ultracomfort UC114 User manual

Model UC114
Power Lift & Recline Chair
OWNER’S MANUAL
AND
LIMITED LIFETIME WARRANTY
401 Bridge Street
Old Forge, Pa. 18518
Phone [phone]
Fax [phone]
www.ultracomfort.com
MSWARB-UC114+UC216-122320

2
Dear Valued Customer,
Thank you for purchasing this UltraComfort Power
Lift and Recline Chair. We believe that this product is
made from the highest quality components available, is
engineered to give you maximum service with minimum
maintenance, and is backed up with the strongest
warranty in the industry. We hope that you enjoy years of
pleasurable use of your UltraComfort chair and that this
chair becomes a true assist to you in both sitting down and
standing up.
Please take a few moments to review this manual to become
familiar with the operation of this chair and our warranty.
Also, please note the following safety information: This
power lift and recline chair is a motor operated appliance
approved for household and commercial use designed to
help you sit down and stand up. Do not allow children to
operate the chair at any time.
Again, thank you for selecting this UltraComfort chair.

3
Safety Guidelines
The symbols below are used in the owner’s manual and/or on the product
to identify warnings and notify you of important safety information. Make sure
you read and understand them completely.
WARNING! Indicate(s) a hazardous situation which, if not
avoided, could result in death or serious injury. This icon is
represented as a black symbol on a yellow triangle with a
black border.
MANDATORY! Failure to perform mandatory actions could
cause personal injury and/or equipment damage. This icon
is represented as a white symbol on a blue dot with a white
border.
PROHIBITED! Indicate(s) an action(s) that should not be
performed under any circumstance. Failure to adhere could
cause personal injury and/or equipment damage. This icon is
represented as a black symbol with a red circle and red slash.
Safety Symbols
The symbols below identify warnings, mandatory actions, and prohibited
actions. They can be found in the owner’s manual and/or on the product. Make
sure you understand all safety labels before operating the product. Do not remove
safety labels from your product.
Read and follow
owner’s manual!
Pinch/Crush Point
Hazard!
Transformer
Crush Hazard!
Fire Hazard!
Child and/or Pet
Crush Hazard!
Adult, Child and/
or Pet Tip Over
Hazard!
continued on next page

4
continued from previous page
Safety Guidelines
Class II Device!
Indoor use only!
Do Not Smoke!
Electrical hazard!
Do not dispose in trash!
Batteries required!

5
MANDATORY
READ THIS MANUAL FIRST BEFORE INSTALLING OR
OPERATING YOUR POWER LIFT AND RECLINE CHAIR.
Your power lift and recline chair has been engineered from the
leg levelers up to provide the ultimate in strength and reliability. Great care
has been taken to provide you with total comfort and safety. UltraComfort
thoroughly inspects and tests each unit prior to shipment.
WARNING
Care should be taken in the unpacking of this unit, so as not to
cause injury to persons or damage to the unit. Dispose of all plastic
bags and covers, as they can be a smothering hazard to small
children.
Do not allow children or pets near the chair while
the chair is operating.
Do not allow children to play with or operate the
chair at any time.
Hand control should be unplugged and placed out of
the reach of children when the chair is not in use.
Do not flop down into the chair when getting into it, or while it is in
its lift position. Flopping down into the chair will damage it and could
cause personal injury.
Do not allow anyone to sit on your lap, or on the arm of the chair, or on
the footrest while in or operating the chair, as it may cause tipping and
could result in personal injury.
Do not place fingers or hands between the seat cushion and the inside
arm of the chair while sitting in the chair or when the chair is in
operation or plugged into a power source.
Do not retrieve fallen objects from inside or under the chair while the
chair is plugged into a power source.
Do not operate the chair if there are any persons,
pets or other obstructions under or in front of the
footrest, under the chair or behind the chair.
Do not position yourself, child and/or pet too high on
the chair while the chair back is reclined. This can
cause a tip over hazard. Make sure you are properly
fitted for the lift chair prior to operating the chair.

6
Do not smoke while operating, sitting or resting in the chair.
To reduce risk of electrical shock, do not immerse any of the
electrical components into a liquid, or spill any liquids onto electrical
components. Do not open any of the electrical components. There are
no serviceable parts.
Warranty will be void if any of the electrical components are opened
by other than a qualified service person.
Make sure the chair is placed at the specified distance from a wall/
corner (page 7). Failure to do so can damage the chair and will void
the warranty.
Do not use any type of electrical extension cord to plug your
chair into an electrical outlet. Make sure that all electrical
products and their wires are positioned away from your
chair as the metal lift frame mechanism could crush them
and create a fire hazard and/or may cause personal injury.
Do not operate your lift chair while intoxicated or taking medications
that impair your mental or physical abilities to operate the chair safely.
Consult with your doctor about any medications you are taking that
may affect the safe operation of the chair.
Do not operate this product if you have any medical conditions that
result in limited, debilitating mental or physical capacity. You should
consult your doctor before using this product.
Consult with your physician regarding using the Trendelenburg
position.
Placing the lift chair in the center of a room or too far away from a wall
will create a tripping hazard, because the power wires for the lift chair
will be crossing main traffic areas in the residence.
Leakage from the 9 VDC backup batteries can result in property
damage. Periodically inspect and replace the batteries. Read the
“Battery Back Up System” and “Care and Maintenance” sections in
this manual.
If the lift chair user is unconscious or sleeping the hand control may
inadvertently become activated in a way that may force the user out
of the chair.
Should you ever encounter a problem with the operation of your
power lift chair, discontinue all use of the product upon discovery of
the problem. Contact the provider from whom you purchased your
chair to arrange service.
Exceeding the stated weight limit listed in this manual can result in
instability of the lift chair, causing a potential tip over hazard.

$POTVMUUIFPXOFSTNBOVBMPGUIFDIBJSBOEBQIZTJDJBOUPEFUFSNJOF
JGZPV BSF DBQBCMF PG NPWJOH PS MJGUJOH UIF DIBJS BT UIJT XJMM DBVTF
TFSJPVTJOKVSZJGOPUEPOFQSPQFSMZ
7FSJGZ UIBU BMM PCKFDUT JODMVEJOH IBOET BOE GJOHFST BSF OPU CFUXFFO
UIF BSN PG UIF DIBJS BOE UIF PQFO DPNQBSUNFOU CFGPSF
DMPTJOH UIF DPNQBSUNFOU BT UIJT XJMM SFTVMU JO QSPQFSUZ EBNBHF PS
TFSJPVTJOKVSZ
5IJTJTBOFMFDUSJDBMEFWJDFBOEXJMMCFJNQBDUFECZBOZQPXFSGBJMVSF
5P PQFSBUF UIJT DIBJS QSPQFSMZ ZPV NVTU SFBE BOE VOEFSTUBOE
UIFJOUFOEFEVTFPGUIFQSPEVDUBOEPWFSBMMPQFSBUJPOPGUIFDIBJSBT
NJTVTFPSMBDLPGQSPQFSUSBJOJOHNBZMFBEUPTFSJPVTJOKVSZ
6TFFYUSFNFDBSFXIFOVOQBDLJOHBTTFNCMJOHBOEEJTBTTFNCMJOHPG
UIJTVOJUTPBTOPUUPDBVTFJOKVSZUPQFSTPOTPSEBNBHFUPUIFVOJU
7

8
Wall
Side
View
Corner
Top
View
20"20"20"
6.
Adjust the leg levelers on the bottom of the chair if necessary to level the chair.
Some high pile carpets can obstruct the footrest operation by rubbing against
it. Adjust the levelers to a height above the pile.
7.
Installation Of Your Power Lift Chair
ModelsUC114 and UC216
1. Remove the transformer and hand control from under the chair and place
two 9 volt batteries in transformer as shown. Place transformer on
the fl oor behind the chair.
2. Plug the transformer into a 115-120V 60Hz A.C. outlet and connect
the power cable from the chair into the transformer as shown. Power
cable is located under the chair attached to the motor with white zip
tie. Remove zip tie, extend the cable under and out behind the chair.
UC11420 in. 20 in.
L.E.D. light
L.E.D. light
From motor
To outlet
115-120V A.C.
DC Power
Bottom view of
Transformer
Transformer
Plug
Install two 9 volt batteries
in transformer for battery
backup (See page 12)
(batteries not included)
P
A
T
E
N
T
E
D
3.
4.
5.
Plug the hand control into the
lock located at the back of the
seat and lay it on top of the seat
see page 8 hand control
routing.
Align the back brackets and the
seat brackets, then push on the
seat back until they are locked
into place.
Attach the bottom of the
outside back to the Velcro on
the arm cross rail.
Place the chair in the desired
position in the room, keeping it
20" from the wall. If placing the
chair into a corner, keep it 20"
from the wall as shown. See
distance chart below for your
model.
Distance Required From Wall
When Reclined
Model No. Wall Corner
UC216 20 in. 20 in.

9
Hand Control Inside Arm Routing
To move the hand control from one side to the other, follow the
instructions below.
1. Lift the bottom of outside
back from the Velcro on
the arm cross rail.
2. Remove the hand control
wire from the J-Clip.
3. Unlock the extension
wire, and separate. Note:
This step disables all
lift chair functions.
4. Route the hand control
wire through the opposite
J-Clip.
5. Reconnect the extension
wire, and lock to secure. Extension
Lock J-Clip
Hand Control
J-Clip P-Clip
CARE AND MAINTENANCE
Your lift chair will require routine maintenance checks. You can perform some
of these checks, while others may require assistance from a provider. By
following these maintenance checks, you can make sure your lift chair gives
you years of trouble-free operation. If you have any questions or concerns
regarding your lift chair’s care and maintenance, contact your provider.
Before cleaning your lift chair, consult your provider for the proper types
of cleaner and cleaning methods.
Keep all electrical components free from moisture and liquid spills.
Intended for indoor use only.
Periodically inspect all wiring harnesses to make sure they are not cut,
damaged, frayed, or disconnected. If damage of any type is present,
unplug the lift chair and contact your provider.
Periodically check all fasteners for tightness, wear, and corrosion. If any
of these are present, unplug the lift chair and contact your provider.
Warning: Be careful of pinch points and sharp metal parts (wear
gloves).
Replace the batteries after one use. Replace the batteries yearly, even if
they were not used. Batteries are intended for one use only!

10
1.
2.
To recline your chair, press the down button (S2) and hold until you reach
your desired position. Then release the button.
To return to a seated position from recline, press the 1AMP USB
up button (S1) and hold until the chair returns to a closed Charging Port
seated position. Then release the button.
3. To lift your chair, press the up button (S1) and hold until
you reach your desired height. Then release the button.
4. To return to a seated position from lift, press the
down button (S2) and hold until the chair returns to the
floor, seated position. Then release the button.
5.
6.
To lift your chair from a reclined position, press the
up button (S1) and hold. The chair will keep going past
the seated position and start to lift. Release the button
when the chair reaches the desired height.
To recline your chair from the lift position, press the
down button (S2) and hold. The chair will keep going past
the seated position and start to recline. Release the button
when the chair reaches the desired reclined position.
7. Getting into your lift chair. While standing next to
your chair, press the chair up button (S1) and raise the
chair to a height you can sit against. This height will vary
from person to person depending on the individual’s needs. Raise the chair
high enough so you do not have to flop down into the chair. Flopping down
into the chair will damage it and could cause personal injury. Press the
chair down button (S2). As the chair continues downward, adjust yourself into
a position that is comfortable to you. Continue pressing the button until chair
is in the seated position (chair firmly on the floor), then release the button.
8. Getting out of your chair, press the chair up button (S1) and raise the chair
to a height that enables you to easily stand. Release the button. Return the
chair to the seated position (chair firmly on the floor) after getting out of the
chair so children, pets or obstructions do not get under the chair.
Note: Your UltraComfort power lift chair can be stopped at any time
during lift or recline by releasing the selected button, offering you
a wide range of comfortable positions. Select the position that best
suits your needs. The motor is set to shut off when it reaches its
fully extended or fully retracted position if the selected button is not
released. If you should go past your desired position, select the button
to bring you back to your desired position. You can repeat the process
as often as you like.
USB Disclaimer:
The supplied USB charging port is only intended to be used
with appropriate smart devices such as phones or tablets. Please refer to
device manufacturer’s charging requirements before using. UltraComfort
excludes liability for any damages or data loss regarding the charging device
on a computer or other electronic device connected to the USB port.
Power Lift Chair oPeration
Models UC114 and UC216
AMERICA
L.E.D.
light
S1
S2
AAA
PPP
TTT
EEE
NNN
TTT
EEE
DDD

11
1 2
3
4 5
UC114 Articulating Head Rest
The head rest has three positions. Push the top of the back forward to
adjust the head rest, you will hear a click when it reaches a position,
continue pushing forward until no clicks are heard to return the head
rest to an upright position.

12
P
A
T
E
Battery Back Up System
Your UltraComfort power lift chair comes with a battery back up system so
the chair can return to the seated position in the event of a household power
failure. The batteries have enough energy to bring the chair to a seated
position from the recline position. The batteries do not have enough energy nor
are they intended to operate the chair for a prolonged period of time in the absence
of standard household voltage (120 volt, 60 Hz). Batteries should be
replaced after one use. Batteries should be changed yearly. (See
installation page 8).
Smart Tek™ (Power Indication)
Your power lift chair is equipped with an indicator light on the hand control. This
light illuminates green when any button on the hand control is pressed,
indicating power to the hand control.
Your power lift chair also comes with a power indicator light on the transformer
and on the power cord connecting the motor to the transformer. The lights
illuminate green constantly, indicating power from the outlet to the
transformer and the motor. The lights have been provided to help you
identify electrical disconnects, should they occur, and to help your provider to
diagnose electrical problems, should they occur.
Should the chair not operate and the lights are out, check all
electrical connections to the chair. Make sure everything is plugged in
properly and there is power to the outlet into which the chair is plugged (see
installation on page 8for electrical connections). Should you ever
encounter a problem with the operation of your power lift chair and
the lights are on, such as mechanical problems or one light is out,
discontinue all use of the product upon discovery of the problem.
Contact the provider from whom you purchased your chair. They will be able
to resolve problems and take care of proper factory service if needed. You will
need to be prepared to answer some basic questions about your power
lift chair, such as model and serial number. The model and serial
number are located on the back of the hand control warning label attached
to the cord and the rear of the lift frame. Your provider will ask you
questions about your power indicator lights, such as which one is out.
Prior to calling your provider, check all the electrical connections to the
chair. Make sure everything is plugged in properly and there is power to
the outlet into which the chair is plugged (see installation on page 8 for
electrical connections).
N
T
E
D
T
N

13
CONSUMER ONE YEAR WARRANTY
The manufacturer through its authorized distributor/service organization
warrants this chair to the original consumer only, against defects in material or
workmanship as follows:
Lifetime Warranty
The manufacturer warrants for the lifetime of the chair to the original consumer
only to repair or replace at their option the Lift Mechanism, Chair Frame and
Recline Mechanism.
One Year Parts Warranty
The manufacturer warrants the electrical parts of this chair against defects to the
original consumer only for a period of one year. The labor to replace electrical
and mechanical parts is subsidized for a period of one year. There is no in home
service warranty provided on modelsUC114 and UC216.
Terms Applicable to Warranties
The manufacturer will, at its option, repair and/or replace the defective parts
and/or components provided that the warranty parts have not been subjected
to misuse, abuse or improper service by the consumer; have not been damaged
in transit or handling, and/or have not been altered or repaired by unauthorized
representatives. This warranty does not include costs for unnecessary service
calls, i.e., service calls solely for the purpose of educating the consumer about
the product, finding an unsatisfactory power connection or for examination of
any Warranted parts etc. All repairs must be approved by the manufacturer
before service is provided. Any repairs by unapproved or unauthorized
representatives will void all warranties.
Exceeding the weight capacity of the chair will void all warranties. ModelsUC114
and UC216 weight limit is 375 lbs. Fabric shading cannot be guaranteed for
replacement parts or replacement chairs.
In the event that the product does not conform to this warranty at any
time while this warranty is in effect, the manufacturer will correct the
defect in conformity with the Consumer One Year Warranty.THE ONE
YEAR WARRANTY SET FORTH ABOVE IS THE SOLE AND ENTIRE WARRANTY
PERTAINING TO THE PRODUCT AND IS IN LIEU OF AND EXCLUDES ALL
OTHER WARRANTIES OF ANY NATURE WHATSOEVER, WHETHER EXPRESS,
LIMITED, IMPLIED, OR ARISING BY OPERATION OF LAW INCLUDING, BUT
NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR APARTICULAR PURPOSE. THIS WARRANTY DOES NOT COVER
OR PROVIDE FOR THE REIMBURSEMENT OR PAYMENT OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES. Some states do not allow this exclusion or
limitation of incidental or consequential damages so the above limitation
or exclusion may not apply to you.
The manufacturer shall not be liable for any incidental or consequential damages
or for any other damage or loss not contained in this warranty. This warranty
gives you specific legal rights, and you may also have other rights which may
vary from state to state.

#
AMERICA
UltraComfort 401 BRIDGE ST OLD FORGE PA 18518-2323
PLACE
STAMP
HERE

#

16
#
AMERICA
for Your reCorDs
Please fill in your Power Lift & Recline Chair information below. This
information will be useful in the event that you should ever need to contact
UltraComfort, Inc. concerning your lift chair.
Date of Purchase ___________________________________________________
Model ____________________________________________________________
Serial Number _____________________________________________________
Your UltraComfort representative or provider
Name ____________________________________________________________
Company _________________________________________________________
Address __________________________________________________________
CAUTION
Do not allow children to play on this mechanized furniture
or operate the mechanism.
Leg rest folds down on closing so that a child could
possibly be injured.
Always leave chair in a sitting position. Keep hands
and feet clear of mechanism. Only the occupant should
operate it.

CAUTION
READ BEFORE OPERATING
FAILURE TO DO SO MAYVOID WARRANTY
Chair must be placed to allow free movement
between:
BACK of CHAIR and WALL
FOOTREST andanyobjectinFRONT of CHAIR
Keep children, pets and foreign objects from
back of chair or underneath chair and from in
front of footrest while operating chair.
Do not allow children to play on this mechanized
furniture or operate the mechanism.
Leg rest folds down on closing so that a child
could possibly be injured.
Always leave chair in a sitting position. Keep
hands and feet clear of mechanism. Only the
occupant should operate it.
Failure to do so may cause injury or damage
to chair.
1-866-793-5100
AMERICA
