Unipion CFR-170 User manual

User Manual
(Model : CFR-1700)
Unipion Co., Ltd.

Table of Contents
1. Password Registration
1-1. Registration of password
1-2.Accessbypassword
1-3. Change of password
2. RF Card Registration
2-1.RegistrationofRFCard
2-2.AccessbyRFCard
2-3.DeletionofRFCard
3. Registration/Deletion of Remote Control
3-1. Registration of remote control
3-2.Accessbyremotecontrol
3-3. Deletion of remote control
4. Door opening by Mechanical Key(Emergency)
5. Specification

1. Password Registration
1-1. Registration of password
※Default password of this product is set ‘1234’ (Factory mode)
Code : (L) Password (4~12 digits) (*)
①Open battery cover and press “L” button in the PCB for one second and you can hear
“Bee” sound
②Press your own password (4 ~ 12 digits) in front keypad and press “*” button and you can
hear Bee-Ri-Rik sound
※It is recommended to register your own password number different from Telephone
number, date of birth or 4 digits number etc to avoid any misuse by unauthorized person.
1-2. Access by password
Code : (*) Password (4~12 digits) (*)
①Press “*” button in keypad
※No entry of the key for 5 seconds goes to sleep mode automatically
②Press password (4 ~ 12digits) and then “*” button
③You can hear voice sound “It’s open” and door opens
※Blue LED goes off and Door will be automatically locked after 6 seconds
※You hear voice message “It’s lock” when Door is automatically locked.
1-3. Change password
①Follow same procedure as password registration in 1-1.
②New password is entered, the previous one will be deleted.
2. RF Card Registration

2-1. Registration of RF Card
Code: (R) (1) (*) RFCard
①Open battery cover
②Press “R” button in PCB for one second and you can hear “Bee” sound
③Press “1” and “*” button in keypad and place target RF card to near signal receiving
part of the front body of the door lock
※When the card is registered properly, you hear sound “Bee-Ri-Rick”.
※When you try to register card already registered, you hear “Bee-Bee-Bee” sound and no
registration is made.
④The RF card can be registered one by one (Max. 20 cards). If you want to register
multiple cards at one time, please place the card near signal receiving part in turn.
※In multiple registration of the cards, this process will stop and power off automatically
unless placing next card within 5 seconds.
2-2. Access by RF Card
Code : (START) RF Card
①Press “START” button in the outside body (Blue LED on)
※If you do not place card for 5 seconds, this mode will be stopped automatically.
②Place registered card near signal receiving part
③You can hear voice sound “It’s open”
※Blue LED goes off and Door will be automatically locked again after 6 seconds
※You hear voice message “It’s lock” when Door is automatically locked.
※If the unregistered card is used, you can hear the sound “Please try again”. If the
unauthorized access trial is made more than 3 times, all the operations of the doorlock

will be stopped for 30 seconds.
2-3. Deletion of RF Card
Code:(R) (1) (#)
①Open battery cover
②Press “R” button in PCB for one second and you can hear “Bee” sound
③Press “1” and “#” button in keypad and you hear “Bee-Ri-Rick” sound
※When you hear “Bee-Bee-Bee” sound, take above steps over again to delete cards
3. Registration/Deletion of Remote Control
3-1. Registration of remote control
Code: (R) (2) (*) Remotecontrol
Install the antenna on the top of the product (interior part)
Open battery cover
Press “R” button in PCB for one second and you can hear “Bee” sound
Press “2” and “*” button in keypad
Press the button in the remote control toward the antenna
※In case the remote control is registered properly, you can hear “Bee-Ri-Rick” sound
※When you try to register remote control already registered, you can hear “Bee-Bee-Bee”
sound.
※The remote control can be registered up to 5 units at one time. If you want to register
multiple remote controls at one time, please press the button of each remote control in
turn.
※If you do not push the remote control button within 5 seconds, the registration will finish
and the power will turn off.

3-2. Access by remote control
Press button of the remote control
※Door will open in 3 seconds within 10m distance with voice message “It’s open”
※Door will lock automatically back within 6 seconds with voice message “It’s lock”
3-3. Deletion of Remote control
Code:(R) (2) (#)
Press “R” button in PCB and you can hear “Bee” sound
Press “2” and “#” button in the keypad
※You can hear “Bee-Ri-Rick” sound for deletion of remote control
4. Door Opening by Mechanical Key (Emergency)
①Insert the key in keylock assembly located under the lid at center of front body
②turn key 90° clockwise
③Turn the handle to open the door
※Mechanical key is prepared for emergency such as “no/low battery” and
malfunction of the doorlock etc. Please use this key in emergency case only.

5. Specification
Specification for CFR-1700
ITEM SPECIFICATION
Doorlock : 8 x 1.5(V) AAAlkaline Battery (6V)
Battery Remote control : 3 x 1.5(V) AAAAlkaline Battery
Battery life More than 6 months (10 uses per day)
Power
Emergency Battery
Recharge
Square FC-1 9V
RF Card 125(KHz) FSK type
RF CARD Active distance 5 Cm from reader
No. of card Max 20 cards, 30 cards(Option)
Frequency AM 433.92MHz
Remote Control Reg. Capacity 5 Registration (Unlock from Inside)
Voice Message Open, Lock, Retry, Low Battery Warning
Display, LED Open ,Close LED Blue LED ON in case of Door Open/Close
Error LED Red LED ON in case of Error
Interior Aluminum Die-Casting : 80*50*300 (W*D*H)mm
Dimensions Exterior Aluminum Die-Casting : 80*50*300 (W*D*H)mm
Right,/Left Hinge Exchangeable at Service Depot
Others Automatic Lock Automatic stop of Operation for 3 minutes by
unauthorized access trials more than 3 times
