U-Line H-3616 User manual

PAGE 1 OF 5 0315 IH-3616
πH-3616
WARDROBE
CABINET
1-800-295-5510
uline.com
TOOLS NEEDED
11/32” Nut Driver
(included)
Flathead Screwdriver
Rubber Mallet
CAUTION! Some parts may have sharp
edges. Take care when handling various
pieces to avoid injury. For your safety, wear
work gloves when assembling.

PAGE 2 OF 5 0315 IH-3616
PARTS
4
911
13
6
8
2
7
10
31
5
12
18
16
16
17
17
14
15
PRIMARY ASSEMBLY HANDLE ASSEMBLY
#DESCRIPTION QTY.
1Back Panel 2
2Right Side Panel 1
3Left Side Panel 1
4Top 1
5Shelf 2
6Left Door 1
7 Right Door 1
8Sill 1
9 Bolts (#8-32 x 3/8") 20
10 Nuts (#8-32) 30
11 Hinge Pin 8
12 Coat Rod 1
13 Coat Rod Bracket 2
#DESCRIPTION QTY.
14 Locking Handle with Keys and Dummy
Handle (Set) 1
15 Cotter Pin 1
16 Lock Bar Guide 2
17 Lock Bar (Set) 1
18 Locking Cam 1

PAGE 3 OF 5 0315 IH-3616
ASSEMBLY INSTRUCTIONS
ASSEMBLING CABINET
1. Place the back (1) on a protected surface. The
bottom flange should be facing upward. Bolt panels
together using 7 bolts and nuts. (Nuts on the inside
of the unit.) (See Figure 1)
NOTE: When bolting the unit together, leave the
bolts slightly loose until step 7, unless otherwise
specified.
2. Attached the left side (3) to the back by placing
flange around the back and bolting the back and
sides together. Be sure that the lances on all shelf
adjustment strips point in the same direction.
(See Figure 2)
3. Attach the top (4) to the unit by sliding the outer
flange over the back of the unit and the side flange
on the top over the side panel. The threaded studs
should go through the holes in the top flange of the
side and fasten with 3 nuts. Attach the back to the
top using 4 bolts and nuts. (See Figure 3)
4. Attach right side (2) in the same manner used in
step 2. Make sure the side flange overlaps the back
panel and the flange on the top is over the right
side. Push the side panel up so the studs in the top
go through the holes in the top flange of the side.
Fasten with 3 nuts. (See Figure 4)
TOP
BOTTOM
1
Figure 1
3
1
Figure 2
3
2
1
Flanges on top go over
the back & sides
Threaded studs
go through the
holes in the
flange at the
top of the side.
3
1
4
Figure 3
Figure 4

PAGE 4 OF 5 0315 IH-3616
ASSEMBLY CONTINUED
5. Attach the sill (8) to the sides. Place nuts loosely on
each of the studs and slide the ends of the sill into
the slots on both sides of the unit. Then, securely
tighten with nuts. (See Figure 5)
6. Place a shelf (5) into the lowest lances in the back.
The front of the bottom shelf will rest on the sill.
(See Figure 6)
7. Using two people, set unit upright and tighten all
nuts and bolts. Insert the other shelf into the top
position of the shelf lances. Be sure the shelf edge
with no slots faces the cabinet front. The slots on the
other three sides fit over the lances on the cabinet
walls, which hold the shelf in place.
8. Attach a coat rod bracket (13) beneath the left side
of the cabinet shelf by inserting one bolt through the
hole in the left edge of the shelf. Secure with a nut.
Attach the right bracket in the same way. Slide the
coat rod (12) through the holes in the brackets.
(See Figure 7)
9. Attach the left door (6) to the unit. Place the door on
the hinges, align the holes, and drive the four hinge
pins (11) into place. (See Figure 8)
10. Repeat step 9 for the right door (7).
11. Adjust the levelers underneath the front of the unit to
ensure the cabinet is leveled.
NOTE: The doors will not align properly if the
cabinet is not leveled.
5
8
Insert shelf into
bottom lances.
Figure 6
6
11
7
Figure 8
12
13
Figure 7
8
Slide studs into the slots
located near the bottom
of each side panel.
Nuts placed loosely
on studs of the sill.
Figure 5

PAGE 5 OF 5 0315 IH-3616
πCHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
1-800-295-5510
uline.com
ASSEMBLY CONTINUED
14
Figure 8
Open position Closed position
Figure 9
Open position Closed position
17
19
18
18
17
17
19
18
18
17
Figu re 11 Figure 12
19
16
Figure 10
ATTACHING HANDLE
1. Place the locking handle (14) on the right hand
door and fasten with two slotted bolts and lock
washers. (See Figure 8)
2. Turn the handle to the open position (See Figure 9)
and place the locking cam (19) over the square
shank of the door handle. Place the cotter pin (16)
through the hole of the square shank.
(See Figure 10)
3. With the handle still in the open position, hook the
lock bars (18) into the locking cam (19). Once in
position, slowly rotate the door handle to the closed
position so the lock bars protrude from the holes at
the top and bottom of the door. (See Figure 11)
4. Slide the nylon lock bar guides (17) over the lock
bar (18) ends and through the door slots. Push firmly
until the guides snap into place. If necessary, turn
the handle back to the open position and gently
tap with a hammer until the guides snap into place.
(See Figure 12)
5. Attach dummy handle (15) to the left door using two
slotted bolts and lock washers.
