Ubiquiti UniFi Switch Flex Mini User manual

UniFi Switch Flex Mini Power Adapter (5V, 1A)*
Package Contents
* Included only in the single-pack of the USW-Flex-Mini.
System Requirements
Linux, Mac OS X, or Microsoft Windows 7/8/10
Java Runtime Environment 1.8 or above recommended
Web Browser: Google Chrome (Other browsers may have limited functionality)
UniFi Controller software v5.12.5 (or newer), available at: ui.com/download/uni
Hardware Overview
USW-Flex-Mini Quick Start Guide

System LED
RJ45 Link/Speed/Activity LED (Ports 1- 5)
PoE In Port
Ports 2 - 5
Flashing White Initializing.
Steady White Factory defaults, waiting for adoption.
Alternating White/Blue Device is busy; do not touch or unplug it. This usually indicates that a process such as a rmware upgrade is
taking place.
Steady Blue Successfully adopted by a network and working properly.
Flashing Blue
This is used to locate a device.
When you click Locate in the UniFi Controller software,
the System LED will ash blue. The software will also
display the location of the UniFi Switch on the map.
Off No Link
Amber Link established at 10/100 Mbps
Flashing indicates activity
Green Link established at 1000 Mbps (1 Gbps)
Flashing indicates activity
This RJ45 port supports a 10/100/1000 Mbps Ethernet connection and 802.3af/at PoE
input.
RJ45 ports support 10/100/1000 Mbps Ethernet connections.
USW-Flex-Mini Quick Start Guide

Power Port
Reset Button
Connect the included Power Adapter to the Power port.
Resets to factory defaults. The device should be running after bootup is complete. Press
and hold the Reset button for about 10 seconds until the LED starts ashing and then
becomes solidly lit. After a few seconds, the LED will turn off, and the device will
automatically reboot.
Connecting Power
OR
Connecting Ethernet
USW-Flex-Mini Quick Start Guide

Software Installation
Download and install the latest version of the UniFi Controller software at
ui.com/download/uni and follow the on-screen instructions.
Note: If you already have UniFi Controller v5.12.5 or newer installed, skip to
“Adopting the UniFi Switch” .
After you have installed the software and run the UniFi Installation Wizard, a login screen will
appear for the UniFi Controller management interface. Enter the admin name and password
that you created and click Sign In.
To adopt the UniFi Switch, proceed to “Adopting the UniFi Switch” .
You can manage your network and view network statistics using the UniFi Network Controller
management interface. For information on using the UniFi Network Controller software, refer
to the User Guide located on our website at: ui.com/download/uni
Adopting the UniFi Switch
1. From the UniFi Controller dashboard, click Devices in the left menu bar.
USW-Flex-Mini Quick Start Guide

2. On the Devices screen, locate the UniFi Switch in the list of devices under the Model
column. To adopt the UniFi Switch, click Adopt.
3. The System LED on the UniFi Switch will turn blue to conrm that it has been successfully
adopted.
Specications
USW-Flex-Mini
Dimensions 107.16 x 70.15 x 21.17 mm
(4.22 x 2.76 x 0.83")
Weight 150 g (5.29 oz)
Networking Interfaces (5) 10/100/1000 Mbps RJ45 Ports
PoE In Interface 802.3af/at PoE (Pins 1, 2+; 3, 6-)
Max. Power Consumption 2.5W
USW-Flex-Mini Quick Start Guide

USW-Flex-Mini
Power Method USB Type C, 5V
802.3af/at PoE (44 - 57VDC, 0.05 - 0.04A)
Power Supply 5V, 1A Power Adapter*
Voltage Range
USB Type C 4.7 - 5.2VDC
802.3af/at PoE 44 - 57VDC
LEDs
System Status
RJ45 Data Ports Link/Speed/Activity
ESD/EMP Protection ± 16kV Air, ± 12kV Contact
Operating Temperature -5 to 45° C (23 to 113° F)
Operating Humidity 10 to 90% Noncondensing
Certications CE, FCC, IC
* Included only in the single-pack of the USW-Flex-Mini.
Safety Notices
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specied by the manufacturer.
WARNING: Failure to provide proper ventilation may cause re hazard. Keep at least 20 mm of
clearance next to the ventilation holes for adequate airow.
WARNING: To reduce the risk of re or electric shock, do not expose this product to rain or
moisture.
WARNING: Do not use this product in location that can be submerged by water.
WARNING: Avoid using this product during an electrical storm. There may be a remote risk of
electric shock from lightning.
Electrical Safety Information
1. Compliance is required with respect to voltage, frequency, and current requirements indicated on the
manufacturer’s label. Connection to a different power source than those specied may result in
improper operation, damage to the equipment or pose a re hazard if the limitations are not followed.
2. There are no operator serviceable parts inside this equipment. Service should be provided only by a
qualied service technician.
Limited Warranty
ui.com/support/warranty
The limited warranty requires the use of arbitration to resolve disputes on an individual basis, and, where
applicable, specify arbitration instead of jury trials or class actions.
USW-Flex-Mini Quick Start Guide

Compliance
FCC
Changes or modications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions.
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
ISED Canada
CAN ICES-3(B)/NMB-3(B)
Australia and New Zealand
CE Marking
CE marking on this product represents the product is in compliance with all directives that are applicable
to it.
WEEE Compliance Statement
Online Resources
USW-Flex-Mini Quick Start Guide
