U-Line Echelon Wine Captain 2275ZWC Configuration guide

2275ZWC 2000 Se ri e S
FEATURES
8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX [phone] U-LINE.COM
• Wine bottle capacity of up to 43 bottles (.75L)
• Touch glass digital control featuring easy view command center manages key functions
and provides user alerts such as an audible door open alarm
• U-Select control system
• Digital controlled dual zone system, temperature settings can be set independently
• Temperaturesettingfrom34to60˚Fallowsforcontrolledstorageofanywine
varietal
• Sabbath / Blackout mode turns off all lighting and controls display and automatically
resets after 36 hours
• UL residential listing
• Lighted black interior optimizes elegant display of wines and can be manually turned
on for display with door closed; automatically shuts off after four hours
• Solid beech wood trimmed, full-extension black vinyl coated wine racks allow for full
access to stored wines
• Standard commercial stainless steel handle is interchangeable with professional handle
option
• Self-closing door ensures a positive door seal and prevents door bounce back
• Stainlessandoverlaymodelshaveaeldreversibledoor
• LowEcoated,argongaslledthermopaneglassdoorprovidesprotectionfrom
potentiallyharmfulUVraysandaddedinsulatingenergyefciency
• Blackvinylcladtexturedcabinetismoreresistanttoscratching,peelingandaking
• Solid beech wood trim on wine racks can be stained to match surrounding cabinetry
• Overlay model accepts a full 3/4" overlay frame and can be fully integrated into all
styles of cabinetry with zero clearance
• Allowa2-1/2"clearanceonhingedsidefor90˚dooropeningwheninstalledadjacent
to a wall (for stainless steel model)
• Allow 1/4" width overall for proper installation (see backside for details)
• No additional clearance around sides, top or rear of unit is needed for ventilation
• Donotobstructfrontgrilleairow
• Durablefactoryinstalledlevellegsprovideamorepreciseundercountert
Stainless Overlay
Dual Zone System
featured in 2275ZWC.
2275ZWC – Each zone
canbeadjustedtoa
specictemperature.
INTEGRATION INTERIOR / EXTERIOR PERFORMANCE
2275ZWC
WINE CAPTAIN®MODELS
Solid door
overlay

DIMENSIONS AND SPECIFICATIONS
OVERALL DIMENSIONS
8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX [phone] U-LINE.COM
2275ZWC
Height 34-1/8" (86.6)
Width 23-15/16" (60.8)
Depth 23-1/4" (59.3)
With stainless steel handle 25-1/8" (63.8)
Shipping weight:
Stainless model 144 lbs (65 kg)
Overlay model 144 lbs (65 kg)
Running amps 2.4
Maximum start-up amps 5.5
Amps pertain to voltage rating 110/115 volt, 60 Hz
Capacities:
Wine bottle storage (0.75L) Up to 43
24"
1-1/2”
24-3/16”
7”
2275ZWC
Stainless U-2275WCS-00
Overlay U-2275ZWCOL-00
Solid door overlay U-2275ZWCOL-60
2275WCS Stainless Model 2275ZWCOL Overlay Model
Please visit www.u-line.com for installation guide.
All specifications are subject to change without notice.
23-1/4"
23-15/16"
23-15/16"
34-1/8"
2275ZWCOL Wood Overlay Model
34-1/8"
23-1/4"
2275ZWCS Stainless Steel Model
3-13/16"
3-13/16”
23-1/4"
23-15/16"
23-15/16"
34-1/8"
2275ZWCOL Wood Overlay Model
34-1/8"
23-1/4"
2275ZWCS Stainless Steel Model
3-13/16"
3-13/16”
WINE CAPTAIN®MODELS
