ProductDescription
1.Within the infrared sensing range of the human body, the alarm
data can be reported to the host when a person walks back and
forth, and the host will push the alarm information to the
mobile phone APP to achieve the function of real-time alarm;
2.Within the infrared sensing range of the human body, when a
person walks back and forth, the associated lights can be
automatically turned on to achieve linkage.

① Detectionwindow
② Batterycompartment
③ Networkaccessbutton

InstallationInstructions

Installationrequirements
1.Theinfrareddetectionsensitivityisthehighestwhenitmoves
horizontallyrelativetothedetectionwindowofthedevice,andthe

Instruction Manual
sensitivityistheworstwhenitmovesvertically,soyoushouldchoosea
suitableinstallationpositionwheninstalling.
2.Theequipmentshouldnotbeinstalledinplaceswherethefoundation
isnotfirm,andtheequipmentshouldnotshakeafterinstallation.
3.Becausetheequipmentissensitivetoairconvectionandtemperature,
theinstallationlocationshouldavoidclosetocoldandheatsourcesand
placeswithlargeairconvection:suchasvents,airconditioners,electric
heaters
4.Theequipmentshouldbeabletolookdirectlyintotheprotectedarea,
andthereshouldbenoobstaclestoavoiddetectingblindspots.
5.Theequipmentcannotdirectlyfacethefluorescentlamp
6.Installationheightfrom2.2mto2.5m
InstallationSteps
1.Removethebatterycoverasshownbelow,andremovethebattery
isolationsheet


Instruction Manual
2.Way1
Usematching3Mgluetofixitinplace.Theinstallationdiagramisas
follows:

3.Way2：
Usethebrackettoconnect,clipthebrackettothedevicebayonet,
thenusethematchingscrewstofixtheuniversalbasetoaproper
position,andfinallyclampthedevicetotheuniversalbase.The
installationdiagramisasfollows:

4. Productdirectionadjustment

Instruction Manual
Thesensitivityoftheproductismostsensitivewhenthehumanbody
movesverticallyrelativetothebattery


APPinstructions
UIOT smart home APP remote control
1. Install UIOT smart home APP
Scan the qr code with your mobile phone to download the "UIOT smart home" APP,
or search for "UIOT smart home" in the APP market to download and install.
2. Add equipment
Premise: acquire UIOT intelligent server, power on and network;Power on the
device to be added.
Step 1: open and log into the UIOT "smart home" APP.
Step 2: enter "my" - "equipment management" - "+", find and click "Infrared Body
Sensor", according to the APP prompt, insert the card pin into the mesh hole
for 3 seconds and release.
Step 3: after setting the device name and room, complete the addition.
3. APP control
Through the "UIOT smart home" APP, you can:
1) Check the current device alarm and fault status.
2) Set the device state as the linkage trigger source to realize automatic control
of the device.
3) Pay attention to the system control, and then the APP of the system control
device will receive the notification.

Instruction Manual
4) Get help, mine - help, get more guidance to use.
4.Delete device
In the case of the net, long press the shortlist button for 8 seconds.
TechnicalSpecifications
Product size：φ76.5×31mm
Working voltage：2 AA batteries
Working temperature：-10~45℃
Working humidity: <95% RH (no condensation)
Communication mode：ZigBee
Communication distance:50-80m(Open and unobstructed)
Detection distance:≤5m
Detection angle：120°
Notice
1. There are fragile components in the product, please avoid destructive actions
such as dropping, heavy pressure, etc.;
2. The product contains precision electronic components, so pay attention to
waterproof and avoid high temperature during use;
3. Do not let foreign objects fall into the machine;
4. Do not disassemble or modify the machine in any way;
5. The mains power supply must be cut off during the installation process to
avoid accidents;
6. Wiring strictly in accordance with the product wiring diagram;
7. Do not press the device hard during the wiring process to avoid damage to
the device;
8. When fixing the bottom shell, do not press hard to avoid damage to the shell;
9. Do not install the equipment in a humid environment.
Warranty
Warranty Policy Service Commitment
According to the national three guarantees regulations, with valid bills and
warranty certificates,
Enjoy the following three packs of services:
1. If the product has performance failure within 7 days from the date of sale,
the user can choose to return, exchange or repair for free
2. Within 15 days from the date of sale, if the product has a performance failure,
the user can choose to exchange it or repair it for free (after the exchange,

Instruction Manual
the three guarantee period of the product itself will be recalculated.)
3. If the product has a performance failure within 1 year from the date of sale,
the user can choose free maintenance service
4. After the warranty period, if the product has performance failure, the user
can choose toll repair service
Non-warranty regulations
Within the validity period of the three guarantees, in the following situations
(not limited to the following situations), you will not bear the responsibility
of the three guarantees.
However, reasonable maintenance fees should be provided.
1. No valid bills and three packs of certificates
2. Unauthorized alteration of the three guarantee certificate
3. The product name, model, and code on the invoice or three-guarantee
certificate does not match the actual product
4. Failure to properly use, maintain, and store in accordance with the product
instruction manual causes damage or failure
5. The user (not the party responsible for the three guarantees) repairs, damages
or malfunctions caused by improper disassembly
6. Damage or malfunction not caused by product quality problems
7. Machine failure beyond the warranty period
8. Damage or malfunction caused by force majeure
