UltraLux SCRFC25 User manual

1
www.ultralux.bg
USER MANUAL
RF Controller for single colour LED lighting –SCRFC25
Technical details:
•Working temperature: -20 ÷ +60˚C
•Working Voltage: DC 12V ÷ 24V
•Dimensions: 127/41/32 mm
•Output current: max. 25 А
•Max. output power: 300W (12VDC), 600W
(24V DC)
•Frequency: 433.92 MHz
•Remote distance: Up to 20 m
•Static power consumption: <1W
Product Feature
Designed for single color constant voltage LED lights,
Working voltage DC12-24V.
High watt output design, up to 1*25A/ 300W.
Memory function, each time power-on reserve the mode which stop in the last power-down.
Easy connection to achieve multiple dimmers sync-work by RJ45 terminal.
Adopts RF 14keys remote control with fashion appearance, no need line-of-sight. Control range up to
20 meters.
Long-press the brightness and speed key can get the fast adjustment, convenient for operation.
Interface Specifications
Direction for use
Connect the load wire at first, followed by the power wire; Please ensure short circuit can not occur
between wires before turning on the power；
Adopts RF remote technology, 14 buttons in total.

2
www.ultralux.bg
Name
Description
Set button
For setting the night light and matching code with receiver. Under night light mode, press “Set
button” and hold on for 10 seconds will go into the night light setting. Press the set button again to
save the setting and quit out.
ON
Turn on
OFF
Turn off
Brightness +
The brightness will add 1 level after each time press. Long-press can get fast adjusting.
Brightness -
The brightness will reduce 1 level after each time press. Long-press can get fast adjusting.
Hot brightness key +
4 levels brightness (10%、30%、70%、100%) hot selection key, lights will go to next one after each
pressing.
Hot brightness key -
4 levels brightness (10%、30%、70%、100%) hot selection key, lights will go to last one after each
pressing.
Mode key
3 modes in total: 100% static, flash, breathe
Night light
Press the button go to night light mode（night light Setting：Under night light mode, press “Set
button” and hold on for 10 seconds will go into the night light setting, press the left button to down
the brightness, press the right button to up the brightness. Adjustable range: 1%-10%.）
Speed +
Add the speed of dynamic mode. Long-press can get fast adjusting.
Speed -
Reduce the speed of dynamic mode. Long-press can get fast adjusting.
Delay button
The light will be delay off in 30 seconds.
Tips: Receiver can be controlled by any one the same remote as factory default; remote control delivered with unique RF code as
factory default; if unique-control is needed, please matching the code before installation and using.
Matching code operation
If unique-control or new-coded-remote is needed, pairing the remote and the receiver as below operation
instruction before using:
Step 1: Pressing key “set” and hold on, power on the controller, the load LEDs will be 50% brightness white as
responding.
Step 2: Continuously to press the key “Mode key“ for 3 times within 5 seconds after step 1 ,the brightness of LEDs
will change from 25% -10% -back to preset level.
Code learning successfully, the LEDs will be back to the status before the power off, and the receiver only can be
control by the remote.
If not, please re-operate from step 1 to 2.
Only the latest paired 4 remote controllers can be recognized.
Clear code operation
Back to factory default, wall-panel can be controlled by any one the same remote control.
Step 1: Pressing key “set” and hold on, power on the controller, the load LEDs will be 50% brightness white as
responding.
Step 2: Continuously to press “Delay button“ 3 times within 5 seconds after step 1 ,the brightness of LEDs will
change from 25% -10% as responding.
Code clearing successfully, the LEDs will be back to the status before the power off, and the receiver can be
controlled by any remote control (any one the same remote control can be used to clear the code).
If not, please re-operate from step 1 to 2.

3
www.ultralux.bg
Typical connection diagram
Connection diagram of three controllers with realized synchronization (master-slave mode)
