SAFETY GUIDELINES
CONTENTS
䡵SAFETY GUIDELINES .....................4
1

SAFETY GUIDELINES
WARNING!
ALWAYS drive safely with your hands on the
steering wheel. You have full responsibility and
assume all risks related to the use of the
Uconnect® features and applications in this ve-
hicle. Only use Uconnect® when it is safe to do so.
Failure to do so may result in an accident involv-
ing serious injury or death.
Ensure that all persons read this manual carefully before
using the radio system. It contains instructions on how to
use the system in a safe and effective manner.
•Glance at the screen only when safe to do so. If
prolonged viewing of the screen is necessary, pull over
at a safe location.
•Stop use immediately if a problem occurs. Failure to
do so may cause injury or damage to the product.
Return it to your authorized dealer to repair.
•Make certain that the volume level of the system is set
to a level that still allows you to hear outside traffic
and emergency vehicles.
•The law in some states/provinces prohibits the Front
Seat DVD Viewer. As a result, it may be disabled prior
to delivery to you. If you move to another state/
provinces, you should consult your dealer for the
proper enable/disable setting for your new area.
4 SAFETY GUIDELINES

INTRODUCTION
CONTENTS
䡵WARNINGS ............................6
䡵SAFETY REFERENCES.....................6
䡵INTENDED USE .........................6
䡵SYSTEM CARE ..........................6
▫Software Update........................6
▫Safe Usage Of The Radio System ............6
▫Connections ...........................7
▫Touchscreen ...........................7
▫CD/DVD Drive ........................7
▫GPS Navigation Antenna — If Equipped.......8
▫Satellite Radio Antenna — If Equipped ........8
▫Other Electronic Devices ..................8
2

WARNINGS
This manual contains WARNINGS against operating
procedures that could result in an accident or bodily
injury. If you do not read the entire manual, you may
miss important information. Observe all WARNINGS!
The information given in this manual is subject to change.
SAFETY REFERENCES
Before operating this system for the first time, please read
this manual carefully. Note the safety precautions de-
scribed in this manual. If you have any questions, please
contact the vehicle manufacturer or your authorized dealer.
INTENDED USE
Generally recognized rules of radio technology were
maintained during the development and manufacture of
the radio system. When using this product, be aware of
state/province-specific norms and guidelines.
Visit
DriveUconnect.com for updates, additional infor-
mation, compatible phones, etc.
SYSTEM CARE
Software Update
Both navigation data and Gracenote® data are software
updatable. Visit DriveUconnect.com or contact your
authorized dealer for the latest available software.
Safe Usage Of The Radio System
Read all instructions in this manual carefully before
using your radio system to ensure proper usage!
Your radio is a sophisticated electronic device. Do not let
young children use your radio.
Permanent hearing loss may occur if you play your music
or the radio at loud volumes. Exercise caution when
setting the volume on your radio.
6 INTRODUCTION

NOTE: Many features of this radio are speed dependent
and it is not possible to use the touchscreen keyboard
while the vehicle is in motion.
Keep drinks, rain, and other sources of moisture away
from your radio. Besides damage to your radio, moisture
can cause electric shocks as with any electronic device.
NOTE: In a convertible vehicle, the system performance
may be compromised with the roof top down.
Connections
Never force any connector into the ports of your radio.
Make sure your connectors are the correct shape and size
before you connect.
Any attached cable should be routed so that it will not
apply any pressure to the connection.
Do not use a USB device which will interfere with the
operation of opening the display.
Touchscreen
Do not touch the screen with any hard or sharp objects
(pen, USB stick, jewelry, etc.) which could scratch the
touchscreen surface!
NOTE: It is possible to use a plastic stylus for touch-
screen enabled devices such as a PDA and Pocket PCs.
Do not spray any liquid or caustic chemicals directly on
the screen! Use a clean and dry micro fiber lens cleaning
cloth to clean the touchscreen.
If necessary, use a lint-free cloth dampened with a
cleaning solution, such as isopropyl alcohol, or an iso-
propyl alcohol and water solution ratio of 50:50. Follow
the solvent manufacturer’s precautions and directions.
CD/DVD Drive
Do not insert any damaged, warped, scratched or dirty
CDs or DVDs into the CD/DVD player.
2
INTRODUCTION 7

Discs that have been modified with an adhesive label
should not be used in the CD/DVD player.
Do not insert more than one CD/DVD at a time into the
drive slot.
Do not insert anything other than the supported CD/
DVD formats. See the Disc Mode section in this manual
for information on supported CD/DVD formats.
GPS Navigation Antenna — If Equipped
The antenna for the navigation GPS system is mounted in
various locations (depending on the vehicle model)
within the dashboard or on the roof of the vehicle. Do not
place items on the dashboard or around the GPS antenna
location. Objects placed within the line of sight of the
antenna will decrease performance. Do not place items
directly on or above the antenna.
Satellite Radio Antenna — If Equipped
The antenna for the SiriusXM Satellite radio is mounted
on the roof of the vehicle. Do not place items on the roof
around the roof top antenna location. Objects placed
within the line of sight of the antenna will cause de-
creased performance. Larger luggage items should be
placed as far from the antenna as possible. Do not place
items directly on or above the antenna.
Other Electronic Devices
You may bring other electronic devices into your vehicle
(e.g., PDA, iPod®, laptop computer, etc.). Some of these
devices may cause electromagnetic interference with the
GPS. If a degradation in the navigation system is ob-
served, turn the devices off, or keep them as far away
from the GPS antenna as possible.
8 INTRODUCTION

GENERAL HANDLING
CONTENTS
䡵USER INTERFACE ELEMENTS ..............10
▫Buttons On The Touchscreen ..............10
▫Buttons On The Faceplate ................10
䡵STEERING WHEEL AUDIO CONTROLS — IF
EQUIPPED ............................13
▫AM/FM/SAT Operation .................14
▫HDD/Disc/USB/iPod®/BTSA Operation .....14
▫VIDEO ENTERTAINMENT SYSTEM (VES™)
OPERATION .........................14
䡵AUDIO SETTINGS .......................14
▫Volume .............................14
▫Audio Control Menu ....................14
3
