Ultra Auto Tech X270-1 User manual
FCC ID NOTICE
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the part responsible for compliance void the user’s authority to operate
this device.
REV.20.5.1
S FETY
!
UVC LED handheld Disinfectant
with LED flash light
with Built-in Safety Feature
PAGE 2
OWNER'S MANUAL
TABLE OF CONTENTS
Table of Contents & Warranty.................................................Page 2
Important Notes.......................................................................Page 3
UVC Basics..............................................................................Pages 4-5
System Operation....................................................................Pages 7
Product Overview....................................................................Pages 6
X270-1
The manufacturer warrants to the original purchaser of the UVC LED Wand that the product shall be free from
defects in material and workmanship. However, should this product be proven to be defective, within a (1) year
period from the original date of purchase, the manufacturer will, without charge to the purchaser (excluding any
charges incurred to have the product delivered to the manufacturer), repair or replace any part of the UVC LED
Wand which the manufacturer agrees to be defective. After the initial 1 year period the manufacture shall repair
or replace defective products with a nominal processing fee of $30.00 USD. All warranties apply to the original
purchaser ONLY. Repairs or replacement of defective modules shall remain at the discretion of the manufacturer.
All other parts, components, accessories and/or optional equipment are not included in the manufacturer’s
warranty. This warranty is non-transferable. Request for warranty service from any Factory Authorized Dealer
must be accompanied with the original purchase receipt or have product registered by authorized dealer
on manufacturer’s website. Failure to comply with any of these conditions may result in warranty being voided.
This warranty does not cover the following: removal and reinstall labor charges, shipping charges, abuse,
misuse, and/or parts there of. This warranty is void upon modification, repairs, or alterations of any part of the
product. The manufacturer shall not be held liable for any consequential damages due to breach of this or any
other warranty, expressed, or implied. This warranty gives you specific legal rights. Your specific legal rights may
vary for each region.
WARRANTY (USA & CANADA)
CERTAIN DAMAGES EXCLUDED - The manufacturer expressly disclaims any liability or responsibility for
incidental damages caused by the product, including economic loss, loss of use of the product, or any other
costs relating to the care and custody of the product. The manufacturer disclaims liability or responsibility for any
consequential damages caused by the product or resulting from its use, including the cost of repairing or
replacing other property damaged by the product or caused by its use, whether or not the product is working
properly. The manufacturer does not warrant that the product is fool-safe against human error or misuse.
PAGE 3
OWNER'S MANUAL
IMPORTANT NOTES
ATTENTION
Please take a moment to review the safety precautions before
operating your system.
1. Use UV goggles and/or full-face shields.
2. Cover any exposed skin
1) In rare instances of to UVC light, temporary prolonged direct exposure
eye and skin damage has been exhibited, such as cornea injury
(sometimes referred to as “welder’s eye”) although this generally heals
after a couple of days. Therefore, safety recommendations with UVC
LEDs include protecting skin (in particular open wounds) and, most
importantly, the eyes from UVC radiation. UV radiation is easily
absorbed by clothing, plastic or glass. Once absorbed, UV radiation is no
longer active. When working with open UV radiation, personal protective
equipment covering all exposed areas is recommended. When working
around UVC devices, one should:
X270-1 has an additional safety feature to minimize the exposer of UV
radiation. Our unique sensor will sense where the UV light is shining and
will turn off if it is tilted upward from the treatment surface to eliminate
any harm to you.
3) Please use 5V 1A USB adaptor to charge the unit. Please fully charge
the unit before the first use. (it may take up to 3 hours)
4) In some instances, you may hear the buzz sound during the operation.
2) Please keep the X270-1 away from the reach of children.
X270-1
PAGE 2
OWNER'S MANUAL
TABLE OF CONTENTS
Table of Contents & Warranty.................................................Page 2
Important Notes.......................................................................Page 3
UVC Basics..............................................................................Pages 4-5
System Operation....................................................................Pages 7
Product Overview....................................................................Pages 6
X270-1
The manufacturer warrants to the original purchaser of the UVC LED Wand that the product shall be free from
defects in material and workmanship. However, should this product be proven to be defective, within a (1) year
period from the original date of purchase, the manufacturer will, without charge to the purchaser (excluding any
charges incurred to have the product delivered to the manufacturer), repair or replace any part of the UVC LED
Wand which the manufacturer agrees to be defective. After the initial 1 year period the manufacture shall repair
or replace defective products with a nominal processing fee of $30.00 USD. All warranties apply to the original
purchaser ONLY. Repairs or replacement of defective modules shall remain at the discretion of the manufacturer.
All other parts, components, accessories and/or optional equipment are not included in the manufacturer’s
warranty. This warranty is non-transferable. Request for warranty service from any Factory Authorized Dealer
must be accompanied with the original purchase receipt or have product registered by authorized dealer
on manufacturer’s website. Failure to comply with any of these conditions may result in warranty being voided.
This warranty does not cover the following: removal and reinstall labor charges, shipping charges, abuse,
misuse, and/or parts there of. This warranty is void upon modification, repairs, or alterations of any part of the
product. The manufacturer shall not be held liable for any consequential damages due to breach of this or any
other warranty, expressed, or implied. This warranty gives you specific legal rights. Your specific legal rights may
vary for each region.
WARRANTY (USA & CANADA)
CERTAIN DAMAGES EXCLUDED - The manufacturer expressly disclaims any liability or responsibility for
incidental damages caused by the product, including economic loss, loss of use of the product, or any other
costs relating to the care and custody of the product. The manufacturer disclaims liability or responsibility for any
consequential damages caused by the product or resulting from its use, including the cost of repairing or
replacing other property damaged by the product or caused by its use, whether or not the product is working
properly. The manufacturer does not warrant that the product is fool-safe against human error or misuse.
PAGE 3
OWNER'S MANUAL
IMPORTANT NOTES
ATTENTION
Please take a moment to review the safety precautions before
operating your system.
1. Use UV goggles and/or full-face shields.
2. Cover any exposed skin
1) In rare instances of to UVC light, temporary prolonged direct exposure
eye and skin damage has been exhibited, such as cornea injury
(sometimes referred to as “welder’s eye”) although this generally heals
after a couple of days. Therefore, safety recommendations with UVC
LEDs include protecting skin (in particular open wounds) and, most
importantly, the eyes from UVC radiation. UV radiation is easily
absorbed by clothing, plastic or glass. Once absorbed, UV radiation is no
longer active. When working with open UV radiation, personal protective
equipment covering all exposed areas is recommended. When working
around UVC devices, one should:
X270-1 has an additional safety feature to minimize the exposer of UV
radiation. Our unique sensor will sense where the UV light is shining and
will turn off if it is tilted upward from the treatment surface to eliminate
any harm to you.
3) Please use 5V 1A USB adaptor to charge the unit. Please fully charge
the unit before the first use. (it may take up to 3 hours)
4) In some instances, you may hear the buzz sound during the operation.
2) Please keep the X270-1 away from the reach of children.
X270-1
PAGE 4
UVC BASICS
What is UV light and how does UV light sanitize?
UV light has three wavelength categories: UV-A, UV-B, and UV-C. UV-C
light is a short-wavelength, ultraviolet light that breaks apart germ DNA,
leaving it unable to function or reproduce. In other words, UVC light is
germicidal (UVA and UVB light are not).
UVC LEDs are compact, durable and well suited to battery powered
operation for point-of-care tools. These devices quickly and reliably provide
low to high level disinfection on a range of surfaces.
Why UVC disinfection?
Almost all current surface disinfection methods use chemical agents.
Chemical disinfection can be confusing and inconsistent because of the
many products available. To ensure proper disinfection, the selected agent,
manner of use (immersion vs contact) and the treatment time must be
correctly and consistently applied. Deep ultraviolet light, albeit in the form of
germicidal mercury lamps, has been used and proven over the past 100
years to be effective as part of high level disinfection protocols.
Are UVC LEDs effective against COVID-19 (Coronavirus) ?
Studies have confirmed that UVC light can be effective for combating
SARS-COV
(https://www.tandfonline.com/doi/full/10.1080/15459620701329012).
However, additional studies are needed to determine and confirm the
specific dose response required to inactivate COVID-19 on different
surfaces and materials.
OWNER'S MANUAL
X270-1
PAGE 5
UVC BASICS
As the threat of antibiotic resistant microorganisms increases, UVC LEDs
are becoming the method of choice to deliver on demand, quantifiable
surface disinfection at the point-of-need.
Surface Disinfection
Additional Information
Ultraviolet germicidal irradiation (UVGI) is a disinfection method where
UVC light is used to inactivate microorganisms by disrupting their
DNA/RNA and leaving them unable to reproduce.
A 2014 study in the American Journal of Infection Control found that a
portable wand killed 100 percent of several types of bacteria commonly
found on surfaces after just five seconds, and inactivated 90 % of
especially hardy spore-forming bacteria after 40 seconds. According to
the researchers, a UVC device is a reasonable alternative to using
chemicals to disinfect surfaces.
OWNER'S MANUAL
X270-1
CHARGING THE UNIT
Please use the cable provided to fully charge
the UVC wand. Plug the one side of the cable to
the unit and the other side to a USB power
adaptor (USB power adaptor not included).
USB power adaptor should be rated at 5V (1A).
PAGE 4
UVC BASICS
What is UV light and how does UV light sanitize?
UV light has three wavelength categories: UV-A, UV-B, and UV-C. UV-C
light is a short-wavelength, ultraviolet light that breaks apart germ DNA,
leaving it unable to function or reproduce. In other words, UVC light is
germicidal (UVA and UVB light are not).
UVC LEDs are compact, durable and well suited to battery powered
operation for point-of-care tools. These devices quickly and reliably provide
low to high level disinfection on a range of surfaces.
Why UVC disinfection?
Almost all current surface disinfection methods use chemical agents.
Chemical disinfection can be confusing and inconsistent because of the
many products available. To ensure proper disinfection, the selected agent,
manner of use (immersion vs contact) and the treatment time must be
correctly and consistently applied. Deep ultraviolet light, albeit in the form of
germicidal mercury lamps, has been used and proven over the past 100
years to be effective as part of high level disinfection protocols.
Are UVC LEDs effective against COVID-19 (Coronavirus) ?
Studies have confirmed that UVC light can be effective for combating
SARS-COV
(https://www.tandfonline.com/doi/full/10.1080/15459620701329012).
However, additional studies are needed to determine and confirm the
specific dose response required to inactivate COVID-19 on different
surfaces and materials.
OWNER'S MANUAL
X270-1
PAGE 5
UVC BASICS
As the threat of antibiotic resistant microorganisms increases, UVC LEDs
are becoming the method of choice to deliver on demand, quantifiable
surface disinfection at the point-of-need.
Surface Disinfection
Additional Information
Ultraviolet germicidal irradiation (UVGI) is a disinfection method where
UVC light is used to inactivate microorganisms by disrupting their
DNA/RNA and leaving them unable to reproduce.
A 2014 study in the American Journal of Infection Control found that a
portable wand killed 100 percent of several types of bacteria commonly
found on surfaces after just five seconds, and inactivated 90 % of
especially hardy spore-forming bacteria after 40 seconds. According to
the researchers, a UVC device is a reasonable alternative to using
chemicals to disinfect surfaces.
OWNER'S MANUAL
X270-1
CHARGING THE UNIT
Please use the cable provided to fully charge
the UVC wand. Plug the one side of the cable to
the unit and the other side to a USB power
adaptor (USB power adaptor not included).
USB power adaptor should be rated at 5V (1A).
PAGE 6
Product Overview
OWNER'S MANUAL
X270-1
Product Overview
UVC LED
LED Flash Light
UVC ON/OFF STATUS
CHARGING COMPLETED
CHARGING
OPERATION BUTTON
CHARGING PORT
CHARGING
STATUS LED CHARGING
COMPLETED
UVC LED
ON
STATUS LED
LOW BATTERY
PAGE 7
SYSTEM OPERATIONS
OWNER'S MANUAL
X270-1
FLASH LIGHT OPERATION
1. Press and release the operation button once.
2. The white LED flashlight will turn on.
3. Press and hold the operation button for 2 seconds.
4. The white LED flashlight will turn off.
UVC LED DISINFECTION OPERATION
TO TURN ON
1. Point the UVC LED toward the surface to disinfect. The operation
button should be facing toward the surface and the Status LED
should be visible.
2. Press and release the operation button 2 times. .
If the White LED was off, the White LED flashlight will turn on briefly,
then turn off.
If the White LED was on, then the White LED flashlight will turn off.
3. The UVC LED Disinfection light will turn on for 5 minutes.
4. The Status Blue light will turn on while the UVC LED Disinfection
light is on.
5. Scan the infected surface back and forth 5 to 10 times slowly to
complete the disinfecting process. (20 - 30 second UVC exposure)
TO TURN OFF
1. Press and hold the operation
button for 2 seconds.
2. The UVC LED Disinfection
light will turn off.
3. The Status Blue light will turn off. 1 inch
PAGE 6
Product Overview
OWNER'S MANUAL
X270-1
Product Overview
UVC LED
LED Flash Light
UVC ON/OFF STATUS
CHARGING COMPLETED
CHARGING
OPERATION BUTTON
CHARGING PORT
CHARGING
STATUS LED CHARGING
COMPLETED
UVC LED
ON
STATUS LED
LOW BATTERY
PAGE 7
SYSTEM OPERATIONS
OWNER'S MANUAL
X270-1
FLASH LIGHT OPERATION
1. Press and release the operation button once.
2. The white LED flashlight will turn on.
3. Press and hold the operation button for 2 seconds.
4. The white LED flashlight will turn off.
UVC LED DISINFECTION OPERATION
TO TURN ON
1. Point the UVC LED toward the surface to disinfect. The operation
button should be facing toward the surface and the Status LED
should be visible.
2. Press and release the operation button 2 times. .
If the White LED was off, the White LED flashlight will turn on briefly,
then turn off.
If the White LED was on, then the White LED flashlight will turn off.
3. The UVC LED Disinfection light will turn on for 5 minutes.
4. The Status Blue light will turn on while the UVC LED Disinfection
light is on.
5. Scan the infected surface back and forth 5 to 10 times slowly to
complete the disinfecting process. (20 - 30 second UVC exposure)
TO TURN OFF
1. Press and hold the operation
button for 2 seconds.
2. The UVC LED Disinfection
light will turn off.
3. The Status Blue light will turn off. 1 inch
http://www.ultrastarters.com/ultra-safety
ULTRA AUTO TECH., CORP
LOS ANGELES, CA
Table of contents
