Ulti Mate U4 Instruction manual

1
Owner’s Manual
Owner’s Manual
Document No. 98-1450A5 •June 2017 • ©2017 Atlantic Ultraviolet Corporation®• ASSEMBLED IN THE USA
Read and Follow All Safety Instructions. Save These Instructions.
Installation,
Operation
& Maintenance
Models U4, U7, U9 & U15
Extensive Product Information Available at:
ultraviolet.com
buyultraviolet.com

2
TABLE OF CONTENTS
SAFETY WARNINGS ...........................................................................................................................................................3
SAFETY INSTRUCTIONS .................................................................................................................................................. 3
SAFETY LABELING............................................................................................................................................................3
CAUTION...............................................................................................................................................................................3
PRODUCT APPLICATION .................................................................................................................................................4
ConstruCtion ........................................................................................................................................................................................4
PrinCiPle of oPeration ........................................................................................................................................................................4
limitation of use..................................................................................................................................................................................4
Water Quality .....................................................................................................................................................................................4
unPaCking ..............................................................................................................................................................................................5
INSTALLATION ...................................................................................................................................................................5
loCation .............................................................................................................................................................................5
Dimensional Data...............................................................................................................................................................6
reCommenDeD installation .............................................................................................................................................7-9
grounD kit installation ................................................................................................................................................. 10
MAINTENANCE................................................................................................................................................................. 10
insPeCtion ......................................................................................................................................................................... 11
Quartz sleeve installation, Cleaning or rePlaCement ................................................................................................ 11
rePlaCement of Broken Quartz sleeve.......................................................................................................................... 12
lamP installation rePlaCement ...................................................................................................................................... 13
DisPosal of merCury aDDeD lamP ..................................................................................................................................13
OPTIONAL ACCESSORIES ............................................................................................................................................. 13
TROUBLESHOOTING ......................................................................................................................................................14
TECHNICAL SPECIFICATIONS.....................................................................................................................................14
REPLACEMENT PARTS................................................................................................................................................... 15
USER ASSISTANCE ........................................................................................................................................................... 16
PRODUCT REGISTRATION ............................................................................................................................................16
WARRANTY ........................................................................................................................................................................ 16
Patent notiCe...................................................................................................................................................................16
These instructions generally describe the installation, operation and maintenance of the UltimateTM line of water purifiers,
Models U4, U7, U9 and U15. Questions that are not specifically answered by these instructions should be directed to the Factory.
Atlantic Ultraviolet Corporation®takes all possible precautions when packaging equipment to prevent damage. Carefully inspect
and report all damage upon receipt of product. Do not install damaged equipment.
Follow all instructions on all labels and tags. Carefully inspect all packing materials before discarding to prevent the loss of
accessories, mounting hardware, spare parts or instructions.
The information and recommendations contained in this publication are based upon data
collected by the Atlantic Ultraviolet Corporation®and are believed to be correct. However, no
guarantee or warranty of any kind, expressed or implied, is made with respect to the information
contained herein. Specications and information are subject to change without notice.

3
SAFETY WARNINGS
SAFETY INSTRUCTIONS
• All personnel should be alerted to the potential hazards indicated by the product safety labeling on this unit.
• The following conventions are used to indicate and classify precautions in this manual and on product safety labeling. Failure to
observe precautions could result in injury to people or damage to property.
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
To guard against injury, basic safety precautions should be observed, including the following:
1. Read and follow ALL safety instructions.
2. Do not use this water purifier for other than its intended purpose as described in this manual.
3. Do not alter design or construction.
4. Do not remove any labels or devices.
5. To prevent the risk of severe or fatal electrical shock, special precautions must be taken since water is
present near electrical equipment. Always disconnect power before performing any service or maintenance.
6. Avoid exposure to direct or reflected germicidal ultraviolet rays. Germicidal ultraviolet rays are
harmful to the eyes and skin.
7. Intended for indoor use only. The water purifier should be protected from the elements and from temperatures below freezing.
8. Do not operate water purifier if lamp cable, lamp connection, power cord and/or plug are damaged, or if any other damage to
the water purifier is visible or suspected
9. Electrical power supplied, to the water purifier, MUST match power requirements listed on the water purifier.
10. Plug the water purifier only into an approved ground fault circuit interrupt (GFCI) receptacle.
11. Do not operate without proper electrical ground.
12. Do not exceed water purifier’s maximum rated flow capacity.
13. Do not exceed maximum operating pressure of 100 PSI.
14. Read and follow all notices and warnings on the water purifier.
15. SAVE THESE INSTRUCTIONS.
This symbol/pictorial is used to identify the need to
wear protective gloves.
!
Caution indicates a POTENTIALLY
hazardous situation, which, if not avoided,
MAY result in minor or moderate injury.
Caution used without the safety alert symbol in-
dicates a potentially hazardous situation, which,
if not avoided, may result in property damage.
This symbol/pictorial is used to identify an
ULTRAVIOLET LIGHT hazard.
This symbol/pictorial is used to identify an
ELECTRICAL SHOCK or ELECTROCUTION
Warning indicates a POTENTIALLY
hazardous situation, which, if not avoided,
COULD result in death or serious injury.
This symbol/pictorial is used to identify the need to
wear approved ultraviolet blocking eyewear. This symbol/pictorial is used to identify the need to wear
approved ultraviolet blocking face shield.
This symbol/pictorial is used to identify components
which must not be disposed of in trash
Danger indicates an IMMINENTLY
hazardous situation, which, if not avoided,
WILL result in death or serious injury.
SAFETY LABELS CAUTION
Danger Label: Hazardous Voltage
and Ultraviolet Radiation (00-0199A1)
It is the user’s responsibility to determine and validate the
suitability of this equipment for use in the user’s system or
process.
No warranty or representation is made by the manufacturer
with respect to suitability or performance of this equipment
or to the results that may be expected from its use.
The user should periodically inspect, clean as necessary
and confirm the presence and good legibility of the product
safety labels. Contact the factory for replacement labels in
the event that any of the labels are missing or illegible.
Date: 7/1/10
Model No: Ultimate U15 (120V 50/60Hz)
Part No: 25-8315A1
Location of Danger Label
(00-0199A1)

4
PRODUCT APPLICATION
ConstruCtion
• The water purifier is designed to mount vertically.
• The water purifier’s chamber is passivated and electropolished type 304 Stainless Steel.
• The water purifier has a flow control valve inserted in the inlet fitting of the chamber.
• Translucent plug provides indication of germicidal lamp operation.
PrinCiPle of oPeration
The UltimateTM design has been carefully conceived to provide adequate germicidal dosage throughout the disinfection chamber.
The dosage, as it applies to ultraviolet disinfection, is a function of time and the intensity of ultraviolet radiation to which the
water is exposed. The exposure time, in seconds, is the total time it takes the water to flow through the disinfection chamber
exposing it to the germicidal lamp. Exposure time is related to the flow rate; the higher the flow rate, the lower the exposure time
or the lower the flow rate, the higher the exposure time. The ultraviolet intensity is the amount of energy, per unit time, emitted by
the germicidal lamp. The dosage is the product of ultraviolet intensity and the exposure time. The operation of the UltimateTM is
as follows:
• Water enters the purifier and flows into the annular space between the quartz sleeve and the chamber wall.
• Suspended microorganisms are exposed to the ultraviolet rays emitted by the germicidal lamp.
• The LED indicator light, located on the ballast, and the translucent plug on top of chamber provides visual indication of
germicidal lamp operation.
• Water leaving the purifier is instantly ready for use, no further contact time is required.
limitation of use
The water purifier is intended for the use with visually clear water, not colored, cloudy or turbid. See “Water Quality” section
below. The water purifier is NOT intended for the treatment of water that has an obvious contamination or intentional source,
such as raw sewage; nor is the unit intended to convert wastewater to microbiologically safe drinking water.
Water Quality
Water quality plays a major role in the transmission of germicidal ultraviolet rays. It is recommended that the water does not
exceed the following maximum concentration levels:
Table 1 - Maximum Concentration Levels
Turbidity < 1 NTU
Manganese 0.05 mg/1
Total Suspended Solids 10 mg /1
pH: 6.5 - 9.5
Color: None
Hardness 6 GPG or 102.6 PPM
Iron 0.3 mg/1
Tannins: < 0.1 ppm (0.1 mg/l)
UV Transmission >85% per cm*
* Contact Factory for recommendations on applications where UV transmission is < 85%
Effectively treating water with higher concentration levels than listed above can be accomplished, but may require added
measures to improve water quality to treatable levels. If, for any reason, it is believed the ultraviolet transmission is not
satisfactory, contact the factory.

5
UNPACKING
• Remove the UltimateTM Ultraviolet Water Purifier from its shipping carton.
• Atlantic Ultraviolet Corporation®takes all possible precautions when packaging this unit to prevent damage. Carefully
inspect the disinfection chamber, lamp cable, lamp connection, power cord and plug for damage, report all damage
immediately. Do not assemble or operate if there is any damage, visible or suspected.
• Germicidal lamp is packed separate in a cardboard tube, to ensure maximum protection in shipping. Keep aside until ready
for installation.
• Quartz sleeve is packed separate in a cardboard tube, to ensure maximum protection in shipping. Keep aside until ready for
installation.
• Carefully inspect all packing materials to prevent the loss of accessories, mounting hardware, and spare parts.
• Do not discard packing materials until unit is assembled and check out is complete.
INSTALLATION
loCation
1. The water purifier is intended for indoor use only. The water purifier is designed to mount vertically. The water purifier
should be protected from the elements and from temperatures below freezing. The ambient temperature, in the area
surrounding the water purifier, should be between 35oF and 100oF.
2. The water purifier must be connected to the cold water line only. Inlet water temperature should not exceed 100º F.
3. Electrical power supplied to the water purifier MUST match power requirements listed on the water purifier. Use of a voltage
surge protector is recommended.
4. Install water purifier within 48” of a known good ground. Water Purifier will need to be installed into approved
ground fault circuit interrupt (GFCI) receptacle. Where a 2-prong or unprotected 3-prong receptacle is encountered, it must
be replaced by a properly grounded Ground Fault Circuit Interrupt (GFCI) receptacle. Installation must be in accordance
with the National Electrical Code and any local codes and ordinances by a qualified electrician.
5. The water purifier should be located in a dry, well-lit area, which provides enough room to perform routine maintenance.
The UltimateTM is designed to mount in a vertical position, with the gland end up. Unit must be mounted to a secure wall or
structure using the brackets provided. It is not recommended to have the unit solely supported by the plumbing to the unit.
(The quartz sleeve and lamp are removed from the gland end.) Allow a service area of at least one chamber length from the
gland end, for replacement of the lamp or cleaning/replacing quartz sleeve, as well as a minimum of 6” on the opposite end of
the water purifier. Minimum clearance to the floor 18’’
6. Choose a location for your UltimateTM unit that is isolated from vibration. Vibration will damage lamp and lead to
premature system failure.
7. The water purifier should be located closest to the point of use. This eliminates the possibility of purified water being
re-contaminated by bacteria in the water distribution system after purification.
8. If your system is subject to water hammer conditions, it is recommended that you install a water hammer suppressor. Water
hammer may cause damage to the O-Ring seal.
9. As with any water handling device, the purifier should be located in an area where any possible condensation or
leakage from the purifier, accessories and/or plumbing will not result in damage to the purifier or to the area surrounding the
purifier. For added protection, it is recommended that a suitable drain pan be installed under the purifier. The drain
pan must be plumbed to an adequate, free flowing drain to prevent water damage in the event of a leak. There are
numerous leak detection/flood stop devices, available on the market today, designed to stop the flow of water, reducing
the chance of water damage due to leakage. For more details regarding leak prevention and/or limiting damages due
to leaks, please contact the factory. (Continued on Page 6)
The UltimateTM Ultraviolet Water Purifier includes:
• 1 - Disinfection Chamber
• 1 - STER-L-RAY ®Germicidal Ultraviolet Lamp
• 1 - Surelite®Ballast manufactured for UltimateTM
• 1 - CRYSTAL CLEARTM Quartz Sleeve
• 1 - O-Ring
• 1 - Teflon®Washer
• 1 - PromateTM Static Gland Nut
• 2 - Mounting Brackets (Upper & Lower)
• 1 - Bracket Nut
• 1 - Owner’s Manual
• 1 - Grounding Kit

6
Table 2 - Ultimate®Dimensional Data
Model A B C D E F G H J K
U4 3-7/8” Dia. 2-7/8” 1/4” Dia. 14-11/16” 1-1/2” 3” 14-11/16” 3/4” MNPT 17-5/8” 10-3/4”
U7 5-3/4” Dia 3-1/2” 1/4” Dia. 15-1/8” 2-1/8” 4-1/4” 14-3/4” 3/4” MNPT 17-7/8” 10-9/16”
U9 5-3/4” Dia. 3-1/2” 1/4” Dia. 19-3/8” 2-1/8” 4-1/4” 18-15/16” 3/4” MNPT 21-1/8” 14-17/32”
U15 5-3/4” Dia. 3-1/2” 1/4” Dia. 33-5/8” 2-1/8” 4-1/4” 33-3/8” 1” MNPT 36-1/2” 28-1/2”
All specifications, dimensional data, etc are approximate and subject to change without notice.
10. The water purifier should be located after all other water devices, such as De-ionizers, Water Softeners, Carbon Filters, Pre-
Filters, Reverse Osmosis, Pressure Tanks, and Pumps. This reduces the chance of the purified water being re-contaminated by
bacteria in any of these units.
11. Flow direction - water enters the unit through the lower fitting and exits through the upper fitting. The flow control is
mounted in the lower (inlet) fitting.
12. Installation requires a 5-micron sediment filter be installed, in line, prior to the water purifier. The sediment filter will stop or
trap any particulates from entering the water purifier. Particulates may cause deposit on the quartz sleeve as well as interfere
with the purifier’s ability to disinfect the water. The sediment filter may also help to reduce the amount of routine cleaning of
the quartz sleeve.
13. Shut off valves and unions should be installed on both the inlet and outlet sides of the water purifier. The use of bypass valves
is not recommended. The shut off valves allow the purifier to be isolated from the water supply, which is required when
removing the quartz sleeve.
Dimensional Data
Figure 1 - Dimensional Drawing

7
reCommenDeD installation
Figure 2 -Recommended Installation
Note: Drain Pan Recommended. Water purier should be installed at minimum of 18” above oor
Note: Use of Metal Pipe is recommended for connection to both the purier inlet and outlet 12” past the rst elbow (avoids ultraviolet degradation of exposed plastic pipe)

Incoming Water Supply
COMMON PRE-TREATMENT or PUMPING DEVICES
1. Deionizer 2. Water Softener 3. Carbon Filters (GAC) 4. Pressure Tank 5. Pump 6. Reverse Osmosis 7. Prefilters
Cold Water Line
Ultraviolet Water Purifiers should be installed closest to the point of use. (POU)
5 Micron Filter
Valve Union
Elbow
Elbow
OPTIONAL EQUIPMENT
Flow Control Valve
POINT OF USE (POU)
Ultraviolet Water Purifiers
should be installed closest
to the point of use.
Ultraviolet
Water Purifier
Outlet Line to point of use to be as short as possible
Recommended Minimum
Clearance for Lamp or
Quartz Sleeve Removal




Union








Valve
OPTIONAL EQUIPMENT
Mounting Kit


Model DIM. "X"
MIN 1 10
3
/
8
"
MIN 1.5 14
15
/
16
"
MIN 3 12
7
/
8
"
MIN 6 22" MIN 9 29"
Use of Metal Pipe is
recommended for 12"
past elbow to the inlet
or from the outlet.
(avoids ultraviolet degradation
of exposed plastic pipe)
22"
WARNING: Grounding kit must be installed. See “Grounding Kit Installation” in the “Installation” section for proper instructions.

8
installation - stePs 1 to 10
Step 1 - Install bottom bracket
Step 2C - Secure the top bracket to the
mounting surface
Step 4 - Place O-Ring over end of quartz sleeve
until seated against the static gland nipple
Step 6B - Firmly tighten the static
gland nut by hand
Step 8 - Lower, DO NOT DROP, ultraviolet
lamp into quartz sleeve
Step 2A - Install top bracket and bracket nuts
Step 3A - Slowly slide quartz sleeve into the
disinfection chamber
Step 5 - Place Teflon® washer over quartz
sleeve until it rests on O-Ring
Step 7A - Insert the lamp part of the way into
the disinfection chamber
Step 9 - Thread translucent sight port plug into
static gland nut and hand tighten
Step 2B - Place chamber & top bracket
assembly onto the bottom bracket
Step 3B - Carefully guide quartz sleeve until it
seats into bottom center of water purifier
Step 6A - Install static gland nut over quartz
sleeve and onto static gland nipple
Step 7B - Attach the lamp socket
connector to the lamp
Step 10 - Install Grounding Kit, Plumb unit,
and plug ballast into an approved Ground
Fault Circuit Interrupt (GFCI) receptacle

9
installation
Always disconnect power to the unit, before performing any service or maintenance.
Lamp and quartz sleeve are easily damaged. Exercise care when removing or replacing.
NOTE: Screws are needed to secure water purifier to mounting surface and ARE NOT included. Please use screws
appropriate for the mounting surface.
• Unpack the water disinfection chamber and components following the steps in the “Unpacking” section on Page 5.
• Be sure that you have read and followed all the instructions mentioned in the “Location” section on Page 5.
• To allow for adequate room for installation and maintenance of the UltimateTM Ultraviolet Water Purifier refer to
“Dimensional Data” Figure 1 and Table 2 on Page 6.
• Use the “Dimensional Data” Figure 1 on Page 6, to mark the location of the bracket mounting pattern on the surface where
the unit will be mounted. (Refer to Dimensions “D”, “E”, & “F”.)
For added protection, a suitable drain pan must be installed under the purifier. The drain pan must be
plumbed to an adequate, free flowing drain to prevent water damage in the event of a leak. There are numerous leak
detection/flood stop devices, available on the market today, designed to stop the flow of water, reducing the chance of
water damage due to leakage. For more details regarding leak prevention and/or limiting damages due to leaks, please
contact the factory.
Installation Steps 1 to 10
1. Install the bottom bracket to the mounting surface (with screws not included). The lip of the bracket should face down.
2. Place top bracket over the static gland nipple where the lip of the bracket faces up (refer to “Dimensional Data” Figure 1
on Page 6 ). Install bracket nut onto the static gland nipple so that it holds the bracket against the top of the chamber - hand
tighten only. Place the chamber & top bracket assembly onto the bottom bracket. (Upward facing fingers on the lower bracket
straddle the bottom rim of the chamber.) Align the top bracket so that it faces the mounting surface and is in line with the
bottom bracket. Secure the top bracket to the mounting surface (with screws not included).
3. Slowly slide the quartz sleeve into the disinfection chamber, guiding it through the gland fitting until it seats into bottom
center of water purifier. NOTE: Use care to keep the quartz sleeve parallel to the chamber. Angling the quartz sleeve in any
direction could result in the breakage of the quartz sleeve.
4. Place the O-Ring over the end of the quartz sleeve and push the O-Ring down the quartz sleeve until it is seated against the
static gland nipple.
5. Place the Teflon®washer over the quartz sleeve until it rests on the O-Ring.
6. Install the static gland nut over the quartz sleeve and onto the static gland nipple. Be careful when installing static gland nut.
Firmly tighten the static gland nut by hand. Hand tightening will provide the required seal. DO NOT USE HAND TOOLS,
tightening with hand tools is likely to cause the quartz sleeve to break.
7. Insert the lamp part of the way into the disinfection chamber, then attach the lamp socket connector to the lamp; make sure
the connector is fully seated on the ultraviolet lamp. Carefully slide the lamp into the quartz sleeve.
8. Lower, DO NOT DROP, the ultraviolet lamp into the quartz sleeve so that the lamp is resting at the
bottom of the quartz sleeve.
9. Thread the translucent sight port plug (connected to the lamp socket connector) into the static gland nut and hand tighten.
10. Install Grounding Kit following the instructions in the “Grounding Kit Installation” on page 10.
• Plumb unit following the recommended installation in “Unit Installation” Figure 2 on page 7.
• When all plumbing connections are complete, allow water to enter the water purifier at a low flow rate, until the purifier is
full. With the purifier pressurized, it should be checked for leaks. If the unit leaks, make sure that the static gland nut is firmly
tightened. DO NOT use seal compounds to stop the leak. If the leak continues, close the inlet shut-off valve; release the
pressure on the unit and drain. Inspect the quartz sleeve for damage. Be sure that the O-Ring and Teflon®washer are on in the
correct order on the quartz sleeve (not inside the static gland nut).
• Re-pressurize unit and check for leaks. Once it is determined that there are no leaks, the inlet valve can be full opened.
• Once the plumbing hook ups are made, it is good practice to disinfect the “downstream” plumbing between the purfier and
point of use. This is done by introducing chlorine or other disinfectant solution directly into the purifier chamber, a 100 parts
per million of chlorine is suggested. (Continued on Page 10)
IN ORDER TO PERFORM THIS TASK, BE SURE TO WEAR THE FOLLOWING SAFETY
EQUIPMENT: SAFETY GOGGLES OR A FACE SHIELD, AS WELL AS GLOVES

10
• (Continued from Page 9) With the disinfectant solution in the purifier chamber, turn the ultraviolet purifier on.
Open the “down-stream” outlet until a chlorine or disinfectant solution odor is noticed. Close the outlet and allow the
disinfectant to remain in the plumbing for at least three (3) hours. Flush the plumbing with ultraviolet purified water;
allow the water purifier to run for a minimum of 5 minutes before use to ensure no chlorine or disinfectant solution smell
can be detected. This will allow the chlorine or disinfectant solution to be flushed through the pipe.
• Plug the ballast into an approved Ground Fault Circuit Interrupt (GFCI) receptacle. Where a 2-prong or
unprotected 3-prong receptacle is encountered, it must be replaced by a properly grounded Ground Fault Circuit Interrupt
(GFCI) receptacle. Installation must be in accordance with the National Electrical Code and any local codes and ordinances
by a qualified electrician.
Avoid exposure to direct or strongly reflected germicidal ultraviolet rays. Germicidal ultraviolet rays
are harmful to the eyes and skin.
GrounDinG Kit installation
Photo 3 - Copper wire in contact with
the screw and bolt on unit
Photo 2 - Front view of copper pipe
with ground placement
Photo 1 - Side angle view of copper
pipe with ground placement
To ensure proper operation and safety of your water purifier, your unit must be grounded to a known good ground.
Purpose: To permanently connect a ground wire from the water purifier chamber to a known ground.
Placement: Select a location that is visible as well as accessible. Connect the ground strap to a known ground or a water pipe that
is metallic, with no intervening plastic fittings between it and the power ground. An electrician can measure the resistance between
the water pipe and an electrical outlet ground to ensure your ground selection is correct.
Installation:
1. Wrap the copper strap tight around the pipe and line-up the strap end hole with another hole on the copper strap as well as a
hole on the brass colored “S” clip.
2. Pull strap as tight as possible to ensure contact between the strap and the pipe.
3. Insert the bolt threw both copper holes and into the threaded hole on the brass colored “S” clip.
4. Remove 5/8” of the ground wire insulation and insert into the bolt hole as shown and install the screw.
5. Ensure that the strap is securely fastened to the pipe and that the copper wire is in contact with the screw and bolt.
MAINTENANCE
The water purifier is designed to operate with a minimal amount of maintenance, providing the water quality does not exceed
maximum concentration levels, see “Water Quality” in the “Product Application” section. Ordinary maintenance consists of;
• Lamp replacement is recommended every 10,000 hours of operation, approximately 12 months of continuous service.
• Cleaning of the quartz sleeve, when conditions warrant. It is recommended that the inspection of quartz sleeve be performed
after one month of use. If quartz sleeve is found to be coated (not clear), then frequency of cleaning must be done more often.
Deposits or discoloration on the surface of quartz sleeve are caused by excessive levels of the subject contaminant within
the water that is in contact with the quartz sleeve. Most deposits on the quartz sleeve are caused by an excess of calcium
(hardness), iron or manganese. Table 1 on Page 4 lists the maximum recommended concentration of these minerals in the
water that passes through the ultraviolet purifier. If you encounter difficulty due to deposits on the quartz sleeve, your dealer
will be able to recommend suitable pretreatment to reduce or eliminate the offending contaminant. If quartz sleeve is clean
(clear) then frequency of cleaning may be extended.
• Always disconnect the water supply and completely drain the water purifier if it will be subjected to temperatures below
• Contact factory with questions.
freezing.

11
insPeCtion
1. Regularly inspect the water purifier to ensure that the germicidal lamp is still in operation.
SureliteTM Electronic Ballast designed specifically for the UltimateTM line of water purifiers, includes an LED that
provides visual indication (Green and Red LED Indicators) of the germicidal ultraviolet lamp operation and a PromateTM
Audio Alarm that alerts the user to lamp failure. The Electronic Ballast does not indicate the level of ultraviolet intensity or
transmission through the water.
2. To ensure proper operation of the water purifier, regular biological testing of the purifier output water should be performed
on a schedule recommended by local public health authorities, or at minimum; at installation, quarterly for the first year of
service and annually, at lamp replacement, for the life of the water purifier.
3. Additional testing should be performed whenever modifications, change or additions are made to plumbing system, pumps,
well source water etc. to ensure adequate disinfection under new condition.
4. As with any water purifier installation, routine maintenance is necessary to ensure your equipment is operating correctly.
Regular inspection must also include the inspection of the ground to ensure grounding wires are secure to both the water
purifier and grounding point as originally installed. Regular inspection must also include confirmation that approved ground
fault circuit interrupt (GFCI) receptacle is still operational and that water purifier is plugged into this GFCI. Any components
which are damaged, or broken should be replaced.
Quartz sleeve installation, CleaninG or rePlaCement
Figure 3 - Quartz Sleeve Exploded View
Always disconnect power to the unit, before performing any service or maintenance.
Lamp and quartz sleeve are easily damaged. Exercise care when removing or replacing.
1. Disconnect power to water purifier.
2. Shut off water supply to water purifier via inlet and outlet shut off valve. Drain chamber.
3. Remove lamp, following the steps in “Lamp Replacement” section on page 13.
4. Unscrew static gland nut from end of the chamber. Avoid striking quartz sleeve with static gland nut.
5. Remove Teflon®washer and O-Ring from end of quartz sleeve. Teflon®washer will sometimes remain within the static gland
nut. If so, remove Teflon®washer from static gland nut before proceeding.
6. Carefully remove quartz sleeve from chamber.
7. Once the quartz sleeve is removed, moisten a clean, lint-free cloth with denatured alcohol or a mild, non-abrasive detergent
and clean quartz. Stubborn stains usually can be removed with dilute hydrochloric acid. NOTE: Follow all manufacturer’s
instructions and precautions when handling chemicals
8. Reassemble in reverse order. Be sure O-Ring is placed on quartz sleeve before Teflon®washer.
9. Tighten static gland nut firmly by hand only, DO NOT USE HAND TOOLS. Tightening with hand tools is likely to cause
the quartz sleeve to break.
10. When all connections are complete allow water to enter the water purifier at a low flow rate until the purifier is full. With the
purifier pressurized, it should be checked for leaks.
11. If no leaks occur, install lamp, following the steps in “Lamp Replacement” section on page 13.
Germicidal ultraviolet rays are harmful to eyes and skin. Do not restore power to water
purifier until quartz sleeve, lamp and connections have been properly reinstalled.
IN ORDER TO PERFORM THIS TASK, BE SURE TO WEAR THE FOLLOWING SAFETY
EQUIPMENT: SAFETY GOGGLES OR A FACE SHIELD, AS WELL AS GLOVES

12
Broken Quartz is SHARP. It is recommended that protective goggles and gloves are worn when handling
broken quartz sleeve.
1. Disconnect power to water purifier.
2. Shut off water supply to water purifier via inlet and outlet shut off valve. Drain chamber.
3. Remove the lamp following the steps in “Lamp Replacement” section on page 13.
4. Unscrew static gland nut from end of the chamber. Avoid striking quartz sleeve with static gland nut.
5. Remove Teflon®washer and O-Ring from end of quartz sleeve. Teflon®washer will some times remain within the static gland
nut. If so, remove Teflon®washer from static gland nut before proceeding.
6. Carefully remove as much of the broken quartz sleeve as possible.
7. To remove fragments of quartz sleeving, hold the purifier vertically and shake. The quartz fragments will break and drop out
of the purifier through the gland fitting. Flush water through chamber being careful to remove all quartz fragments from the
interior of the chamber.
8. Carefully discard all pieces of the broken quartz sleeve.
9. Align the end of the quartz sleeve with the gland fitting of the chamber.
10. Carefully slide the quartz sleeve into the chamber, guiding it through the gland fitting until it seats into bottom center of water
purifier. NOTE: Use care to keep the quartz sleeve parallel to the chamber, angling the quartz sleeve in any direction could
result in the breakage of the quartz sleeve.
11. Re-install O-Ring, Teflon®washer, and static gland nut. Be sure O-Ring is placed on quartz sleeve before Teflon®washer.
Tighten static gland nut firmly by hand only, DO NOT USE HAND TOOLS. Tightening with hand tools is likely to cause
quartz sleeve to break.
12. When all connections are complete allow water to enter the water purifier at a low flow rate until the purifier is full. With the
purifier pressurized, it should be checked for leaks.
13. If no leaks occur, reinstall lamp, following the steps in “Lamp Replacement” section on page 13.
Germicidal ultraviolet rays are harmful to eyes and skin. Do not restore power to water
purifier until quartz sleeve, lamp and connections have been properly reinstalled.
rePlaCement of BroKen Quartz sleeve
Figure 4 - Quartz Sleeve Exploded View
IN ORDER TO PERFORM THIS TASK, BE SURE TO WEAR THE FOLLOWING SAFETY
EQUIPMENT: SAFETY GOGGLES OR A FACE SHIELD, AS WELL AS GLOVES

13
Broken Quartz is SHARP. It is recommended that protective goggles and gloves are worn when handling
broken quartz sleeve.
1. Disconnect power to water purifier.
2. Remove lamp from cardboard packing tube.
3. Shut off water supply to water purifier via inlet and outlet shut off valve.
4. Unscrew translucent plug from static gland nut. DO NOT USE HAND TOOLS
5. Carefully remove lamp from chamber.
6. While holding lamp end, disconnect lamp socket from the lamp.
7. Reinstall in reverse order
Germicidal ultraviolet rays are harmful to eyes and skin. Do not restore power to water
purifier until quartz sleeve, lamp and connections have been properly reinstalled.
DisPosal of merCury aDDeD lamPs
Germicidal ultraviolet lamps, like standard fluorescent lamps contain small amounts of mercury. Mercury added
lamps should not be placed in the trash. Dispose of properly. For further information regarding the disposal and
recycling of lamps containing mercury, along with Federal and State requirements visit www.lamprecycle.org. For
more information on germicidal ultraviolet lamps, visit Ultraviolet.com or BuyUltraviolet.com.
OPTIONAL ACCESSORIES
SENTRYTM Safety Sensor: Indicators provide constant visual monitoring of normal operation. In the event of ballast or lamp
failure the safety sensor indicates an alarm condition. The safety sensor is capable of operating an optional audio alarm
and/or solenoid valve.
PromateTM Time Delay Mechanism: Provides a 2-minute warm up period during which the ultraviolet lamp achieves its full
germicidal output before the water is allowed to flow through the water purifier. The time delay mechanism is used in conjunction
with, and is electrically connected to the Solenoid Valve.
PromateTM Solenoid Valve: Operated in conjunction with the Safety Sensor or Time Delay Mechanism, this valve prevents water
flow through the water purifier when an abnormal condition is detected or in the event of power failure.
PromateTM Elapsed Time Indicator: A non-resettable display of the water purifier operating hours. Useful for scheduling and
recording maintenance and lamp replacement.
PromateTM Safety Goggles: Safety eyewear should be used as general-purpose safety protection and for additional shielding
from ultraviolet rays.
PromateTM Face Shield: Adjustable headgear and lightweight visor provides eye and face protection from
germicidal ultraviolet rays.
lamP installation or rePlaCement
Figure 5 - Lamp Replacement
IN ORDER TO PERFORM THIS TASK, BE SURE TO WEAR THE FOLLOWING SAFETY
EQUIPMENT: SAFETY GOGGLES OR A FACE SHIELD, AS WELL AS GLOVES

14
TROUBLESHOOTING
Table 3 - Troubleshooting
Problem Possible Cause Corrective Action
Purifier not operating No electrical power Verify that the purifier is connected to a live power
source.
Water leaking from purifier
Cracked or broken quartz sleeve
Shut down purifier, drain, and replace quartz sleeve.
See “Quartz Sleeve Installation, Cleaning or
Replacement” or “Replacement of Broken Quartz
Sleeve” in the “Maintenance” section.
Quartz sleeve sealing O-Ring (s) worn, damaged
Shut down purifier, drain, and remove static gland
nut, replace sealing O-Ring. See “Quartz Sleeve
Installation, Cleaning or Replacement” in the
“Maintenance” section.
Poor, or loose, connections or fittings
Tighten suspect connection or fitting; or shut down
purifier, drain, and remove fitting or connection. Clean
threads; reapply thread sealing tape and reinstall.
Poor purifier disinfection performance
Quartz sleeve fouled
Clean quartz sleeve, see “Quartz Sleeve Installation,
Cleaning or Replacement” in the “Maintenance”
Section.
Germicidal lamp output depreciating
Replace lamp, as it nears its end of life (EOL).
See “Lamp Installation or Replacement” in the
“Maintenance” section.
Germicidal lamp not functioning Replace lamp. See “Lamp Installation or
Replacement” in the “Maintenance” section.
Low input voltage Verify input voltage to purifier.
Change in water quality
Have water tested to confirm that it does not exceed
maximum recommended concentration levels for use
with this purifier.
Ballast No. 10-0505B Has Lamp-out Protection
If power is applied to the ballast without a lamp connected to the circuit or if the lamp fails, the ballast’s lamp-out protection
will prevent the ballast from operating, and a red LED light will illuminate and audio alarm will sound. To reset: disconnect the
ballast from power and reconnect or replace the lamp. The ballast must remain disconnected from power for (2) minutes to
reset. After 2 minutes restore input power, ballast should resume proper operation.
The equipment that this ballast is used with requires connection to a known good ground. It is the User’s
responsibility to ensure that their equipment is properly grounded in compliance with the National Electrical Code and any
applicable local codes. Equipment wiring and hook up should be performed by a qualified, licensed electrician. Failure to comply
with this requirement could result in serious injury or death.
TECHNICAL SPECIFICATIONS
Table 4 - Technical Specifications
Model: U4/120 U7/120 U9/120 U15/120
Flow Rate (GPM): 47915
Inlet\Outlet Size: 3/4”M NPT 3/4”M NPT 3 /4”M NPT 1”M NPT
Length: 4-15/16” 6-13 /16” 6-13 /16” 6-13 /16”
Width: 3-7/8” 5-3/4” 5-3/4” 5-3/4”
Height: 18-9/16” 18-7/8” 23-1/16” 37-1/2”
Chamber Diameter: 3-7/8” 5-3/4” 5-3/4” 5-3/4”
Shipping Weight: 9 Lbs 10 Lbs 11 Lbs 16 Lbs
Voltage: j120V 50/60Hz 120V 50/60Hz 120V 50/60Hz 120V 50/60Hz
Power Consumption: k20 Watts 20 Watts 24 Watts 45 Watts
Max Operating Pressure: 100 PSI 100 PSI 100 PSI 100 PSI
Ambient Temperature: 35° F - 100° F 35° F - 100° F 35° F - 100° F 35° F - 100° F
Always disconnect power to the water purifier before performing any service or maintenance
IMPORTANT: This unit is to be serviced ONLY by qualified, and appropriately licensed, personnel.
j
k
220v 50/60Hz
are also
available.
Consult factory.
Total power
consumption,
including ballast loss
(based on 120v).
All specifications,
dimensional data etc.
are approximate and
subject to change
without notice.

15
REPLACEMENT PARTS
Figure 6 - Exploded View U4, U7, U9 and U15
Table 5 - Replacement Parts
Item No. Description Quantity U4 U7 U9 U15
1 A SureliteTM Ballast 120v Red/Green Alarm 1 10-0505B 10-0505B 10-0505B 10-0505B
1 B SureliteTM Ballast 220v Red/Green Alarm 1 10-0152A 10-0152A 10-0152A 10-0152A
2STER-L-RAY ®4 Pin Single Ended Lamp 1 05-0640A 05-0640A 05-0641A 05-0642A
3 Static Gland Nut 1 25-8105D 25-8105D 25-8105D 25-8105D
4Teflon®Washer 1 00-0229A 00-0229A 00-0229A 00-0229A
5 O-Ring Buna-N 1 00-8300A 00-8300A 00-8300A 00-8300A
6 Bracket Nut 1 25-8106B 25-8106B 25-8106B 25-8106B
7CRYSTAL CLEARTM Quartz Sleeve 1 15-8110A1 15-8110A2 15-8110A3 15-8110A4
8 Wall Bracket (Top) 1 25-8108B 25-8111B 25-8111B 25-8111B
9 Disinfection Chamber 1 25-8136A 25-8137A 25-8138A 25-8139A
10 Wall Bracket (Bottom) 1 25-8107A 25-8112A 25-8112A 25-8112A
11 Jam Nut ¼-20” 2 50-1388 50-1388 50-1388 50-1388
12 ¼” Lock Washer 1 50-1330 50-1330 50-1330 50-1330
13 Grounding Kit * 1 35-8300A 35-8300A 35-8300A 35-8300A
All specifications, dimensional data, etc are approximate and subject to change without notice.
*Ground kit includes Item No. 11 & 12

16
USER ASSISTANCE
WARRANTY
We warrant that this product will be free from defects in material and workmanship for a period of one year from the date of
shipment thereof or the product’s total rated life, whichever first occurs. Within the warranty period we shall repair or replace
such products, which are returned to us with shipping charges prepaid, and which are determined by us to be defective. This
warranty will not apply to any product, which has been subjected to misuse, negligence, or accident; or misapplied; or modified;
or repaired by unauthorized persons; or improperly installed.
The Buyer shall inspect the product promptly after receipt and shall notify us at our main office in writing of claims, including
claims of breach of warranty, within thirty (30) days after the Buyer discovers or should have discovered the facts upon which
the claim is based. Failure of the Buyer to give written notice of a claim within the time period shall be deemed to be a waiver
of such claim.
The provisions of the above warranty are our sole obligation and exclude all other remedies or warranties, expressed or implied,
including warranties of merchantability and fitness for a particular purpose, whether or not purposes or specifications are
described herein. We further disclaim any responsibility whatsoever to the customer, or to any person, for injury to person,
damage to, or loss of property or value caused by any product which has been subjected to misuse, negligence, accident; or
modified or repaired by unauthorized persons; or improperly installed.
Under no circumstances shall the Atlantic Ultraviolet Corporation®be liable for any incidental, consequential or special damages,
losses or expenses arising from the contract for this product, or in connection with the use of, or inability to use, our product for
any purpose whatsoever.
Patent notiCe
No attempt has been made to determine the patent status of applications illustrated or described in this publication. Inclusion
in this publication of any design or method of use, which may be patented, is not to be construed as promoting or sanctioning
unauthorized use.
Atlantic Ultraviolet Corporation®
makes every effort to ensure that
the UltimateTM Ultraviolet Water
Purifiers are products of superior
quality and workmanship. This manual
describes the installation, operation
and maintenance of the UltimateTM
Ultraviolet Water Purifiers
Please read and become familiar with
the contents of this manual before
installing or using this unit. If after
reading the manual you still have
questions, or concerns, regarding the
installation or use of this unit, contact
our offices, weekdays between 8:30 am
and 5:00 pm Eastern Time, at:
Atlantic Ultraviolet Corporation®
375 Marcus Boulevard
Hauppauge, New York, 11788
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
Website: www.ultraviolet.com
www.buyultraviolet.com
PRODUCT REGISTRATION
Please REGISTER your product immediately - you can do this in a number of ways. Go online to Ultraviolet.com and on the
bottom left of each page either click on “Fill out Warranty Reg. Form on-line!” complete and hit submit or click on “Download a
PDF of the Warranty Reg. card” which you can print, fill out and mail in. If you prefer to register over the telephone please call
631-273-0500.
Atlantic Ultraviolet Corporation®takes all possible precautions when packaging equipment to prevent damage. Carefully inspect
and report all damage. Do not install damaged equipment. Follow all instructions on any labels or tags. Carefully inspect all
packing materials before discarding to prevent the loss of accessories, mounting hardware, spare parts or instructions.
For your convenience, record the following information below. The model and serial number can be found on a label located on
the UltimateTM Ultraviolet Water Purifier. Keep this manual, along with proof of purchase, handy when contacting our offices.
Purchased From: Date:
Model: Serial No.:
