Uberhaus F993 User manual
2
SafetyInformation ..... ... .. .3
PackageContentsList .. ..6
Preparation .. ....8
AssemblyInstructions ... .. 9
Installation Instructions ..... ....15
Operating Instructions ..... ..18
Care and Maintenance ..21
Troubleshooting .. ... 23
ReplacementPartsList .... .. ..25
Warranty ... .. .26
TABLEOFCONTENTS
DANGER
Ifyou smell gas:
1.Shutoffgastotheappliance.
2.Extinguishanyopenflame.
3.Openlid.
4.Ifodour continues,keepawayfrom the
applianceand immediatelycall yourgas
supplieroryour firedepartment.
WARNING
1.Donotstoreorusegasolineor other
flammableliquidsorvapoursinthe
vicinity ofthisor anyotherappliance.
2.AnLP cylindernotconnectedfor use
shall notbestoredinthevicinity ofthis
or anyotherappliance.
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn
3
SAFETYINFORMATION
WARNING Hazardsorunsafe
practiceswhichcouldresult insevere
personalinjuryordeath.
CAUTION Hazardsorunsafepractices
whichcouldresultinminorpersonal
injury.
WARNING
CAUTION
WARNING
Donottrylightingthisappliancewithout first reading
the “LIGHTINGINSTRUCTIONS”section ofthis
manual.
WARNING
Donotusethe grill iftheodourofgasispresent. Contactcustomerserviceat1-866-206-0888.
WARNING
Neverattempttousedamagedequipment. Seeyourlocalliquidpropane dealerforrepair.
WARNING
Checkallgassupplyfittingsforleaksbeforeeachuse. Donotusethe grill untilall connectionshavebeen
checkedanddonot leak.Donot smokewhileleaktesting. Neverleaktestwithanopenflame.
WARNING
Donotinstall thisunit intocombustibleenclosures.
Thereshouldbeaminimumclearanceof24 inches
fromallsidestocombustiblematerials.
WARNING
Thisgrill isnot intendedtobe installed inoron
recreationalvehiclesand/orboats.
WARNING
Whenlighting,keep yourfaceand handsasfar
awayfromthegrill aspossible.
WARNING
MaximumLP gastanksizeis12inchesindiameter
by18-1/2inchestall.Donot useatankwithoutan
OverfillPreventionDevice(OPD), whichprevents
thetankfrombeingoverfilledandpossibly
damagingyourgrill.
WARNING
Donotstoregrillindoorsunless the cylinderis
disconnected. Donotstorecylinderinabuilding,
garage, oranyotherenclosed area, and keep out
ofreachofchildrenat alltimes.
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn
4
BEFORE LIGHTING
Inspectthegassupplyhosespriortoturning onthegas.Ifthereisevidenceofcuts, wear, orabrasion,it must
bereplaced priortouse.
Onlythepressureregulatorandhoseassemblysuppliedwiththeunitshouldbeused.Neversubstitute
regulatorsforthosesuppliedwiththegrill.Contactcustomerserviceforproperreplacement.
Screwthe regulator(typeQCC1)ontothe cylinder. Leakcheck the hoseandregulatorconnectionswithasoap
and watersolutionbeforeoperatingthegrill (See “LeakTesting”instructionson page16).
Donotturnonthe gasattheLPgascylinderunlessthegashoseisproperlyconnected totheside burnergas
pipesystemand allburnervalvesareinthe “OFF”position.
Keepaspraybottleofsoapywaternearthe grillandcheck the connectionsbeforeeachuse.
WARNING
Donotleavethegrill unattendedwhilecooking.
WARNING
Failuretoproperlyplacethe burneroverthe orifice
couldcauseafiretooccurbehindand beneaththe
valvepanel,therebydamagingthegrill andmaking
it unsafetooperate.
WARNING
Spidersandinsectscan nestinside theburners
ofthe grill anddisrupt gasflow.
Inspect the grillat leasttwiceayear.
CAUTION
Whenusingamatchtolight thegrill,makesureto
usetheattachedlightingrod.
CAUTION
Beforecleaning,makesurethe gassupplyand
controlknobsareinthe “OFF”positionandthe
burnershavecooled.
CAUTION
Thegrill bodyisheavyandwill requiretwoor
morepeopletolift andpositionontogrillcart.
LP GASCYLINDERWARNING
1.Donotstoreorusegasolineorotherflammablevapoursandliquidsinthevicinityof thisoranyother
appliance.
2. Aliquidpropanecylindernotconnectedforuseshouldnot be stored inthevicinityofthisoranyother
appliance.
3. Donotstorespareliquidpropane gascylindersunderornearthisappliance.
4. Neverfillthe cylinderbeyond 80percentcapacity.
5. Liquidpropane cylindersmustbeprovidedwithalistedoverfilling preventiondevice.
6. If theinformationaboveisnot followedexactly,afireresultingindeathorseriousinjurycouldoccur.
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn
5
SAFETYPRACTICES TOAVOIDINJURY
When properlycaredfor,yourgrillwillprovide safe,reliableserviceformanyyears. However, extremecare
mustbe used asthe grillproducesintenseheatthatcanincreaseaccidentpotential.
When usingthisappliancebasicsafetypracticesmustbefollowed, includingthefollowing:
Donotrepairorreplaceanypart ofthe grill unlessspecificallyrecommended inthismanual.Allotherservice
shouldbereferred toaqualified technician.
The grillisforoutdooruseonly.
The grillisnotintendedtobeinstalledinoron recreationalvehiclesand/orboats.
Childrenshouldnotbeleft alone orunattendedinanareawherethe grillisbeingused. Donotallowchildren
tosit,standorplayonoraround thegrillat anytime.
Donotstoreitemsofinteresttochildrenaroundorbelowthegrillorcart.Donot allowchildrentocrawlinside
the cart.
Neverletclothing, pot holdersorotherflammablematerialscomeincontactwithortoo closetoanygrate,
burnerorhotsurfaceuntilit hascooled.The fabriccouldignite, causingseriouspersonalinjury.
Forpersonalsafety,wearproperapparel.Loosefitting garmentsorsleevesshouldneverbewornwhileusing
thisappliance. Somesyntheticfabricsarehighlyflammableandshouldnotbewornwhilecooking.
Onlycertaintypesofglass,ceramic, earthenware,orotherglazedutensilsaresuitableforgrill use.Other
typesofmaterialsmayshatterwithsuddentemperaturechanges.Useonlylowormediumheat settingsin
accordancewiththemanufacturer’sguidelines.
Donotheatunopened foodcontainersasabuild-upofpressuremaycausethecontainerstoburst.
Useacoveredhand when openingthe grill lid. Neverleanoveranopengrill.
When lighting aburner,alwayspaycloseattentiontowhatyou aredoing. Makecertainyouareawareof
whichburneryou arelightingsothat yourbodyandclothingremainclearofopen flames.
When usingthe grill, donottouchthegrill rack, burnergrateorimmediatesurroundingsastheseareas
becomeextremelyhot andcouldcauseburns.Useonlydrypotholders. Moistordamppotholdersonhot
surfacesmaycausesteamburns.Donotuseatowelorbulkyclothinplaceofpotholders.Donotallow
potholderstotouchhotportionsofthegrillrack.
Greaseisflammable.Lethotgreasecoolbeforeattemptingtohandleit.Donot allowgreasedepositsto
collect inthegreasetrayat thebottomofthe grill’sfirebox.Clean the greasetrayoften.
Donotusealuminumfoiltoline thegrill racksorgrillbottom.Thiscanseverelyupsetcombustion airflowor
trapexcessiveheatinthe controlarea.
WARNING
Donottrylightingthisappliancewithout first
readingthe “LIGHTINGINSTRUCTIONS”section
ofthismanual.
CALIFORNIAPROPOSITION65WARNING
Theburningofgasfuelgeneratessomeby-
products, whichareknownbytheStateof
Californiatocausecancerorreproductiveharm.
Tominimizeexposuretothesesubstances,always
operatethisunitaccordingtothecareand use
manual,ensuringyou providegoodventilation
whencookingwithgas.
TESTEDINACCORDANCEWITH
ANSIZ21.58a
LATESTSTANDARDandCGA1.6a-2008
STANDARD FOROUTDOORCOOKINGGAS
APPLIANCES.THIS GRILLISFOROUTDOORUSE
ONLY.
Checkyourlocalbuilding codesforthepropermethod
ofinstallation.Intheabsenceoflocalcodes, follow
eithertheNationalFuelGasCode,ANSI Z223.1/NFPA
54, orCAN/CGA-B149.1,NaturalGasand Propane
Installation Code, ElectricalCode, ANSI/NFPA70
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn
6
WARNING
Donot install thisunitincombustibleenclosures.Thereshouldbeaminimumclearanceof 24inchesfromall
sidestocombustiblematerials.
Forproperlightingandperformanceofthe burners,keep theburnerportsclean. Itisnecessarytoclean them
periodicallyforoptimumperformance. The burnerswillonlyoperateinoneposition andmustbe mounted
correctlyforsafeoperation.
Exercisecautionwhencleaninggrill.Toavoidsteamburns,donotuseawetspongeorclothtoclean thegrill
whileitishot.Somecleanersproducenoxiousfumesorcan igniteifappliedtoahotsurface.
Neveruseadented orrustypropane cylinder.
Turnoffallcontrolknobsandmakecertainthegrilliscoolbeforeusing anytypeof aerosolcleaneron or
aroundit.The chemicalthatproducesthesprayingactioncould,inthe presenceof heat, igniteorcausemetal
partstocorrode.
Donotusethegrilltocookexcessivelyfattymeatsorotherproducts, whichpromoteflare-ups.
Donotoperatethegrillunderunprotectedcombustibleconstructions. Useonlyinwell ventilated areas.Donot
useinbuildings, garages,sheds,breezewaysorothersuchenclosed areas.
Thisunit isintended foroutdooruseonly.
Keepthe areassurrounding the grillfree fromcombustiblematerialsincluding,fluids,trash,and vapourssuch
asgasoline orcharcoallighterfluid.Donot obstructtheflowofcombustion andventilationair. Ifthe unit is
storedindoors,makesureitiscool.
Thisliquidpropanegasgrillisdesignedforoptimumperformancewithout theuseofbriquettes.Donotplace
briquettesontheflametamersasthiswill blocktheventtothe grillburners. Adding briquettescandamage
ignition components,thusvoiding thewarranty.Donot usebriquettesofanykindinthegrill.
Keepthe backofthecartfree andclearfromdebris. Keepanyelectricalsupplycordand thefuelsupplyhose
awayfromanyheated surface.
Neverusethe grillinextremelywindyconditions.Iflocatedinaconsistentlywindyarea (oceanfront,
mountaintop,etc.),awindbreakwill be required.Alwaysadheretotheclearancespecifications.
PLACEMENTOFTHEGRILL
Outdoorcookingappliancesshouldnotbe usedunderoverheadcombustibleconstruction.
When determiningasuitablelocationtakeintoaccount concernssuchasexposuretowind, proximitytotraffic
paths, andkeepinggassupplylinesasshort aspossible.
Placethe grillinwell-ventilatedareas.Neverplacethegrillinabuilding,garage,breezeway,shedorother
suchenclosedareas.Duringheavyuse,the grillwillproducealotof smoke.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
7
S.1.5Volt “AA”SizeAlkaline
Battery----------1pc.sT.GreaseBox----------1pc.W.GreaseTray-------- 1pc.
ACKAGECONTENTSLIST
A. FireboxAssembly--------1pc.
B.BottomPanel & TankBolt-1pc.
C. Wheel-----------------------2pcs.
D. Left SideShelf&Control
Panel------1pc.
E.FrontPanel------------1pc.
F. CartLeg, FrontLeft--------1pc.
G.CartLeg,BackLeft--------1pc.
H. Cart Frame---------------2pcs.
I.CartLeg, Front Right-----1pc.
J. Cart Leg,BackRight-----1pc.
K.Cart CasterInsert---------2pcs.
L. Bezel----------1pc.
M.Side BurnerControlKnob ----
---1pc.
N. FixBar-------------1pc.
O.TriangleBracket, Left---2pcs.
P.TriangleBracket,Right--
2pcs.
Q. WheelAxle----------1pc.
R. CartBeam------------------1pc.
100
200
300400500
600
700
800
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
8
Pack
Description Requiredfor
assembly Extra
hardware Total
AA5/32-in.x10-mmTruss Head Screw
38 pcs.2pcs.40pcs.
BB5/32-in.LockingWasher36 pcs.2pcs.38pcs.
CC1/4-in.x15-mm TrussHeadScrew
18 pcs.2pcs.20pcs.
DD1/4-in.Locking Washer26 pcs.2pcs.28pcs.
EE TankBolt1pc.--1pc.
FF AllenKey 1pc.--1pc.
GG1/4-in.AxleFlatWasher2pcs.1pc.3pcs.
HH1/4-in. Nut2pcs.1pc.3pcs.
II5/32-in.Nut3pcs.1pc.4pcs.
JJ 1/4-in.x61-mm Truss Head Screw
8pcs.1pcs.9pcs.
KK 1/4-in.FlatWasher14 pcs.2pcs.16pcs.
X.DiagonalBarBarrier-----1pc.
Y.WarmingRack----------1pc.
ZA.FlameTamers-------4pcs
ZB. Cooking Grids----------2pcs.
Beforebeginningassembly,makesureallpartsarepresent. Comparepartswithpackagecontentslist
and diagramabove.Ifanypart ismissingordamaged,do notattempt toassembletheproduct. Contact
customerserviceforreplacementparts.
•Estimatedassemblytime:50 minutes
•Toolsrequired forassembly:
PhillipsScrewdriver(not included)andWrench(not included)
•Note: Therightand left sidesofthegrill aredesignatedasifyouarefacingthefront ofthegrill.
HARDWARECONTENTS
PREPARATION
AA
BB
CC
DD
EE
GG HH II
PhillipsScrewdriver
Wrench
JJ
FF
KK
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
9
1. CartAssembly
a)Placethe CartCasterInsert(K)intothe
CartLeg, Front Left (F) andCartLeg,
BackLeft (G).AsshowninFig.1.
b)AttachCartLeg,Front Left (F) and
CartLeg,BackLeft (G)withCart Frame(H)
Usingfour1/4-in.x15-mmTruss Head
Screws(CC)and four1/4-in. Locking
Washers(DD).Makesuretheflatside of
Cartframe(H)facesouttotherightwhen
attaching. AsshowninFig.2.
c)AttachCartLeg,Front Right (I)and
CartLeg,BackRight(J)totheCart
Frame(H)usingfour ¼-in. 15mm
Truss Head Screws(CC)andfour
¼-in.Locking Washers(DD). Makesure
the flat sideofCart Frame(H)facesout
tothe left whenattaching.AsshowninFig. 3.
2. Wheel Assembly
Insert WheelAxle(Q)throughCartLeg,Front
Right(I)andCartLeg,BackRight(J). Place
theWheels(C)on the WheelAxle(Q)andsecure
withtwo1/4-in.Flat Washers(GG)and two1/4-in.
Nuts(HH). AsshowninFig.4.
ASSEMBLYINSTRUCTIONS
Fig. 1
HH
GG
DD
I
J
CC
H
K
F
G
I
Fig. 3
Fig.4
Fig. 2
F
G
H
CC
DD
J
Q
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
10
3. Bottom Panel Assembly
a)Usefour1/4-in.x61-mmTruss HeadScrews(JJ)
andfour1/4-in.LockingWashers(DD)toconnect
thebottomoftheleftcartlegstotheBottom
Panel(B). Makesurethe cart legsareflush
withthe BottomPanel(B)and tightenthe
screws.AsshowninFig.5.
b)Repeat step3a)toattachrightsidelegstothe
BottomPanel(B).
4. TriangleBracketAssembly
Useeight 5/32-in. x10-mmTruss Head
Screws(AA)andeight5/32-in.Locking
Washers(BB)toconnectTriangle
Bracket (O&P) toCartLeg,BackLeft(G)
andCart Leg, BackRight(J)totheback
bottompanel.AsshowninFig. 6.
5. Front PanelAssembly
Usefour5/32-in.x10-mm TrussHead
Screws(AA)andfour5/32-in.Locking
Washers(BB)toattachthe Front Panel(S)
totheCartLeg, FrontLeft(F) andCartLeg,
FrontRight(I)asshowninFig. 7.
NOTE:Flat facingofFrontPanel(S)should
faceout.
Fig. 5
Fig.6
Fig. 7
JJDD
AA
BB
J
G
AA
BB
F
F
B
O
P
S
I
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
11
6. Condiment Tray Assembly
Usefour5/32-in.x10-mm TrussHead
Screws(AA)andfour5/32-in.Locking
Washers(BB)toattachthe Condiment
Tray(T) totheCartLeg,FrontLeft(F)
and CartLeg, Front Right (I).Usetwo
5/32-in. x10-mmTruss Head Screws(AA)
Andtwo5/32-in.nut(II)tosecureunderside
Ofthe Condiment Tray. AsshowninFig.8.
Hint: TheCondimentTray(T) willsit
aboveFront Panel(S)asshownin
Fig. 8. Besurethe CondimentTray(T)
openingisfacingoutwardtowardsthe
frontofthegrill.
7. FixBarAssembly
Removethetwo5/32-in.X15-mm
Truss Head Screwsthat areat the rearof
thecartlegs.ThenplacetheFixBar(N)
inthepre-drilledholeson the sidesofthe
CondimentTray(T).Fromtheoutsides
of theCondimentTraysecurethe bar
withthetwo5/32-in.15mm screws.
AsshowninFig.9.
8. DiagonalBarBarrier
Useone5/32-in.x10-mmTrussHead
Screw(AA)withone5/32-in.Locking
Washer(BB)andone5/32-in.Nut(II)to
secureonesideoftheDiagonalBar
Barrier(Y)totheundersideofthe
CondimentTray(T).Useone5/32-in.
x10-mmTrussHeadScrew(AA)andone
5/32-in. LockingWasher(BB)toassemble
theotherside oftheDiagonalBarBarrier(Y)
totheBottomPanel(B).AsshowninFig.10.
9. CartBeamAssembly
Usingfour5/32-in.x10-mm TrussHead
Screws(AA)andfour5/32-in.Locking
Washers (BB)toconnecttheCartBeam(R)
toCartLeg, Back Left (G)andCart Leg,
BackRight(J).AsshowninFig.11.
NOTE:SmoothsideofCart Beam(R)should
faceawayfromcart.
Fig. 8
Fig. 9
Fig. 10
AA
BB
R
T
Fig. 11
Y
AA
I
J
G
AA
II
T
AA
BB
II
B
T
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
12
10. FireboxAssembly
a)RemovetheFireboxAssembly (A)
fromthe cartonand carefullyplace
ontothe grillcart.Lidhandlewill face
frontandbe aboveCondimentTray(T).
AsshowninFig.12.
NOTE:Wesuggest that twopersonslift
thefireboxwhenassembling. Besure
thehoseandregulatorareplacedinside
thecartwhenplacing Firebox(A).Be
suretoremoveall packagingmaterial
duringassembly.
.
b)Liftthe lidand frominside theFireboxAssembly(A)
attachtheCartFrame(H)using four ¼-in.x15-mmTruss
HeadScrews(CC),four ¼-in. LockingWashers(DD),and
four ¼-in.Flat Washers(KK).AsshowninFig.13.
c)Fromthe leftandrightsidesof theFireboxAssembly(A)
exteriorsecuretheFireboxAssembly(A)tothe rearleg
withtwo5/32-in.x10-mmTruss HeadScrews(AA),
two5/32-in.Locking Washers(BB), andtwo ¼-in.
Flat Washers(KK).AsshowninFig. 13.
11. Right sideShelfAssembly
a)Alignthe holesonSideShelf (D)
withtheholeslocatedon the sideof the
firebox. Attachfrominsidethefireboxby
usingthree 1/4-in. x15-mm TrussHead
Screws(CC)and three1/4-in.Locking
Washers(DD)and three ¼-in. FlatWasher(KK).
b)Securesideshelfand firebox
controlpanelswithone5/32-in.x10-mm
TrussHeadScrew(AA)and one5/32-inLockingWasher(BB)
andone ¼-in.Flat Washer(KK). AsshowninFig. 14.
Fig. 14
Fig. 12
Fig.
13
A
CC
DD
A
BB
AA
KK
T
H
KK
A
800 700
600
500
400
300
200
100
T
BB
AA
D
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
13
c)Usefour5/32-in.x10-mmTruss Head Screw(AA)
and four5/32-inLockingWasher(BB)
toassembletheTriangleBracket,
Right(P)tothebottomrearofSide
BurnerShelf(D)andCart Leg,BackRight(J).
AsshowninFig.15.
12. LeftSideShelfAssembly
RepeatStep 11toassembleLeft
Side Shelf (E)and Triangle
Bracket,Left (O).asshowninFig.16.
Note: Insert theallen Key intotheholepriorto
placingtheknobonthevalvestem.Placethe knob on
thevalvestemandtighten.
13. ElectronicIgniterBatteryInstallation
Unscrewthe electronicigniterbutton
and placethebattery(V)intothehousing
withthepositiveterminal(+)facing
outward.Replacetheignitionbutton
afterthebatteryhasbeeninstalled
asshowninFig.17.
Fig. 15
Fig.16
Fig. 17
V
AA
BB
D
P
100
200
300 400 500
600
700
800
E
O
AA
KK
BB
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
14
14. Install theGrease Tray
Installthe GreaseTray(X)fromtherearofthe grill
bysliding the trayontheglidesattherearofthe
grilluntilcenteredunderthecooking area
AsshowninFigure18
15. PositionFlameTamersandCookingGrids
a)The FlameTamers(ZA)areshipped inthe main
fireboxassembly. Pleasecheck the placementof
and makesuretheFlameTamers(ZA)inthechannels
toensurethe FlameTamersarecenteredoverthe burners.
b)The CookingGrids(ZB)arealsoshipped inthe
FireboxAssembly(A).Placethe CookingGrids(ZB)inthe
mainfireboxassemblybeforeusingyourgrill.The Cooking
Grids(ZB)shouldbe positionedfromthefrontofthe firebox
tothe rearforaproperfit.
16.LiquidPropaneTankInstallation
Fromrearofgrillplacetheliquidpropane
tankintotheBottomPanel(B)hole
and tighten the TankBolt (EE)
tosecure.AsshowninFig.19.
17. LiquidPropaneHook-Up
Attachtheregulatortothepropanecylinderby
turning the regulatorhandleclockwiseasshown
inFig.20.Iftheoutdoorcooking applianceisnot
inuse,thegasmust beturned “OFF”attheLiquid
PropaneCylinder.
Check allgassupplyfittingsforleaksbefore
eachuse.Donotusethegrilluntil all connections
have beencheckedand donot leak (see “LeakTesting”instructionsonpage16).
Fig. 20
PropaneCylinder
Regulator
Fig. 19
TankBolt
Always keep theLPcylinderat
90°(upright)orientation to
providevapour withdraw.
Fig.18
X
W
100
200
300400 500
600
700
800
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
15
INSTALLATIONINSTRUCTIONS
GASHOOK-UP
Onlythepressureregulatorandhoseassemblysuppliedwiththegrillshouldbeused. Anyreplacement
pressureregulatorandhoseassemblymustbespecifiedbythegrill manufacturer.
Thisgrill isconfiguredforLiquidPropaneonly. DonotuseaNaturalGassupply.
Totalgasconsumption(perhour)withall burnersset on “HIGH”:
Mainburners12,000 BTU/Hr.
Total36,000 BTU/Hr.
The installation ofthisappliancemustconformwithlocalcodesor,intheabsenceoflocalcodes, with
eitherthe NationalFuelGasCode, ANSI Z223.1/NFPA54,NationalGasPropaneInstallation Code,CSA
B149.2.
InstallationinCanadamustbeinaccordancewiththeStandardCAN/CGA-B149.2(installationcodefor
gasburningappliancesandequipment)andlocalcodes.
LIQUID PROPANECYLINDERREQUIREMENTS
(20-lb.Cylinder)
AdentedorrustyLiquidPropane Cylindermaybehazardousand shouldbechecked byyoursupplier.
Neveruseacylinderwithadamagedvalve.TheLiquidPropane Cylindermustbeconstructedand
marked inaccordancewiththespecificationsforLiquidPropane Cylindersbythe NationalStandardof
Canada,CAN/CSA-B339,Cylinders, SpheresandTubesforTransportation ofDangerousGoods
Commission.
The 20-lb.Cylinder musthaveashutoffvalveterminating inavalveoutletspecified, asapplicable, for
connection typeQCC1inthe standardforcompressedgascylindervalveoutlet andinlet connection
ANSI/CGA-V-1.
Storage ofanoutdoorcookinggasapplianceindooris permissibleonlyif thecylinderisdisconnectedand
removed fromtheoutdoorcooking gasappliance.TheCylindersystemmust bearranged forvapour
withdrawal. ThecylindermustincludeacollartoprotecttheCylindervalve.
Manifoldpressure:(operating)10incheswatercolumn(W.C.),(non-operating)11.2incheswatercolumn
(W.C.).
LiquidPropane Cylindersmustbeprovidedwithalistedoverfillingprevention device.
Removetheplasticvalve coverfromtheLiquidPropane Cylinder. Makesurethegrillgashosesdonot
contactthegreasepan orgrill fireboxwhentheLiquidPropaneCylinderisplaced intothecart.
CONNECTINGTHELIQUID PROPANECYLINDER
ToconnecttheLiquidPropaneGasSupplyCylinder:
a)The cylindervalveshouldbeinthe “OFF”position. Ifnot, turnthevalve
clockwiseuntilit stops.
b)Makesurethe cylindervalvehasthepropertype-1externalmalethread
connectionsperANSI Z21.81.
c)Makesurethe burnervalvesareinthe “OFF”position.
d)Inspectthevalveconnections,portand regulatorassembly.Removedebrisandinspectthe hose
fordamage.
e)Whenconnectingtheregulatorassemblytothe valve,useyourhand totighten the nutclockwise
until it stops. Useofawrenchcoulddamagethequickcouplingnutandresultinahazardous
situation.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
16
f)Openthecylindervalve fullybyturningthevalvecounterclockwise.
g)Beforelightingthegrill,useasoapandwatersolutiontocheck alltheconnectionsforleaks.
h)Ifaleakisfound,turnthecylindervalve “OFF”anddonotusethegrilluntilalocalLiquidPropane
dealercan makerepairs.
WARNING
Neverattempttousedamagedorobstructedequipment. SeeyourlocalLiquidPropanedealerforrepair.
DISCONNECTINGTHELIQUID PROPANECYLINDER
1.Turnthegrillburnervalves “OFF”and makesurethegrill iscool.
2.TurntheLiquidPropaneCylindervalve “OFF”byturningclockwiseuntilit stops.
3.Detachthe regulatorassemblyfromthecylindervalvebyturningthequickcoupling nut
counterclockwise.
4.Placedustcaponcylindervalveoutlet wheneverthe cylinderis notinuse.Onlyinstallthetype of
dustcapon the cylindervalveoutletthat isprovided withthecylindervalve. Othertypesofcapsor
plugsmayresultinleakageofpropane.
LEAKTESTING
GENERAL
Although gasconnectionsonthegrill areleaktestedpriortoshipment, acompleteleaktest must be
performedattheinstallationsite.Beforeeachuse,checkallgasconnectionsforleaksusing the
procedureslisted below.
If thesmell ofgasisdetectedatanytime,youshouldimmediatelychecktheentiresystemforleaks.
BEFORETESTING
Makesureallpackingmaterialshavebeen removed fromthegrill, includingtheburnertie-downstraps.
WARNING
Checkallgassupplyfittingsforleaksbeforeeachuse. Donot usethe grilluntilall connectionshavebeen
checkedanddonotleak. Donot smokewhileleaktesting. Neverleaktest withanopenflame.
Makeasolutionofonepart liquiddetergentandone partwater.Youwill need aspraybottle, brush,or
rag toapplythesolutiontothefittings.Fortheinitialleaktest,makesuretheLiquidPropaneCylinderis
80%full.
TOTEST
1.Turntheburnervalvesoff.
2.TurntheLiquidPropaneCylindervalvecounterclockwisetoopen the valve.
3.Apply the soapsolution toallgasfittings. Soap bubbleswillappearwherealeakispresent.
4.If aleakispresent, immediately turnthegassupply “OFF”andtightenleaky fittings.
5.Turnthegasback “ON”andrecheck.
6.Shouldthegascontinuetoleakfromanyof thefittings,turnthegassupply “OFF”andcontact
customerserviceat 1-866-206-0888
7.If thereisevidenceofexcessive abrasionorwear, orthehoseiscut, itmustbe replacedpriortothe
outdoorcookinggasappliancebeing put intooperation.
Pleasemakesurethe cylindervalveconnectiondevice
properlyandsafelymateswiththeconnectiondevice
attachedtotheinletofthepressureregulator.
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn
17
Only thosepartsrecommendedbythemanufacturershouldbeusedonthegrill.Substitutionswill void
the warranty.
INSTALLER FINALCHECK
•Maintainspecifiedclearanceof24inchesfromcombustiblematerialsand construction.
•All internalpackaginghasbeenremoved.
•The hoseandregulatorareproperlyconnectedtotheLiquidPropane Cylinder.
•The unithasbeentested andisfreeofleaks.
•The gassupplyshutoff valvehasbeen located.
•All burnersareinstalled.
•Keeptheinstructionmanualforfuturereference.
Itisveryimportant tokeepyourappliance’sclearandawayfrom anycombustiblematerials.
Maintainatleast24inchesofclearancefromsides andback anddonot use underoverhead
combustibleconstruction.
WARNING
1.Storageofanoutdoorcookinggasapplianceindoorispermissibleonlyifthe cylinderisdisconnected
andremovedfromthe outdoorcookinggasappliance.
2.Cylindermust bestoredoutdoorsout ofthe reachofchildrenand mustnotbe stored inabuilding,
garage oranyotherenclosedarea.
WARNING
1.DonotstorespareLiquidPropaneCylindersunderornearthisappliance.
2.Neverfill thecylinderbeyond 80percent capacity.
3.If theinformation aboveisnot followed exactly,afire,possiblycausing seriousinjuryordeath,may
occur.
Nooverheadcombustible
construction
800
700
600
500400300
100
Fig.21
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
18
OPERATINGINSTRUCTIONS
GeneralUse of theGrill
Eachmainburnerisratedat12,000BTU/Hr. Themaingrillburnersencompass theentirecookingarea
and aresideported tominimizeblockagefromfallinggreaseanddebris.Abovetheburnersareflame
tamers. Theigniterknobsarelocatedon thecenterportionof thevalvepanel.Eachrotaryigniteris
labeled onthecontrolpanel.
UsingtheGrill
Grillingrequireshighheatforsearingandproperbrowning.Mostfoodsarecookedata “HIGH”heat
settingfortheirentirecookingtime.However,when grillinglargepiecesofmeat orpoultry,itmaybe
necessarytoturnthe heattoalowersetting aftertheinitialbrowning.Thismethodcooks the food
thoroughly without burningtheoutside.
Food cookedforalong timeorbasted withasugar-based marinademayneedalowerheatsetting near
the end ofitscooking time.
Tobegin:
1.Makesurethegrill hasbeenleaktestedand isproperlyplaced.(Seepage16.)
2.Removeanyremainingpackingmaterials.
3.Lightthe grillburnersusing the LightingInstructionsonnext page.
4.Turnthecontrolknob(s)tothe “IGNITE/ HIGH”setting, and preheatthegrill for15 minutes.The grill
lidshouldbe closedduring the pre-heat period.
5.Placethe food on the grill andcooktothedesireddegree ofpreparation.Ifnecessary,adjust theheat
setting. Thecontrolknob maybepositionedatanysetting between “HIGH”and “LOW”.
LIGHTINGINSTRUCTIONS
BeforeLighting
Inspectthegassupplyhosepriortoturningon the gas.Ifthereisevidenceofcuts,wear,orabrasion,it
must bereplacedpriortouse.
Screwtheregulator(typeQCC1)ontothecylinder,and leakcheckthehoseandregulatorconnections
beforeoperating thegrill(seethe “LeakTesting”instructionson page16).
Only thepressureregulatorandhoseassemblysuppliedwiththe unit shouldbeused.Neversubstitute
regulators.If areplacementisnecessary,contactcustomerserviceforproperreplacement.
WARNING
Donotusethe grillif the odourofgasispresent. Contactcustomerserviceat1-866-206-0888.
TOLIGHTTHEMAINBURNERS
1. Open lidduringlighting.
2. Makesureallthe knobsareinthe “OFF”position,and then turntheLiquidPropane Cylindervalve
“ON”byslowly turningcounterclockwise.
3. Pushand turnMainBurnercontrolknobtoIGNITE/HIGH, atthesametime,press andholdelectronic
ignition button tolight the burner.
4. Oncetheburnerislit,releasethe electronicignitionbuttonandknob.
5.If ignitiondoesnot occurin5seconds, turntheknobtoOFF,wait5minutesandrepeat the lighting
procedureorlight bymatch.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
19
WARNING
Whenlighting, keepyourfaceand handsasfar
awayfromthe grillaspossible.
CAUTION
Whenusingamatchtolightthe grillmakesureto
usethe attachedlighting rod.
CAUTION
Removethewarmingrack whenusingamatch
tolightthegrill.
TOMATCHLIGHTTHEGRILL
If aburnerwill notlightafterseveralattemptsusingthecontrolknobs, the burnersmaybelitwithamatch.
MainBurner
1.If you have alreadyattemptedtolight the mainburnerwiththeigniter, allow5minutesforany
accumulatedgastodissipate.
2.Insert amatchintothe lighting rodasshownFig.22.
Ignitethe matchandinsertthrough the cookinggridstotheburner.
3.If theburnerdoesnotlightwithinsecondsturntheknobtothe “OFF”position, wait5minutesand try
again.
Fig.22
IGNITE/HI
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
20
CAREAND MAINTENANCE
StainlessSteel
Therearemanystainlesssteelcleanersavailable. Alwaysusethemildestcleaningprocessfirst,
scrubbinginthedirection ofthegrain.Donotusesteelwoolasitwillscratchthe surface.Totouchup
noticeablescratchesinthe stainless steel,sandverylightlywithdry100 grit sand paperinthedirection of
the grain.
Greasespecks cangatherand bakeontothesurfacesofthestainlesssteel,givingtheappearanceof rust.
Forremoval,useanabrasivepadwithastainless steelcleaner.
Cooking Grates
The easiest waytoclean the grillisimmediatelyaftercookingiscompleted andthe flameshavebeen
turnedoff.
WearaBBQmitttoprotect yourhandfromheatandsteam.
Scrub the hotcookinggratesbydippingabristledBBQbrushintap water.Cleaningwillbemoredifficult
if thegrilliscooled off.
Grease Pan
The greasepanshouldbeemptied,wiped downandwashedaftereachusewithamilddetergentand
warmwatersolution.Checkthegreasepanfrequentlyanddonotallowexcess greasetoaccumulateand
flowout ofthegreasepan.
Grill Burners
Extremecareshouldbetakenwhen removing aburner.It mustbe correctlycenteredontheorifice
beforeanyattemptismadetorelight the grill.Frequency ofcleaningwill dependonhowoften you use
the grill.
Failuretoproperly placetheburnerovertheorificecouldcauseafiretooccurbehind andbeneaththe
valvepanel,therebydamagingthegrill andmakingit unsafetooperate.
Beforecleaning,makesurethegassupplyandcontrolknobsareinthe “OFF”positionand theburners
have cooled.
Toremovethemainburnersforcleaning:
1.Locatetheburnerscrewat the rearof thefirebox.
2.Removethescrewand lifttheburneroutofthefirebox.
Toclean thegrillburners:
1.Clean the exteriorof the burnerwithawirebrush.
Useametalscraperforstubbornstainsordebris.
2.Clearcloggedportswithastraightenedpaperclip.
Neveruseawooden toothpickasit maybreakoff
andclog theport.
3.Checkandclean burners/ venturetubesforinsects
andinsectnests. Acloggedtubecanleadtoafirebeneath,
andbehindthe maincontrolpanel.
Toreinstallthemainburners:
1. Inserttheburneroverthemainburnergasvalve(part#15on Page26).
2. Makesurethe orificestud(A)is inside the burnerventure(B)asshowninFig.23.
3. Align the burnerscrewholewiththefireboxhole,insert screwandtighten.
Fig.23
B
A
CAUTION
1.Keep outdoorcooking gasappliancearea clearand freefromcombustiblematerials,gasoline
andotherflammablevapoursand liquids.
2.Donot obstructtheflowofcombustibleand ventilationair.
3.Keep the ventilationopening(s)of the enclosurefreeandclearfromdebris.
PDF 件使用 "pdfFactory Pro" 试用版本创建 ÿwww.fineprint.com.cn
Table of contents
Languages:
Other Uberhaus Kitchen Appliance manuals
