X-Wind High Performance CPU Cooler
As computer processors become more and more powerful, they
typically generate more heat. Accordingly, air cooling solutions for
processors tend to be large, heavy and loud. Ultra's X-Wind CPU
coolers offer a balance of performance and price without being
excessively loud or cumbersome. Because the X-Wind has several fins
(as many as 120!), there is more surface area than a typical machined
heatsink, so heat is effectively pulled away from the CPU and quickly
dissipated.X-Wind's design allows for the use of a larger, quieter fan to
push air in between the many fins. If you're disappointed with the
noise from your current CPU cooler, fed up with higher temperatures
or concerned that your behemoth two pound heatsink is going to
damage your motherboard or processor, Ultra has your solution!
Sku: ULT33048 ULT33049 ULT33050 ULT33131
Socket Type: Socket 940/939/754/478 Socket 940/939/754/478 Socket 940/939/754/478 Socket LGA 775
Material: Aluminum Copper Copper Copper
Cooler Dimension: 103x103x55 (mm) 103x103x55 (mm) 129x129x55 (mm) 129x129x55 (mm)
Heat Sink
Dimension: 103x103x55 (mm) 103x103x55 (mm) 129x129x55 (mm) 129x129x55 (mm)
Fan Dimension: 90x90x25 (mm) 90x90x25 (mm) 120x120x25 (mm) 120x120x25 (mm)
Rated
Volta
g
e
/
Current: DC 12V/0.26 A DC 12V/0.26 A DC 12V/0.4 A DC 12V/0.4 A
Power
Consum
p
tion: 3.12 W 3.12 W 4.8 W 4.8 W
Fan Speed: 2800 RPM +- 10%RPM 2600 RPM +- 10%RPM 1200-2200 RPM +- 10%RPM 1200-2200 RPM +- 10%RPM
Airflow: 53.5 CFM 44.49 CFM 53.5-78.5 CFM 53.5-78.5 CFM
Static Pressure: 3.44mm-H2O 3.44mm-H2O 1.77mm-H2O 1.77mm-H2O
Noise Level: 30 dB(A) +- 10% 25 dB(A) +- 10% 15-25 dB(A) +- 10% 15-25 dB(A) +- 10%
Bearing Type Sleeve Dual Ball Bearing Dual Ball Bearing Dual Ball Bearing
Weight: 270g 652g 747g 747g
Thermal Grease: Silicon / Carbon / Metal
Oxide Com
p
.
Silicon / Carbon / Metal
Oxide Com
p
.
Silicon / Carbon / Metal
Oxide Com
p
.
Silicon / Carbon / Metal
Oxide Com
p
.
Life Time: 30,000 Hrs 50,000 Hrs 50,000 Hrs 50,000 Hrs
Supports: AMD CPU up to Athlon 64 FX
55, Athlon 64 X2 4200+, Athlon
64 3800+, Opteron 2.4 Ghz,
Sempron 3400+, Pentium 4 3.0
Ghz
AMD CPU up to Athlon 64 FX
62, Athlon 64 X2 4800+, Athlon
64 4000+, Opteron 2.6 Ghz,
Sempron 3400+, Pentium 4 3.4
Ghz
AMD CPU up to Athlon 64 FX
62, Athlon 64 X2 4800+, Athlon
64 4000+, Opteron 2.6 Ghz,
Sempron 3400+, Pentium 4 3.4
Ghz
Intel Pentium D 3.4 GHz and
Higher, Pentium 4 3.8 Ghz and
Higher, Celeron 3.33 GHz and
Higher.
UPC: 022769330488 022769330495 022769330501 022769331317
