contact
with oil, petroleum based products or dry cleaning fluids
• This appliance is intended to warm and dry towels and therefore is hot to touch.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
• Do not immerse your towel rail in any liquid
Safety Information
The finish of your Turner Hastings Heated Towel Rail is hard wearing and easy to
maintain. However any harsh scrubbing, scratching or acid based cleaning
products will damage the surface of your towel rail. Cleaning with a soft cloth and a
non-abrasive cleaning agent will give the best results.
Care Information
6

Warranty Information
Turner Hastings covers all its products with a satisfaction guarantee. In addition, Turner
Hastings will supply a replacement product where a fault is shown to be caused by
manufacture, materials or workmanship providing the goods have been installed
correctly and according to installation instructions. This guarantee does not include
removal, freight or installation costs. Turner Hastings’ products come with guarantees
that cannot be excluded under Australian Consumer Law and you are entitled to a
replacement or refund for a major failure & compensation for any other reasonable
foreseeable loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does not amount
to a major failure.
All of the Turner Hastings Towel Rails have a 10 year warranty, the timer has a 2 year
warranty and the finish has a 5 year warranty. To use the warranty, repair or service
the customer must provide purchase invoice/receipt.
If the product develops a fault within the warranty period due to normal wear and
tear, Turner Hastings at its discretion will recognise whether it’s a faulty product or not.
If it is impossible or not economical for the manufacturer to repair the product, the
manufacturer will replace the faulty product with a new unit of the same model or if
there is no stock available of the same model as the product, the manufacturer will
replace the product with a new unit of a similar size. No responsibility can be taken
for altered dimensions and lining up of existing holes.
The repair service offered within the warranty period only covers the faults and
problems as developed from the manufacturer’s errors. Any damage caused by
improper use or carelessness or incorrect wiring is not covered.
Turner Hastings is not responsible for any monetary loss or injuries caused by
improper use of this product.
7

Contact Us
[e-mail]
Phone: [phone]
www.turnerhastings.com.au
