ULTIMATRON FRANCE POWERCUBE ULT-1500 User manual
POWERCUBE
ULT-1500
USER MANUAL
Thank you for purchasing our energy storage series products. Please read the user’s
manual carefully before using the product and keep it well. This manual helps you to operate
this equipment correctly. But this is not an introduction to hardware and software configura-
tion. For any product configuration, please refer to the relevant contract or consult your
dealer. The pictures in this manual are for reference only, thank you.
CAUTION
PACKAGE CONTENTS
1. ULT-1500 2. AC CHARGING LINE
3. USER MANUAL 4. BAG
1
INTRODUCTION
SPECIFICATION
1485Wh (25.6V/58Ah)
LiFePO4
Pure Sine Wave
16kg
370x311.5x235mm
PD 100W ( 5V/3A 9V/3A 12V/3A 15V/3A 20V/5A)2x USB-C
AC
4x USB-A QC3.0 ( 5V/3A, 9V/2A,12V/1.5A) per port Max.18W
1x Car Socket
2x DC5521
13.6V/8A, Max 108.8W
13.6V/8A, Max 108.8W
Peak Power：
1600W/1 minutes
2000W/1 seconds
AC 200-240V~ 50Hz
Rated Power: 1500W
AC 100-120V~ 50/60Hz
Rated Power: 1500W
Capacity
N.W net weight
Size
Battery Type
Input
Inverter Waveform
AC Output
DC Output
700W Max. ( 90~120V/60Hz ) 1000W Max. ( 200~240V/50Hz )
XT60 / Solar 12-30V/Max 10A ( Max 300W )
DC 5521 12-28.5V/Max 7A ( Max 200W )
Total share 8A Max
US/JP
4*AC output port
EU/AU
4*AC output port
2
14
2
3
5
6
7
8
4
1
9
10
12
13
11
DC Output Port
DC ON/OFF Switch
Car Socket
DC Input Port
1
2
3
4
AC Input Port
Solar Input Port
AC ON/OFF Switch
AC Output Ports
5
6
7
8
LCD Display
USB ON/OFF Switch
QC3.0 USB-A Ports x4
PD100W USB-C Ports x2
9
10
11
12
Main Power Button
Ground Connection
13
14
LCD DISPLAY
3
1
2
3
5
4
12
17
11
6
18
10
13
7
8 9
14 15 16
2
3
5
Battery Information
indication
Input indication
Protection indication
Battery Power Level
Battery lock protection
6
Battery high/low
temperature indication
1
4
Battery Power Level %
Battery failure/Low
voltage indicate
7
811
10
Input power
Output indication
DC/ Car Outlet Output
AC Output Icon
USB-C Output
Icon
9
USB-A Output
Icon
Output power
Remaining time
indication
12
13
14
15
16
17
18
Remaining discharge
charge time
Minutes
Hours
Functional failure
Low temperature
indication
Over temperature
indication
System failure
indication
Overload protection
indication
Over temperature
protection indication
If there is no operation for 3 minutes when the product is working, the screen automatically
turn off and the power indicator enter into " breathing light”mode. Click the On/off button to
light on the screen, the power indicator enter into the“on” mode. When switch on the porta-
ble power station with all the output port swith off and without charge. The portable power
station will switch off automatically if there is no any other opretations within 10 mintures
During the operation, you can press the On/Off button to light on/off the screen display at
any time.
The screen will not automatically turn off the display when there is any protection start-up-
prompt or abnormal alert. The screen automatically turn off function will only be activated
after the fault is solved.
CAUTION
Under the condition that the total power does not exceed 1500W, all AC outlets can work
togehter at the same time.
1. Long press the main power button 3S to turn on. The main power indicator and the screen
lights up, enters the standby state.
2. Plug in AC appliances.
3. Press the AC on/off switch to turn on the AC output function. The product starts to supply
power to external AC appliances.
4. Long press the AC power on/off switch to turn off the AC output.
5. When not using the product for a long time，please long press the main power switch for
3S to turn off to save power.
HOW TO USE THE AC OUTPUT FUNCTION
4
AC
ON/OFF
HOW TO USE USB OUTPUT
HOW TO USE DC OUTPUT
1. Long press the main power button to turn on.The main power indicator and the screen lights
up, enters the standby state.
2. Press the USB on/off switch to turn on the USB function.
3. Plug in the USB devices and start to use.
1. Long press the main power button to turn on.The main power indicator and the screen lights
up, enters the standby state.
2. Plug in the DC devices.
3. Press the DC on/off switch to turn on the DC function.
4. After use, press the DC on/off switch to turn off the DC output.
5. When not using the product for a long time，please long press the main power switch for
3S to turn off to save power.
5
HOW TO CHARGE
> Please charge the ULT-1500 before using.
> Please fully charge the battery before long storage.
Please check the ULT-1500 remaining power level every 3 months and full recharge it again.
> There are 3 input ports on the Portable Power Station: 1* AC Input Port, 1* solar panel input
port and 1* DC5521 port.
1. Super Quick charging：AC Input (AC power supply can be used to charge Portable Power
Station with a maximum power of 1000W through the AC charging port.).
2. Solar charging.
3. Car charging.
6
SOLAR PANEL SERIES/PARALLEL
CHARGING
Portable Power Station support Solar Panel charging Max 300W.
You can purchase solar panels and dedicated cable accessories that match the Portable
Power Station to achieve a high-power solar fast charging experience.
The maximum voltage of solar panels that Portable Power Station can support is 30V, and
the maximum current is 10A.
It must be charged by solar panels with a voltage lower than 30V.
The input voltage exceeding 30V has the risk of damaging the product.
7
CAUTION
ATTENTION:
8
FAQS
DAILY USAGE TIPS
WARRANTY
No, because this product is a products with battery, according to international air transporta-
tion standards and regulations, battery capacity products cannot exceed 100Wh.
Because this product uses an air-cooled system, the built-in fan can better help the product to
dissipate heat, so it is normal for a slight noise to occur.
1. Can the product be taken on the plane?
Because the product has a low power, it needs to be fully recharged and used again.
2. The consumers’power is within the rated output power range of the
Portable Power Station but cannot be used ?
3. Why is there a noise sometimes ?
The portable power station needs to be stored in a dry environment, and the correct storage
method can prolong the service life of the portable power station.
4. How do I store the product when it's not in use?
Please use a dry non-abrasive cloth to wipe. Do not wipe directly with a wet cloth or chemical
solvent. If you want to wipe it more cleanly, we recommend that you use a cotton swab with a
small amount of absolute alcohol to wipe. Do not expose the product to large amounts of
water.
5. How do I clean the product if it is dirty?
1. This product uses high-quality original lithium-ion batteries, no memory effect, large capaci-
ty, and durable. Recommended to use it within the range of 10°C ~ 30°C to get the best
charging performance.
2. Please stay away from TV, radio and other equipment to avoid interference when charging.
3. Please disconnect the power cord and keep it if not to use this device for long time.
The Ultimatron PowerCube ULT-1500 provides an 24-months warranty
CAUTION
1. Do Not store this device together with coins, jewelry, keys and other metal objects to avoid
short circuit.
2. Keep away from heat, don't throw it in fire water or other liquids, high temperature, including
direct sunlight.
3. This equipment is not suitable for people with reduced physical, sensory or mental abilities
or lack of experience and knowledge (including children), unless the person responsible for
their safety supervises or guides their use of the equipment.
4. Children should be supervised and guided if to use this device, to avoid any safety issues.
5. The device may become hot while charging, which is normal. Do not cover the device with
towels, clothing or other items.
6. Please dispose of the waste according to the regulations, and do not dispose of the built-in
battery as domestic garbage to avoid explosion.
7. This product is only used for emergency energy storage power supplies, and cannot replace
standard DC or AC power supplies for household appliances or digital products.
8. There is a non-removable rechargeable battery inside your device. Do not try to remove the
battery, otherwise the device may be damaged.
Recharge device every 3 months Use original certified cable No contact with liquids
Do not disassemble Prevent from falling Prevent from high temperature
9
