Unit UT371 User manual

Model UT371/372
OPERATING MANUAL

TABLE OF CONTENTS
TITLE PAGE
3
3
4
5
6
7
8
9
11
13
13
15
17
Overview
Unpacking Inspection
Safety Information
Rules For Safe Operation
International Electrical Symbols
The Meter Structure
Functional Buttons
Setup
Display Symbols
Measurement Operation
A. RPM Measurement
B. Counts
C. Data Transferring and USB
Model UT371/372: OPERATING MANUAL
1

TABLE OF CONTENTS
TITLE PAGE
18
18
19
20
20
20
21
21
22
Specifications
A. General Specifications
B. Environmental Requirements
Accuracy Specifications
A. RPM
B. Counts
Maintenance
A. General Service
B. Replacing the Battery
Model UT371/372: OPERATING MANUAL
2

Model UT371 and UT372 is a stable, safe and reliable digital non-contact Tachometer.
This Tachometer can measure RPM and counts. RPM range is 10 ~ 99999 while
counts range is 0 ~ 99999.
Open the package case and take out the Meter. Check the following items carefully
to see any missing or damaged part:
Description
English Operating Manual
Reflecting Tape
USB Interface Cable (UT372 only)
Software(UT372 only)
1.5V Battery (LR6)
Overview
This Operating Manual covers information on safety and cautions. Please read the
relevant information carefully and observe all the Warnings and Notes strictly.
Item
1
2
3
4
5
Qty
1 piece
10 pieces
1piece
1 piece
4 pieces
Unpacking Inspection
Model UT371/372: OPERATING MANUAL
3

In the event you find any missing or damage, please contact your dealer immediately.
This Meter complies with the standards IEC61010-031, IEC61326, : in pollution
degree 2
Use the Meter only as specified in this operating manual, otherwise the protection
provided by the Meter may be impaired.
In this manual, a Warning identifies conditions and actions that pose hazards to the
user, or may damage the Meter or the equipment under test.
A Note identifies the information that user should pay attention to.
International electrical symbols used on the Meter and in this Operating Manual are
explained on page 6.
Safety Information
Model UT371/372: OPERATING MANUAL
4

Rules For Safe Operation
Before using the Meter inspect the case. Do not use the Meter if it is damaged
or the case (or part of the case) is removed. Look for cracks or missing plastic.
Do not use or store the Meter in an environment of high temperature, humidity,
explosive, inflammable and strong magnetic field. The performance of the
Meter may deteriorate after dampened.
Do not point laser directly at eye.
Replace the battery as soon as the battery indicator appears. When the
battery is between 4.5V ~4.8V, the battery indicator appears. When the
battery is between 4.3V ~ 4.5V, battery indicator blinking, the Meter will be
turned off after 1 minute.
When opening the battery door, must make sure the Meter is power off.
When servicing the Meter, use only the same model number or identical
electrical specifications replacement parts.
The internal circuit of the Meter shall not be altered at will to avoid damage
of the Meter and any accident.
Model UT371/372: OPERATING MANUAL
5

Soft cloth and mild detergent should be used to clean the surface of the
Meter when servicing. No abrasive and solvent should be used to prevent
the surface of the Meter from corrosion, damage and accident.
Turn the Meter off when it is not in use and take out the battery when not
using for a long time.
Constantly check the battery as it may leak when it has been using for some
time, replace the battery as soon as leaking appears. A leaking battery will
damage the Meter.
International Electrical Symbols
Warning. Refer to the Operating Manual
Deficiency of Built-In Battery
Conforms to Standards of European Union
Model UT371/372: OPERATING MANUAL
6

Figure 1
The Meter Structure (see figure 1)
Tachometer Light Source.
LCD Display.
USB Port (UT372 only)
Housing
Functional Buttons
Model UT371/372: OPERATING MANUAL
7

Functional Buttons
Below table indicated for information about the functional button operations.
Button Operation Performed
l Press once to turn the meter on.
l Press and hold for 1 minute to turn it off.
l When measuring RPM and Counts, press once to enter the Hold mode. Press it again
to exit hold mode.
l When measuring RPM and Counts, press it to toggle between RPM and Counts feature.
l Press and hold for 1 minute to enter setup feature, the LCD displays USB. After that,
each press to step through LED / SR / AOFF / CLK / exiting setup feature to enter RPM
or Count. You could press ON/OFF button to exit setup mode and returning to normal
measurement mode at any time.
l Press this button to choose maximum reading, minimum reading, average reading,
zerong, Tune
l Under Tach measurement mode, press M/M/A button to select MAX/MIN/AVE and
normal value measurement,
After entering USB/LED/SR/AOFF/CLK mode, press this button to setup 0 or 1 and time.
l In the RPM or COUNT mode.press and hold the button for more than second the
relative time will be clear and execute HOLD function In the COUNT mode pressing the
button will be clear.
ON/OFF
R/C
M/M/A
Model UT371/372: OPERATING MANUAL
8

Setup
A. USB setup
Press R/C button to select USB feature after turning on the Meter. Then press M/M/A
button to setup 0 or 1. 0 means turn the USB off. 1 means enable the USB feature.
B. LED setup
Press R/C button to select LED feature after turning on the Meter. Then press M/M/A
button to setup 0 or 1. 0 means turn the LED laser off. 1 means enable the LED
laser feature.
C. SR sampling rate setup
Press R/C button to select SR feature after turning on the Meter. Then press M/M/A
button to setup 005 ~ 255. Press and hold M/M/A button to access quick setting.
D. AOFF setup
Press R/C button to select AOFF feature after turning on the Meter. Then press
M/M/A button to setup 0 or 1. 0 is disable auto power off feature. 1 means enable
auto power off feature,
After enable auto power off feature, the Meter will be auto power off after ten minutes
Model UT371/372: OPERATING MANUAL
9

if you do not press any button for 10 minutes. You could press ON/OFF button to
turn on the Meter again after the Meter is off.
E. CLK setup
Press R/C button to select CLK feature after turning on the Meter. Then press M/M/A
button to setup 0 or 1. 0 is hours and minutes format. 1 is minutes and seconds
format.
Model UT371/372: OPERATING MANUAL
10

Display Symbols (see figure 2)
Figure 2
Model UT371/372: OPERATING MANUAL
11

1
2
3
4
5
6
7
8
9
10
11
12
Unit of Tachometer
Unit of Counts
Time
The battery is low.
Indicator of Sleep Mode
Measurement of RPM and Counts
Data Hold is on
Display of Maximum reading
Display of Minimum reading
Display of Average reading
USB is on
Display of Measurement reading l
Number Meaning
Model UT371/372: OPERATING MANUAL
12

Warning
Warning
To reserve battery, the USB feature will be automatically off when the Meter
is restarted. The other setting remains unchanged.
The Time will be off after the HOLD feature is enabled. The time will be on
again after existing HOLD mode.
l
l
A. RPM Measurement (see figure 3)
l Do not point laser directly at eye.
l When carrying out measurement, the distance must be more than 50mm.
l To avoid hurt yourself or damage to the meter, do not let speedy rotary
object to touch the Meter.
Measurement Operation
Model UT371/372: OPERATING MANUAL
13

Figure 3
To carry out RPM measuremnet, follow the
following procedure:
Apply a piece of reflecting tape to the object
under test.
Position the Meter on a flat place. Hold the Meter
50~200mm from the Tachometer light source to
the object under test.
Press ON/OFF button, the Meter is default to
enter the RPM measurement mode. Point the
Tachometer light source to reflective tape, the
vertical angle of the reflecting tape is not greater
than 30°.
The LCD displays the RPM reading.
Note:
When measuring RPM, the LCD displays “0.0000”
if there is no signal for continuous 7 seconds.
When the RPM reading is greater than 99999.
the LCD displays OL.
1.
2.
3.
4.
1.
2.
Model UT371/372: OPERATING MANUAL
14

Figure 4
B. Counts
Self-lighted Counts (see figure 4)
1. Position the Meter on a flat place. Hold the
Meter 50~200mm and at the vertical angel not
greater than 30° from the Tachometer light source
to the object under test.
2. Press the ON/OFF button
3. Press the R/C button to select Count mode.
4. Point he Tachometer light source to the object
under count
5. The LED scans the object under count, the
Meter accumulates the counts and displays the
quantity.
Note:
1.The object under count must be reflective,
otherwise Counts feature cannot be used
Model UT371/372: OPERATING MANUAL
15

Receiving Light Source Outside (see figure 5)
Figure 5
Position the Meter on a flat place. Hold the Meter
50~200mm and at the vertical angel not greater than
30° from the Tachometer light source to the object under
test.
Set up the Meter, object under counts and outside light
source as figure 5
Press ON/OFF button
Turn the LED off, refer to page 9 point B.
Then press R/C button to select Counts mode.
The object under count passes through between the
Meter and the outside light source, the Meter accumulates
the counts and displays quantity.
Note:
Under the count mode, when the quantity is greater
than 99999 RPM, the Meter displays OL and hold the
data.
Press M/M/A button zeroing the Counts.
Press ON/OFF to re-start Counting.
1.
2.
3.
4.
5.
6.
1.
2.
3.
Model UT371/372: OPERATING MANUAL
16

Figure 6
C. Data Transferring and USB (UT372 only, see figure 6)
Connect the USB interface cable, the Meter and the computer as per the figure 6.
Model UT371/372: OPERATING MANUAL
17

A. General Specifications
l Display: 5 digits LCD display, Maximum display 99999.
l Overloading: Display OL.
l Battery Deficiency: Display .
l Sampling Rate: 5 mini-second to 255 mini seconds adjustable.
l Transducer Tyype: Photo Diode and Laser
l Measurement Distance: 50mm ~ 200mm
l Drop Test: one meter
l Power: 4pcs x 1.5V batteries (AA)
l Dimensions: 184 x 56 x 34mm
l Weight: Approximate 100g (excluding battery)
Specifications
Model UT371/372: OPERATING MANUAL
18

B. Environmental Requirements
l For indoor use only.
l Altitude: 2000m
l Temperature and humidity:
Ø Operating:
0oC~30oC( 85%R.H)
30oC~40oC ( 75%R.H)
40oC~50oC ( 45%R.H)
Ø Storage:
-20oC~ +60oC( 85%R.H)
l Safety/ Compliances: IEC61010-031, IEC61326, IEC 61010-1
pollution degree 2.
l Certification:
