Ultra Start 12xx Series User manual

INSTALL GUIDE
www.ultrastarters.com
Technical Support: 866-698-5872 ext 0
[e-mail]
Covers All 12xx and 13xx Series
Advanced Remote Starters
The system must be placed into Service Mode before any service work is started on the
vehicle. It is the sole responsibility of the vehicle owner to ensure that this is done. The
manufacturer accepts no liability or responsibility for accidental starting of the vehicle.
CARBON MONOXIDE - Never Start in an Enclosed Building (Garage, Carport etc...)
- The Hood Pin Safety Switch Must Always be Installed!
Warning!!
CARBON MONOXIDE MAY CAUSE SERIOUS INJURY, EVEN DEATH!
It is the sole responsibility of the user to place the system in Service Mode
when parking in an enclosed area ex: garage, partially enclosed area
ex: carport, or when the vehicle is being serviced.

Table of Contents Page 2
Component/Feature List Page 3
Recommend Installation Procedures Page 4-5
Wiring Diagrams Page 6-7
Wire Description Page 8-9
6 Pin Connector
Auxiliary Connectors
Optional Connectors
Jumper Positions
Quick Start Installation Page 10
Basic Installation
Plug-in The Module
Manual Transmission Vehicles Page 11
Additional Connections
Clutch Bypass
Important Tach Notes Page 12-13
Auto Tach Learn (Tach & TachLess Models)
Quick Tach Learn
Program Overview and Quick View Programming Page 14-15
Entering Program Mode
Quick View Programming
System Reset
Programming Menus Page 16-20
Program Menu 1 (User Settings)
Program Menu 2 (Additional Settings)
Program Menu 3 (Starter Settings)
Program Menu 4 (Tach Settings)
Remote Transmitter Page 21
Transmitter Programming
Battery Replacement
Door Lock Relay Wiring Diagrams Page 22-23
Diagnostics Page 24
Table of Contents
INSTALL MANUAL REMOTE VEHICLE STARTER
PAGE 2

Feature List
- Control module - 4 button remote transmitter’s
- Antenna with built in - 6 pin Main harness
Program Button and LEDs - 14 pin auxiliary harness
- 3 pin keyless entry harness - 2 pin auxiliary harness*
- Hood pin switch - 3 pin auxiliary harness*
- Install & Owner guides
*13xx series models only
- Auto Tach (Tachless, TL series only) learning with Quick Learn
- Run Time: 4/15/45 minutes
- Door locks: .125s/.75s/3s / Double unlock / Ignition lock/unlock
- Horn output 5ms/10ms/50ms
- Timer or Cold Start (LT series) with 4 different start intervals
- Programmable Wait to Start or (+/-) diesel Glow plug input
- Ground While Running/Anti-grind protection/Starter kill
- System Override Protection/Service Mode (Valet)
- Park light and LED diagnostics
- PadLoc (remote transmitter “LOCK”
- Dual car operation - up to 4 different transmitter codes
- Panic mode - Car Finder mode
- Engine Idle mode - Turbo Timer mode
Please read manual thoroughly.
If the vehicle is a MANUAL TRANSMISSION, a “M” series
remote starter must be installed. Any model number followed
by the letter “M” is specially designed for MANUAL
TRANSMISSION vehicles. The “M” series remote starter will
not work in an AUTOMATIC TRANSMISSION vehicle.
Components
REMOTE VEHICLE STARTER INSTALL MANUAL
PAGE 3

Recommended Installation Procedures
Remote car starters and alarms should be professionally
installed. Review the installation and owner manuals and acquire a
vehicle wiring diagram for the vehicle to be worked on. Take a few
moments to walk around the vehicle looking for any damages and
make note if any are found. Also check other functions such as the
lighting system, warning or check engine lights. Check if the vehicle
has a factory security or anti-theft system (Transponder or PASS-
LOCK). These systems will require additional parts and labor to
complete the installation. Use of the proper tools and testing
equipment is also very important. Never use a grounding style test
light. Use only a circuit safe test light or digital Volt/Ohm meter to
test for wires in the vehicle. It is the sole responsibility of the installer
to test and verify all connections.
Proper Connections - Remote Starters can handle loads of up to
30 amps for extended periods of time. It is critical to insure that all
high current connections are properly soldered and insulated with
quality electrical tape. Failing to insure proper connections will result
in warranty being VOID and can result in damage to the vehicle and
remote starter module. The manufacture is not responsible for any
such damages. It only takes a few more minutes to do the job right.
Under Hood Connections - Route the hood pin and tach wire
through the firewall into the engine compartment. If possible route
the wires through a factory rubber grommet. If drilling a hole through
the firewall, BE CAREFUL. Always check for obstructions on both
sides of the firewall. After drilling, use a snap in grommet to protect
the wires from sharp edges. Use split loom to insulate the wires, route
the wires clear of moving parts and extreme heat. The hood pin
switch must always be installed and the tach wire should always be
soldered and taped properly.
INSTALL MANUAL REMOTE VEHICLE STARTER
PAGE 4

Recommended Installation Procedures
Mounting The Control Module - Never mount the module in the
engine compartment. Select a location under the dash to install the
main module. Be certain that the module is securely attached and
does not obstruct any serviceable areas. Do not force or jam the
module into tight places instead of mounting. The module must be
free from all moving parts such as brake, clutch and gas pedal
linkages. Do not place the module directly in front of a heater vent.
Installing the External Long Range Antenna - To insure the best
possible reception, place the antenna in the center of the windshield
below the tint screen and behind the rear view mirror. Before
attaching to the glass ensure that the surface is clean and dry. Run
the cable under the head liner and behind the A-pillar panel. Be
careful not to pinch the antenna cable. Plug the antenna into the
BLUE connector on the Control Module.
Testing The System - When the installation is complete, it will be
necessary to test that the system is working correctly. The system’s
default programming will work on the majority of vehicles, but might
need to be adjusted for some applications. If the installation
requires special timing or additional features, proceed to Program
Mode. The system must be Tach Learned (Tachless learned on TL
models) before the remote starter will make a start attempt. If the
remote starter does not make a start attempt check if the park lights
are flashing a diagnostic code, if so look the code up in the
Diagnostic Chart to find the shutdown input that is preventing the
system from starting. If the vehicle does make a start attempt but
fails to start. Check all connections and insure that all wiring is
connected correctly. The vehicle may be equipped with a factory
anti-theft system. Vehicles equipped with factory anti-theft systems
will usually have some sort of Security or Anti-Theft light located in
the instrument cluster.
REMOTE VEHICLE STARTER INSTALL MANUAL
PAGE 5

Wiring Diagram
11
55
33
22
44
66
1
2
3
4
5
6
7
8
9
10
11
12
13
14
YELLOW
YELLOW
PURPLE**
BLUE/WHITE***
GREEN
RED/WHITE
WHITE
BLUE
RED
BROWN
GREEN/WHITE
RED
ORANGE
GREEN**
WHITE*
WHITE/BLUE
BLACK
BLUE
BLACK/WHITE**
PINK
Re-arm Output (-)250ma
Door Pin Input (+)**
Tach Detection Input (A/C)***
Heater/Accessory Output (+)
Trunk Release Output (-)250ma
Park Light Output (+)10amp
Diesel Wait To Start Input (+or-)
12volt Input (+)30amp
Dis-arm Output (-)250ma
Hood Pin Switch Input (-)
Ignition Output (+)
Parking Brake Input (-)**
Brake Light Switch Input (+)
Selectable Output (+)*
Horn Output (-)250ma
System Ground Input (-)
12volt Input (+)30amp
Ground While Running Output (-)
Door Pin Input (-)**
Starter Output (+)
*See pages 8-9 for wiring descriptions.
** “M” series MANUAL TRANSMISSION vehicles only!!!
*** Optional connection on “TL” models
NOTE: 250ma outputs are low current and may require additional
parts (relays) to active optional features.
INSTALL MANUAL REMOTE VEHICLE STARTER
PAGE 6

ACTIVE RF ANTENNA**
1 2
3
NOTE: The jumpers control the output from the WHITE wire on the
main 6- pin harness. This is an 30amp relayed output.
*The factory default setting of the Selectable Output jumper is position #3.
Output on White wire Jumper position
Second Starter Position 1
Second Accessory Position 2
Second Ignition Position 3
Status Led’s Program Button
**The antenna MUST be connected for the system to operate
*The centre pin of the keyless entry harness is ONLY available with plug-in
devices such as the VP-1, DL-3, DL-7 and Data Bus Modules.
Overloading this output will damage the remote starter.
1
2
3
1
2
3
4
1
2
3
1
2
Jumpers
Wiring Diagram
REMOTE VEHICLE STARTER INSTALL MANUAL
PAGE 7
GREEN
WHITE/VIOLET
RED*
BLACK
BLUE
RED
Door Lock Output (-)250ma
Ground While Running Output (-)250ma
12v Output (+)250ma (see notes above)*
Ground Output (-)250ma
Door Unlock Output (-)250ma
12Volt Output (+)250ma
(-) Input Trigger (13xx Series Only)
NOTE: The 2 pin white and 3 pin white auxiliary connectors are not
available on the 12xx series.

Wiring Descriptions
MAIN CONNECTOR (6pin)
Pin Function Description
1-YELLOW Starter Output - This wire will test 0V in OFF, ACCESSORY and in
the ON key positions. 12v during START ONLY.
2-GREEN Heater/Acc Output - This wire will test 0V in the OFF and START
key positions. 12-14V in the ACCESSORY
and RUN key positions.
3-RED 12volt Input(30amp) -Supplies 12votls for the IGNITION, PARK
LIGHT and SELECTABLE outputs.
4-RED 12volt Input(30amp) - Supplies 12 volts for ACCESSORY and
STARTER outputs.
5-BLUE Ignition Output - This wire will test 0V in the OFF and
ACCESSORY key positions.12V in the
IGNITION, START and RUN positions.
6-WHITE Selectable Output - Output for 2nd IGNITION, 2nd ACCESSORY
or 2nd STARTER.
AUXILIARY CONNECTOR (14pin)
Pin Function Description
1-YELLOW Re-arm(-) - 0.75 second pulse output when is pressed and after
remote start shutdown.
Used for factory alarm re-arm. (Menu 3)
2-RED/ Trunk Release(-) - Programmable output. Hold or button
WHITE for 3 seconds, output will stay active
(max 5 seconds) or (-)park light.
3-BROWN Dis-arm(-) - 0.75 second pulse when and is pressed and before
remote starter activation. Used for factory alarm dis-arm.
4-ORANGE Ground When Running(-) - Output active during remote start.
/Starter Kill Programmable Starter Kill. (Menu 3)
5-WHITE/ Horn(-) - Output to activate factory horn. (Menu 1&2)
BLUE
6-BLACK/ Parking Brake(-) - Input to detect (-) when parking brake switch
WHITE is applied. (“M” series)
7-PURPLE Door Pin(+) - Input to detect 12v when door is open. (“M” series)
8-WHITE Park Light(+) - 10amp positive output to activate park lights.
Programmable output (menu 2)
INSTALL MANUAL REMOTE VEHICLE STARTER
PAGE 8

Wiring Descriptions
Pin Function Description
9-GREEN/ Hood Pin(-) - Input to detect ground when hood is open.
WHITE MUST BE CONNECTED.
10-GREEN Door Pin(-) - Input to detect (-) when door is open. (“M” series)
11-BLACK Ground(-) - System chassis ground input.
12-PINK Brake Light (+) - Positive brake light switch input. Used to detect
the brake switch being applied.
13-BLUE/ Tach(A/C) - A/C Tach signal input. Used to detect engine speed to
WHITE indicate vehicle is running. (Optional on “TL” models)
(Coil, Injector, cam/crank position sensors)
14-BLUE Diesel(+/-) - Programmable Wait to Start Input. Detects 12v or
negative signals. (Menu 3)
LOCK/ UNLOCK CONNECTOR (3pin red)
Pin Function Description
1-GREEN Lock(-) - Programmable LOCK output. (Menu 1)
2-RED 12volts - 250ma 12volt output for relays.
3-BLUE Unlock(-) - Programmable UNLOCK output. (Menu 1)
ANTENNA CONNECTOR (4pin Blue)
RF Antenna with Program Button and LEDs
TEMP SENSOR or INSTANT START CONNECTOR (2pin white)*
Connector for Instant Start or Temperature Sensor inputs.
AUXILIARY CONNECTOR (3pin white)*
Pin Function Description
1-WHITE/ Ground While Running(-) - 250ma ground output while
VIOLET remote starter is active.
2-BLACK Ground(-) - 250ma ground output.
3-RED 12volts(+) - 250ma 12volt output.
*13xx Series Only
REMOTE VEHICLE STARTER INSTALL MANUAL
PAGE 9

Step 1 - Connect All Of the Following Wires
Main Connector (6pin)
YELLOW Starter Output - 12volts during start position only.
GREEN Heater/Acc Output - 12volts in the accessory position off during
start and 14volts during run.
RED 12volt 30amp Input - 12volts from ignition harness or battery.
RED 12volt 30amp Input - 12volts from ignition harness or battery.
BLUE Ignition Output - 12volts in the ignition, start and run positions.
WHITE* Selectable Output - Selectable Output for vehicles that may
require a 2nd Ignition, Accessory or Start.
*(See jumper diagram page 7)
Auxiliary Connector (14pin)
BLACK System Ground Input - Connect to Chassis Ground.
WHITE Park Light Output - Connect to Park Light system.
GRN/WHT Hood Pin Input - Connect to the Hood Pin Safety Switch.
BLUE/WHT* Tach Input - Connect to A/C Tach source. (Above 2 volts AC)
PINK Brake Switch Input - Connect to (+) when the brake pedal
is applied.
*Not necessary on TL models only.
“M” Series (yellow cases)
BLK/WHT Park Brake Input - Connect to Park Brake wire.
GREEN** or Door pin Input - Connect to (-) wire when door open
PURPLE** Door pin Input - Connect to (+) wire when door open
NOTE: Blue/White must be connected on “M” series.
**Connect only ONE of the door input wires.
Important!
Never install an AUTOMATIC TRANSMISSION module into a
MANUAL TRANSMISSION vehicle!
INSTALL MANUAL REMOTE VEHICLE STARTER
PAGE 10

Never install an automatic transmission remote starter into a manual transmission
vehicle!!! Doing so may result in serious injury or death. Do not install remote starters
in convertible vehicles! The following wires must be connected in addition to the
basic remote starter installation.
Park Brake Input- This wire is located at the park brake switch. The wire will
switch to (-) when the park brake is applied.
Never connect the Black/White wire straight to a ground!!!
(-) Door Pin Input- A negative door pin wire will be (+) or neutral when the
door is closed then switch to (-) when the door is opened.
Always ensure that all the vehicles doors are sensed.
(+) Door Pin Input- A positive door pin wire will be (-) or neutral when the door
is closed then switch to (+) when the door is opened.
Always ensure that all the vehicles doors are sensed.
If any Door Pin Switches or the Park Brake Switch is not working correctly...
“DO NOT INSTALL UNTIL THE VEHICLE IS REPAIRED!!!”
Clutch Bypass - In most cases the clutch switch will need to bypassed during
remote starting. This is a temporary bypass, the clutch switch should never be
disconnected or altered to not work as it is indented to”As a Safety Switch”. The
clutch switch is usually a 2 wire switch mounted directly to the clutch pedal. There
are several types of clutch switches that operate in one of the following ways:
NOTE: Blue/White must be connected on “M” series.
Type 1 - Starter Wire Bypass - The starter wire travels form the key switch
through the clutch switch to the starter motor. Connect the remote starters
Starter Output wire directly to the starter motor side of the clutch switch.
Type 2 - Negative (High Current) - This switch grounds the factory starter relay
and allows the vehicle to start. Connect a relay to ground the output side
of the clutch switch wire when the remote starter is activated. The starter
wire is connected at the ignition switch.
Type 3 - Connect Switch - Install a relay to connect the two wires at the switch
when the remote starter is activated. The starter wire is connected at the
ignition switch.
Type 4 - Disconnect Switch Install a relay to disconnect one of the wires at
the clutch switch. The starter wire is connected at the ignition switch.
Testing for the correct wire is critical! Never connect to a circuit if you are not sure
of it’s operation. Contact your dealer or technical support for more information.
REMOTE VEHICLE STARTER INSTALL MANUAL
PAGE 11
Manual Transmission “M” Models

IMPORTANT! The system must be Tach Learned before remote starting.
The Auto Tach Learn is the same for the TL (tachless) series.
1) Turn the ignition key to the “ON” position. The park lights* will turn “ON”
2) Start the vehicle with the key. The LEDs on the antenna will turn on if a
proper tach signal is detected**, after 30-35 seconds the park lights will flash
and the horn (Optional) will honk twice to confirm Tach Learn.
* If the park lights do not turn on check for proper connection on the BLUE
ignition wire at the 6-pin connector. This wire should be connected to the
vehicle main ignition wire and must not turn off during the start position.
If the ignition connection is correct, reset the system (see System Reset
page 15) and repeat step #1.
** If the LEDs do not come “ON” during tach learn, a proper tach signal
was not detected.
NOTE: The LEDs will not turn “ON” for Auto Tach Learn on the TL series.
If the park lights do not flash in Auto Tach Learn mode it may be necessary to
connect to a different tach source. It is important the ignition output from the
remote starter is connected to a wire that does not turn off in the crank position.
The remote starter will not tach learn if connected to the wrong wire.
For best results connect the tach wire to the coil pack or to a fuel injector wire.
New - If the original Tach source is changed a system reset must be
preformed before a new tach signal can be learned to the system.
This does not apply if the Quick Learn feature is being used.
(See page 15 for System Reset).
Your Basic Install Is Complete!
NOTES:
1) If the vehicle does not start when the remote starter is activated, the
park lights will flash a diagnostic code. (See Diagnostic Chart page 24).
2) If the vehicle still does not start, check all connections and check for
factory Anti-Theft system.
INSTALL MANUAL REMOTE VEHICLE STARTER
PAGE 12
Auto Tach (Tachless) Learn

Tach Learning the remote starter is one of the most important steps in
the installation process. Do not tach learn vehicle while the engine is
in high idle. To ensure the best possible tach setting, ensure that the
vehicle is at low idle/ normal operating RPM. Vehicles such as Toyota
and Honda may idle much higher when the engine is warm compared
to starting the vehicle when the engine is cold. The Quick Learn
feature may be used to tach learn the vehicle again but at a normal
engine RPM.
BRAKEBRAKE
1) Start the vehicle and leave it running with the ignition key
until the engine idles down.
2) Press and hold the brake pedal.
3) Press and release, then press and hold the Program Button.
4) The park lights will flash to confirm Quick Learn Tach.
REMOTE VEHICLE STARTER INSTALL MANUAL
PAGE 13
Important Tach Notes
Quick Learn Tach
Quick Learn Tach is designed to re-learn the remote starters tach
setting while the vehicle is at normal idle RPM. Vehicles such as
Toyota and Honda will run at a very high idle for a number of minutes
when first started. If tach learned when the vehicle is at high Idle, then
remote started when the vehicle is cold. The engine does not
increase to the RPM that is was learned at. The following steps can
be used to learn tach at a more suitable idle:
NOTE: The System MUST be “Tach Learn” before the “Quick Learn”
feature will function.
TIP:“Manual Low Idle Learn”. While in “Auto Tach Learn” mode,
firmly apply the park brake and press the brake pedal. Place the
transmission into reverse gear this will lower the Engine Idle.

1) With the ignition in the OFF position, turn the ignition key from “Off” to “On” 3
times, ON-OFF-ON-OFF-ON within three seconds.
NOTE: Leave the key in the ON position
2) Press and release the Program Button. The park lights will flash and the horn
(optional) will honk to confirm entering program mode.
3) Select desired Program Menu (See below). The park lights will flash and
horn (optional) will honk to confirm the selected menu.
4) Select Programmable Setting:
a) Press and release the Program Button the correct number of times to
select the desired Program Setting. The park lights and LEDs will flash
and the horn (optional) will honk to indicate the Program Setting that has
been selected. For example: 1 flash/honk= Program Setting 1;
2 flashes/honks= Program Setting 2; etc…
b) Press and Hold the Program Button until the park lights flash and the
horn(optional) honks to confirm the desired setting. For example: 1 flash/
honk= Setting 1; 2 flashes/honks= Setting 2; 3 flashes/honks= Setting 3.
c) Turning the ignition key to the “Off” position or 30 seconds of no activity
will exit Program Mode. This will be confirmed with a light flash and a
long horn (optional) honk. The Program Menu may be changed at any
time by pressing the transmitter button (below), this will allow the
installer to jump from one menu, then quickly jump to another menu and
change another setting without re-entering Program Mode.
Ignition 3x
On/Off
On/Off On
Press and
Release the
Program Button
For Menu 3,
press the
button
For Menu 1,
press the
button
For Menu 4,
press the
button
For Menu 2,
press the
button
INSTALL MANUAL REMOTE VEHICLE STARTER
PAGE 14
Entering Program Mode
Program Menus
Menu 1: User Settings ( Button) Page 16
This program menu is for the adjustments for the user and door lock options.
Menu 2: Additional Settings ( Button) Page 17
This program menu is for additional settings.
Menu 3: Starter Settings ( Button) Page 18-19
This program menu is for various remote car starter applications.
Menu 4: Tach Settings ( Button) Page 20
This program menu is for tach signal adjustments.

Menu 1 - Press 1 Flash 2 Flashes 3 Flashes
1 Ignition Lock Enabled Lock Only Disabled
2 Horn Honk Type 1 Type 2 All Honks
3 Lock&Unlock Options Double Unlock 3 second 3/4 second
4 Unlock/Disarm 125ms 750ms
Menu 2 -Press 1 Flash 2 Flashes 3 Flashes
1 Secure Service Mode 15 seconds 5 seconds
2 Park Light Output 30 seconds (-) Park Light (+)Park Light
3 Horn Timing 5ms 50ms 10ms
4 Button #4 ( Button) Trunk Release Garage Door Car Finder
5 Reservation Mode Manual Auto Reservation
Menu 3 -Press 1 Flash 2 Flashes 3 Flashes
1 Lock/ Unlock Type Type 1 Type 2 Normal
2 Gas/ Diesel Negative 15 second Gas/Positive
3 Rearm Output Type 1 Type 2 Rearm
4 Run Time 4 Min 45 Min 15 Min
5 Crank Time 10 seconds 3 seconds 5 seconds
6 Starter Disable/GWR Active Passive GWR
7 Safety Start Mode Press twice Press once
Menu 4 -Press 1 Flash 2 Flashes 3 Flashes
1 Low Idle Learn Low Idle Learn
2 Adjust For Over Crank Reduced by 10%
3 Adjust For under Crank Increased by 10%
**Bold type indicates settings that are Factory Default.
System Reset
The system reset will clear any changes made to the Program Menu’s as well
as the Tach setting. When the system reset is complete the system must be
Tach learned before the remote starter will operate.
1) Turn the ignition key from “Off” to “On” 3 times, ON-OFF-ON-OFF-ON within
three seconds. (Leave the key in the ON position)
2) Press and release the Program Button located on the antenna. The park
lights will turn on and the horn (optional) will honk one time.
3) Then press and hold the Program Button until the park lights flash and the
horn (optional) will honk 3 times slowly to confirm system reset.
System is now reset to factory defaults.
NOTE: System Reset does not delete the transmitter codes from memory.
* See the following pages for more detailed programming instructions.
REMOTE VEHICLE STARTER INSTALL MANUAL
PAGE 15
Quick View Programming

Setting 1 Ignition Auto Lock
1) Enable 1 Flash/Honk Doors Lock/Unlock with Ignition key.
2) Ignition Lock Only 2 Flashes/Honks Doors Lock when ignition is turned “ON” only.
*3) Disable 3 Flashes/Honks Lock/Unlock with remote transmitter ONLY
Press & Release the Program Button 1 Time (Setting 1) Confirmed with 1 LED flash.
Press & Hold the Program Button until the appropriate # of park lights/horn (optional) honks, then release
Press & Release the Program Button to proceed to the next step.
Setting 2 Horn Honk Settings (Auxiliary Connector Pin 5)
1) Lock/Unlock chirps Disable 1 Flash/Honk Honks for Panic/Car Finder Only.
2) Lock/Unlock chirps Enable 2 Flashes/Honks No Honks for Start ONLY
*3) All Chirps Enable 3 Flashes/Honks Honks for all features.
Press & Release the Program Button 2 Times (Setting 2) Confirmed with 2 LED flashes.
Press & Hold the Program Button until the appropriate # of park lights/horn (optional) honks, then release.
Press & Release the Program Button to proceed to the next step.
Setting 3 Door Lock Options
1) Double Unlock Pulse 1 Flash/Honk .75 Second lock & 2 unlock pulses
2) 3 Second Lock & Unlock 2 Flashes/Honks 3 Second Lock & Unlock Pulses
*3) .75 Sec Lock & Unlock 3 Flashes/Honks .75 Second Lock & Unlock Pulses
Press & Release the Program Button 3 Times (Setting 3) Confirmed with 3 LED flashes.
Press & Hold the Program Button until the appropriate # of park lights/horn (optional) honks, then release.
Press & Release the Program Button to proceed to the next step.
Setting 4 Door Unlock & Disarm Pulse Duration
1) Short Pulses 1 Flash/Honk 125ms pulses on Unlock & Disarm outputs
*2) Normal Pulses 2 Flashes/Honks 750ms pulses on Lock/Unlock & Disarm outputs
Press & Release the Program Button 4 Times (Setting 4) Confirmed with 4 LED flashes.
Press & Hold the Program Button until the appropriate # of park lights/horn (optional) honks, then release.
Press & Release the Program Button to proceed to the next step.
NOTE: Settings 5, 6 and 7 are not available.
INSTALL MANUAL REMOTE VEHICLE STARTER
PAGE 16
Menu 1- User Settings
Press and
Release the
button for
Menu 1
Press and Release
the Program Button
# of Times for
Setting Chosen
Press and Hold
the Program Button
to Change Option
Ignition 3x
On/Off
On/Off On
Press and
Release the
Program
Button

Setting 1 Secure Valet Mode (time required to set the system into Service Mode)
1) Secure Valet 1 Flash/Honk Hold the Program Button for 15 seconds
*2) Normal Valet 2 Flashes/Honks Hold the Program Button for 5 seconds
Press & Release the Program Button 1 Time (Setting 1) confirmed 1 LED flashes.
Press & Hold the Program Button until the appropriate # of park light/horn (optional)honks, then release.
Press & Release the Program Button to proceed to the next step.
Setting 2 Parking Light/Trunk Output (14 pin auxiliary connector pins 2&8)
1) 30 sec. Output 1 Flash/Honk On for 30 seconds when is pressed
2) Negative Park Lights 2 Flashes/Honks Switches the Park Lights/Trunk Outputs
*3) Park Lights 3 Flashes/Honks 2 Flashes when is pressed
Press & Release the Program Button 2 Times (Setting 2) confirmed 2 LED flashes.
Press & Hold the Program Button until the appropriate # of park light/horn (optional)honks, then release.
Press & Release the Program Button to proceed to the next step.
Setting 3 Horn Honk Timing (14 pin auxiliary connector pin 5)
1) 5 ms Pulse Output 1 Flash/Honk Short(Quiet) Horn Output Pulses
2) 15 ms Pulse Output 2 Flashes/Honks Long(Loud) Horn Output Pulses
*3) 10 ms Pulse Output 3 Flashes/Honks Normal(Medium) Horn Output Pulses
Press & Release the Program Button 3 Times (Setting 3) confirmed 3 LED flashes.
Press & Hold the Program Button until the appropriate # of park light/horn (optional)honks, then release.
Press & Release the Program Button to proceed to the next step.
Setting 4 Button Operations
1) Trunk Release 1 Flash/Honk Button activates Trunk Release
2) Garage Door Interface 2 Flashes/Honks Button activates Garage Door Interface
*3) Car Finder 3 Flashes/Honks Button activates Car Finder Mode
Press & Release the Program Button 4 Time (Setting 4) confirmed 4 LED flashes.
Press & Hold the Program Button until the appropriate # of park light/horn (optional)honks, then release.
Press & Release the Program Button to proceed to the next step.
Setting 5 Reservation Mode ( “M” units only)
1) Manual Reservation 1 Flash/Honk Activate Reservation Mode by pressing Button
*2) Auto Reservation 2 Flashes/Honks Activate Reservation Mode by pressing brake
Press & Release the Program Button 5 Time (Setting 5) confirmed 5 LED flashes.
Press & Hold the Program Button until the appropriate # of park light/horn (optional)honks, then release.
Press & Release the Program Button to proceed to the next step.
REMOTE VEHICLE STARTER INSTALL MANUAL
PAGE 17
Menu 2- Additional Settings
Press and
Release the
button for
Menu 2
Ignition 3x
On/Off
On/Off On
Press and
Release the
Program
Button
Press and Release
the Program Button
# of Times for
Setting Chosen
Press and Hold
the Program Button
to Change Option

Setting 1 Special Door Lock/Unlock Operations (Factory Alarm Rearm).
1) Type 1 1 Flash/Honk Unlock before start. Lock pulse after start and shutdown.
2) Type 2 2 Flashes/Honks Lock pulse ONLY after remote start shutdown.
*3) Type 3 3 Flashes/Honks Default Lock/ Unlock Pulses.
Press & Release the Program Button 1 Time (Setting 1) Confirmed with 1 LED flashes.
Press & Hold the Program Button until the appropriate # of park lights/horn (optional) honks, then release.
Press & Release the Program Button to proceed to the next step.
Setting 2 Gas/Diesel Mode (Auxiliary Connector Pin 12, 12xx series)
1) (+) Input 1 Flash/Honk (+) Glow Plug input. Waits maximum 30 seconds
.2) Time Delay 2 Flashes/Honks Waits for approximately 15 seconds.
*3) Gas/ (-) Input 3 Flashes/Honks Waits 2 seconds if no diesel input is detected.
Press & Release the Program Button 2 Times (Setting 2) Confirmed with 2 LED flashes.
Press & Hold the Program Button until the appropriate # of park lights/horn (optional) honks, then release.
Press & Release the Program Button to proceed to the next step.
Setting 2 Gas/Diesel Mode (Auxiliary Connector Pin 12, 13xx series)
1) (-) Input 1 Flash/Honk (-) Glow Plug input. Waits maximum 30 seconds.
2) Time Delay 2 Flashes/Honks Waits for approximately 15 seconds.
*3) Gas/ (+) Input 3 Flashes/Honks Waits 2 seconds if no diesel input is detected.
Press & Release the Program Button 2 Times (Setting 2) Confirmed with 2 LED flashes.
Press & Hold the Program Button until the appropriate # of park lights/horn (optional) honks, then release.
Press & Release the Program Button to proceed to the next step.
NOTE: Setting 2 will vary depending on the board layout 12xx or 13xx series..
Setting 3 Rearm Output (Auxiliary Connector Pin 1)
1) Type 1 1 Flash/Honk Pulse after start and with lock.
2) Type 2 2 Flashes/Honks Pulse after start only.
*3) Factory Re-arm 3 Flashes/Honks Pulse with lock and after starter shutdown.
Press & Release the Program Button 3 Times (Setting 3) Confirmed with 3 LED flashes.
Press & Hold the Program Button until the appropriate # of park lights/horn (optional) honks, then release.
Press & Release the Program Button to proceed to the next step.
INSTALL MANUAL REMOTE VEHICLE STARTER
PAGE 18
Menu 3- Starter Settings
Press and
Release the
button for
Menu 3
Ignition 3x
On/Off
On/Off On
Press and
Release the
Program
Button
Press and Release
the Program Button
# of Times for
Setting Chosen
Press and Hold
the Program Button
to Change Option

Setting 4 Run Time
1) 4 Minutes 1 Flash/Honk Runs for approx. 4 minutes when activated.
2) 45 Minutes 2 Flashes/Honks Runs for approx. 45 minutes when activated.
*3) 15 Minutes 3 Flashes/Honks Runs for approx. 15 minutes when activated.
Press & Release the Program Button 4 Times (Setting 4) Confirmed with 4 LED flashes.
Press & Hold the Program Button until the appropriate # of park lights/horn (optional) honks, then release.
Press & Release the Program Button to proceed to the next step.
Setting 5 Maximum Crank Time
1) 10 Seconds 1 Flash/Honk 10 sec max time that the starter will stay engaged.
2) 3 Seconds 2 Flashes/Honks 3 sec max time that the starter will stay engaged.
*3) 5 Seconds 3 Flashes/Honks 5 sec max time that the starter will stay engaged.
Press & Release the Program Button 5 Times (Setting 5) Confirmed with 5 LED flashes.
Press & Hold the Program Button until the appropriate # of park lights/horn (optional) honks, then release.
Press & Release the Program Button to proceed to the next step.
Setting 6 Anti-Grind/Starter Kill (Auxiliary Connector Pin 4)
1) Active 1 Flash/Honk (-)When locked and during remote start (Anti-Grind).
2) Passive 2 Flashes/Honks (-)When locked/ 30 seconds after ignition is OFF or pressed
*3) GWR 3 Flashes/Honks (-) Output during remote start only. (Anti-grind/ Bypass)
Press & Release the Program Button 6 Times (Setting 6) Confirmed with 6 LED flashes.
Press & Hold the Program Button until the appropriate # of park lights/horn (optional) honks, then release.
Press & Release the Program Button to proceed to the next step.
Setting 7 Safety Start
1) Safety On 1 Flash/Honk Press the button twice within 3seconds to remote start.
*2) Safety Off 2 Flashes/Honks Press the button once to remote start vehicle.
Press & Release the Program Button 7 Times (Setting 7) Confirmed with 4 LED flashes.
Press & Hold the Program Button until the appropriate # of park lights/horn (optional) honks, then release.
Press & Release the Program Button to proceed to the next step.
REMOTE VEHICLE STARTER INSTALL MANUAL
PAGE 19
Menu 3- Starter Settings - continued

Setting 1 Low Idle Learn- Same function as doing the Quick Tach Learn.
This option is used for vehicles that maintain a High or Erratic idle after starting and need
more than 30 seconds to establish a stable idle.
1) Enter Program Mode.
2) Press and release the button on the remote.
3) Start the vehicle.
4) Press and release the Program Button (LEDs will be flashing one time)
5) Press and hold the Program Button for 3 seconds.
6) Release the Program Button. LEDs will be on steady to indicate correct tach signal. The
park lights will flash twice and the horn (optional) will honk twice to confirm that the tach
signal has been learned.
NOTE: Must Tach Learn (see page 12) before Low Idle or Quick Tach learn.
Setting 2 Over-Crank Adjustment.**
1) Enter Program Mode.
2) Press and release the button on the remote.
3) Press and release the Program Button twice. (LEDs will flash 2 times consecutively)
4) Press and hold the Program Button.
NOTE: The park lights will flash and the horn will honk one time each time the park lights
flash and the horn honks the setting is increased.
5) Release the Program Button. (Exit Program Mode and test remote starter)
Setting 3 Under-Crank Adjustment.**
1)Enter Program Mode.
2)Press and release the button on the remote.
3)Press and release the Program Button three times. (LEDs will flash 3 times consecutively)
4) Press and hold the Program Button.
NOTE: The park lights will flash and the horn will honk one time each time the park lights
flash and the horn honks the setting is increased.
5) Release the Program Button. (Exit Program Mode and test remote starter)
**Repeat steps 1-5 if necessary.
INSTALL MANUAL REMOTE VEHICLE STARTER
PAGE 20
Menu 4- Tach Settings
Ignition 3x
On/Off
On/Off On
Press and
Release the
Program
Button
Press and
Release the
button for
Menu 4
Press and Release
the Program Button
# of Times for
Setting Chosen
Press and Hold
the Program Button
to Change Option
