U-Prox Keypad MF User manual

Integrated Technical Vision Ltd.
http://www.itvsystems.com.ua 1
U-Prox-Keypad MF.
Mifare reader. User manual
Introduction
The Mifare U-Prox-Keypad MF reader with built in keypad is
intended to be applied in different access control systems, using
RS232, Wiegand 26, Wiegand 32, Wiegand 34, Wiegand 37,
Wiegand 40, Wiegand 42 and Touch Memory interface.
The direct and reverse ID bytes order supported. Secure mode with
reader and cards serialization available.
The interface type is to be changed by special PC program. If you need to change the
interface type, please call your distributor. The reader placed in elegant plastic case with
bicolor LED indicator and keypad on front panel.
Types of cards
Integrated Technical Vision ltd manufactures readers operating with various kinds of Mifare®
cards: MIFARE®Standard, MIFARE®Hi-Memory, MIFARE®Ultralight, MIFARE®DESFire,
MIFARE®CLASSIC 1k, MIFARE®Classic 4k, MIFARE®CLASSIC 7UID.
Features
Case
Material ABS plastic
Color black
Dimensions 119.4 х65.4 х17.5 mm
Weight 240 g
Ambient Conditions
Oper. temp. -0°C . . . +60°C
Stor. temp -0°C . . . +80°C
Humidity 100% rel. at +25 0C
Electrical
Voltage +9. . . +16 VDC
Max current up to 75 mA
Voltage ripple up to 500 mVp-p.
Read Range
Typical read range is 40…50 mm and depends on tag type used.
Wiring
Reader has 8 wire cable for connecting to the access control panel.
Table 1. The wires assignment.
Wiegand
RS232 (reader)
DB-9 (computer)
Color
Function
Green
Data 0
Rx
3
White
Data 1
Tx
2
Red
+V
+V
Black
GND
GND
5
Brown
Red Led
-
Orange
Green Led
-
Blue
Beep
-
Yellow
Hold
Hold
AWG22 multiwire signal cable is recommended.
Using this cable the maximum length of 150
meters can be obtained
*
.
When you connect the reader to the interface
TouchMemory (iButton), and it does not work
consistently (for example, does not transmit the
*
Not for RS232 interface
Figure 1

Integrated Technical Vision Ltd.
http://www.itvsystems.com.ua 2
code identifier controller), you should use 4,7kOm resistor (supplied) installed between the
terminal and iButton "Earth" reader, as shown in Fig. 1.
When using twisted pair (STP, UTP, FTP) to connect the reader should be followed the order
of connection shown in Fig. 2.
Figure 2
Type of interfaces
The proximity reader is intended to apply in different access control systems, using RS232,
Wiegand 26, Wiegand 32, Wiegand 34, Wiegand 37, Wiegand 40, Wiegand 42 and
TouchMemory interface.
Mounting
It is recommended to mount the reader on a wall closely to a
door at appropriate height.
Do not place the reader on the metal surfaces, since it
causes decreasing of reading distance.
Reader installation
Loosen the screw at the bottom of the reader.
Remove the top cover, remove the back plate.
Mount the back plate of reader on the wall using the
fixtures provided (see fig. 1).
Prepare all wires for connection and connect them to the
reader in according to Table 1 and User Manual of the
access control panel to be utilized.
Insert the reader in the back plate (see fig. 2).
Put the top cover and tighten screw at the bottom of the
reader.
Ensure that all locking tabs are securely engaged.
The Reader Operation
The RFID Card Code Reading
The card code reading is annunciated by built-in buzzer and LED lamp according to
interface type and annunciation mode (see Section «Data transfer and Annunciation»).
Repeated reading will be available after 0.75 sec if the card is removed from the reader
sensing area.
Figure 1
Figure 2

Integrated Technical Vision Ltd.
http://www.itvsystems.com.ua 3
Data transfer and control of annunciation
The reader is provided with two-colour LED indicators and buzzer. LED and buzzer function
according to interface type programmed and annunciation mode.
Wiegand Interface
Engaging of LED and buzzer is possible automatically or by grounding of corresponding
wire according to Table 2.
Keypad codes
Reader transmits keypad codes in one of the programmed modes –package or digit-by-
digit.
In package mode reader stores up to 10 presses of ‘0’ to ‘9’ keys and transmits package
after the ‘#’ key press. If there are less than 10 digits pressed the leading digits filled with
hexadecimal digit ‘F’. The ‘*’ key press clears all previous key presses.
In digit-by-digit operation mode reader transmits the key code immediately after the key
press with 6-bit package. The key codes are in the table below:
Key
Code transmitted
key
Code transmitted
(hex)
(binary)
(hex)
(binary)
0
01
000001
6
2C
101100
1
02
000010
7
2F
101111
2
04
000100
8
31
110001
3
07
000111
9
32
110010
4
29
101001
*
34
110100
5
2A
101010
#
37
110111
DORADO digit-by-digit operation. In this mode reader transmits the key code immediately
after the key press with 8-bit package. The key codes are in the table below:
Key
Code transmitted
Key
Code transmitted
(hex)
(binary)
(hex)
(binary)
0
F0
11110000
6
96
10010110
1
E1
11100001
7
87
10000111
2
D2
11010010
8
78
01111000
3
C3
11000011
9
69
01101001
4
B4
10110100
*
5A
01011010
5
A5
10100101
#
4B
01001011
Table 2. Annunciation mode:
Data transmissions from reader comply with standard Wiegand26, Wiegand32, Wiegand34,
Wiegand37, Wiegand40, and Wiegand42.
Buzzer
Red LED
Green LED
00
Beep on card read
LED normally on, switch off at reading
Blinking at reading
01
Control from outside
LED normally on, switch off at reading
Blinking at reading
02
Beep on card read
Switch off
Blinking at reading
03
Control from outside
Switch off
Blinking at reading
04
Beep on card read
LED normally on, switch off at reading
Control from host
05
Control from outside
LED normally on, switch off at reading
Control from host
06
Beep on card read
Control from host
Control from host
07
Control from outside
Control from host
Control from host
08
Beep on card read
Possibly to control
from outside
LED normally on, switch off at reading
Possibly to switch off from outside
Blinking at reading Possibly to
switch on from outside
Data transfer depends on interface type. For TouchMemory interface it is identifier Type 01
according to DS1990.
Depending on length of Wiegand interface used, data transmitted for MIFARE®Classic 1K,
may vary as shown in table below for card ID B8 26 E0 FC. The first byte in this ID is XOR
of all bytes of ID:
Direct order
Reverse order
Parity bits
W26
0-26E0FC-1
1-FCE026-0
+
W32
B826E0FC
FCE026B8
-

Integrated Technical Vision Ltd.
http://www.itvsystems.com.ua 4
W34
1-B826E0FC-0
1-FCE026B8-0
+
W37
1-0B826E0FC-1
1-0FCE026B8-0
+
W40
B826E0FC82
FCE026B882
-
W42
1-00B826E0FC-0
1-00FCE026B8-0
+
Interface RS232
To control annunciation send control packet to the reader. Packets should be transmitted
with 2 400 baud rate, 8 bit data, no parity, 1 stop bit.
Table 3.Packet format
Bit
7
6
5
4
3
2
1
0
Byte 0
0
1
0
0
1
0
0
1
Byte 1
–
–
red LED
blinking
–
red
LED lit
–
–
–
Byte 2
green
LED lit
–
green LED
blinking
–
–
Buzzer
beeps
–
Buzzer
continuous
1 –corresponds LED or buzzer switched on. LED blinking and buzzer ‘beeps’control bits
have the highest priority.
Annunciation does not change until next control packet received.
Reader transmits data as follows:
# of byte
0
1 ... 10
11
12
data:
bit
7
6
5
4
3
2
1
0
Dest.
23h
data
checksum
0Dh
Value
0
0
1
1
x
x
x
X
Check-sum: exclusive OR of low nibbles of bytes from 1 to 10, high nibble of always must
be 3h.
Example: Card code 7E000460AA will be sent as:
23h, 37h, 3Eh, 30h, 30h, 30h, 34h, 36h, 30h, 3Ah, 3Ah, 3Bh, 0Dh.
Serialization
†
The readers may be serialized for use in secure applications, with specially encoded cards.
Serialized readers will read only cards emitted for them and will not read other Mifare cards.
For convenient use reader still transmits unique card ID but only for cards encoded for the
reader. For not encoded cards reader transmits nothing. Contact your distributor for details.
Limited Warranty
Integrated Technical Vision Ltd. warrants that for a period of eighteen months from the date
of purchase, the product shall be free of defect in materials and workmanship under normal
use and that in fulfillment of any breach of such warranty, Integrated Technical Vision ltd.
shall, at its option, repair or replace the defective equipment upon return of the equipment
to its repair depot. This warranty applies only to defects in parts and workmanship and not
damages incurred in shipping or handing, or damages due to causes beyond the control of
Integrated Technical Vision Ltd. such as lightning, excessive voltage, mechanical shock,
water damage, or damage arising out of abuse, alteration or improper application of the
equipment.
The foregoing warranty shall apply only to the original buyer, and is and shall be lieu of any
and all other warranties, whether expressed or implied and of all other obligations or
liabilities on the part of Integrated Technical Vision Ltd. This warranty contains the entire
warranty. Integrated Technical Vision Ltd. neither assumes, nor authorizes any other
person purporting to act on its behalf to modify or to change this warranty, nor to assume
for it any warranty or liability concerning this product.
In no event shall Integrated Technical Vision Ltd. be liable for any direct, indirect or
consequential damages. Loss of anticipated profits, loss of time or any other losses
incurred by the buyer in connection with the purchase, installation or operation or failure of
this product.
†
For Mifare 1K cards only
