Unipoe P6-S20FL User manual

User Guide
16-Port10/100Mbps+2 Gigabit TP/SFP Combo PoE Switch
PoE Port 1-4:Max 60W，PoE Port5-12：Max 32W

- 1 -
PoE Switch x 1
User Guide x1
Power Cord x1
Accessories(Rack Mount Accessory Kit*2 ,Rubber Feet*4, screw*8)
If any part is lost and damaged, please contact your local agent immediately.
The 16FE+2G Combo is Gigabit Uplink Unmanaged Switch which provides you with a high-performance, low-cost,
easy-to-use, seamless and standard upgrade to boost your old network to 1000Mbps. Increase the speed of your network
server and backbone connec ons, making Gigabit connec on to a server or uplinking a network necessarily.
The LCD not only can display the PoE work status, accurate judgment port of load, can also help customer and engineer
mely discover and solve the network failure,improve work efficiency and quality.
Its PoE ports can automa cally detect and supply power with those IEEE 802.3af/at compliant Powered Devices (PD). The
electrical power is transmi ed along with data in one single cable allowing you to expand your network where there are no
power lines or outlets, where you wish to fix devices such as AP, IP Cameras or IP Phones, etc.
The Front Panel Consists of Ethernet Ports. The LED indicators and LCD are also located on the panel.
The PoE Switch is with the func on of the LCD display and PoE. The LCD can display the working condi on of PoE port not
only, s ll can accurately show the state of each port, such as: Output power, Overload, Short circuit, Light load, Low voltage,
Over voltage,High temperature, and so on...
Standard
VLAN
16-Port 10/100Mbps+2G Combo Unmanaged PoE Switch
Port Status 17T
18T 18S
17S
17T/S 18T/S
16*10/100Mbps Port
2*10/100/1000Mbps Port
LED indicator（Port Status indicator）
DIP switch
2*1000Mbps share SFP Slots
PoE port Status
Package Contents
Front Panel
PoE Status
13-16 ports without PoE
Chek the following contents of your package

- 2 -
The DIP switch located on the le panel.
Standard:the factory default mode, 16FE+2G Combo can normal communica on between port 1~18.
:1~1
6
port can be isolated each other but 1~16 port can connect to17/18 port a er open CCTV mode to stop
broadcast storm to increase forwarding rate of frame.1~16 port up to 250m PoE distance allows you to expand your
network via Ethernet cable to where there is no power line or outlet but where you want to fix device such as IP
Cameras.
PWR Green Off: No Power supply.
Light:Indicates the switch has power.
LINK/ACT Green
Off: No device is connected to the corresponding port.
Light:Indicates the link through that port is successfully
established at 10/100/1000Mbps.
Blink: Indicates that the Switch is ac vely sending or
receiving data over that port.
Speed Green
Off: Indicates the link through established at 10Mbps.
Blink:Indicates the link through established at 100Mbps.
Light:Indicates the link through established at 1000Mbps.
PoE Orange
Off: No PoE powered device (PD) connected.
Light:There is a PoE PD connected to be port, which supply power successfully.
Blink: Indicates port abnormal power supply.
DIP Switch
VLAN Mode
LED indicator
LED Color Funcon

- 3 -
The rear panel of the PoE Switch indicates an AC inlet power socket, which accepts input power from 100 to 240V AC,
50/60HZ.
Connect the female connector of the power cord here, and the male connector to the AC(Alterna ng Current) power
outlet. Please make sure the voltage of the power supply meets the requirement of the input voltage
The switch already comes with lightning protec on mechanism. You can also ground the switch through the PE (Protec ng
Earth) cable of AC cord or with Ground Cable.
This part describes how to install your Ethernet Switch and make connec ons to it. Please follow the following instruc ons
in avoid of incorrect installa on causing device damage and security threat.
Before cleaning the switch, unplug the power plug of the switch first. Do not clean the switch with wet cloth or liquid;
Do not place the switch near water or any damp area. Prevent water or moisture from entering the switch chassis;
Do not place the switch on an unstable case or desk. The switch might be damaged severely in case of a fall;
Ensure proper ven la on of the equipment room and keep the ven la on vents of the switch free of obstruc on;
Make sure that the opera ng voltage is the same one labeled on the switch;
Do not open the chassis while the switch is opera ng or when electrical hazards are present to avoid electrical shocks.
Install the Switch on a desktop, please a ach these cushioning rubber feet provided on the bo om at each corner of the
Switch in case of the external vibra on. Allow adequate space for ven la on between the device and the objects around it.
16-Port 10/100Mbps+2G Combo Unmanaged PoE Switch
17T/S 18T/S
100~240V AC 50/60Hz
Power Socket
Grounding column
Rear Panel
Power socket
Grounding colum
Installaon the Switch
Desktop Installaon

- 4 -
The switch is rack-mountable and can be installed on an EIA-19 inch equipment rack. To do this, first, please install the
moun ng brackets on the switch’s side panels (one on each side), secure them with the included screws, and then use the
screws provided with the equipment rack to mount the switch on the 19 inch rack.
Please connect the AC power cord into the rear of the switch and to an electrical outlet (preferably one that is grounded ).
When the switch is power on, the LED indicators flash momentarily for one second, which represents a rese ng of the
system.The Power LED indicator turns on green.
Note: Please confirm the voltage is correct before power on, otherwise the switch will be damaged.
(The power input is:100V-240Vac, 50/60Hz.)
Turn on the Switch
16-Port 10/100Mbps+2G Combo Unmanaged PoE Switch
17T/S 18T/S
16-Port 10/100Mbps+2G Combo Unmanaged PoE Switch
17T/S 18T/S

- 5 -
Model 16FE+2G Combo
Standard
IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x
IEEE802.3af, IEEE802.3at
Network Media
10BASE-T: UTP category 3,4,5 cable (≤100m)
100BASE-TX: UTP category 5 cable (≤100m)
1000BASE-T: UTP category 5e cable (≤100m)
1000BASE-X: MMF, SMF
MAC Address Table
4K, Auto-learning, Auto-aging
Transfer mode
Store-and-Forward
Frame Forward Rate
10Base-T: 14881pps/Port
100Base-TX: 148810pps/Port
1000Base-T/X: 1488095pps/Port
Switching Capacity
G
Dimensions (L*W*H)
440*232*45mm
Fan Quan ty
2
Power Input
AC: 100~240V, 50/60Hz
PoE Port
Port1~12
PoE Power on RJ45
Mode A 1/2(+),3/6(-)
PoE Power Output
Voltage: 55V DC Power: 32W(Max)
PoE Power Budget 300W
Temperature
Opera ng Temperature: 0°C ~ 40 °C (32 °F ~104°F )
Storage Temperature: -40 °C ~ 70 °C (-40 °F ~158°F )
Humidity
Opera ng Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
7.2
