EN
We determine the correct adapter (C) size
by inspecting the bearing we will install. We
either search by the bearing standard such
as 6802 for example, or we take a vernier and
measure inner and outer dimension of the
bearing. Adapter 25 x 14, where 25 represents
the outer dimension of the bearing and
14 represents the inner dimensions of the
bearing, in mm.
Installing bottom bracket bearings such as
BB30, can be done both sides at the time,
like shown on pictures 4 to 7. Installing other
bearings on the frame, one side at the time is
suggested.
To protect the frame against scratches, we use
one of the two plastic protectors (D) on the
opposite side, between the second handle
and the frame.
After selecting the bearing adapter and
sliding both bearing and adapter onto the
threaded rod (A) (pictures 4, 5), we take the
second handle with quick release system (B).
By locking and unlocking the handle (pictures
6, 7), we enable the handle to quickly slide
towards the bearing adapter.
After locking the sliding system, start to turn
the handle in the clockwise direction to press
the bearing into the frame (picture 7). Make
sure both adapter and the bearing are aligned
with the frame bearing opening.
