TypeS AC533654 User manual

User Manual
BC
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
JUMP STARTER & WIRELESS POWER BANK
WITH BUILT-IN USB-C CABLE
WP ITM. AC533654

2
6.14 x 3.5 x 1.34 in (156 x 89 x 34 mm)
0.97lbs (441g)
Lithium-Ion
29.6 Wh
5V 2A
5V 3A / 9V 2A
5V 3A / 9V 2A
5V 3A / 9V 2A
Total 5V 3A
400A 3S
-20ºC ~ 34ºC (-4ºF ~ 93ºF)
-20ºC ~ 40ºC (-4ºF ~ 104ºF) Avg. Temp.
0ºC ~ 34ºC (32ºF ~ 93ºF)
4-5 hours (5V 2A input)
2-2.5 hours (18W USB-C input) 18W charger not included
Product Dimensions:
Product Weight:
Internal Battery:
Battery Capacity:
Input (Micro USB):
Input (USB-C):
USB-A Output:
USB-C Output:
Cable + USB-C Output:
Jump Start Current:
Operating Temperature:
Storage Temperature:
Charging Temperature:
Charging Time:
TECHNICAL SPECIFICATIONS:
FEATURE OVERVIEW :
1. Smart Protection Circuit
2. Jumper Cables Port
3. LED Flashlight, Strobe &
Hazard Modes
4. Hazard Light
5. USB-A Output
6. Micro USB Input
7. USB-C Output / Input
8. LCD Display
9. Mode Button: Power, LED, Hazard
Light & Language Selection
10. Wireless Charging Pad
11. Positive Clamp (Red)
12. Negative Clamp (Black)
13. Polarity Circuit Protection Box
with Built-in LED Indicators
4 4
10
11
12 13
5
6 7 8 9
2
31

3
INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS
• Always wear safety glasses when jump starting a battery (to protect your
eyes), and gloves when handling a battery (to protect your hands).
• When jump starting a vehicle please ensure that the gray plug is securely
tted into the jump starter socket on the jump starter.
• Ensure the battery clamps are connected correctly, and the connectors are
free from rust and dirt.
• Do not allow this product to become wet. Exposure to excessive moisture
will damage the unit.
• Do not immerse the product in water.
• Do not operate the product in explosive atmospheres, such as in the
presence of ammable liquid, gas or dust.
• Do not modify or disassemble this product.
• Do not store in locations where the temperature may exceed 104ºF (40ºC).
• Charge only using the charger provided.
• Under extreme heat conditions, battery leakage may occur. Avoid contact
with your skin. In case of skin or eye contact, rinse immediately with clean
water and seek medical attention.
• If battery leakage occurs, take it to your local battery recycling center for
disposal. Do not attempt to use.
• This car jump starter is for use with 12V vehicles only. Using on non-12V
vehicles may cause serious damage to the vehicle, jump starter, or injury
to the user. Refer to the owner’s manual for the vehicle if you are uncertain
what voltage the vehicle runs on.
BATTERY DISPOSAL
The battery is self-contained and not consumer replaceable. The battery must
be disposed of properly when it no longer holds a charge. Proper charging
practices will increase the life of the product. For information on battery
recycling, call toll-free 800-822-8837.
For information regarding air travel safety with batteries please check the U.S.
Department of Transportation prior to travel at:
http://phmsa.dot.gov/safetravel/batteries
or contact your airline if traveling from a country outside the U.S.
Note: The Car Jump Starter gives 29.6 watt hours of power.
WARNING:

4
WARNING CONT.:
IMPORTANT SAFETY INSTRUCTIONS
WARNING - When using this product, basic precautions should always be
followed, including the following:
a) Read all the instructions before using the product.
b) To reduce the risk of injury, close supervision is necessary when the product
is used near children. Children should not operate this device unless under
strict supervision by a person responsible for their safety.
c) Do not put ngers or hands into the product.
d) Do not use any
attachment that is not sold by jump starter manufacturer which
may result in a risk of re, electric shock, or injury to persons.
e) To reduce risk of damage to the electric plug and cord, pull the plug rather
than the cord when disconnecting the jump starter.
f) Do not use a battery pack or appliance that is damaged or modied.
Damaged or modied batteries may exhibit unpredictable behavior
resulting in re, explosion or risk of injury.
g) Do not operate the jump starter with a damaged cord or plug, or a
damaged output cable.
h) Do not disassemble the jump starter; take it to a qualied service person
when service or repair is required. Incorrect reassembly may result in a risk
of re or electric shock.
i) To reduce the risk of electric shock, unplug the jump starter from the outlet
before attempting any instructed servicing.
j) WARNING - RISK OF EXPLOSIVE GASES.
1) WORKING IN VICINITY OF A LEAD ACID BATTERY IS DANGEROUS.
BATTERIES GENERATE EXPLOSIVE GASES DURING NORMAL BATTERY
OPERATION. FOR THIS REASON, IT IS OF THE UTMOST IMPORTANCE
THAT YOU FOLLOW THE INSTRUCTIONS EACH TIME YOU USE THE
JUMP STARTER.
2) To reduce risk of battery explosion, follow these instructions and
those published by battery manufacturer and manufacturer of any
equipment you intend to use in vicinity of the battery. Review
cautionary marking on these products and on engine.
k) The device shall be stored indoors and protected from the elements;
l) The unit shall not be charged outdoors;
m) When in use, steps should be taken to reduce the exposure to rain, sleet,
snow, and the like.
n) PERSONAL PRECAUTIONS
1) Consider having someone close enough by to come to your aid
when you work near a lead-acid battery.
2) Have plenty of fresh water and soap nearby in case battery acid
contacts skin, clothing, or eyes.

5
3) Wear complete eye protection and clothing protection. Avoid
touching eyes while working with battery.
4) If battery acid contacts skin or clothing, wash immediately with soap
and water. If acid enters eye, immediately ood eye with running cold
water for at least 10 minutes and get medical attention immediately.
5) NEVER smoke or allow a spark or ame within the vicinity of battery
or engine.
6) Be extra cautious to reduce risk of dropping a metal tool onto battery.
It might spark or short-circuit battery or other electrical part that may
cause explosion.
7) Remove personal metal items such as rings, bracelets, necklaces, and
watches when working with a lead-acid battery. A lead-acid battery can
produce a short-circuit current high enough to weld a ring or the like to
metal, causing a severe burn.
o) When charging the internal battery, work in a well ventilated area and do
not restrict ventilation in any way.
p) Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, ush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected from the battery may
cause irritation or burns.
q) Do not expose a jump starter to re or excessive temperature. Exposure to
re or temperature above 130°C (266°F) may cause explosion.
r) Have servicing performed by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the product is
maintained.
s) Attach output cables to a battery and chassis as indicated
below. Never allow the output clamps to touch one another.
t) Dropping, hitting, or other excessive amounts of force
to the Jump Starter may damage the unit (external and
internal), which may result in loss of operation, electrical
re, or cause other serious damage.
u) Do not overcharge the internal battery or short circuit
output connector.
v) This product is suitable for use in home, oce, household workshop or
garage. Do not operate in rough environment such as repair facility.
WARNING: This Jump Starter is only intended to jump start 12V cars, trucks,
boats, or motorcycles with an internal combustion engine and single lead-acid
battery systems. Do not use this device to jump start batteries outside of these
four types of vehicles; doing so may cause a re or other serious injuries. Refer to
the user manual for additional safety information.
WARNING CONT.:
SAVE THESE INSTRUCTIONS

6
PACKAGE CONTENTS:
CHECKING THE POWER LEVEL
CHARGING YOUR MOBILE DEVICES:
Jump Starter
Power Bank
12V USB Charger &
Micro USB
Charging Cable
Storage Case Safe & Smart
Jumper Cables
Press to check the battery status of
the Jump Starter.
When charging, the battery indicator will glow.
Jump Starter is fully charged when the battery
indicator is solid and reads 100%.
We recommend using the
original charging cable
that came with your mobile
device, or an approved cable
certied by the mobile device
manufacturer. Three mobile
devices can be charged at the
same time by utilizing USB-A,
USB-C Output ports & built-in USB-C cable. To begin charging, press once.
While charging, press to check the battery capacity.
Press the power button once to enable wireless charging
function. Place the device on top of WIRELESS CHARGING
ICON to start. LCD screen is ON for 60 seconds while wireless
charging is in progress. The power level will vary during charging.
You may need to adjust the orientation to have the best charging.
NOTE: The wireless charging feature only works on devices that allow Qi (inductive) wireless
charging. Only use the wireless charging pad with Qi-certied devices.
WIRELESSLY CHARGING YOUR MOBILE DEVICES:

7
NOTE: Fully charge the Jump Starter upon receipt. Check battery status periodically and recharge every
2-3 months and after every use to maintain the efciency and to prolong the life of the internal battery.
CHARGING THE JUMP STARTER:
At home:
Micro USB Cable
1. Plug included Micro USB Charging Cable into a USB-A
port on a 2A USB wall adapter (not included).
2. Connect the Micro USB Charging Cable into the Micro USB
Charge Input Port on the Jump Starter.
3. Disconnect the Jump Starter when it is fully charged. Store
the Jump Starter in a safe place when not in use.
Built-in USB-C Cable
1. Plug built-in USB-C cable into a USB-C port on a 18W(or above) wall adapter
(not included)
2. Disconnect the Jump Starter when it is fully charged. Store the Jump Starter in a
safe place when not in use.
3. Disconnect the Jump Starter when it is fully charged. Store the Jump Starter in a safe
place when not in use.
NOTE : In order to reduce the risk of re or electric shock, an adapter shall be chosen that is suitable for
the application and is certied as a Class 2 or LPS power supply or power adapter.
In Car:
1. Plug bundled Micro USB Charging Cable into bundled 12V
USB Charger then connect it to 12V socket in vehicle.
2. Connect the Micro USB Charging Cable into the Micro USB
Charge Input Port on the Jump Starter.
3. Disconnect the Jump Starter when it is fully charged. Store the
Jump Starter in a safe place when not in use.
Other Charging Method
USB-A to USB-C Cable /USB-C to USB-C Cable
(cables not included)
1. Plug one end of USB-C Charging Cable into a USB-A
or USB-C port on a 18W (or above) wall adapter (not
included).
2. Connect the other end of USB-C Charging Cable into the
USB-C Charging Input Port on the Jump Starter.
3. Disconnect the Jump Starter when it is fully charged. Store
the Jump Starter in a safe place when not in use.

8
1. Press the to power on the Jump Starter;
ensure the power level is 50% or higher.
JUMP STARTING:
BEFORE YOU JUMP START!
Before you attempt to jump start your vehicle, ensure your vehicle is
in Park. Unplug all USB charging cables. Ensure manual transmission
vehicles are in Neutral with the Emergency Brake engaged.
The Cable Clamps are color-coded, RED for
POSITIVE (+) and BLACK for NEGATIVE
(-). DO NOT mix up the cables or allow the
metal ends to touch together because this may
damage the battery, charging system and/or
electronics on a vehicle.
Locate the vehicle battery and follow the steps below. We recommend
jump starting when the Jump Starter battery level is > 50%.
INTELLI-STEP SMART DISPLAY:
The Jump Starter is programmed to display step-by-step instructions to
Jump Start your vehicle. When the Jump Starter is powered on, plug the
Jumper Cables into the Jumper Cables Port and follow the progressive
prompts on the LCD Display. The detailed steps are provided in the next
section for reference.
JUMP STARTING:
Red
Black
2. Insert the GRAY end of the Jumper Cables into
the Jumper Cables Port. The LCD Display will
read: Clamp cables to battery.

9
JUMP STARTING CONT.:
3. Connect the RED clamp to the POSITIVE (+)
post on the car battery. The POSITIVE battery
post will be slightly larger than the NEGATIVE
post, and will be marked with a PLUS (+) sign.
There may also be a RED plastic protective
cover over the positive battery post.
4. Connect the BLACK clamp to the NEGATIVE
(-) post on the car battery. The NEGATIVE
will be marked with a MINUS (-) sign. There
may be a BLACK plastic protective cover
over the negative battery post.
NOTE: Do not connect the RED clamp (+)
and the BLACK clamp (-) at the same time.
Connect the RED clamp rst, then the BLACK clamp.
CAUTION: DO NOT lean directly over the battery while making jumper
connections.
5. Check the LED status on the Polarity Circuit Protection Box. Proceed to
the next step unless the LED is ashing RED and BEEPING. Reference
Polarity Protection Circuit Status chart in the next section.
6. Once the clamps are properly connected to the vehicle battery, the LCD
Display will read: Ready, Start vehicle ignition.
You have 90 seconds to start your vehicle
before the Jump Starter shuts off in order
to prevent the vehicle battery from reverse
charging the unit.
NOTE: If vehicle does not crank, or cranks very slowly, wiggle the
cable clamps on the vehicle battery to ensure they are making good
contact. Wait 60 seconds before trying to jump start your vehicle again.
Each new jump start attempt requires disconnection of both
clamps from the vehicle battery and reconnection.

10
The engine should start if there are no other problems (such as a bad
starter or ignition circuit problem). Do not attempt to jump start the
vehicle more than 3 times with the Jump Starter. If the vehicle fails to
start after 3 attempts, it is likely due to alternative reasons that should
be checked by an auto mechanic.
7. When the engine starts, the LED
on the Polarity Circuit Protection
Box will blink RED and beep.
The LCD Display will also read:
Successful jump, unplug cables.
8. Disconnect the cables from your vehicle within 30 seconds. First
remove the RED/POSITIVE (+) clamp and then the BLACK/
NEGATIVE (-) clamp.
9. Do not allow the metal ends of the jumper cable clamps to touch each
other, or the RED clamp to touch anything metal on the car. Now
unplug the
GRAY end of the jumper cables from the Jump Starter.
This will reset the jumper cables. In 30-seconds the Jump Starter will
power off automatically.
10. Keep the engine running for 20 to 30 minutes, or drive the car to
recharge the battery.
NOTE: If the engine dies shortly after it has been jump started, or
as soon as the jumper cables are disconnected, it probably means
the vehicle charging system is not working (bad alternator, voltage
regulator, wiring problem, or loose/ dirty battery cables). Please seek
professional help from an auto mechanic to nd the root cause of the
problem. The Jump Starter may not work correctly for vehicles that
require remote battery jumper locations (e.g.: battery located in trunk
or other location). Please consult the owner’s manual for your vehicle.
JUMP STARTING CONT.:

11
Message on LCD Screen Message Meaning
Low Power, charge at least 50% Jump Starter battery below 50%
Battery Protected, Unplug, Start over Wrong connection
Device is too hot, Cool before use
Temperature of Jump Starter is above
131°F / 55°C
JUMP STARTING CONT.:
Polarity Protection Circuit Status
Solid LED On Flashing LED LED Off
Status (Light & Sound Indicator) Status Meaning
Red Light Green Light Sound
None The car battery is ready for jump start
None The Jump Starter needs to be charged
None The car battery is ready for jump start. If
the indicator doesn’t turn solid Green, the
car battery voltage is higher than the Jump
Starter. You can still jump start your battery,
but may need to charge your Jump Starter.
Beeping Disconnect the jumper cables from the car
battery and Jump Starter. Either the car jump
start is complete or there is a connection
problem.
None This status shows after 90 seconds time out.
Disconnect the jumper cables from the car
battery and Jump Starter to reset. Reconnect
the jumper cables to jump start the vehicle.
None Please contact TYPE S for troubleshooting

12
Function Action Remarks
Turn on the Jump Starter Press the
Switch language
to Spanish
Press and hold for 5 seconds until
the word “English” is shown on the LCD
screen, then press once to enter
Spanish mode. Press twice to conrm.
Remain in Spanish
mode if product is
idle for 5 seconds
Switch language
to French
Press once while in Spanish mode.
Press twice to conrm.
Remain in French
mode if product is
idle for 5 seconds
Switch language
to Japanese
Press once while in French mode.
Press twice to conrm.
Remain in Japanese
mode if product is
idle for 5 seconds
Switch language
to Korean
Press once while in Japanese mode.
Press twice to conrm.
Remain in Korean
mode if product is
idle for 5 seconds
Switch language
to English
Press once while in Korean mode.
Press twice to conrm.
Remain in English
mode if product is
idle for 5 seconds
LANGUAGE SELECTION:
HAZARD LIGHT / FLASHLIGHT:
Flashlight - Spotlight Press and hold for three seconds
Strobe Light Press once while in spotlight mode
Hazard Light Press once while in strobe light mode
Turn Off Press once while in hazard light mode /
Press and hold for three seconds
Hazard Light - Red Light Press twice
Strobe Light Press once while in red light mode
Hazard Light Press once while in strobe light mode
Turn Off Press once while in hazard light mode / Press twice
* Instruction messages on the LCD screen can be turned on/off by pressing
for 10 seconds.

13
TYPE S
LIMITED WARRANTY
TYPE S warrants, to the original purchaser, that its products are free from
defects in material and workmanship for 1 year from the date of original
purchase. Where permitted by law, TYPE S’s liability shall be limited
to that set forth in this limited express warranty. This limited express
warranty shall be the exclusive remedy of the purchaser and TYPE S
makes no other warranty of any kind aside from the limited express
warranty stated above.
NOTE: Warranty only applies for North American customers of
purchases made in North America.
CONDITIONS OF WARRANTY
If during the 1 year warranty period your new product is found to be
defective, TYPE S will repair such defect, or replace the product, without
charge for parts or labor subject to the following conditions:
1. All repairs must be performed by TYPE S.
2. All warranty claims must be accompanied by a copy of the sales
receipt or bill of sale.
3. The equipment must not have been altered or damaged through
negligence, accident, improper operation, or failure to follow the
product instructions for installation, use, or care.
4. The replacement of parts is excluded from the warranty when
replacement is necessary due to normal wear and tear.
5. Repair or replacement parts supplied by TYPE S under this warranty
are protected only for the unexpired portion of the original warranty.
6.
This is a “repair or replace” warranty only, and does not cover the costs
incurred for the installation, removal or reinstallation of the product, or
damage to any mobile phone, electronic device or vehicle.
WARRANTY:

14
OWNER’S RESPONSIBILITIES:
TYPE S will make every effort to provide warranty service within a reasonable period
of time. SHOULD YOU HAVE ANY QUESTIONS ABOUT SERVICE RECEIVED
OR IF YOU WOULD LIKE ASSISTANCE IN OBTAINING SERVICE, PLEASE CALL
TOLL FREE 1.866.294.9244 DURING REGULAR BUSINESS HOURS, MONDAY
THROUGH FRIDAY 8:00 AM TO 5:00 PM (Pacic Standard Time). For customer
service and technical support, please call us at 1.866.294.9244
(English only) or
email us at [email protected]. If at that time it is determined that a replacement
unit is needed, the support representative will issue a Return Authorization and
instruct on how to get a new unit. TYPE S makes no other warranty of any kind aside
from the limited express warranty stated herein.
NOTE: Toll-free number is for North American customers ONLY.
DISCLAIMER OF WARRANTIES, INCLUDING WARRANTY
OF MERCHANTABILITY AND WARRANTY OF FITNESS FOR
PARTICULAR PURPOSE: EXCEPT AS SPECIFICALLY SET
FORTH HEREIN, NO WARRANTY OR REPRESENTATION,
EXPRESS OR IMPLIED, IS MADE AS TO THE CAR JUMP
STARTER. TYPE S AND/OR ITS AFFILIATES EXPRESSLY
DISCLAIMS, WITHOUT LIMITATION, ANY STATUTORY
WARRANTIES AND ALL IMPLIED WARRANTIES, INCLUDING
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE.
TYPE S and/or its afliates are not responsible for a user’s intended or actual use of
the Car Jump Starter. In no event shall TYPE S and/or its afliates have any liability
for any losses (whether direct or indirect, in contract, tort or otherwise) incurred
in connection with the Car Jump Starter, including but not limited to damaged
property, personal injury and/or loss of life. Neither shall TYPE S and/or its afliates
have any liability for any decision, action taken based on relying on the stability or
performance of the Car Jump Starter. TYPE S and/or its afliates, the manufacturer,
distributor and seller shall not be liable for any injury, loss or damage, incidental or
consequential, arising out of the use or intended use of the product.
WARRANTY CONT.:

15
FCC Compliance Statement:
Jump Starter & Power Bank
Model: AC533654
Responsible Party:
TYPE S
2975 Red Hill Ave., Ste. 100, Costa Mesa, CA 92626
Tel: [phone]
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference
that may cause undesired operation.
This device complies with Part 18 of the FCC Rules.
Warning: Changes or modications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modications or change to this equipment. Such modications or
change could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits
for Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The ‘Qi’ symbol is a trademark of the Wireless Power Consortium
WARRANTY CONT.:

16
Issue Cause Remedy
Cannot jump start Wrong clamp
connection
Make sure to clamp the RED jumper
cable to the POSITIVE (+) post on
the car battery. And BLACK jumper
cable to NEGATIVE (-) post or car
interior. Refer to Page 9 for details.
90-Second timer
to jump start has
expired.
Jump Starter timed out. Disconnect
the cables from the vehicle battery
and reconnect.
Low battery status Recharge the unit via USB cable until
at least 50% charge.
LED light on the
clamp box keeps
ashing
Protection circuit
is working
Refer to the status table on the
indicator box or page 11 of the
manual.
Hazard light or
ashlight does
not turn on
Low battery Recharge the unit via USB cable.
The unit is
charging
As a safety precaution, the hazard
light or ashlight will not work while
the unit is charging. Please unplug
the unit from charging or wait until
the unit nishes charging before
using the light.
TROUBLESHOOTING:
A Horizon Brands Company
2975 Red Hill Ave., Ste. 100, Costa Mesa, CA 92626
Mon - Fri, 8AM - 5PM (Pacic Time)
Tel: [phone] (English only)
| [email protected]
©2023 TYPE S. All rights reserved.
www.typesauto.com
Made in China
ML-533654_V1
