EXI5160 8/6/03 11:59 AM Page 1

EXI5160 7/30/3 5:44 PM Page 2

Step 2 Install and Charge the Handset Battery
TO INSTALL THE HANDSET BATTERY
When the handset battery pack is fully charged,
after 15-20 hours of charging, plug the telephone
cord into the base unit and then into a telephone
wall jack.
Your phone is set for tone dialing. If your local
network requires pulse dialing, please see
“Choosing the dialing mode” on page 16.
ARemove the cover.
TO SET CALLER ID, LANGUAGE AND DIALING OPTIONS
APress and hold call id/menu.
BPress vol/ / or vol/ / to move
the pointer to an option.
CPress select to change the option setting.
DPress end to exit, and return the handset
to the base.
OPTIONS INCLUDE
AAuto Talk On/Off
BCIDCW On/Off
(Caller ID on call waiting)
CArea Code Enter/Remove
DDial Pulse/Tone
DPlug the AC adapter cord into the base
unit and then into a 120V AC outlet.
EPlace the handset in the base and charge
continuously for 15 - 20 hours before using
the phone.
BConnect the battery pack
connector with the
correct polarity.
CReplace the cover.
memorydeleteselectredial
pause channel
vol
Note: There are five setup options available. They are
Caller ID options [Auto Talk, CIDCW (Caller ID on Call
Waiting), Area Code], Dial Mode and Language.
QUICK REFERENCE GUIDE
Step 3 Connect to Phone Line
Step 4 Setting Menu Options
Uniden Parts Department at
[phone]
Hours: M-F 8:00 a.m. to
5:00 p.m. CST.
We can also be reached on
the web at www.uniden.com
Make sure you have received the following items in
the package. If any of these items are missing or
damaged, contact the Uniden Parts Department.
• Base unit
• Handset
• AC adapter
• Rechargeable battery
• Telephone cord
• Beltclip
• This owner’s manual
• Other printed
material
QUICK REFERENCE GUIDE [ 3 ]www.uniden.com
Step 1 Checking the Package Contents
ELanguage English/French/Spanish
EXI5160 8/1/03 12:08 PM Page 3

[ 4 ] www.uniden.com
Contents
Quick Reference Guide 3
Welcome/Features 5
Controls and Functions 6
Getting Started
Setting up the Phone 8
Mounting the Base Unit on a Wall 13
Setting Menu Options 15
Basics
Making and Receiving Calls 18
Adjusting the Handset Ringer and
Earpiece Volume 19
Redial 20
Tone Dialing Switch Over 20
Traveling Out-of-Range 20
Selecting a Different Channel 21
Page 21
Flash and Call Waiting 21
Voice Mail Waiting Indicator 22
Memory Dialing
Storing Phone Numbers and Names 23
Steps for Entering Names and Special Characters 25
Making Calls with Memory Dialing 26
Chain Dialing 27
Editing a Stored Name and/or Phone Number 28
Erasing a Stored Name and Phone Number 30
RocketDial
RocketDial 31
Storing and Editing the RocketDial 31
Making Calls with the RocketDial 31
Deleting the RocketDial 32
Caller ID Features
Caller ID and Call Waiting Caller ID 33
When the Telephone Rings 33
Viewing the Caller ID Message List 34
Deleting Information from the Caller ID List 35
Using the Caller ID List 37
Additional Information
Changing the Digital Security Code 39
Installing the Beltclip 39
Headset Installation 39
Note on Power Sources 40
Maintenance 40
Troubleshooting 41
General Information 44
Precautions & Warranty 45
I.C. Notice 47
Index 48
EXI5160 7/30/3 5:44 PM Page 4

[ 5 ]www.uniden.com
Welcome Congratulations on your purchase of the Uniden cordless phone. This cordless phone is
designed and engineered to exacting standards for reliability, long life, and outstanding
performance.
Note: Some illustrations in this manual may differ from the actual unit for
explanation purposes. The color of your cordless telephone may vary.
Be sure to visit our web site: www.uniden.com
Uniden®and RocketDial®are registered trademarks of Uniden America Corporation.
AutoTalk, AutoStandby, UltraClear Plus, Random Code and AutoSecure are trademarks of
Uniden America Corporation.
Features • 5.8 GHz Extended Range Technology
• 3 Line Backlit Display
• Caller ID and Call Waiting Caller ID
• RocketDial
• 10 Number Memory Dialing
• 32 Digit Redial
• Flash and Pause
• English, French or Spanish Display Option
• Tone/Pulse Dialing
• Page/Find handset
• Earpiece Volume Control
• Ringer Volume Control (High-Low-Off)
• Hearing Aid Compatible
• 20 Channel Autoscan
As an ENERGY STAR®Partner, Uniden has determined that this product or
product models meets the ENERGY STAR®guidelines for energy efficiency.
ENERGY STAR®is a U.S. registered mark.
EXI5160 7/30/3 5:44 PM Page 5

CONTROLS AND FUNCTIONS[ 6 ] www.uniden.com
memorydeleteselectredial
pause channel
call id/menu RocketDial
vol
2
3
4
1
5
7
6
8
9
12
20
16
15
14
11
10
13 19
18
17
1. Handset antenna
2. Beltclip hole
3. Optional headset jack
4. Handset battery compartment
5. Handset earpiece
6. LCD display
7. call id (Caller ID)/menu key
8. vol/ / (volume & scroll) key
9. vol/ / (volume & scroll) key
10. /tone/ (left cursor) key
11. redial/pause key
12. select key
13. Handset microphone and
ringer speaker
14. RocketDial key
15. end key
16. talk/flash key
17. #/ (right cursor) key
18. memory key
19. delete/channel key
20. Handset charging contacts
Controls and Functions
EXI5160 7/30/3 5:44 PM Page 6

CONTROLS AND FUNCTIONS [ 7 ]www.uniden.com
charge/in use
find handset
24 25
21
22
23
21. charge/in use and VMWI
(voice mail waiting) LED
22. find handset key
23. Base charging contacts
24. Telephone line jack
25. DC IN 9V jack
EXI5160 7/30/3 5:44 PM Page 7

GETTING STARTED[ 8 ] www.uniden.com
Setting up the Phone
Do the following steps:
A. Choose the best location C. Connect the base unit
B. Install the rechargeable battery pack into the handset
A. Choose the best location
Before choosing a location for your new phone, read the INSTALLATION
CONSIDERATIONS included in the PRECAUTIONS. Here are some important guidelines
you should consider:
•The location should be close to both a phone jack and a continuous power outlet
which is not switchable.
•Keep the base and handset away from sources of electrical noise such as motors,
microwave ovens, and fluorescent lighting.
•The base can be placed on a desk, tabletop, or mounted on a standard wall plate.
Avoid excessive moisture,
extremely low temperatures,
dust, mechanical vibration,
or shock
Avoid heat sources, such as radiators,
air ducts, and sunlight
Avoid television sets and other
electronic equipment
Avoid noise sources such as a window
by a street with heavy traffic
Avoid microwave ovens
Avoid personal computers
Avoid other cordless telephones
Choose a central location
If your home has
specially wired alarm
equipment connected to
the telephone line, be
sure that installing the
system does not disable
your alarm equipment.
If you have questions
about what will disable
your alarm equipment,
contact your telephone
company or a qualified
installer.
EXI5160 7/30/3 5:44 PM Page 8

GETTING STARTED
GETTING STARTED [ 9 ]www.uniden.com
B. Install the rechargeable battery pack into the handset
The handset is powered by a rechargeable battery pack.
The battery recharges automatically when the handset is
placed in the base unit.
Charge the handset battery pack for at least 15-20
hours before using your new cordless telephone for the
first time! To maximize the charge capacity of your battery
pack, DO NOT plug the telephone cord into the base unit
and wall jack until the battery is fully charged.
1) Press down on the handset battery case cover (use the
finger indention for a better grip) and slide the cover
downward to remove.
2) Plug the battery pack connector (red & black wires) into
the small jack inside the battery compartment.
(The connector notches fit into the grooves of the jack only
one-way.) Match the wire colors to the polarity label in the
battery compartment, connect the battery, and listen for
a click to insure connection.
3) Make sure you have a good connection by slightly pulling
on the battery wires. If the connection is secure, the
battery jack will remain in place.
For optimum
performance use only
the Uniden BT-800
rechargeable battery
pack supplied with your
phone.
EXI5160 7/30/3 5:44 PM Page 9

GETTING STARTED[ 10 ] www.uniden.com
4) Place the battery case cover back on the handset by sliding
it upwards until it clicks into place.
5) Place the handset in the base unit face forward for 15-20
hours without interruption. The base unit’s LED light
(labeled charge/in use) illuminates once the handset is
placed in the base. The LED light will illuminate regardless
if the battery pack is connected or not.
DO NOT rely on the LED light as an indicator that the
battery pack is connected and the handset is charging!
If the base charge/in use LED light does not illuminate:
• Check to see if the AC adapter is plugged into the base
unit and the electrical wall outlet properly. (Use only the
supplied AC adapter. Do not use any other AC adapter.)
• Check to see if the handset is sitting correctly in the
base and making good contact with the base unit’s
charging contacts.
• Replacement batteries
are also available
through the Uniden
Parts Department at
[phone],
Monday through Friday
from 8:00 a.m. to
5:00 p.m. or online at
www.uniden.com
• The handset should
always sit in charging
cradle face forward to
make good contact
with base unit’s
charge contacts.
EXI5160 7/30/3 5:44 PM Page 10

GETTING STARTED
GETTING STARTED [ 11 ]www.uniden.com
• Even when the
battery pack is not
being used, it will
gradually discharge
over a long period
of time. For optimum
performance, be sure
to return the handset
to the base unit after
a telephone call.
•Talk Mode -
The handset is off the
base and talk/flash
has been pressed,
enabling a dial tone.
•Standby Mode -
The handset is not in
use. The handset may
be on or off the base,
but talk/flash key
has not been pressed.
Cleaning the charging contacts
To maintain a good charge, it is important to clean the
charging contacts on both the handset and base unit once
a month. Using water only, dampen a cloth to clean the
charging contacts. Then make sure to go back over the
charging contacts with a dry cloth before returning the
handset to the base to charge.
The last number dialed in the redial memory, the names and the numbers stored in the
memory locations or CID list are retained for up to 30 minutes while you replace the
battery pack.
Low battery alert
When the battery pack is very low and needs to be charged,
the phone is programmed to eliminate functions in order to
save power. If the phone is not in use, ¨Low Battery¨
appears on the LCD and none of the keys will operate.
If the phone is in use, ¨Low Battery¨ flashes and the
handset beeps. Complete your conversation as quickly as
possible and return the handset to the base unit for charging.
Do not use paint thinner, benzene, alcohol, or other chemical products. Doing so
may discolor the surface of the telephone and damage the finish.
EXI5160 7/30/3 5:44 PM Page 11

GETTING STARTED[ 12 ] www.uniden.com
Place the power cord so
that it does not create
a trip hazard or where
it could become chafed
and create a fire or
electrical hazard.
Use only the supplied
AD-314 AC adapter.
Do not use any other
AC adapter.
• Connect the AC adapter to a continuous power supply.
• Place the base unit close to the AC outlet so that you can unplug the AC adapter easily.
C. Connect the base unit
1) Connect the AC adapter to the DC IN 9V jack
and to a standard 120V AC wall outlet.
2) Set the base on a desk or tabletop, and
place the handset on the base unit.
3) Make sure that the charge/in use LED illuminates.
If the LED does not illuminate, check to see that the AC adapter is plugged in
and that the handset makes good contact with the base charging contacts.
Route the cord.
•After installing the battery pack in the handset, charge your handset at least 15-20
hours before plugging into the phone line. Once the handset battery pack is fully
charged, connect the telephone line cord to the base and telephone wall outlet.
4) Connect the telephone line cord to the TEL LINE jack and
to a telephone outlet once the handset is fully charged.
Modular
If your telephone outlet isn't modular,
contact your telephone company
for assistance.
EXI5160 7/30/3 5:44 PM Page 12

GETTING STARTED
GETTING STARTED [ 13 ]www.uniden.com
Mounting the Base Unit on a Wall
Standard wall plate mounting
This phone can be mounted on any standard wall plate.
1) Plug the AC adapter into the DC IN 9V jack.
2) Wrap the AC adapter cord inside the molded
wiring channel as shown.
3) Plug the AC adapter into a standard 120V AC
wall outlet.
4) Plug the telephone line cord into the TEL LINE
jack. Wrap the cord inside the molded wiring
channel as shown.
5) Plug the telephone line cord into the telephone
outlet.
6) Align the mounting slots on the base with the
mounting posts on the wall. Then push in and
down until the phone is firmly seated.
DO NOT use an AC
outlet controlled by
a wall switch.
EXI5160 7/30/3 5:44 PM Page 13

GETTING STARTED[ 14 ] www.uniden.com
Direct wall mounting
If you don't have a standard wall plate, you can mount your phone directly to the
wall. Before doing this, consider the following:
•Avoid electrical cables, pipes, or other items behind the mounting location that
could cause a hazard when inserting screws into the wall.
•Try to mount your phone within 5 feet of a working phone jack to avoid excessive
lengths.
•Make sure the wall material is capable of supporting the weight of the base
and handset.
•Use #10 screws (minimum length of 1-3/8 inches) with anchoring devices suitable
for the wall material where the base unit will be placed.
1) Insert two mounting screws into the wall (with their
appropriate anchoring device), 3-15/16 inches apart.
Allow about 1/8 of an inch between the wall and screw heads
for mounting the phone.
2) Refer to steps 1 through 6 on page 13 to mount the telephone.
EXI5160 7/30/3 5:45 PM Page 14

GETTING STARTED
GETTING STARTED [ 15 ]
Setting Menu Options
There are five setup options available. They are Caller ID options [AutoTalk, CIDCW
(Caller ID on Call Waiting), Area Code], Dial Mode and Language.
AutoTalk allows you to answer the phone without pressing the talk/flash button.
If the phone rings when AutoTalk is on, simply remove the handset from the base
and the phone automatically answers the call. If the phone rings when AutoTalk
is off, you must press talk/flash to answer the call.
Caller ID options
To change your AutoTalk and CIDCW:
1) Press and hold call id/menu. The following screen appears.
2) Use vol/ / or vol/ / to move the pointer to the
selection that you would like to change.
Press select to toggle between ¨On¨ and ¨Off¨ for AutoTalk and CIDCW.
3) Press end and return the handset to the base unit to complete the setting.
The handset returns to standby mode.
To enter your Area Code:
If you enter a 3-digit area code number in the Area Code option, your local area
code does not appear in Caller ID messages. Do not program this option if your
calling area requires 10-digit dialing. When reviewing Caller ID messages, you will
see only the local seven digit number. For calls received from outside your local area
code, you will see a full 10-digit number.
•If your calling area
requires 10-digit
dialing, do not
program the Area
Code option.
•The cordless phone
features include
AutoTalkTM and
AutoStandbyTM.
AutoTalk allows you
to answer a call by
just removing the
handset from the base
so you don't have to
waste time pushing
buttons. AutoStandby
allows you to hang up
by simply returning
the handset to the
base.
www.uniden.com
EXI5160 8/1/03 11:51 AM Page 15

GETTING STARTED[ 16 ] www.uniden.com
Make sure your battery
pack is fully charged
before choosing the
dialing mode.
1) When the phone is in standby mode, press and hold
call id/menu. The Caller ID setting screen appears.
2) Press vol/ / twice to select ¨Area Code¨.
3) Press select.
4) Use the number keys (0 - 9), or delete/channel to enter the
3-digit area code.
5) Press select. A confirmation tone sounds and the displayed area code is entered.
6) Press end or return the handset to the base unit to complete the setting.
The handset returns to standby mode.
When the area code has already been stored in memory, the
stored area code will be displayed. To change it, use the
delete/channel and number keys to enter the new area code.
Then press select. A confirmation tone sounds. To complete the
setting, press end or return the handset to the base unit.
Choosing the dialing mode
Most phone systems use tone dialing which sends DTMF tones through the phone
lines. However, some phone systems (such as those in rural areas) still use pulse
dialing. The default setting is tone dialing. Depending on your dialing system, set
the mode as follows:
EXI5160 7/30/3 5:45 PM Page 16

GETTING STARTED
GETTING STARTED [ 17 ]www.uniden.com
1) When the phone is in standby mode, press and hold
call id/menu. The following screen appears.
2) Press vol/ / three times to select ¨Dial¨.
3) Press select to toggle between ¨Tone¨ and ¨Pulse¨ for
each setting.
4) Press end or return the handset to the base unit to complete the setting.
The handset returns to standby mode.
•If you are not sure of your dialing system, set for tone dialing and make a trial call.
If the call connects, leave the setting as is. Otherwise, set for pulse dialing.
•If your phone system requires pulse dialing and you need to send the DTMF tones for
certain situations during a call, you may "Switch Over" to tone dialing. (Refer to
"Tone Dialing Switch Over" on page 20.)
Setting the language
1) When the phone is in standby mode, Press and hold
call id/menu. The following screen appears.
2) Press vol/ / four times to select ¨Language¨.
3) Press select to toggle ¨Eng¨ (English), ¨Fr.¨ (French) or
¨Esp¨ (Spanish) for each setting.
4) Press end or return the handset to the base unit to complete the setting. The
handset returns to standby mode.
There are three
languages to choose
from; English, French
and Spanish.
EXI5160 7/30/3 5:45 PM Page 17

BASICS[ 18 ] www.uniden.com
Making and Receiving Calls
Pick up the handset (AutoTalk:
On) or pick up the handset and
press talk/flash (AutoTalk: Off).
1) Pick up the handset.
2) Press talk/flash.
3) Listen for the dial tone.
4) Enter the number.
OR
1) Pick up the handset.
2)
Enter the number, then press
talk/flash .
1) Pick up the handset.
2) Press talk/flash.
3) Listen for the dial tone.
4) Press redial/pause.
OR
1) Pick up the handset.
2) Press redial/pause, then
press talk/flash.
Handset On Base Handset Off Base
To receive
a call
To make
a call
To hang up
To redial
Press talk/flash (AutoTalk: Off),
or press talk/flash, /tone/ ,
#/ or any number key
(AntoTalk: On).
1) Press talk/flash.
2) Listen for the dial tone.
3) Enter the number.
OR
Enter the number, then press
talk/flash.
1) Press talk/flash.
2) Listen for the dial tone.
3) Press redial/pause.
OR
Press redial/pause, then press
talk/flash.
Press end or return the handset to the base (AutoStandby).
Refer to page 15
"Setting Menu Options"
to turn On the AutoTalk
feature if desired.
EXI5160 7/30/3 5:45 PM Page 18

BASICS
BASICS [ 19 ]www.uniden.com
Adjusting the Handset Ringer and Earpiece Volume
Handset ringer tone and volume
Press the volume up key or volume down key (labeled as
vol/ / or vol/ / ) in standby mode to select one of five
ringer tones and volume combinations.
Earpiece volume
Press the volume up key or volume down key (labeled as vol/
/or vol/ / ) during a call to change the earpiece volume
of the handset. This setting will remain in effect after the tele-
phone call has ended.
Temporarily Mute Ringer
If the handset is off the base, simply press end to temporarily mute the incoming
ring. The ringer will sound with the next incoming call.
call id/menu RocketDial
vol
EXI5160 7/30/3 5:45 PM Page 19

BASICS[ 20 ] www.uniden.com
Redial
The redial/pause key redials the last number dialed. The redialed number can be up
to 32 digits long.
Tone Dialing Switch-over
Some telephone companies use equipment that requires
pulse dialing (sometimes referred to as rotary dialing).
If you need to enter tone dialing digits, you can switch-
over to tone dialing during the call. This feature is useful
when you need tone dialing to use automated systems, for
example, entering your bank account number after you have called your bank.
Initially make your call with the pulse dialing mode. Once your call connects, press
the /tone/ . Enter the desired number. These digits will be sent as tone dialing.
Once the call ends, the tone mode is canceled and pulse dialing mode resumes.
Traveling Out-of-Range
During a call, as you begin to move your handset too far from your base unit, noise
increases. If you pass the range limits of the base unit, your call will terminate
within 1 minute.
memorydeleteselectredial
pause channel
• The tone feature only
applies when the dial
mode is set to pulse.
• This special number
can be stored in a
memory location. This
is referred to as Chain
Dialing (See page
27).
EXI5160 7/30/3 5:45 PM Page 20
