TV One CC-300 CORIOconsole User manual

CC-300
CORIOconsole
Operation Manual
Version 1.4

CC-300
CORIOconsole
Operation Manual
Version 1.4
99 Washington Street
Melrose, MA 02176
Phone [phone]
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com

CC-300 CORIOconsole Operation Manual
3
Table of Contents
1.0 Disclaimer..................................................................................................4
1.1 Regulatory Agency Acceptance...........................................................................4
1.2 FCC Statement....................................................................................................4
2.0 IMPORTANT SAFETY INSTRUCTIONS...................................................6
3.0 CAPABILITY, TERMS OF REFERENCE AND OVERVIEW SUMMARY.16
3.1 Device Capabilities............................................................................................16
4.0 UNPACKING AND INSTALLATION.........................................................17
4.1 Shipping Carton.................................................................................................17
4.2 Furnished Accessories.......................................................................................17
5.0 FUNCTIONAL CHECK ............................................................................18
5.1 Important Safety Instructions .............................................................................18
5.2 Factory Reset ....................................................................................................19
5.3 Initial Operation Check Using Factory Default Settings......................................19
5.4 Manual configuration of connection....................................................................22
5.5 Auto IP Detection...............................................................................................24
5.6 Calypso controller configuration.........................................................................24
5.7 Locking the keyboard.........................................................................................27
5.8 Standby mode ...................................................................................................27
5.9 Connection problems?.......................................................................................28
6.0 CC-300 IN OPERATION..........................................................................30
6.1 Navigation..........................................................................................................30
7.0 RETURN PROCEDURE..........................................................................31
7.1 To return a unit for repair...................................................................................31
7.2 TECHNICAL SUPPORT....................................................................................32
8.0 WARRANTY POLICY ..............................................................................33
9.0 Connector pinouts....................................................................................34
9.1 Ethernet connector ............................................................................................34
9.1.1 Straight through cable........................................................................................34
9.1.2 Crossover cable.................................................................................................34
9.2 Power connector................................................................................................34
9.3 RS232 / DB9 connector.....................................................................................34
10.0 Specification ............................................................................................35
10.1 Control Methods ................................................................................................35
10.2 Mechanical ........................................................................................................35

CC-300 CORIOconsole Operation Manual
2
10.3 Environmental....................................................................................................35

CC-300 CORIOconsole Operation Manual
4
1.0 DISCLAIMER
This product is intended for professional and/or home use. This product is not
intended for use in a medical environment and does not have the required
certifications for such use. Similarly, use aboard any aircraft or spacecraft
while in flight or as an adjunct to any surface, airborne or marine navigation
system or any offshore marine activity, including control of any watercraft, or
any use similar to those specifically herein mentioned is prohibited. Use in the
aforementioned circumstances would require additional testing and
certification.
You have not become the owner of any software - you have merely
purchased the right to use the software. You may make one copy of the
software for your own use. Other copies will be deemed a breach of copyright.
No warranty is made either expressed or implied including but not limited to
any implied warranties of merchantability or fitness for a particular purpose. In
no event shall the supplier or manufacturer of this product be liable for errors
found within, or be liable for any direct, indirect or consequential damages or
loss in connection with the purchase or use of this hardware software or
manual. The sole and exclusive liability to the supplier and manufacturer
regardless of the form of action shall not exceed the replacement cost of the
materials described herein.
By using this equipment you have indicated that you have agreed to the terms
listed above. If you do not wish to agree or the above terms are contrary to
your conditions of purchase you may return the equipment, unused, to your
supplier. All trademarks and copyrights are acknowledged. E&OE.
1.1 Regulatory Agency Acceptance
European ‘CE’ Mark Statement
Emissions: BS EN 61000-6-1:2001 (Generic Immunity Standard for
Residential, Commercial and Light Industrial)
Immunity: BS EN 61000-6-3:2001 (Generic Immunity Standard for
Residential, Commercial and Light Industrial)
1.2 FCC Statement
Class A Device: This equipment has been tested and found to comply with
the limits for a Class A digital device pursuant to Part 15 of the FCC Rules.
These limits are designed to provide a reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the Instruction Manual, may cause
harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.

CC-300 CORIOconsole Operation Manual
5
Caution: This equipment is intended for use in the manner prescribed in the
Instruction Manual. Any user changes or modifications not expressly
approved by TV One Multimedia Solutions could void the user’s authority to
operate the equipment. Connecting this equipment to external devices
requires no specially shielded cabling for FCC compliance. The Instruction
Manual shows or describes the proper connection of this equipment for
operation that insures FCC compliance.
Direct all inquiries regarding FCC compliance to:
TV One Multimedia Solutions
1350 Jamike Drive
Erlanger, KY 41018
859.282.7303
859.282.8225 (Fax)
Manual Version Information
Version: 1.4
Release Date: December, 2007
Manual Copyright Notice
This Operation Manual is the intellectual property of TV One, ©2006. No
portion of this manual may be copied or reproduced in any manner or by any
means, including, but not limited to electronic and electro-mechanical, without
the express written permission of TV One.
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
FAX [phone] - TestEquipmentDepot.com

CC-300 CORIOconsole Operation Manual
6
2.0 IMPORTANT SAFETY INSTRUCTIONS
To insure the best from this product, please read this manual carefully. Keep
it in a safe place for future reference.
To reduce the risk of electric shock, do not remove the cover from the unit.
No user serviceable parts inside. Refer servicing to qualified personnel.
2.1 Power and connections
This unit is not disconnected from the AC power source as long as it is
connected to the wall outlet. The off state for this unit is called standby mode.
In standby mode the unit is designed to consume a reduced quantity of power
compared to normal operating modes.
When not using the unit for a long period of time, insure that the AC power
cord is disconnected from the wall outlet.
The AC wall outlet should be installed near to the unit and be easily
accessible.
Do not plug in or attempt to operate an obviously damaged unit.
2.2 Water and moisture
To reduce the risk of fire and personal injury, operation of this device outdoors
and/or exposure to rain, water or excessive moisture is expressly prohibited.
The apparatus shall not be exposed to dripping or splashing and no objects
filled with liquids, such as vases, shall be placed on the apparatus.
2.3 General care
Do not force switches or external connections.
When moving the unit, disconnect the serial port connections first then the
power cable and finally the interconnecting cables to other devices.
Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as
this may damage the unit. Use a clean dry cloth.
2.4 Location
Installation of this unit should be in a cool dry place, away from sources of
excessive heat, vibration, dust, moisture and cold.

CC-300 CORIOconsole Operation Manual
7
2.5 Intellectual property
Some IC chips in this product include confidential and/or trade secret
property. Therefore you may not copy, modify, adapt, translate, distribute,
reverse engineer, reverse assemble or decompile the contents thereof.

CC-300 CORIOconsole Operation Manual
8
2.0 IMPORTANT: CONSIGNES DE SECURITE
Afin de tirer le meilleur de ce produit, merci de lire attentivement ce manuel.
Gardez-le dans un endroit sûr pour pouvoir le consulter à nouveau.
Afin de réduire le risque de choc électrique, ne retirez pas l’unité de sa
protection.
Aucune pièce réparable par l’utilisateur à l’intérieur. Référez-vous à des
personnes qualifiées.
2.1 Alimentation électrique et connexions
Cette unité n’est pas déconnectée de la source de courant électrique tant
qu’elle est connectée à la prise murale. Le mode éteint de cette unité est
appelé mode de veille. En mode de veille, cette unité est conçue pour
consommer une quantité réduite de courant par rapport aux modes normaux
d’utilisation.
Lorsque vous n’utilisez pas l’unité pendant une longue période, assurez-vous
que le câble d’alimentation électrique est déconnecté de la prise murale.
La prise murale de courant doit être installée près de l’unité et aisément
accessible.
Ne branchez pas et n’essayez pas d’utiliser une unité visiblement
endommagée.
2.2 Eau et humidité
Pour réduire les risques d’incendie et de dommages corporels, l’utilisation de
cet appareil à l’extérieur et/ou son exposition à la pluie, l’eau ou une humidité
excessive est expressément interdite.
L’appareil ne doit pas être exposé aux gouttes ou aux éclaboussures et aucun
objet contenant de l’eau, comme par exemple un vase, ne doit être posé sur
l’appareil.

CC-300 CORIOconsole Operation Manual
9
2.3 Entretien général
Ne forcez pas les boutons ou connexions externes.
Lorsque vous déplacez l’unité, déconnectez d’abord les connexions de ports
en série puis le câble d’alimentation et enfin les câbles de connexion avec
d’autres appareils.
N’essayez pas de nettoyer l’unité avec des dissolvants chimiques ou des
produits nettoyants en aérosol, car cela peut endommager l’unité. Utilisez un
chiffon propre et sec.
2.4 Emplacement
L’installation de cette unité doit se faire dans un endroit frais et sec, éloigné
de sources excessives de chaleur, de vibrations, de poussière, d’humidité et
de froid.
2.5 Propriété intellectuelle
Certaines puces IC dans ce produit contiennent des éléments propriétaires
confidentiels et/ou des secrets commerciaux. Vous ne devez donc pas copier,
modifier, adapter, traduire, distribuer, démonter, désassembler, ou
décomposer leur contenu.

CC-300 CORIOconsole Operation Manual
10
2.0 INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Para sacar el mejor provecho de este producto, léase este manual con
detenimiento. Guárdelo en un lugar seguro para poder hacerle referencia en
el futuro.
Para reducir el riesgo de calambre, no quite la cubierta del aparato.
No hay piezas utilizables dentro. Remítase todo mantenimiento a personal
cualificado.
2.1 Corriente y conexiones
Mientras esté conectada a una toma de electricidad, el aparato seguirá
conectado a la fuente de corriente CA. A la posición de «off» de este aparato
se le denomina posición de espera. En la posición de espera, el aparato está
diseñado a consumir una cantidad reducida de electricidad en comparación
con los modos de operación normales.
Asegúrese de desconectar el cable de corriente CA de la toma de la pared
cuando no va a utilizar el aparato por un periodo largo de tiempo.
La toma CA de la pared ha de estar instalada cerca del aparato y debe ser
fácilmente accesible.
No enchufe ni intente operar un aparato que esté evidentemente dañado.
2.2 Agua y humedad
Para reducir el riesgo de fuego o de daños personales, se prohíbe la
utilización de este aparato en el exterior y/o su exposición a la lluvia, al agua
o a atmósferas de excesiva humedad.
El aparato no debe situarse cerca de zonas en las que haya riesgo de goteo
o salpicaduras. Tampoco deben colocarse objetos que contengan agua
(jarrones, por ejemplo) en el mismo.

CC-300 CORIOconsole Operation Manual
11
2.3 Cuidado general
No forzar interruptores o conexiones externas.
Al mover el aparato, desconecte las conexiones del puerto en serie primero,
luego el cable de electricidad y finalmente los cables interconectados a otros
aparatos.
No intente limpiar el aparato con disolventes químicos o productos de
limpieza aerosol, ya que podrían dañar el aparato. Utiliza un paño limpio y
seco.
2.4 Ubicación
Este aparato se debe instalar en un lugar seco y fresco, lejos de fuentes de
calor excesivas, la vibración, el polvo, la humedad y el frío.
2.5 Propiedad intelectual
Algunos chips con circuito integrado de este producto incluyen propiedad
confidencial y/o propiedad de secreto comercial. Por lo tanto queda prohibido
copiar, modificar, adaptar, traducir, distribuir, usar técnicas retroactivas,
desmontar, o recopilar los contenidos del mismo.

CC-300 CORIOconsole Operation Manual
12
2.0 WICHTIGE SICHERHEITSVORSCHRIFTEN
Lesen Sie diese Bedienungsanleitung bitte sorgfältig, um Ihr Produkt optimal
nützen zu können, und bewahren Sie sie zum späteren Nachschlagen an
einem sicheren Ort auf.
Entfernen Sie bitte keinesfalls die Abdeckung, um der Gefahr eines
Stromschlags vorzubeugen.
Im Inneren des Geräts befinden sich keine Teile, die vom Benutzer gewartet
werden können. Lassen Sie Wartungsarbeiten nur von Fachpersonal
durchführen.
2.1 Stromversorgung und anschlüsse
Solange das Gerät mit einer Steckdose verbunden ist, bleibt die
Stromversorgung aufrecht. Der Ausschaltzustand des Geräts wird als
Standbymodus bezeichnet. Im Standbymodus verbraucht das Gerät weniger
Strom als in den üblichen Betriebsarten.
Wird das Gerät über einen längeren Zeitraum hinweg nicht verwendet, ziehen
Sie bitte das Stromkabel aus der Steckdose.
Die Steckdose sollte sich in der Nähe des Geräts befinden und leicht
zugänglich sein.
Verbinden Sie ein offensichtlich beschädigtes Gerät keinesfalls mit einer
Steckdose und versuchen Sie auch nicht, es zu bedienen.
2.2 Wasser und feuchtigkeit
Um die Gefahr eines Brandes oder einer Körperverletzung zu verringern, ist
es ausdrücklich verboten, dieses Gerät im Freien in Betrieb zu nehmen
und/oder es Regen, Wasser oder hoher Feuchtigkeit auszusetzen.
Das Gerät darf keinen Tropfen oder Spritzern ausgesetzt werden und es
dürfen keine mit Flüssigkeiten gefüllte Behälter, wie Vasen, auf das Gerät
gestellt werden.

CC-300 CORIOconsole Operation Manual
13
2.3 Allgemeine pflege
Wenden Sie bei der Handhabung von Schaltern und Anschlüssen keine
Gewalt an.
Beim Umstellen des Geräts entfernen Sie zuerst die seriellen Anschlüsse,
dann das Stromkabel und zum Schluss die Verbindungskabel zu anderen
Geräten.
Versuchen Sie keinesfalls, das Gerät mit chemischen Lösungsmitteln oder
Sprayreinigern zu reinigen, da dies das Gerät beschädigen könnte.
Verwenden Sie ein sauberes, trockenes Tuch.
2.4 Aufstellung
Das Gerät sollte an einem kühlen, trockenen Ort aufgestellt werden, fern von
übermäßiger Wärme, Vibrationen, Staub, Feuchtigkeit und Kälte.
2.5 Gewerbliches eigentum
Einige integrierte Schaltkreise in diesem Produkt enthalten vertrauliche
Informationen und/oder Betriebsgeheimnisse. Sie dürfen daher diese Inhalte
nicht kopieren, modifizieren, adaptieren, übersetzen, verteilen,
rückentwickeln, rückassemblieren oder dekompilieren.

CC-300 CORIOconsole Operation Manual
14
2.0 BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Lees deze handleiding zorgvuldig door om het beste uit uw product te halen.
Bewaar het op een veilige plek voor raadpleging in de toekomst.
Haal nooit het omhulsel van de eenheid af, dit om de kans op een elektrische
schok te verminderen. Maak het apparaat nooit open: er bevinden zich geen
door de gebruiker in te stellen onderdelen in het apparaat. Laat service en
onderhoud over aan een gekwalificeerde technicus.
2.1 Elektriciteit en aansluiting
Deze eenheid is niet van de wisselstroom voedingsbron gescheiden wanneer
de stekker nog in het stopcontact zit. Wanneer de eenheid uitstaat, staat deze
nog in de stand-by modus. In de stand-by modus vergt de eenheid minder
stroom dan in de normale "aan" modus.
Wanneer u de eenheid voor langere tijd niet gebruikt, zorg er dan voor dat de
stekker van het wisselstroomsnoer uit het stopcontact is getrokken.
Het wisselstroom stopcontact moet dichtbij de eenheid geïnstalleerd worden
en makkelijk toegankelijk zijn.
Als de eenheid duidelijk beschadigd is moet u deze nooit op het lichtnet
aansluiten of bedienen.
2.2 Water en vocht
Om het risiko op brand en persoonlijk letsel te beperken is het gebruik van dit
apparaat buiten en/of blootstelling aan regen, water of overdadige
hoeveelheden vocht uitdrukkelijk verboden.
Het apparaat mag niet worden blootgesteld aan druppels of bespatting en er
mogen geen objecten die gevuld zijn met vloeistoffen, zoals vazen, op het
apparaat geplaatst worden.

CC-300 CORIOconsole Operation Manual
15
2.3 Algemeen onderhoud
Forceer schakelaars of externe aansluitingen nooit.
Bij verplaatsing van de eenheid, de seriële poortaansluitingen eerst
loskoppelen, dan de voedingskabel en als laatste de snoeren naar andere
apparaten.
Probeer de eenheid nooit met chemische oplosmiddelen of
schoonmaakmiddelen in een spuitbus schoon te maken, omdat dit de eenheid
kan beschadigen. Gebruik een schone droge doek.
2.4 Plaatsing
Deze eenheid moet geïnstalleerd worden op een koele droge plaats, uit de
buurt van bronnen van extreme hitte, vibraties, stof, vocht en kou.
2.5 Intellectueel eigendom
Sommige IC chips in dit product bevatten vertrouwelijke informatie en/of
fabrieksgeheimen. U mag daarom de inhoud hiervan niet kopiëren, wijzigen,
aanpassen, vertalen, verspreiden, nabouwen, of decompileren.

CC-300 CORIOconsole Operation Manual
16
3.0 CAPABILITY, TERMS OF REFERENCE AND OVERVIEW SUMMARY
3.1 Device Capabilities
The CC-300 CORIOconsole provides a Video Production Switcher type
interface for the C2 series of Dual Video Processors and Calypso controllers.
Two rows of 14 buttons are provided for Preview and Program functionality of
mixed format sources. Fades and wipes may be either automatic with preset
times or manually controlled via the fader bar. The joystick employs full range
of motion to allow precise positioning of P-I-P inserts and other functions.
Fixed purpose function keys along with the integrated LCD screen combined
with “soft” function keys provides total control over a single C2 series unit
using a RS232 link or over multiple C2 series units using an IP link.
At home in both broadcast and display environments, the CC-300
CORIOconsole provide access to all controls with a minimum of keystrokes
giving fast access to the powerful CORIO2 features.
Fig 1. Line drawing of the CC-300 CORIOconsole
Four connectors are available at the rear of the unit. A locking12 volt DC
connector supplies the power for the console. Simple connection to multiple
Video Processors is supported by connecting through a local area network
using the IP socket. A RS232 connector provides a method to download
firmware upgrades from a PC computer and allows control of a single Video
Processor using the supplied serial cable. An option socket is provided for
future expansion of controller facilities.
A single Video processor can also be controlled directly by connecting a
network crossover cable (see 9.1.2 for connection details) between the IP
sockets of the CC-300 CORIOconsole and the Video Processor.

CC-300 CORIOconsole Operation Manual
17
Fig 2. Location of keys and legends
Throughout this manual reference is made to Menu keys, Softkeys and
legends, Fig 2 shows the position on the console of these keys along with the
location of the status line at the bottom of the LCD screen.
4.0 UNPACKING AND INSTALLATION
4.1 Shipping Carton
The CC-300 CORIOconsole arrives double boxed for maximum protection
during shipping. You are encouraged to retain both boxes and all packing
material so the unit can be returned in the unlikely event that repairs should
ever become necessary.
4.2 Furnished Accessories
Carefully unpack the carton and perform an inventory of the contents. In
addition to the CC-300 CORIOconsole, the standard accessories include:
1 AC Power Cable
1 12V 4Amp DC power supply
1 Operations Manual
1 Rackmount Kit, 2 Ears and 8 Screws
If any items are missing or defective, contact your supplier. If you are unable
to resolve the problem with your supplier, contact TV One via the web at
http://www.tvone.com/supportfor prompt replacement.
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
FAX [phone] - TestEquipmentDepot.com

CC-300 CORIOconsole Operation Manual
18
5.0 FUNCTIONAL CHECK
5.1 Important Safety Instructions
The AC power cable (Mains Lead) furnished with the unit will conform to the
type in use at your geographic locale. Please compare the plug on your cable
with the three types of power cable plugs currently being shipped to make
certain you have received the correct power cable.
If you did not receive the correct cable, DO NOT attempt to modify the
incorrect cable. Instead, immediately contact your dealer or contact TV One at
the sales office nearest to your geographic location and request the proper
cable.
US AC Cable Plug Example:
UK AC Mains Lead Plug Example:
EU AC Mains Lead Plug Example:

CC-300 CORIOconsole Operation Manual
19
AGAIN, DO NOT ATTEMPT TO MODIFY AN INCORRECT AC CABLE
(MAINS LEAD). REPLACE IT WITH A CORRECT PART PRIOR TO USING
THE CC-300 CORIOconsole.
Power is never totally removed from the unit when it’s plugged into an active
AC outlet. Selecting Standby from the system menu only places the unit in a
powered down mode. Pressing the ‘TAKE’ button will bring the unit out of
standby and restart the console as if the power had been recycled. This is not
a true off and on switch.
Never remove the unit from a cabinet unless the unit has been completely
disconnected from AC power.
5.2 Factory Reset
To restore all operational parameters to their original condition, select
‘Restore defaults’ from the system menu then press ENTER to confirm.
All stored settings are lost when the unit is reset.
A Firmware update will also perform a complete factory reset
5.3 Initial Operation Check Using Factory Default Settings
All the examples in this manual are given with relation to the setup illustrated
in the picture below: A CC-300 CORIOconsole, a TVOne C2-7100 video
processor and a Calypso ION-LT2 control unit are all connected to a local
network; the IP address, subnet and port settings of each individual unit are
shown in the picture.
Connect the 12v power supply into the socket on the back of the CC-300
CORIOconsole, this should be locked into position by rotating the connector
clockwise after insertion. Connect the AC power cable to the 12volt power
supply and turn on the power.
