HotPort® 5020-M mesh node
Items to purchase
You need to purchase and install
50 Ohm terminators (Firetide P/N 7020-1002)
on unused antenna connectors.
If you do not already have one, you need to
purchase a HotView Pro™ management license
and install it on the HotView Pro server.
Required tools
• Administrator computer
• #2 Phillips screwdriver
• Small adjustable wrench
• Wire cutters to cut tie wraps on cables
• Weatherproofing kit with electrical
tape and butyl mastic or silicon tape
• Plastic tie wraps (optional)
• Ladder
3 Log into the mesh node with a computer.
You need to connect your computer directly to the mesh node. To do this, you have to
change the TCP/IP4 address of the computer to be an address on the 192.168.224.xxx
subnet. 192.168.224.150 is the default IP address of nodes.
1. From the computer connected to the node, do one of the following:
• Windows 7 users: go to Start, and then enter View Network
Connections in the search box. Right-click on Local Area Connection >
Properties. From the Networking tab, select TCP/IP4,and then click Properties.
• Windows XP users: go to Start > Connect To > Show all connections > right-
click Local Area Connection and select Properties. Select Internet Protocol,
and then click Properties.
• Windows 8 users: go to Network and Internet > Network Connections > right-
click Wired Ethernet Connection > Properties > Select Internet Protocol
Version 4, and then click Properties.
2. Enter an IP address for your computer of the format 192.168.224.xxx (where xxx is
an address on the same subnet as the node), and then click Apply. Do not use
192.168.224.150.
3. From a command prompt window, start a continuous ping to verify connectivity.
ping 192.168.224.150 -t
4 Log into the HotView Pro server.
1. Start the HotView Pro Launcher.
2. Single-click to start the Quick Launch feature of HotView Pro, which
starts the server and client software at the same time.
3. When prompted, enter:
• User Name: hv_admin
• Password: firetide
4. Click Log In.
5 Load the mesh node into HotView Pro.
1. Go to Mesh > Add Mesh > login with the default information:
• Mesh IP address: 192.168.224.150
• User name: admin
• Password: firetide
2. Click Log In. The node will appear in the HotView Pro interface within a minute.
6 Configure the mesh node.
After you log into the node:
Apply a saved configuration file compatible with your network settings
—OR—
Set the country code and manually configure the wireless settings
Best practice: Copy a configuration file from a HotPort 7000 series mesh node already
in your network. You can use a Network Gateway Interface (NGI) or Gateway Server
(GWS) but those settings do not copy to HotPort 5020-M mesh nodes.
Applying a saved configuration
1. Right-click the HotPort 5020-M mesh node.
2. Select Apply Mesh Configuration.
1Unpack the mesh node and accessories.
2Connect to the mesh node.
Caution! Do not use port 2 or port 3 of a DC HotPort 7020 mesh node to
power a HotPort 5020 node. A HotPort 5020 node needs PoE+ or 802.3at,
and the ports of a HotPort 7020 mesh node are PoE 802.3af-compliant only.
Caution! You cannot use a HotPort 7020 power source (12V) to power to a
HotPort 5020-M mesh node, which requires 15V.
HotPort 5020-M mesh node connections:
• Attach the 5dBi omni-directional staging antennas to these connectors:
• Radio 1/Antenna connector 1
• Radio 2/ Antenna connector 1
• Attach the Ethernet cable from the computer to the mesh node
• Attach the HotPort 5020-M mesh node to the PoE+ injector
• Attach the PoE+ injector and AC cable to power
Caution! You must use the power cable that comes with the node. If you use
a different power cable, you void the product warranty.
Safety Information
Firetide®equipment must be installed by qualified personnel.
Follow safe work practices and use approved non-conducting ladders,
shoes, and other safety equipment. Make sure all equipment is in good
condition. For more information about safety refer to the Firetide website.
Warning! Failure to comply with instructions marked with this symbol
might expose you to non-insulated dangerous voltage that might be
of sufficient magnitude to cause the risk of lethal electric shock to
persons.
Warning! Failure to comply with instructions marked with this symbol
might result in severe personal injury including electrical shock or
permanent damage to equipment.
Caution! Failure to comply with instructions marked with this symbol
might result in data loss or minor injuries.
Documentation
This information is subject to change without notice.
For the current version, visit Firetide Partner portal.
Customer support
Contact your Firetide reseller or visit: http://firetide.com/support/ PoE+
IN
OUT
Box contents
• One HotPort 5020-M mesh node
• Two 5 dBi omni-directional antennas
• Two RP-SMA to type-N adapters
• One PoE+ injector
• One AC power cable (USA type)
• One DC power connector (field
installable)
• One weatherized Ethernet RJ-45
connector (field installable)
• One Ethernet cable (shielded Cat5e)
• Mount kit
• Quick start sheet
• Warranty card
Firetide, Inc.
2105 South Bascom Avenue, Suite 220
Campbell, CA 95008
www.firetide.com
January 2016
P/N 700-0090-001 Rev C
©2016Firetide, Inc. All
rights reserved.
Setting the country code
The system periodically prompts you until the country code is set. When the country
code is set, the node operates at full radio strength and the channels are appropriate
for the country of operation.
Caution! Make sure you configure the node for the correct country of
operation.
1. When the system prompts you to set the country code, select Set Country Code
Now.
2. Select the country of operation from the drop-down list.
3. Click Apply.
Configuring the radios
Each mesh node has two radios.
1. Go to Configuration > Wireless
2. Set the Mesh ID and ESSID.
3. Set the wireless mode and channel for
Radio 1 and Radio 2.
4. Set the wireless and end to end security
if needed.
5. Click Apply.
7 Do indoor testing.
Send data from the administrator computer connected to one mesh node to another
computer connected to another mesh node. After you finish the tests, remove the
staging antennas and Ethernet cable and disconnect from power.
8 Prepare the node for outdoor installation.
Warning! Use appropriately rated antennas for outdoor applications.
Warning! Failure to comply with these installation instructions might result in
severe personal injury including electrical shock or permanent damage to
equipment.
Warning! Make sure that all safety equipment is in good condition. Do not use
broken or damaged tools or equipment. Always use safe work practices and
obey all local and national guidance for earth ground requirements and
electricity.
Note: Collect all tools before you install the node.
1. Attach antennas rated for outdoor use.
2. Attach 50 Ohm terminators to unused antenna connectors.
3. To a pole that you can install at a permanent outdoor site, attach these items:
• C-bracket
• Antennas
4. Attach the node to the bracket.
5. (Optional) Attach a PoE injector.
Note: The PoE+ injector is not weatherproof. Do not expose it to rain or direct
sunlight.
9Check the outdoor environment for safety.
Do not install this product on a windy or rainy day.
10 Install the mesh node in its permanent location.
Note: Refer to the Firetide Best Practices Guide for detailed instructions.
1. Use the correct safety equipment to install the node in its permanent
outdoor location:
• Install a lightning suppressor.
• Use shielded Cat5e cable and connect to earth ground at both ends.
• Install all grounding equipment.
• Make all cable connections weatherproof.
2. (Optional) Attach the PoE+ assembly to power the device.
Caution! Do not use port 2 or port 3 of a HotPort 7020 mesh node to power a
HotPort 5020 mesh node. A HotPort 5020 mesh node needs PoE+ or 802.3at,
and the ports of a HotPort 7020 mesh node are PoE 802.3af-compliant only.
3. (Optional) Use plastic tie wraps to keep the cables tidy.
4. Supply power to the node.
5. Ping the IP address of the node to make sure it works.
Resetting the node to the factory default settings
Do a reset when you remove a device from the field or when communication with a
device is lost. The reset button is behind the pressure relief valve on the left side of
the port connector.
Caution! When a HotPort 5020-M mesh node is reset, configuration
information is erased. The system does not erase the USA (840) country code.
For this procedure you need:
• Paper clip, stiff wire, or thin piece of plastic or wood
• Computer with HotView Pro
• Ethernet cable
• #2 Phillips screwdriver
To reset a HotPort 5020-M mesh node:
1. Supply power to the node.
Wait until the power LED comes on. After
one minute, the node is ready to be reset.
2. Remove the pressure relief valve, and
put it in a safe place.
3. Press and hold for 20 seconds the reset
button with the paper clip or other tool.
The Radio 1 LED blinks to indicate that the
software is rebooting, and you can stop
pressing the reset button.
4. Wait one minute, and then log in with
HotView Pro.
5. Configure the node or apply a previously
saved configuration file.
6. Replace the pressure relief valve that
covers the reset button.
Upgrading the firmware
By default, the system uses the configuration in cache for multiple upgrades.
Best practice: Upgrade the image two times because you want the backup image and
primary images to be the same.
By default, the scheduler activates the firmware immediately.
If you select the Activate Later check box, the scheduler copies the firmware image to
the node but does not activate the firmware.
1. Go to Network > Upgrade Firmware
The upgrade scheduler appears.
2. Click New Scheduler.
3. Select Upgrade.
4. (Optional) Select the time: Later. Use the calendar to a future date and time.
5. Click the tab to select a device type (HotPort Nodes for a mesh network), and then
select the mesh by ID or name.
Note: The system selects all nodes within a mesh for simultaneous upgrade because all
of the nodes have to run the same firmware. If a node should not receive the upgrade
image, you can remove the mark from the upgrade check box.
6. (Optional) Select Activate Later.
7. Select the upgrade image.
8. Click OK.
The “upgrade complete” message means that the image file is on the node and is
valid. You can then activate a few nodes at a time until all of the nodes are running
the same firmware version. After the system activates the firmware, the node
automatically reboots.
End User License Agreement
Visit the Firetide website to download a copy of the End User License Agreement
(EULA).
Radio 1
Radio 2
Pressure relief valve
Power LED

Other Uni-Com Network Hardware manuals

Uni-Com USRobotics USR4503 User manual

Uni-Com

Uni-Com USRobotics USR4503 User manual

Uni-Com USR USR4524-MINI User manual

Uni-Com

Uni-Com USR USR4524-MINI User manual

Uni-Com USR4524 User manual

Uni-Com

Uni-Com USR4524 User manual

Popular Network Hardware manuals by other brands

D-Link SHARECENTER PRO 1100 Quick installation guide

D-Link

D-Link SHARECENTER PRO 1100 Quick installation guide

Seagate GoFlex Home Specifications

Seagate

Seagate GoFlex Home Specifications

Huawei SmartAX MA5616 Configuration guide

Huawei

Huawei SmartAX MA5616 Configuration guide

APM ALINE-8110 Specification sheet

APM

APM ALINE-8110 Specification sheet

NT NetX X Series installation guide

NT

NT NetX X Series installation guide

YOSensi LNRM user guide

YOSensi

YOSensi LNRM user guide

Fortinet FortiGate 400F Series quick start guide

Fortinet

Fortinet FortiGate 400F Series quick start guide

SonicWALL PRO 4100 Getting started guide

SonicWALL

SonicWALL PRO 4100 Getting started guide

TRENDnet TEG-S4M8FXM supplementary guide

TRENDnet

TRENDnet TEG-S4M8FXM supplementary guide

QNAP ES1640dc v2 Quick installation guide

QNAP

QNAP ES1640dc v2 Quick installation guide

D-Link DI-102 - Load Balancing Device user manual

D-Link

D-Link DI-102 - Load Balancing Device user manual

Fortinet FortiADC 2200F quick start guide

Fortinet

Fortinet FortiADC 2200F quick start guide

Atlantic Cozytouch installation manual

Atlantic

Atlantic Cozytouch installation manual

Video Products RJ45-5EWTP-QR-PCB Operation manual

Video Products

Video Products RJ45-5EWTP-QR-PCB Operation manual

Richardson RFPD RadioCarbon RFPD-RC-4450-50 quick start guide

Richardson RFPD

Richardson RFPD RadioCarbon RFPD-RC-4450-50 quick start guide

Panduit SmartZone PVIQ Series Technical reference

Panduit

Panduit SmartZone PVIQ Series Technical reference

CommScope M3200 instruction sheet

CommScope

CommScope M3200 instruction sheet

Cyclades AlterPath OnBoard Administrator's guide

Cyclades

Cyclades AlterPath OnBoard Administrator's guide

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
