ULTIMEA Nova S70 User manual

Nova S70
Model No.: U3920
Nova S70 3.1.2 Channel Dolby Atmos Soundbar
EN: User Manual
DE: Benutzerhandbuch
JP: ユーザーマニュアル
FR: Manuel de l'Utilisateur
IT: Manuale d'uso
ES: Manual del usuario

Contents
06 Benutzerhandbuch Deutsch
01 User Manual English
Connection and Installation 02
11 ユーザーマニュアル 日本語
接続と設置 12
16 Mode d'Emploi Français
Raccordement et installation 17
21 Manuale d'uso Italiano
Connessione e installazione 22
26 Manual del usuario Español
Conexión e instalación 27
Anschluss und Installation 07

Soundbar
2 SOUNDBAR CONTROLS
Subwoofer
Power Adaptor HDMI Cable Stereo 3.5mm to RCA
Audio Cable
1
Remote Control
Digital Optical
Cable
Wall Mounted Kit Wall Bracket
2
User Manual
1
2
HDMI Adaptor
“ ”: Volume Down
Control Panel
“ ”: Power Button
Press to power on / Hold for 3 seconds to power off.
1
“ ”: Input Mode
Press to switch channels: eARC-HD IN (HDMI IN)-
OPT (OPTICAL)-BT-AUX-USB.
2
3“ ”:
“ ”: Volume Up
4
5
Press to switch to Bluetooth channel and enter pairing
mode. Hold for 3 seconds to disconnect the current
device and connect to a new device manually on your
mobile phone / PC / TV (BT ID: Nova S70).
BT
4321 5
3920
Nova S70
6-pin Cable for
Soundbar Connection (140mm)
Nova S70
Model No.: U3920
Prefer video tutorial?
WE ARE
READY
TO HELP [email protected]
support.ultimea.com
[phone] (US) Mon-Fri 9am-5pm (PST)
[phone] (EU) Mon-Fri 9am-5pm (CET)
1 ACCESSORIES LIST
User Manual
01
@ultimea_official
Setup guidance video, or
USER MANUAL on ULTIMEA
website.
4
1
1 1 1 1

02
8“ ”: Volume Up
9“ ”: Volume Down
14
Press to adjust bass level, the display will show :
“ ”: BASSMAX
15 “ ”: Mute / Recover the volume.
Remote Control
10
For BT and USB mode only: Skip to previous track.
“ ”: Previous
11
For BT and USB mode only : Skip to next track.
“ ”: Next
Press to switch among Movie, Dialogue, Music mode, the display will
show: “ ”, “ ”, “ ”.
6“ ”: EQ
Press to switch channels: eARC-HD IN (HDMI IN)-OPT (OPTICAL)-BT-AUX-USB.
7“ ”: INPUT
12 “ ”: Play / Pause
For BT and USB mode only.
USB mode: Hold for 3 seconds to switch between single loop playback
and list loop playback.
14
1
2
3
8
5
10
9
13
15
12
7
6
4
11
3
“ ”: BT
1
Press to power on / Hold for 3 seconds to power off.
“ ”
:
Power Button
“ ” : e ARC
Press to switch to HDMI eARC channel.
2
5
Press to switch to OPTICAL channel.
4“ ”: OPT
Press to switch to Bluetooth channel and enter pairing mode.
Hold for 3 seconds to disconnect current device and connect to a new
device manually on your mobile phone / PC / TV (BT ID: Nova S70).
Press to switch to HDMI IN channel.
“ ”: HD IN
13
Press to adjust upward-ring sound level, the display will
show: “ ”, “ ”, “ ”.
“ ”: Dolby Atmos
AUX
OPT
USB
SUB OUT
DC IN
HDMI OUT (eARC)
HDMI IN
3 SOUNDBAR INSTALLATION
Assembly Steps
Set the two parts of the Soundbar on the same
level and align the connection joints. Connect
the two parts by pushing parallelly to combine
as one piece.
Plug in 6pin Cable.
1
2
Step 1
Step 2
”, “ ”, “ ”.”, “”, “
“

AUX
OPT
USB
SUB OUT
DC IN
HDMI OUT (eARC)
HDMI IN
5 CONNECT TO TV VIA HDMI OUT eARC / ARC
AUX
OPT
USB
SUB OUT
DC IN
HDMI OUT (eARC)
HDMI IN
Note: Please turn on the “CEC” function on your TV.
When eARC / ARC is connected, your TV remote control can control the soundbar and TV simultaneously:
Turn on / off Adjust the volume
eARC / ARC
HDMI
Note:
Make sure your TV HDMI supports eARC, otherwise the Dolby Atmos audio signal cannot be transmitted.
Atmos: If you are watching a movie in the Dolby Atmos format, please set the audio output on your TV to Pass Through:
TV Settings > Home > Settings > Sound > Digital Audio Output > Pass Through
DTS: If you are watching a movie in the DTS format, please set the audio output on your TV to PCM：
TV Settings > Home > Settings > Sound > Digital Audio Output > PCM
Step 1:
Connect one end of the HDMI cable to the
eARC / ARC port on the back of your TV.
Step 2:
Then connect the other end into the HDMI
OUT (eARC) port of the soundbar.
Step 3:
Press “eARC” button on the remote control
to select “HDMI OUT (eARC)” input.
HDMI OUT (eARC)
What’s the difference between: HDMI IN, HDMI ARC, HDMI eARC?
HDMI IN is a standard HDMI input that allows you to connect devices to your TV or audio system. It supports audio and video signals, but it does not
support audio return channel (ARC) or enhanced audio return channel (eARC) functionality.
HDMI ARC is a special HDMI port that supports two-way communication between your TV and audio system. This means that audio can be sent from
your TV to your audio system, and audio system can send audio back to your TV.
HDMI eARC (Enhanced Audio Return Channel) is an updated version of HDMI ARC that supports higher quality audio formats such as Dolby Atmos
and DTS:X.
1 2
03
4 CONNECT TO SUBWOOFER
6 CONNECT TO OTHER DEVICE VIA HDMI IN
AUX
OPT
USB
SUB OUT
DC IN
HDMI OUT (eARC)
HDMI IN
SUB OUT
AUX
OPT
USB
SUB OUT
DC IN
HDMI OUT (eARC)
HDMI IN
HDMI IN
(eARC / ARC)
HDMI OUT
HDMI IN
HDMI OUT(eARC)
Step 1: Connect the HDMI Cable to the HDMI OUT (eARC) port on the Soundbar and the other
end to the eARC / ARC port on the TV.
Step 2: Connect the HDMI cable to the HDMI OUT port on the other device (Such as DVD or
game consol) and the other end to HDMI IN port on the Soundbar.
Step 3: Press " " button on Soundbar or Remote Control to switch to HDMI IN channel.
Note: Your TV HDMI needs to support eARC to transmit the Dolby Atmos audio format
to your Soundbar.
Step 1
Step 2
Step 3

AUX
OPT
USB
SUB OUT
DC IN
HDMI OUT (eARC)
HDMI IN
AUX
OPT
USB
SUB OUT
DC IN
HDMI OUT (eARC)
HDMI IN
7 CONNECT TO TV VIA OPTICAL / AUX
OPTICAL
OPTION 1: OPTICAL
Make sure the cable is connected to OPTICAL OUT port
on your TV, and the other end to OPTICAL port on the
Soundbar.
Make sure the optical plug is inserted correctly as it
shows in the picture. Do not insert the plug upside down
and break the optical.
DIGITAL AUDIO
OUT
OPTICAL
OPTICAL
AUX
OPTION 2: AUX
Connect the 3.5mm to RCA audio cable to connect
to your TV's RCA AUDIO OUT port.
Make sure the color of the cables ends matches the
color of the TV ports.
AUX
AUDIO OUTPUT
RL
AUDIO IN
RL
In Optical Mode: If there is no sound, try setting the TV audio output to PCM: TV Settings > Home > Settings > Sound > Digital Audio Output > PCM
04
1
2
1
2
Note: lf audio is coming from the internal TV speakers,
mute or minimize the TV volume.
Note: Please remember to unplug the AUX cable from
TV and Soundbar when you want to switch other mode.
Note: The soundbar should be placed at or near ear level.
8 CONNECT TO BLUETOOTH
Press the “ ” button on the soundbar or remote control to enter Bluetooth pairing mode.
Open your phone’s Bluetooth settings, nd and select “Nova S70” to connect the soundbar.
Batteries Not Included
1
2
Note: If it’s already in the Bluetooth mode and connected, press and hold “ ” button for 3 seconds to disconnect current device and
connect to new device manually on your mobile phone / PC / TV.
9 PLACEMENT OPTIONS
Nova S70

05
11 SPECIFICATIONS
580mm / 22.83"
22mm/0.86"
22mm/0.86"
6mm/0.23"
30mm/1.18"
Overview
Please use the HDMI Adaptor for easy plugging
and unplugging of the HDMI Cable.
Note:
10 WALL MOUNT INSTALLATION
4.15kg / 9.15lbs
5.1kg / 11.24lbs
Soundbar
Subwoofer
Dimensions and Weight
800(W) x 38(H) x 90(D)mm 31.5" x 1.5" x 3.5"
270(W) x 115(H) x 270(D)mm 10.6" x 4.5" x 10.6"
Net Weight
332(W) x 432(H) x190(D)mm 13.1" x 17" x 7.5"
Packaging
Gross Weight
Model Number U3920
Power Supply
Soundbar Drivers
Frequency Response
Standby Power
AC 100-240V, ~50 / 60Hz
(3.1" x 1.2") x 3 (Soundbar)+ 1.8" x 2 (upward-ring Driver)
+ 2.25" (Subwoofer)
45Hz - 18kHz
＜0.5W
Operating Temperature 0°C - 45°C / 32°F - 113°F
Bluetooth Version 5.3

Nova S70
Modell Nr.: U3920
Bevorzugen Sie ein
Video-Tutorial?
WIR SIND
BEREIT ZU
HELFEN [email protected]
support.ultimea.com
[phone] (US) Mon-Fri 9am-5pm (PST)
[phone] (EU) Mon-Fri 9am-5pm (CET)
1 ZUBEHÖRLISTE
Setup-Anleitung Video, oder
USER MANUAL auf ULTIMEA
Website.
Benutzerhandbuch
06
@ultimea_official
Soundbar
2 SOUNDBAR-BEDIENELEMENTE
Subwoofer
Netzadapter HDMI-Kabel Stereo 3.5mm auf RCA
Audiokabel
Fernbedienung
Optisches Digitalkabel
Wandmontage-Kit Wandhalterung Benutzerhandbuch
HDMI-Adapter
“ ”: Lautstärke verringern
Bedienfeld
“ ”: Einschalttaste
Zum Einschalten drücken / zum Ausschalten 3 Sekunden
lang gedrückt halten.
1
“ ”: Eingangsmodus
Drücken, um den Kanal zu wechseln: eARC-HD IN (HDMI IN)-
OPT (OPTICAL)-BT-AUX-USB.
2
3“ ”:
“ ”: Lauter
4
5
Drücken Sie , um zum Bluetooth-Kanal zu wechseln und den
Kopplungsmodus zu aktivieren. Halten Sie die Taste 3 Sekunden
lang gedrückt, um die Verbindung mit dem aktuellen Gerät zu
trennen und sich manuell mit einem neuen Gerät auf Ihrem
Mobiltelefon / PC / Fernseher zu verbinden. (BT ID: Nova S70).
BT
4321 5
6-pin Kabel für
Soundbar-Anschluss (140mm)
DE
21
3920
Nova S70
4
2
1
1 1
1 1 1

07
8“ ”: Lautstärke aufwärts
9“ ”: Lautstärke runter
14
Drücken Sie diese Taste, um den Basspegel einzustellen; auf dem Display wird angezeigt :
“ ”: BASSMAX
15 “ ”: Stummschaltung / Wiederherstellung der Lautstärke.
Fernsteuerung
10
BT- und USB-Modus: Zum vorherigen Titel springen.
“ ”: Zurück
11
BT- und USB-Modus: Sprung zum nächsten Titel.
“ ”: Nächster
Drücken Sie diese Taste, um zwischen den Modi Film, Dialog und Musik
umzuschalten; auf dem Display wird angezeigt: “ ”, “ ”, “ ”.
6“ ”: EQ
Zum Umschalten der Kanäle drücken:
eARC-HD IN (HDMI IN) -OPT (OPTICAL)-BT-AUX-USB.
7“ ”: INPUT
12 “ ”: Wiedergabe / Pause
Nur für BT- und USB-Modus.
USB-Modus: Halten Sie die Taste 3 Sekunden lang gedrückt, um zwischen
Einzelschleifenwiedergabe und Listenschleifenwiedergabe umzuschalten.
14
1
2
3
8
5
10
9
13
15
12
7
6
4
11
3
“ ”: BT
1
Zum Einschalten drücken / zum Ausschalten 3 Sekunden lang gedrückt halten.
“ ”
:
Einschalttaste
“ ” : e ARC
Drücken, um zum HDMI eARC-Kanal zu wechseln.
2
5
Drücken, um zum OPTICAL-Kanal zu wechseln.
4“ ”: OPT
Drücken Sie , um zum Bluetooth-Kanal zu wechseln und den Kopplungs-
modus zu aktivieren. Halten Sie die Taste 3 Sekunden lang gedrückt, um
die Verbindung mit dem aktuellen Gerät zu trennen und sich manuell mit
einem neuen Gerät auf Ihrem Mobiltelefon / PC / Fernseher zu verbinden.
(BT ID: Nova S70).
Drücken, um zum HDMI IN-Kanal zu wechseln.
“ ”: HD IN
13
Drücken Sie die Taste, um die Lautstärke nach oben zu regeln, auf dem
Display erscheint: “ ”, “ ”, “ ”.
“ ”: Dolby Atmos
AUX
OPT
USB
SUB OUT
DC IN
HDMI OUT (eARC)
HDMI IN
3 SOUNDBAR-INSTALLATION
Montageschritte
Stellen Sie die beiden Teile der Soundbar auf
die gleiche Höhe und richten Sie die
Verbindungsstellen aus. Verbinden Sie die
beiden Teile durch paralleles Schieben, um sie
zu einem Stück zusammenzufügen.
Stecken Sie Stereo 6-pin kabel.
1
2
Schritt 1
Schritt 2
DE
”, “ ”, “ ”.”, “”, “
“
