Uberhaus WI150ITT User manual

1
INSTRUCTION MANUAL
Model: WI150ITT
42-Bottle Dual-Zone Wine Cooler
PLEASE READ AND FOLLOW ALL
SAFETY RULES AND OPERATING
INSTRUCTIONS BEFORE USING.

2
APPLIANCE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety warnings in this manual and on your appliance. Always read
and follow all safety warnings.
This is the Safety Alert Symbol. This symbol alerts you to potential hazards that
can kill or injure you and others. All safety warnings will feature the Safety
Alert Symbol and either the words “DANGER”, “WARNING” or “CAUTION”.
Danger means that failure to follow this
safety statement may result in severe
personal injury or death.
Warning means that failure to follow this
safety statement may result in extensive
product damage, serious personal injury, or
death.
Caution means that failure to follow this
safety statement may result in minor or
moderate personal injury, or property or
equipment damage.
All safety statements will alert you do what the potential hazard is, tell you how to reduce the chance
of injury, and let you know what can happen if the instructions are not followed.
CAUTION:
THIS WINE COOLER IS NOT
DESIGNED FOR THE STORAGE
OF MEDICINE OR OTHER
MEDICAL PRODUCTS.

3
IMPORTANT SAFETY GUIDELINES
Before the appliance is used, it must be properly positioned and installed as
described in this manual. The manual must be read entirely before proceeding.
To reduce the risk of fire, electrical shock or injury when using the appliance,
follow basic precautions, including the following:
•Plug appliance into a grounded 3-prong outlet, do not remove grounding prong, do not use an
adapter, and do not use an extension cord.
•Place all panels before operating.
•It is recommended that a separate circuit, serving only your appliance be provided. Use
receptacles that cannot be turned off by a switch or pull chain.
•Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or
explosion. Do not store or use gasoline or other flammable vapours and liquids in the vicinity of
this or any other appliance. The fumes can create a fire hazard or explosion.
•Before proceeding with cleaning and maintenance operations, make sure the unit is unplugged
from the power source.
•Do not connect or disconnect the electric plug when your hands are wet.
•Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result
in electrical shock or death.
•Do not attempt to repair or replace any part of your appliance unless it is specifically
recommended in this material. All other service operations should be referred to a qualified
technician.
FOLLOW WARNING CALL OUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL
•Use two or more people to move and install appliance. Failure to do so can result in back or other
injury.
•To ensure proper ventilation for your appliance, the front of the unit must be completely
unobstructed. Choose a well-ventilated area with temperatures above 60°F (16°C) and below
90°F (32°C). This unit must be installed in an area protected from the elements, such as wind,
rain, water spray or drips.
•The appliance should not be located next to ovens, grills or other sources of high heat.
•All electrical, water and drain connections of this appliance must be installed in accordance with
state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in
accordance with the National Electrical Code and local codes and ordinances is required.
•Do not kink or pinch the power supply cord of appliance.
•The fuse (or circuit breaker) size should be 15 amperes.
•It is important for the appliance to be level in order to work properly. You may need to make
several adjustments to level it.
•Never allow children to operate, play with or crawl inside the appliance.
•Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners may
damage or discolour the interior.
•Do not use this appliance for any other purpose than what was intended.

4
PARTS & FEATURES
WCV42DZ – Dual Zone Wine Cooler
1 Wine Cooler Temperature Controls
(Left Zone)
2 Interior Fan
3 Interior Light
4 Cabinet
5 Wine Cooler Temperature Controls
(Right Zone)
6 Wine Bottle Shelves (10)
7 Wine Bottle Storage
Rack / Basket (2)
8 Levelling Legs

5
IMPORTANT SAFETY INSTRUCTIONS


 WARNING 


To reduce the risk of fire, electrical shock,
or injury when using your appliance, follow
these basic precautions:
•Read all instructions before using the Wine Cooler.
•DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or abandoned
appliances are still dangerous . . . even if they will “just sit in the garage a few days”.
•Before you throw away your old Wine Cooler: Take off the door. Leave the
shelves in place so that children may not easily climb inside.
•Never allow children to operate, play with, or crawl inside the appliance.
•Never clean appliance parts with flammable fluids. The fumes can create a fire
hazard or explosion.
•Do not store or use gasoline or any other flammable vapours and liquids in the
vicinity of this or any other appliance. The fumes can create a fire hazard or
explosion.
- Save these instructions -
ELECTRICAL CONNECTIONS
This appliance should be properly grounded for your safety. The power cord of this appliance is
equipped with a three-prong plug which mates with a standard three-prong wall outlet to minimize the
possibility of electrical shock.
Do not under any circumstances cut or remove the third ground prong from the power cord supplied.
For your personal safety, this appliance must be properly grounded.
This appliance requires a standard 115 / 120 Volt AC ~/ 60Hz electrical grounded outlet. Have the
wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly grounded.
When a standard 2-prong wall outlet is encountered, it is your responsibility and obligation to have a
licensed electrician replace it with a properly grounded 3-prong wall outlet.
The cord should be secured behind the appliance and not left exposed or dangling to prevent
accidental injury.
The appliance should always be plugged into its own individual electrical outlet, which has a voltage
rating that matches the rating label on the appliance. This provides the best performance, and also
prevent overloading house wiring circuits that could cause a fire hazard from overheating. Never
unplug the appliance by pulling the power cord. Always grip the plug firmly and pull straight out from
the receptacle. Repair or replace immediately all power cords that have become frayed or otherwise
damaged. Do not use a cord that shows cracks or abrasion damage along its length or at either end.
When moving the appliance, be careful not to damage the power cord.
EXTENSION CORD
Because of potential safety hazards under certain conditions, it is strongly recommended that you do
not use an extension cord with this appliance. However, if you must use an extension cord it is
absolutely necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance extension cord
having a grounding type plug and outlet. The electrical rating of the extension cord must be 115 volts
and at least 10 amperes.



Warning



Improper use of the grounded plug can result in the risk of electrical shock.

6
INSTALLATION INSTRUCTIONS
BEFORE USING YOUR WINE COOLER
•Remove the exterior and interior packaging materials.
•Check to be sure you have all of the following parts:
Model WCV42DZ
Dual Zone Wine Cooler
10 Wine Bottle Shelves (Wire)
2 Wine Bottle Shelf / Basket (Wire)
•Before connecting this appliance to the power source, let it stand upright for approximately 2
hours. This will reduce the possibility of a malfunction in the cooling system from handling
during transportation.
•Clean the interior surface with lukewarm water using a soft cloth.
INSTALLATION OF YOUR WINE COOLER
•This appliance is suitable for an either free-standing or built-in (fully recessed) installation.
•Place your wine cooler on a floor that is strong enough to support it when it is fully loaded. To
level your wine cooler, adjust the front levelling legs located at the bottom of the appliance.
•Locate the wine cooler away from direct sunlight and sources of heat (stove, heater, radiator,
etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extreme cold ambient temperatures may also prevent the unit from performing
properly.
•Avoid locating the unit in damp areas.
•Plug the wine cooler into an exclusive, properly installed-grounded wall outlet. Do not under
any circumstances cut or remove the third prong (ground) from the power cord. Any questions
regarding power and/or grounding should be directed towards a certified electrician.
BUILT-IN CABINET INSTRUCTIONS
This appliance is suitable for an either free-standing or built-in (fully recessed) installation.
If you plan to use this unit in a built-in application please follow the requirements shown
below.
Cabinet Opening Dimensions
IN (min) CM (min)
Width 24” 61 cm
Depth 24” 61 cm
Height 34 ½” 87.6 cm

7
MODEL WI150ITT
OPERATING YOUR DUAL-ZONE WINE COOLER
It is recommended that the appliance be installed in a place where the ambient temperature is
between 72º-78ºF (22º-25ºC). If the ambient temperature is above or below recommended
temperatures, the performance of the unit may be affected. For example, placing your unit in extreme
cold or hot conditions may cause interior temperatures to fluctuate. The internal range of 40º-65ºF
(4º-18ºC) may not be reached.
Recommended Temperatures for Chilling Wine
Red Wines 58 - 65ºF 14 - 18ºC
Dry / White Wines 48 - 57ºF 10 - 13ºC
Rosé Wines 49 - 51ºF 9 – 11ºC
Sparkling Wines 40 - 47ºF 5 - 8ºC
Left Side / Zone Control Panel
Right Side / Zone Control Panel
ON/OFF POWER
To turn ON or OFF the appliance, press the button/mark and hold for 3 seconds.
SETTING THE TEMPERATURE CONTROL
You can control the internal temperature of each side/zone independently by using the control panel
for each side.
You can press the left side UP and DOWN buttons/marks to control the internal
temperature of each respective side / zone.
Temperature Ranges by Side / Zone
LEFT SIDE 45º - 65º F 7º - 18º C
RIGHT SIDE 45º - 65º F 7º - 18º C
You can select temperature display setting in Fahrenheit or Celsius, by pushing the
ºF
/
ºC
button/mark.
Fahrenheit or Celsius degrees indicator will appear in blue in the temperature display window for each
zone.

8
The degree indicators will appear in the display window.
•The set temperature will increase by 1ºF or 1ºC if you push the UP button/mark once, and will
decrease by 1ºF or 1ºC if you push the DOWN button/mark once.
NOTE:
•If the unit is unplugged, power lost, or turned off, you must wait 3 to 5 minutes before restarting
the unit. If you attempt to restart before this time delay, the wine cooler will not start.
•When you use the wine cooler for the first time, or restart the wine cooler after having been shut
off for a long time, there could be a few degrees variance between the temperature you select
and the one indicated on the LED readout. This is normal and it is due to unit reactivating after an
inactive period. Once the wine cooler is running for a few hours, everything will be back to normal.
STORAGE
Many bottles may differ in size and dimensions. As such, the actual number of bottles you may be
able to store may vary.
NOTE:
LEFT SIDE / ZONE: 21 standard bottles
RIGHT SIDE / ZONE: 21 standard bottles
TOTAL 42 standard bottles
Bottle capacities are approximate maximums when storing traditional Bordeaux 750 ml bottles and
include bulk storage.
INTERIOR LIGHT
•Interior lights are available in both zones.
•You can turn the interior light on in each zone by pushing the button marked with the “bulb”
symbol .
To turn lights off, simply push the button marked with the “bulb” symbol again.
Control Panel Lock
•Your wine cooler is equipped with an automatic control panel lock function. This function will
prevent any unwanted changes to your temperature or power settings.
•The lock function will activate automatically 12 seconds after the last time a button is pushed on
the control panel.
•To unlock the control panel lock press and hold the (UP) and the (DOWN) buttons for 3
seconds. The control panel will beep and blink once, indicating that the control panel is unlocked
and settings can be changed.

9
CARE AND MAINTENANCE
CLEANING YOUR WINE COOLER
•Turn off the power, unplug the appliance, and remove all items including shelves.
•Wash the inside surfaces with a warm water and baking soda solution. The solution should be
about 2 tablespoons (30 ml) of baking soda to a quart (1 L) of water.
•Wash the shelves with a mild detergent solution.
•Wring excess water out of the sponge or cloth when cleaning area of the controls, or any
electrical parts.
•Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with
a clean soft cloth.
•Do not use steel wool or a steel brush on the stainless steel. These scrubbers will contaminate
the stainless steel with steel particles and rusting may occur.
POWER FAILURE
•Most power failures are corrected within a few hours and should not affect the temperature of
your appliance if you minimize the number of times the door is opened. If the power is going to be
off for a longer period of time, you need to take proper steps to protect the appliance contents.
MOVING YOUR WINE COOLER
•Remove all items.
•Securely tape down all loose items (shelves) inside your appliance.
•Tape the door shut.
•Be sure the appliance stays secure in the upright position during transportation. In addition,
protect the appliance exterior with a blanket or similar item.
ENERGY SAVING TIPS
•The wine cooler should be located in the coolest area of the room, away from heat producing
appliances, and out of the direct sunlight.
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE
Wine cooler does not operate. Appliance is not plugged in.
The appliance is turned off.
The circuit breaker tripped or a fuse is blown.
Wine cooler is not cold enough. Check the temperature control setting.
External environment may require a higher setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
Appliance turns on and off frequently. The room temperature is hotter than normal.
A large amount of contents has been added to the
wine cooler.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The light does not work. Appliance is not plugged in.
The circuit breaker tripped or a fuse is blown.
The light button is “OFF”.
Vibrations. Check to ensure that the Wine Cooler is level.

10
The wine cooler seems to make too much
noise.
The rattling noise may come from the flow of the
refrigerant, which is normal.
As each cycle ends, you may hear gurgling sounds
caused by the flow of refrigerant in your wine cooler.
Contraction and expansion of the inside walls may
cause popping and crackling noises.
The wine cooler is not level.
The door will not close properly. The wine cooler is not level.
The gasket is dirty.
The shelves are out of position.
Display flashes Error message “E0” Connection failure – there is a wire or component that
is not connected correctly.
Display flashes Error message “E1” Temperature sensor failure.
Display flashes Error message “E2” Defrost sensor (coil sensor) failure.
Warranty
Thank you for purchasing this UBERHAUS product. These products have been made to demanding,
high-quality standards and are guaranteed for domestic use against manufacturing faults for a period
of 12 months from the date of purchase. This warranty does not affect your statutory rights.
For service within the warranty period, please contact the store where the product was purchased.
Product model number and proof of purchase are required for any service request. RONA reserves
the right to repair or replace the defective product, at its discretion.
For any other question, please call our toll-free service line at 1-866-283-2239, Monday to Friday from
8 AM to 6 PM, Eastern time.
Normal wear and tear, including accessory wear, is not covered under this warranty. The product is
guaranteed for 12 months if used for normal trade purposes, and is valid for the original buyer only.
Any warranty is deemed invalid if the product has been overloaded or used improperly, or subject to
neglect or attempted repairs other than by an authorized agent. Heavy-duty, daily professional or hire
usage are not guaranteed. RONA is not responsible for any costs related to labour, injuries or any
other loss incurred during the product installation, repair or replacement, including any indirect or
consequential damages.
Due to continuous product improvement, we reserve the right to change the product specifications
without prior notice.
