Ubiquiti LTU-Rocket User manual

LTU-Rocket GPS Antenna Mount External GPS Antenna
Metal Strap Zip Ties (Qty. 2) Universal Bracket
IP67 Upgrade Kit
(Vent and Gasket)
Gigabit PoE (24V, 1A) with
Mounting Bracket
Power Cord
Package Contents
Antenna Compatibility
The LTU-Rocket is designed for use with the following Ubiquiti® airMAX® Sector
antenna models* for Point-to-MultiPoint mode:
AM-5AC21-60
AM-5AC22-45
AM-V5G-Ti
AM-M-V5G-Ti
AM-5G16-120

AM-5G17-90
AM-5G19-120
AM-5G20-90
AP-5AC-90-HD
* Requires Universal Bracket (included).
Installation Requirements
Clear line of sight between LTU™ AP and stations
Clear view of the sky for proper GPS operation
Vertical mounting orientation
Mounting point:
At least 1 m below the highest point on the structure
For tower installations, at least 3 m below the top of the tower
Ground wires – min. 10 AWG (5 mm ) and max. length: 1 m. As a safety
precaution, ground the LTU radio to a grounded mast, pole, tower, or grounding
bar.
WARNING: Failure to properly ground your LTU radio will void your
warranty.
Outdoor, shielded Category 6 (or above) cabling and shielded RJ45 connectors
are required for all wired Ethernet connections.
Surge protection should be used for all outdoor installations. We recommend
that you use two Ethernet Surge Protectors, model ETH-SP-G2, one near the
device and the other at the entry point to the building. The ETH-SP-G2 will
absorb power surges and safely discharge them into the ground.
Note: For guidelines about grounding and lightning protection, follow
your local electrical regulatory codes.
2

* Shown without antenna.
Hardware Overview

LTU Antenna Connectors
GPS Antenna Connector
Used to attach RF antenna cables (not included).
Used to attach the GPS Antenna.

Signal LEDs
Link LED
GPS LED
MGMT LED
Data LED
Each LED will light when the wireless signal strength is equal to or greater than
the LED’s threshold value for the current channel width setting. The default
threshold values for each channel width are shown below:
Off RF Off
Syncing
Beaconing
Registering
On Operational
Off No GPS Synchronization
Non-Operational (Weak Signal)
On Operational (Strong Signal)
LED not used.
Off No Ethernet Link
On Ethernet Link Established

Power LED
Management Port
Reset Button
Data Port
Random Flash Ethernet Activity
Off No Power
On Powered On
Port not used.
To reset to factory defaults, press and hold the Reset button for more than 10
seconds while the device is powered on.
Gigabit PoE port for handling all user traffic and powering the device. Default
IP address: 192.168.1.20
Installation Overview
We recommend that you configure your LTU-Rocket radio before site installation.
The following sections provide detailed installation instructions. Perform these
instructions in the sequence given.
Connecting Power over Ethernet
1.
2.

3.
WARNING: Use only the included adapter, model POE-24V-5X-HD.
Failure to do so can damage the unit and void the product warranty.
LTU Configuration
Access the LTU Configuration Interface for configuration. By default, Access Point
mode is already enabled for the LTU-Rocket. You can choose to configure
settings such as Link Name, Duty Cycle, Channel Bandwidth, and Frequency.
The PTMP stations will scan and find the LTU-Rocket and do not need any
frequency set as long as they are set with the same Channel Bandwidth and Link
Name.
Configuration Using Browser-Based Interface
1. Configure the Ethernet adapter on your computer with a static IP address on
the 192.168.1.x subnet.
2. Launch your web browser. In the address field, type: http://192.168.1.20
Then press enter (PC) or return (Mac).

3. Select your Country and Language. You must agree to the Terms of Use,
EULA, and Privacy Policy to use the product. Click Continue.
4. Click the icon.
5. Configure the following settings:
a. If needed, change the Channel Bandwidth, Frequency, Output Power
(EIRP), Antenna Gain, and Max TX Modulation settings. The Channel
Bandwidth should be the same on all devices in the PtMP link.
b. In the Security Key field, enter a combination of alphanumeric characters (0-
9, A-Z, or a-z).
Note: The key is an alphanumeric password between 8 and 63
characters long.

6. Click Save Changes.
7. Configure a unique IP address for the Data port:
a. Click the icon.
b. For the Data IP Address option:
DHCP Have your router use DHCP reservation to assign a unique IP
Address.
Static Change the IP Address, Netmask, and other settings to make them
compatible with your network.
c. Click Save Changes.
Upgrade for IP67 Compliance
To protect the LTU-Rocket from intrusion by water, dust, and insects, we
recommend installing the IP67 Upgrade Kit (included):
1.
2.

Note: Do not damage or remove the post on the Port Cover.
3.
4.
5.

Hardware Installation
Installing the Ground Wire
1.
2.

3. At the installation site, secure the other end of the ground wire to a grounded
mast, pole, tower, or grounding bar.
WARNING: Failure to properly ground your LTU radio will void your
warranty.
Note: The ground wire should be as short as possible and no longer
than one meter in length.
Mount to an airMAX Sector Antenna
The LTU-Rocket is designed to mount directly onto the Ubiquiti antennas listed in
“Antenna Compatibility”. The airMAX Sector antenna AM-5AC21-60 is shown in
this section:
1.
2.

Mount the External GPS Antenna
Locate a mounting point that has a clear view to the sky, and is above and as far
away as possible from the LTU-Rocket.
1. 
OR

2.
3.
Connecting Power over Ethernet
1.

2. 
OR
Note: If the IP67 Upgrade Kit is installed, first apply dielectric grease to
the cable connector and port.
3.

WARNING: The LTU-Rocket must receive a minimum of 15W. Ensure
that the voltage range of the PoE source is within these limits:
4-pair operation: 18-54V
2-pair operation: 30-54V
OR
WARNING: Use only the included adapter, model POE-24V-5X-HD.
Failure to do so can damage the unit and void the product warranty.
Optional

Installer Compliance Responsibility
Devices must be professionally installed and it is the professional installer’s
responsibility to make sure the device is operated within local country regulatory
requirements.
Antenna
Select your antenna from the list. If Auto Output Power is enabled, transmit output
power is automatically adjusted to comply with the regulations of the applicable
country. For a Custom antenna, Antenna Gain is entered manually. Note the
requirements and antenna types listed below.
Cable Loss (When applicable)
Enter the cable loss in dB. Output power is adjusted to compensate for loss
between the radio and the antenna.
Certified Antenna Types
This radio transmitter FCC ID: SWX-LTUR / IC: 6545A-LTUR has been approved
by FCC / ISED Canada to operate with the antenna types listed below with the
maximum permissible gain for each antenna type indicated. Antenna types not
included in this list or having a gain greater than the maximum gain indicated for
that type, are strictly prohibited for use with this device.
Antenna Frequency Gain
Sector 5 GHz 22 dBi
Specifications
LTU-Rocket

LTU-Rocket
Dimensions 244 x 82 x 48 mm (9.61 x 3.23 x 1.89")
Weight 0.468 kg (1.03 lb)
RF Connectors (2) RP-SMA Weatherproof (CH0, CH1)
(1) SMA Weatherproof (GPS)
GPS Antenna External, Magnetic Base
Power Supply 24VDC, 1A Gigabit, 4-Pair Passive PoE (Included)
Power Method Proprietary Passive PoE
Pins 1, 2; 4, 5+ and Pins 7, 8; 3, 6-
Supported Voltage Range +18 to +54VDC
(Either/Both RJ45 Ports for Redundancy)
Max. Power Consumption 15W
Networking Interface
Data Port (1) 10/100/1000 Ethernet Port
Bluetooth v4.0
Management Port (1) 10/100/1000 Ethernet Port
(Reserved for Future Use)
Mounting Integrated Pole Mount (Included)
Rocket Mount Compatible
GPS Pole Mount (Included)
Operating Temperature -40 to 55° C (-40 to 131° F)
Weatherproofing IP67
Certifications FCC Part 15.407
CE EN 302502 v1.2.1, EN 301 893 v1.7.1
1 Full range depends on Ethernet cable length.
2 After installation of IP67 Upgrade Kit (included).
System
Maximum Throughput
50 MHz Capacity 675.84 Mbps
Maximum Range 100+ km
Packets per Second 2,000,000
Encryption WPA2-PSK (AES)
Forward Error Correction LDPC
Uplink/Downlink Ratio 25/75, 33/67, 50/50
OS airOS LTU
Wireless Modes AP
Radio
1
2
1

Radio
Max. Conducted TX Power 23 dBm
Frequency Accuracy < 2 ppm
Channel Bandwidth 10/20/30/40/50 MHz Selectable
Programmable Uplink and Downlink Duty Cycles
Operating Frequency (MHz)
Worldwide 4800 - 6200
US/CA U-NII-1 5150 - 5250
U-NII-2A 5250 - 5350
U-NII-2C 5470 - 5725
U-NII-3 5725 - 5850
1 May vary depending on environmental conditions.
2 Depends on regulatory region.
Bluetooth LE Management Radio (MHz)
Worldwide 2400 - 2483.5
Safety Notices
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by the manufacturer.
WARNING: Do not use this product in location that can be submerged by water.
WARNING: Avoid using this product during an electrical storm. There may be a
remote risk of electric shock from lightning.
Electrical Safety Information
1. Compliance is required with respect to voltage, frequency, and current requirements
indicated on the manufacturer’s label. Connection to a different power source than those
specified may result in improper operation, damage to the equipment or pose a fire
hazard if the limitations are not followed.
2. There are no operator serviceable parts inside this equipment. Service should be
provided only by a qualified service technician.
3. This equipment is provided with a detachable power cord which has an integral safety
ground wire intended for connection to a grounded safety outlet.
a. Do not substitute the power cord with one that is not the provided approved type.
Never use an adapter plug to connect to a 2-wire outlet as this will defeat the continuity
of the grounding wire.
b. The equipment requires the use of the ground wire as a part of the safety certification,
modification or misuse can provide a shock hazard that can result in serious injury or
2
2

death.
c. Contact a qualified electrician or the manufacturer if there are questions about the
installation prior to connecting the equipment.
d. Protective earthing is provided by Listed AC adapter. Building installation shall provide
appropriate short-circuit backup protection.
e. Protective bonding must be installed in accordance with local national wiring rules and
regulations.
Limited Warranty
ui.com/support/warranty
The limited warranty requires the use of arbitration to resolve disputes on an individual basis,
and, where applicable, specify arbitration instead of jury trials or class actions.
Compliance
FCC / CAN ICES-3(A)/NMB-3(A)
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules and ISED Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions.
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
Le présent appareil est conforme aux CNR d’ISDE Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
1. l’appareil ne doit pas produire de brouillage;
2. l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
This equipment has been tested and found to comply with the limits for a Class A digital
device. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operations of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own
expense.
IMPORTANT NOTE
Radiation Exposure Statement
This equipment complies with radiation exposure limits set forth for an uncontrolled
environment.
This equipment should be installed and operated with minimum distance 130 cm between
the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
