Unicont SPb MVPC-1901 User manual

Unicont SPb Ltd
Marine Panel Personal Computer
MVPC-1901
Technical Documentation
(1901-4-06042011)
St. Petersburg
2011

Unicont SPb Ltd Technical Documentation MVPC-1901
Page 2
Table of Contents
1. DEVICE DESCRIPTION ................................................................................................3
2. DELIVERY SET...............................................................................................................3
3. TECHNICAL CHARACTERISTICS ............................................................................3
4. DESCRIPTION OF DEVICE CONNECTORS ............................................................5
5. CONTROLS ......................................................................................................................8
6. DEVICE SETTING ..........................................................................................................8
7. DRIVERS AND ON-BOARD DEVICES .....................................................................10
8. WARRANTY ..................................................................................................................11
9. DATE OF PACKING.....................................................................................................12
10. ACCEPTANCE DETAILS ............................................................................................12
11. DATE OF COMMISSIONING .....................................................................................12

Unicont SPb Ltd Technical Documentation MVPC-1901
Page 3
1. Device description
MVPC-1901 is a computer with integrated LCD display. In accordance with its technical
characteristics (electronic cartography, automatics systems and etc.) the present device is meant for a
wide range of tasks.
2. Delivery Set
1. Computer-monoblock 1 piece
2. Corbels for desk-top mounting 2 pieces
3. Sun visor 1 piece
4. Power cable 1 piece
5. Operation manual 1 piece
Upon customer request the MVPC-1901 can be equipped with the following additional
options:
Touchscreen,
CD disk with drivers.
3. Technical characteristics
Electrical Specifications:
Supply voltage: 220VAC (10..36 VDC – at option)
Power consumption: no more than 120W
Protection rate: IP 22
Computer’s characteristics:
Processor: Pentium M 1,86 GHz
RAM: DDR 1024 MB
Flash-HDD capacity: 8 GB
HDD capacity: 120 GB (at option)*
Motherboard: NOVA-8522G10
*if you want to setup additional HDD without assistance, please certain of that HDD’s
jumper setup to “Slave” position.
Characteristics of built-in display:
Resolution: 1280 x 1024 (SXGA)
Diagonal: 19”
Contrast: 700:1
Luminosity: 300 cd/m2
Viewing angles: 160°
Response time: 5 ms (Gray-to-gray)
Brightness control: by twist handle on front panel (“deep”
dimming)

Unicont SPb Ltd Technical Documentation MVPC-1901
Page 4
Operating characteristics:
Overall dimensions: 449 x 418 x 96 mm
Weight: no more that 14 kg
Storage temperature: -20..+70 °C
Operating temperature: -15..+55 °C
Output interface characteristics:
3 x RS-232, 1 x RS-422 (DB-9M)
1 x LPT (DB-25F)
4 x USB (Type A)
1 x USB (Type A, front panel)
2 x PS/2 (keyboard and mouse/trackball)
3 x 3,5 mm jack (microphone input, line audio-input/output)
2 x LAN (RJ-45)
1 x VGA (D-SUB)

Unicont SPb Ltd Technical Documentation MVPC-1901
Page 5
4. Description of device connectors
There are the following connectors on the back panel of device:
Name Type Functionality
M PS/2 Connection of pointing device «mouse” or “trackball”
K PS/2 Connection of keyboard
COM1, COM2, COM3 DB-9M Connection of serial interface RS-232
COM4 DB-9M Connection of serial interface RS-422
USB1, USB2, USB3,
USB4 USB Type A Connection of external devices USB
LPT1 DB-25F Connection of printer
VGA DB-15F Connection of external display
A_IN 3,5 mm jack Line audio input.
Connection of external audio signal source.
A_OUT 3,5 mm jack Line audio-output. Connection of audio receiver.
MIC 3,5 mm jack Connection of microphones
POWER Power connection
LAN1, LAN2 RJ-45 Connection of networking equipment Ethernet
(10Mb/100Mb/1Gb).
Connector «Power»
Pin No. Functionality
1 Power supply voltage 220 VAC – L. Power supply voltage
10..36 VDC – «+»
2 Power supply voltage 220 VAC – N. Power supply voltage
10..36 VDC – «-»
Grounding terminal

Unicont SPb Ltd Technical Documentation MVPC-1901
Page 6
Connector «К», «M»
Pin No. Functionality
1 Keyboard signal
2 Mouse signal
3 GND
4 5 VDC
5 Keyboard synchronous signal
6 Mouse synchronous signal
Connector «COM1», «COM2», «COM3»
Pin No. Functionality
1 DCD
2 RxD
3 TxD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
Connector «COM4»
Pin No. Functionality
1 RX-
2 RX+
3 GND
4 Tx+
5 Tx-
6 NC
7 NC
8 NC
9 NC

Unicont SPb Ltd Technical Documentation MVPC-1901
Page 7
Connector «VGA»
Pin
No.
Functionality
1 Red
2 Green
3 Blue
4 NC
5 NC
6 GND
7 GND
8 GND
9 NC
10 GND
11 GND
12 GND
13 HSYNC
14 VSYNC
15 NC
Connector «LPT1»
Pin
No.
Functionality
1 -STROBE
2 DATA0
3 DATA1
4 DATA2
5 DATA3
6 DATA4
7 DATA5
8 DATA6
9 DATA7
10 -ACKN
11 BUSY
12 PE
13 SELECT
14 -AUTOFD
15 -ERROR
16 -INIT
17 -SLCTIN
18-
25
GND

Unicont SPb Ltd Technical Documentation MVPC-1901
Page 8
5. Controls
On the front of the device you can see:
Waterproof connector USB (Type A)
Power on/off button «Power»
Button «Reset»
Display light brightness control knob
Power supply indicator
To press button “Reset” it is necessary to use any available thin tool (e.g. paper-clip). Such
construction is chosen for prevention of stray keystroke and following “hard” rebooting of the device.
6. Device setting
Device case can be used both for desk-top and panel mounting:
In case of panel mounting it is recommended to prepare seat according to the dimensional
drawing (see Figure 1) to the panel via mounting hole.
In case of desk-top mounting it is recommended to fasten the corbel on the MVPC-1901 case,
prepare a seat for its setting and fix the computer screwing the corbel with the screw M5.
After device setting connect connection cables of external devices and plug them to the
corresponding connectors of MVPC-1901. Screw the connectors to prevent random disconnection of
plugged cables.

Unicont SPb Ltd Technical Documentation MVPC-1901
Page 9
Figure 1. Dimension drawing.
Figure 2. Outline drawing of the device on the brackets with a protective shield.

Unicont SPb Ltd Technical Documentation MVPC-1901
Page 10
7. Drivers and on-board devices
All drivers for MVPC-101 you can find on CD-ROM in the delivery set. Also manufacturer
copy drviers to folder “Drivers” on the “C” disk.
Audio Realtek ALC655 AC'97 Codec
LAN RTL8110SC
Video Intel Extreme Graphics 2
Chipset 852GM

Unicont SPb Ltd Technical Documentation MVPC-1901
Page 11
8. Warranty
The manufacturer guarantees the unit MVPC-1901 complies with this manual provided that
the operation, transportation and storage conditions are adhered to during the warranty period.
The unit’s warranty period expires 24 months from the date of its shipping from the
manufacturer’s storehouse.
Within the warranty period, the owner is entitled for a free repair, or a replacement of a
separate part, provided that the malfunction occurred through the manufacturer’s fault.
Warranty repair is provided if the unit is submitted with the manufacturer’s label and a
legible serial number available on it, as well as this operating manual.
The manufacturer is not responsible and cannot guarantee the unit’s operation:
1. After the warranty period is over;
2. In case of the failure to observe the unit’s operation, transportation, storage and
installation rules and conditions;
3. If the unit is in an unmarketable condition, or has a damaged body, and other causes
beyond the manufacturer’s control;
4. If self-made electrical devices were used.
5. If there was an attempt to repair the unit by a person who is not an authorized
representative of the manufacturer.
If the owner loses this operating manual or the manufacturer’s label with a serial number, the
manufacturer shall not provide their copies, and the owner shall be divested of the right for a free
repair during the warranty period.
Upon the warranty expiry, the manufacturer shall facilitate the repair of the unit at the
owner’s expense.
Note: in case of warranty repair, the unit’s disassembling from the installation site and its
delivery to the manufacturer’s service center are done at the owner’s expense.
Visit the manufacturer’s website www.unicont.spb.ru (section “support/warranty”) to find:
forms to fill in claims,
full warranty description;
full description of the warranty service rendering procedure.
The manufacturer service center’s address and contact details:
Unicont SPb, Ltd.
Bld. 26ЕKibalchich Str., Saint Petersburg, 192174, Russia
tel.: + 7 (812) 622 23 10, [phone]
fax: [phone]
e-mail: [e-mail]

Unicont SPb Ltd Technical Documentation MVPC-1901
Page 12
9. DATE OF PACKING
Marine Panel Personal Computer MVPC-1901 №
name of article designation serial number
Packed Unicont SPb Ltd., Russia.
Manufacturer
according to the requirements of the current technical documentation.
post signature clarification of signature
year, month, day
10. ACCEPTANCE DETAILS
Marine Panel Personal Computer MVPC-1901 №
name of article designation serial number
was manufactured and accepted in accordance with the regulatory requirements of the
state standards and applicable technical documentation, and is suitable for operation.
Quality control representative
Stamp
here signature clarification of signature
year, month, day
11. DATE OF COMMISSIONING
Marine Panel Personal Computer MVPC-1901 №
name of article designation serial number
The unit has been put into operation.
Date of installation: _________________________________________
Place of installation: _________________________________________
Person in charge of installation: _________________________________________
