ULTIMEA U2520 User manual

Poseidon D60
Model No.: U2520
Poseidon D60 5.1 Channel Dolby Atmos Soundbar
EN: User Manual
DE: Benutzerhandbuch
JP: ユーザーマニュアル
FR: Manuel de l'Utilisateur
IT: Manuale d'uso
ES: Manual del usuario

“ ”: Volume Down
Poseidon D60
Model No.: U2520
Prefer video tutorial?
WE ARE
READY
TO HELP [email protected]
support.ultimea.com
[phone](US) Mon-Fri 9am-5pm(PST)
[phone](EU) Mon-Fri 9am-5pm(CET)
1 ACCESSORIES LIST
Subwoofer
Control Panel
“ ”: Power Button
Press to power on / Hold for 3 seconds to power off.
1
“ ”: Input Mode
Press to switch channels: eARC-BT-OPT-AUX-USB.
2
3“ ”: Bluetooth
“ ”: Volume Up
4
5
Setup guidance video, USER
MANUAL or Trouble Shooting
on ULTIMEA website.
2 SOUNDBAR CONTROLS
User Manual
Soundbar Surround Speaker x 2
01
Power Adaptor HDMI Cable
Subwoofer Power
Cable
Stereo 3.5mm to RCA
Audio Cable
1
Remote Control
Digital Optical
Cable Wall Mounted Kit
8
Wall Bracket
4
Mounting Screw
on Speakers
4
User Manual
1
Press to switch to BT channel and enter pairing mode.
Hold for 3 seconds to disconnect current device and
choose to connect to a new device manually on your
mobile phone / PC / TV (BT ID: Poseidon D60).
Stereo RCA to
RCA Cable(6m)
1
4321 5
2520
Poseidon D60

02
3“ ”: BT
8“ ”: Volume Up
9“ ”: Volume Down
14
Press to adjust bass level, the display will show: “bS-1” , “bS 0” , “bS 1”.
“ ”: BASSMX
15 “ ”: Mute / Recover the volume.
Remote Control
1
Press to power on / Hold for 3 seconds to power off.
“ ”
:
Power Button
“ ” : e ARC
Press to switch to HDMI eARC channel.
2
10
BT and USB mode: Skip to previous track.
“ ”: Previous
11
BT and USB mode: Skip to next track.
“ ”: Next
5
Press to switch to AUX channel.
“ ”: AUX
Press to switch to OPT channel.
4“ ”: OPT
Press to switch among Movie, Dialogue, Music mode, the display will
show: “Eq01”, “Eq02”, “Eq03”.
6“ ”: EQ
Press to switch to USB channel.
7“ ”: USB
12 “ ”: Play / Pause
For BT and USB mode only.
USB mode: Hold for 3 seconds to switch between single loop playback
and list loop playback.
3 CONNECT TO TV VIA eARC / ARC
eARC / ARC
HDMI
Note:
Your TV's HDMI port needs to support eARC to transmit the Dolby Atmos audio format to your Soundbar.
Atmos：If you are watching a movie in the Dolby Atmos format, please set the audio output on your TV to Pass Through:
TV Settings > Home > Settings > Sound > Digital Audio Output > Pass Through
DTS: If you are watching a movie in the DTS format, please set the audio output on your TV to PCM：
TV Settings > Home > Settings > Sound > Digital Audio Output > PCM
Step 1:
Connect one end of the HDMI cable to the
eARC / ARC port on the back of your TV.
Step 2:
Then connect the other end into the eARC
port of the soundbar.
Step 3:
Press “eARC” button on the remote control
to select “eARC” input.
eARC
What’s the difference between: HDMI IN, HDMI ARC, HDMI eARC?
HDMI IN is a standard HDMI input that allows you to connect devices to your TV or audio system. It supports audio and video signals, but it does
not support audio return channel (ARC) or enhanced audio return channel (eARC) functionality.
HDMI ARC is a special HDMI port that supports two-way communication between your TV and audio system. This means that audio can be sent
from your TV to your audio system, and audio system can send audio back to your TV.
HDMI eARC (Enhanced Audio Return Channel) is an updated version of HDMI ARC that supports higher quality audio formats such as Dolby
Atmos and DTS:X.
1
2
3
Note: Please turn on the “CEC” function on your TV.
When eARC / ARC is connected, your TV remote control can control the soundbar and TV simultaneously:
Turn on / off Adjust the volume
1 2
13
Press to adjust surround sound level, the display will
show: “ST-1”, “ST 0”, “ST 1”.
“ ”: Surround
Press to switch to BT channel and enter pairing mode. Hold for 3
seconds to disconnect current device and choose to connect to a new
device manually on your mobile phone / PC / TV (BT ID: Poseidon D60).
14
1
2
3
8
5
10
9
13
15
12
7
6
4
11
Note: When input Dolby Atmos source, 'Dolby Atmos' will be indicated as below.

4 CONNECT TO TV VIA OPTICAL / AUX
OPTICAL
DIGITAL AUDIO
OUT
OPTICAL
OPTICAL
OPTICAL
AUX
AUX
AUDIO OUTPUT
RL
AUDIO IN
RL
In Optical Mode: If there is no sound, try setting the TV audio output to PCM: TV Settings > Home > Settings > Sound > Digital Audio Output > PCM
6 CONNECT TO SUBWOOFER AND SURROUND SPEAKERS
Use the 6m RCA-RCA cables to connect the subwoofer
and surround speakers, please pay attention to match
the same color interfaces on the surround speakers
with the corresponding ones on the subwoofer and
place the surround speakers accordingly.
Use power cable to connect your subwoofer and power
port.
1
2
03
7 PAIRING SUBWOOFER
Step 1:
Press and hold the “ ” button on the remote
control for 5 seconds, the display will show “SUb” flashing.
Step 2:
Press and hold the ON/OFF button on subwoofer for 5
seconds, the white LED will be fast flashing.
The subwoofer has been paired with the soundbar
by ULTIMEA.
However you may need to re-pair the soundbar
and subwoofer if there is no sound coming from
the subwoofer.
5 CONNECT TO BLUETOOTH
Press the “ ” button on the soundbar or remote control to enter Bluetooth pairing mode.
Go to the Bluetooth setting on your phone, nd and select “Poseidon D60” to connect the soundbar.
Batteries not included
1
2
Note: If it’s already in the Bluetooth mode and connected, press and hold “ ” button for 3 seconds to disconnect current device and
choose to connect to new device manually on your mobile phone / PC / TV.
The white LED will be solid on when the subwoofer is paired
successfully.
Step 2Step 1
ON/OFF
AC IN
SR
SL ON/OFF
OPTION 1: OPTICAL
Note: If audio is playing from the internal TV speakers, mute or
minimize the TV volume.
Note: Please remember to unplug the AUX cable from TV and
Soundbar when you want to switch to other mode.
Make sure the optical plug is inserted correctly as it shows in the
picture. Do not insert the plug upside down and break the optical.
OPTION 2: AUX
Connect the 3.5mm to 3.5mm Audio Cable to your TV's AUDIO
OUT port.
Not support AUDIO IN port on TV.
1
2
1
2
Make sure the TV's port is OPTICAL OUT, connect both sides
of the cable to OPTICAL, for both the TV and the soundbar.
Poseidon D60

310mm/12.2”
41mm/1.61”
41mm/1.61”
6.5mm/0.26"
40mm / 1.57”
Full 360° Surround (Better Surround)
The soundbar and surround speakers should be placed at or near ear level.
1
2
Front Surround
04
10 SPECIFICATIONS
9 WALL MOUNT INSTALLATION
Overview
5.3kg / 11.68lbs
6.8kg / 14.99lbs
Soundbar
Subwoofer
Dimensions and Weight
400(W) x 70(H) x 90(D)mm 15.7” x 2.8” x 3.5”
155(W) x 244(H) x 215(D)mm 6.1” x 9.6” x 8.5”
135(W) x 70(H) x 90 (D)mm 5.3” x 2.8” x 3.5”
Net Weight
335(W) x 442(H) x192(D)mm 13.1” x 17.4” x 7.5”
Packaging
Surround Speaker
Gross Weight
Model Number U2520
Power Supply
Soundbar Drivers
Frequency Response
Standby Power
AC 100-240V, ~50/60Hz
2.25" x 3 (Soundbar) + 2.25” x 2 (Surround Speaker) + 5.25” (Subwoofer)
40Hz - 18kHz
＜0.5W
Operating Temperature 0°C - 45°C/32°F - 113°F
8 PLACEMENT OPTIONS
Note: Wall-mounted surround speakers follow the same conguration as shown in the above pictures
For a better listening experience, please choose one of the two placement options shown in the illustration above based on
your home environment.

FCC REGULATORY COMPLIANCE
ISED WARNINGS
Please read this user manual carefully and save it for future reference.
SAFETY INSTRUCTIONS
Do not make unauthorized alterations to the product, doing so may compromise safety, regulatory compliance, system
performance, and may void the warranty.
·
Avoid dropping.
·
Do not disassemble.
·
Do not submerge in water
·
Avoid extreme temperatures.
·
Do not use the device outdoors during thunderstorms.
·
· Do not place dangerous items on top of this device (e.g.
· Clean with a dry, soft lint-free cloth. Do not use any corrosive cleaner or oil.
·
To avoid hearing damage, do not listen for extended periods at high volume.
·
Do not expose the batteries to extreme heat sources such as direct sunlight or open flames.
·
The ideal operating temperature for this product and itsaccessories is between 41 /5 and 95 /35 .
·
The adapter should be installed near the device and should be easily accessible.
·
Do not use this product in environments of extreme heat or cold. Never expose this device to strong sunshine or wet
environments.
PROPER DISPOSAL INSTRUCTIONS
Waste Electrical & Electronic Equipment
This mark shown on the product or its packaging, indicates that this product should not be disposed of with other
household waste at the end of its working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate
this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household user should contact either the retailer where they purchased this product, or their local government ofce, for
details of where and how they can take this item for environmentally safe recycling.
Business users should contact their suppliers and check the terms and conditions of the purchase contract. This product
should not be mixed with other commercial wastes for disposal.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interfer. ence by one or more of the following measures:
- Reorient or relocate the receiving antenna. - Increase the separation between the equipment and the receiver.
- Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician
for help.
Any changes or modications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference.
(2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with a minimum distance of 20cm between the radiator & your body. This transmitter
must not be co-located or operating in conjunction with any other antenna or transmitter.
This device contains licence-exempt transmitter(s)/ receiver (s) that comply with Innovation, Science and Economic
Development Canada's licence-exempt RSS (s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d'Innovation, Sciences et
Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes:
(1) L'appareil ne doit pas produire de brouillage;
(2) L'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d' en compromettre le
fonctionnement.
This equipment complies with IC exposure limits set forth for an uncontrolled environment. This equipment shall be installed and
operated with a minimum distance of 20cm between the radiator & body.
Cet équipement est conforme aux limites d'exposition IC dénies pour un environnement non contrôle. Cet équipement doit être
installé et utilisé avec une distance minimale de 20cm entre le radiateur et la carrosserie.
