Contents
Welcome/Features
Quick Reference Guide 4
Controls and Functions 5
Getting Started
Read this First 7
Checking the Package Contents 8
Setting up the Phone 9
Mounting the Base Unit on a Wall 14
Basics
Making and Receiving Calls 16
Terminology 16
Adjusting the Handset Ringer and
Earpiece Volume 17
Redial 17
Tone Dialing Switch-over 17
Traveling Out-of-Range 18
Selecting a Different Channel 18
Page 18
Memory Dialing
Storing Phone Numbers in Memory 19
Making Calls with Memory Dialing 19
One-Touch RocketDial 20
Chain Dialing 20
Erasing a Stored Number from Memory 20
The Integrated Answering Device
The Integrated Answering Device 21
Features 21
Turning the Answering System On/Off 22
Setting Up Your Answering System 22
Using Your Answering System 30
Additional Information
Changing the Digital Security Code 36
Note on Power Sources 37
Maintenance 37
Troubleshooting 38
General Information 40
Precautions & Warranty 41
I.C. Notice 43
Index 44
Remote Operation Card & Memory Location Memo
EXA2245 2/8/2 7:11 PM Page 1
All manuals and user guides at all-guides.com

[ 2 ]
Welcome Congratulations on your purchase of the Uniden EXA2245 cordless telephone and
answering system. This phone is designed and engineered to exacting standards for
reliability, long life, and outstanding performance.
Note: Some illustrations in this manual may differ from the actual unit for
explanation purpose.
Features •2.4 GHz Extended Range Technology
•Integrated Telephone Answering Device (ITAD)
•Voice Prompted Guidance through ITAD Setup Menu
•10 Number Memory Dialing
• RocketDial
•24 Digit Redial
•Flash and Pause
•Pulse/Tone Dialing
•Page/Find Handset
•7 Hour Talk Time/14 Day Standby Time
•Handset Earpiece Volume and Ringer Control
•Hearing Aid Compatible
•20 Channel Autoscan
As an ENERGY STAR®Partner, Uniden has determined that this product or
product models meets the ENERGY STAR®guidelines for energy efficiency.
ENERGY STAR®is a U.S. registered mark.
EXA2245 2/8/2 7:11 PM Page 2
All manuals and user guides at all-guides.com

[ 3 ]
The EXA2245 features include AutoTalkTM and AutoStandbyTM. AutoTalk allows you to answer a call by
just removing the handset from the base so you don't have to waste time pushing buttons. AutoStandby
allows you to hang up by simply returning the handset to the base.
The UltraClear PlusTM true compander circuitry virtually eliminates background noise. This innovative
technology, together with 20 different channels, provides you with the best possible reception during
all your conversations.
To protect you against misbilled calls which might result from your phone being activated by other
equipment, the EXA2245 has Random CodeTM digital security which automatically selects one of over
262,000 digital security codes for the handset and base. Also, the AutoSecureTM feature electronically
locks your phone when the handset is in the base.
RocketDialTM is a one touch speed dial key that automatically dials your most important or frequently
called number. The number dialed, is a preset number stored by the user.
Be sure to visit our web site: www.uniden.com
Uniden®is a registered trademark of Uniden America Corporation.
AutoTalk, AutoStandby, UltraClear Plus, Random Code, AutoSecure, and RocketDial are trademarks of Uniden America Corporation.
EXA2245 2/8/2 7:11 PM Page 3
All manuals and user guides at all-guides.com

[ 4 ] QUICK REFERENCE GUIDE
QUICK REFERENCE GUIDE
Step 1 Charging the Battery
TO INSTALL THE HANDSET BATTERY
Step 2 Connecting Step 3 Setting Up the Answering System
CONNECT TO A PHONE LINE
When the handset battery pack is fully charged,
after 15-20 hours of charging, plug the telephone
cord into the base unit and then into a telephone
wall jack.
Your phone is set for tone dialing. If your local
network requires pulse dialing, please see
“Choosing the dial mode”on page 13.
1Remove the cover.
TURN THE ANSWERING SYSTEM ON
TO RECORD A PERSONAL GREETING
1
Press and hold greeting
until you hear “Record
greeting”and a
confirmation tone.
2Record your personal greeting. (Position
yourself as near to the base as possible and
speak clearly.)
3When finished press greeting again or
play/stop.
1Plug the AC adapter cord into the base unit
and then into a 120V AC outlet.
2Place the handset on the base.
2Connect the battery
pack connector with the
correct polarity.
3Replace the cover.
TO PLUG INTO AC POWER
Note: You must charge the battery continuously for
15 - 20 hours before using the phone.
Press ans on/off.
A pre-recorded greeting will
play and your system is ready
to accept calls.
set/ringer menu
ans on/off find hs volume
greeting memo
skip/ffrepeat/rew
delete play/
stop
status
set/ringer menu
ans on/off find hs volume
greeting memo
skip/ffrepeat/rew
delete play/
stop
status
EXA2245 2/8/2 7:11 PM Page 4
All manuals and user guides at all-guides.com
all-guides.com

[ 5 ]CONTROLS AND FUNCTIONS
Controls and Functions
1
2
4
3
5
6
7
8
13
14
15
12
11
10
9
1. Handset antenna
2. Handset earpiece
3. Talk/batt low LED
4. Flash key
5. Talk key
6. */tone key
7. Redial/pause (p) key
8. Handset microphone and
ringer speaker
9. Memory ( ) key
10. RocketDial key
11. End key
12. Volume ( ) key
13. Channel key
14. Handset charging contacts
15. Handset battery compartment
EXA2245 2/8/2 7:12 PM Page 5
All manuals and user guides at all-guides.com

CONTROLS AND FUNCTIONS[ 6 ]
16 17
set/ringer menu
ans on/off find hs volume
greeting memo
skip/ffrepeat/rew
delete play/
stop
status
mic
26
29
28
30
20
21
19
18
22
23
24
25
31
32
33
34
35
27
16. Telephone line jack
17. DC IN 9V jack
18. Handset retainer clip
19. Delete key
20. Repeat/rewind (rew) key
21. Menu key
22. Set/ringer key
23. Answer (ans) on/off key
24. Find handset (hs) key
25. Base charging contacts
26. Base speaker
27. Status LED
28. Message counter display
29. Play/stop key
30. Skip/fast forward (ff) key
31. Greeting key
32. Memo key
33. Speaker volume keys
34. Microphone
35. Base antenna
EXA2245 2/8/2 7:12 PM Page 6
All manuals and user guides at all-guides.com

GETTING STARTED [ 7 ]
GETTING STARTED
About the digital security code
This cordless telephone uses a
digital security code to
prevent unauthorized access
to your base unit. This
security code prevents other
cordless handsets from making
calls through your base unit.
A random security code will be
assigned automatically
between your base unit and
handset when you charge the
battery pack for the first time.
If you want to change the
security code, see page 36.
Read this First
Step 1 (page 8)
Unpack the telephone and accessories.
Step 2 (page 9)
Next, choose the best location
to set up the base unit.
Step 3 (page 10 to 13)
Then, insert the battery pack into the
handset. Connect the base unit. You must
charge the battery pack for 15-20 hours
before plugging into a telephone line
and using the phone.
This cordless telephone must be set up before use. Follow these steps:
Step 4 (page 22 to 29)
Finally, set up your answering system.
EXA2245 2/8/2 7:12 PM Page 7
All manuals and user guides at all-guides.com

[ 8 ]
Checking the Package Contents
Uniden Parts Department at [phone]
Hours: M-F 7:00 a.m. to 5:00 p.m. CST. We can also be
reached on the web at www.uniden.com.
Make sure you have received the following items in the package. If any of these
items are missing or damaged, contact the Uniden Parts Department.
GETTING STARTED
•Base unit
•Handset
•AC adapter
•Rechargeable battery
•Telephone cord
•This Owner’s Manual
•Other Printed Material
