Unication Group G-Series User manual
PREFACE
1. PREFACE
Unication thanks you for purchasing the G-Series Single Unit Charger.
Before using the single Unit Charger, please read this manual and follow
the instructions for correct charging and installation.
This charger is used for used for Unication G2/G3/G4/G5 voice pagers only.
Failure to follow these safety instructions could result in safety issues, or
damage to your voice pager, charger or other property. Read all the safety
information below before using you G-Series Single Unit Charger.
Charge your G-Series Pager only with Unication provided batteries.
Keep your charger away from any dangerous environments with high
temperature, high humidity, dust, chemicals and corrosive materials.
Do not disassemble your charger or power adapter.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions : (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS.
DANGER - TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
CAREFULLY FOLLOW THESE INSTRUCTIONS.
When connected to a power supply not used in the U.S.A, use a power
adapter for configuration of the power supply if needed.
1-1. IMPORTANT SAFETY INFORMATION
2
PACKAGE
CONTENT
The G-Series Single Unit Charger Standard Package contains
the following items：
2-1. STANDARD PACKAGE
The following items are included in the Full Package：
2-2. OPTIONAL
Item
Illustration
Charger User’s Guide
3
2. PACKAGE CONTENT
Item
Illustration
Micro-USB CableAC/DC Adapter
DC-OUT
5V / 2A
5V / 300mA
CHARGER
APPEARANCE
3. CHARGER APPEARANCE
Introductions
Pager Socket
3-1. FRONT VIEW
3-2. REAR VIEW
2 1
1
Belt Clip Fastener
2
Power Indicator LED
Bluetooth Headset Seat
3
1BT Headset Charging Port
2Micro-USB Charging Port
Output Introductions
4
1
2
3
4
4
CHARGER
APPEARANCE
The G-Series Charger and Voice Pagers provide the following LED
indicators to display the status of the charger.
3-3. LED INDICATOR
No.
1
2
3
LED Item LED Behavior G-Series Charger
Indication
The Charging Cradle
is connected to
power and turned
ON.
G4 Voice Pager
charging in progress
G4 Voice Pager fully
charged
G4 Voice Pager
battery error, or
connection error
with charger
G5 Voice Pager
charging in progress
G5 Voice Pager fully
charged
G5 Voice Pager
battery error, or
connection error
with charger
LED Color LED Action
G-Series Charger LED Green
Green
G4 Voice Pager LED Red
Red
Red
Red
G5 Voice Pager LED Orange
ON
ON
ON
ON
Blinking
Blinking
ON
5
DC-OUT
5V / 2A
5V / 300mA
FEATURE
INTRODUCTION
4. FEATURE INTRODUCTION
The G-Series Single Unit Charger provides charging functionality to Unication
G2/G3/G4/G5 voice pagers, and the Unication Dual Voice Source Bluetooth
Headset
Please make sure the Micro-USB cable is connected correctly to the charger
port before charging.
Step 1
.
Step 2.
NOTE :
Connect the USB cable to power source of choice
(wall socket adapter, computer, vehicle power port)
Connect the cable into the Micro-USB charger port.
If your charger installation is correct but the LED does not turn on
please contact your local dealer.
4-1. INSTALLATION
6
FEATURE
INTRODUCTION
The G-Series Charger should be used for G-Series Voice Pagers only
(G2/G3/G4/G5). Before charging the G-Series Voice Pager, please make
sure that the voice pager battery was provided by Unication.
4-2. CHARGING
7
Step 1.
Step 2.
NOTE :
Please insert the pager vertically into the
charger’s pager pocket as in the following
illustration. Fasten the backclip to the charger
to ensure a stable connection.
Once the pager is inserted correctly the
charger will detect the battery and start
charging.
When the pager is being charged ,the LED
light on the pager will turn on as an indicator.
If a red LED light is flashing on the pager, please remove the pager
from the charger and contact your local dealer.
FEATURE
INTRODUCTION
Unication’s G-Series Charger also offers external Bluetooth headset charging
functionality.
( ※For best compatibility, please use the Unication provided Dual Voice
Source Bluetooth Headset.)
4-4. CHARGING EXTERNAL BLUETOOTH HEADSET
8
Step 1. Insert the Bluetooth charger cable into the Charger Bluetooth
headset charging jack.
Step 2 . Fit your Bluetooth Headset inside the BT Headset seat for ease of
access.
DC-OUT
5V / 2A
5V / 300mA
5. SPECIFICATIONS
SPECIFICATIONS
9
Power Supply
Item Specification
External I/O
Physical
Handling Temperatures
Adaptor Input / Output
Full Recharge Time
Standard USB Power Output
DC Jack Input
Dimensions
5Vdc / 2.0 A
5Vdc / 0.3 A
Weight
120(L) x 126(W) x 40.5(H) mm
208.2g
Operation Temperature
Storage Temperature
0 ~ + 50°C
-10 ~ + 60°C
Input : 100~240VAC / 50~60
Hz Output 5Vdc / 2.0A
Average of 5 hours
ENG-V0.01-20170516
T82GSCHA02A-R
Corporate Headquarters :
Unication Co., Ltd.
Tel. : +886-2-22999678
Address: 5F, No.6, Wu-Kung 5Rd.,
Hsinchuang Dist., New Taipei City, 24890 Taiwan.
E-mail: [email protected]
URL: www.uni.com.tw
North American Branch Office :
Unication USA Inc.,
Tel. : +817-303-9320
Address: 1901 E. Lamar Blvd.,
Arlington, TX 76006, U.S.A.
E-mail: [email protected]
URL: www.unication.com
