U.S. Solid USS-LD00014-120MM User manual

For questions or concerns, e-mail [e-mail], visit www.ussolid.com, or
call [phone]
Automatic Label Dispenser
This manual should be made available to all users of this
equipment. For best results and for maximum durability of
the equipment, carefully read and follow all instructions.

I. Gar I. Product Specifications
I. Gar II. Machine Introduction
Model
USS-LD00014-120MM
USS-LD00014-160MM
Applicable Label
Width
4 - 120mm (0.24 to 4.7
in.)
4 - 160 mm (0.24 to 6.3
in.)
Applicable Label
Length
4 - 200 mm (0.16 to 7.87 in.)
Core Diameter
10 - 75 mm (0.39 to 3 in.)
Max. Roll Diameter
250 mm (9.84 in.)
Display
4 digit LED
Max Feed Speed
60 circles/min
Motor Power
18 W
Voltage
AC110V, 60Hz
Counter
Length Knob
Speed Knob
Power On/Off
Hanger Shaft
Label Guide
U pin
Rewinder Shaft
Sensor
Sensor Bracket
Press Plate
Dispensing Plate
Fixed Bracket
Power Cable
Configuration I for Small Core Diameter
Black Lock

For questions or concerns, e-mail [e-mail], visit www.ussolid.com, or
call [phone]
I. Gar III. Operating Instructions
1. Mount the correct Hanger Shaft onto the machine according to your
label’s core diameter(Configuration I or Configuration II).
2. Install one label roll onto the Hanger Shaft with the labels facing out.
3. Adjust the Fixed Bracket so that it holds the label core against the
roll.
4. Pull the leading edge of the carrier paper under the Press Plate and
fix the Press Plate by Black Lock. Through the Press Plate, around
the Dispensing Plate and down towards the Label Guide Rod. Then,
Configuration II for Large Core Diameter

grip the label paper end into the groove on the Rewinder Shaft and
fix the end with the U Pin. Make sure the paper is fairly straight.
(See the attached picture.)
5. Gently adjust the position of the white rubber on the Label Guide
rod. Note that it is important to exercise care on this step; too much
force may cause the label to tear.
6. Point the sensor towards the desired label stop position. You can
either pivot the sensor on the shaft, or rotate the metal bracket, or
both.
7. Turn the Power Switch to “On”.
8. Adjust the Speed and Length Knobs until the desired settings of the
label feed are achieved.

For questions or concerns, e-mail [e-mail], visit www.ussolid.com, or
call [phone]
. Gar IV. Applications
This machine is suitable for most of translucent and opaque labels, like
self-adhesive label, barcode label, security labels, packaging label,
anti-counterfeit labels, hot stamping stickers, stickers, printing patterns,
chrome paper , and many more!
. Gar V. Pack List .
1 – Automatic Label Dispenser
1 – Power Cable
1 – User Manual
Gar VI. Warranty
The machine’s motor and circuit board have a 1 year warranty. This
warranty covers any defects in material or workmanship under normal
use.
Within 30 days of delivery, U.S. Solid will either work with you to repair
your product with replacement parts, replace the product after receiving
the returned defective machine, or accept a returned defective machine for
a full refund.
After the first 30 days but still within the first 1 year of delivery, U.S. Solid
will send new or refurbished replacement parts at no charge so you can
repair the product on your own.
